Modeltech Blue Max User manual
Page 44 Page 1
Fold along dotted line
Fold along dotted line
Global Hobby Distributors
Attn: Global Services
18480 Bandilier Circle
Fountain Valley CA 92728-8610
3RVW2I¿FH
will not deliver
without proper
postage
_______________________________
_______________________________
_______________________________
(Return Address Here)
Kit Product Number MT3200-1
Check out our website for more information on other exciting Model Tech products!
HTTP://MODELTECH.GLOBALHOBBY.COM
Made in China
FEATURES
ASSEMBLY INSTRUCTIONS
Wing Span: 67.25 Inches (1708mm) OWing Area: 756 Square Inches (48.77dm2)OLength: 49.5 Inches (1257mm)
Weight RTF: 5.5-6.5 Pounds (2495-2948gr) OWing Loading: 16.76-19.81 Ounces/Square Foot (51.15-60.45gr/dm2)
Functions: Ailerons, Elevator, Rudder and Throttle OEngine Required (Glow Version): .40 - .52 Two-Stroke or .52 - .61 Four-Stroke
Power System Required (Electric Version): 4120/05 Brushless Outrunner / 80 Amp Brushless ESC / 4 Cell 4000mAH LiPO
OCompletely Prebuilt and Covered with Iron-On Covering Material
OAccepts Glow Power and Brushless Electric Power Systems
OStable, Predictable Flight Characteristics
OFiberglass Cowl, Durable Main Landing Gear and Wire-Spoke Wheels
ODetails Include Wing Struts, Flying Wires, and Moulded Pilot and Cannon
OComplete Hardware Set - Wheels, Pushrods, Fuel Tank, Clevises, Etc.
OFast and Easy Assembly - Over 140 High-Resolution Photos to Guide You
SPECIFICATIONS
Model Tech Co., Ltd.
Hong Kong
© 2008, Model Tech Co., Ltd.
All Rights Reserved
Version 1 February 2008
Page 2 Page 43
7KDQN\RXIRUSXUFKDVLQJWKH0RGHO7HFK%OXH0D[9$5):HUHFRQ¿GHQWWKDWWKHTXDOLW\RI\RXUQHZDLUFUDIWPHHWVDQG
HYHQH[FHHGV\RXUH[SHFWDWLRQV%HIRUHFRPSOHWLQJWKH¿QDODVVHPEO\RI\RXUQHZDLUFUDIWSOHDVHFDUHIXOO\UHDGWKURXJK
WKHVHDVVHPEO\LQVWUXFWLRQVLQWKHLUHQWLUHW\'RLQJVRZLOOHQVXUH\RXUVXFFHVVWKH¿UVWWLPHDURXQG
These assembly instructions are designed to guide you through the entire assembly process of your new aircraft in the least amount of
time possible. Along the way you'll learn how to properly assemble your new aircraft and also learn tips that will help you in the future.
We have listed some of our recommendations below. Please read through them before beginning assembly.
OPlease read through each step before beginning assembly. You
VKRXOG¿QGWKHOD\RXWYHU\FRPSOHWHDQGVWUDLJKWIRUZDUG2XUJRDO
is to guide you through assembly without any of the headaches and
hassles that you might expect.
OThere are check boxes next to each procedure. After you
complete a procedure, check off the box. This will help prevent you
from losing your place.
OCover your work table with brown paper or a soft cloth, both to
protect the table and to protect the parts.
OKeep a couple of small bowls or jars handy to put the small parts
in after you open the accessory bags.
OWe're all excited to get a new aircraft in the air, but take your
WLPH7KLVZLOOHQVXUH\RXEXLOGDVWUDLJKWVWURQJDQGJUHDW À\LQJ
aircraft.
OIf you come across this symbol , it means that this is an
important point or an assembly hint.
This R/C aircraft is not a toy! If misused or abused, it can cause serious bodily injury and/or damage to property. Fly only in open
DUHDVDQGSUHIHUDEO\DWDGHGLFDWHG5&À\LQJVLWH:HVXJJHVWKDYLQJDTXDOL¿HGLQVWUXFWRUFDUHIXOO\LQVSHFW\RXUDLUFUDIWEHIRUHLWV¿UVW
ÀLJKW3OHDVHFDUHIXOO\UHDGDQGIROORZDOOLQVWUXFWLRQVLQFOXGHGZLWKWKLVDLUFUDIW\RXUUDGLRFRQWUROV\VWHPDQGDQ\RWKHUFRPSRQHQWV
purchased separately.
Model Tech guarantees this kit to be free from defects in both material and workmanship at the date of purchase. This does not cover any component
SDUWVGDPDJHGE\XVHPLVXVHRUPRGL¿FDWLRQIn no case shall Model Tech's liability exceed the original cost of the purchased kit.
,QWKDW0RGHO7HFKKDVQRFRQWURORYHUWKH¿QDODVVHPEO\RUPDWHULDOXVHGIRU¿QDODVVHPEO\QROLDELOLW\VKDOOEHDVVXPHGIRUDQ\GDPDJHUHVXOWLQJIURP
WKHXVHE\WKHXVHURIWKH¿QDOXVHUDVVHPEOHGSURGXFW%\WKHDFWRIXVLQJWKH¿QDOXVHUDVVHPEOHGSURGXFWWKHXVHUDFFHSWVDOOUHVXOWLQJOLDELOLW\
TABLE OF CONTENTS
INTRODUCTION
SAFETY WARNING
OUR GUARANTEE
INTRODUCTION.......................................................................................2
SAFETY WARNING ..................................................................................2
OUR GUARANTEE ...................................................................................2
OUR RECOMMENDATIONS ....................................................................3
LITHIUM POLYMER BATTERY WARNINGS - PLEASE READ................4
TOOLS AND SUPPLIES REQUIRED .......................................................5
A NOTE ABOUT COVERING MATERIAL .................................................5
TIPS FROM THE PROS............................................................................5
KIT CONTENTS ........................................................................................6
WING ASSEMBLY.....................................................................................8
WING MOUNTING ..................................................................................10
STABILISER INSTALLATION .................................................................. 11
HINGING THE CONTROL SURFACES ..................................................14
MAIN LANDING GEAR INSTALLATION .................................................17
MOTOR INSTALLATION - ELECTRIC VERSION...................................19
ENGINE INSTALLATION - GLOW VERSION .........................................21
FUEL TANK INSTALLATION - GLOW VERSION.................................... 23
THROTTLE CONTROL SYSTEM INSTALLATION - GLOW VERSION.. 25
ELEVATOR AND RUDDER CONTROL SYSTEMS INSTALLATION ...... 27
AILERON CONTROL SYSTEM INSTALLATION .................................... 30
COWL INSTALLATION ............................................................................ 31
WING STRUTS AND FLYING WIRES INSTALLATION .......................... 33
PLASTIC PARTS INSTALLATION........................................................... 35
BATTERY HATCH INSTALLATION - ELECTRIC VERSION ONLY ........ 37
FINAL ASSEMBLY................................................................................... 39
C/G AND BALANCING ............................................................................ 41
LATERAL BALANCING ........................................................................... 41
CONTROL THROWS .............................................................................. 41
PREFLIGHT CHECK AND SAFETY ....................................................... 42
REPLACEMENT PARTS LIST ................................................................ 42
PRODUCT EVALUATION SHEET........................................................... 43
PRODUCT EVALUATION SHEET
Telling us what you like and don't like determines what model kits we make and how we make them. We would appreciate it if you would take a few
minutes of your time to answer the following questions about this kit and your modeling interests. Simply fold this form on the dotted lines, seal with
tape and mail it to us. Do not use staples and make sure our address faces out.
Global Hobby Distributors will not disclose the information it collects to outside parties. Global Hobby Distributors does not sell,
trade, or rent your personal information to others. Your privacy is important to us.
1) Kit: Model Tech Blue Max V2 ARF # MT3200-1
2) Where did you learn about this kit?
TMagazine Ads TFriend
THobby Shop TOther
TInternet
:KDWLQÀXHQFHG\RXWKHPRVWWREX\WKLVNLW"
TMagazine Ads TPrice
TType of Model TBox Art
TRecommendation TOther
TInternet
4) Did you have any trouble understanding the written instructions? If
yes, please explain.
TYes TNo
________________________________________________
________________________________________________
________________________________________________
________________________________________________
5) Did you have any trouble understanding any of the photographs?
If yes, please explain.
TYes TNo
________________________________________________
________________________________________________
________________________________________________
________________________________________________
6) Were any of the kit parts:
TDamaged TWrong Size
TMissing TWrong Shape
If you checked any of the boxes above, did you contact our
Customer Service Department to resolve the problem?
TYes TNo
:DVDQ\RIWKHDVVHPEO\GLI¿FXOWIRU\RX",I \HVSOHDVHH[SODLQ
TYes TNo
________________________________________________
________________________________________________
________________________________________________
________________________________________________
8) What did you like most about this kit?
TAssembly Manual TParts Fit
THardware Supplied TPrice
TOther
9) What did you like least about this kit?
TAssembly Manual TParts Fit
THardware Supplied TPrice
TOther
$UH\RXVDWLV¿HGZLWKWKH¿QLVKHGPRGHO",IQRSOHDVHH[SODLQ
TYes TNo
_______________________________________________
_______________________________________________
_______________________________________________
_______________________________________________
11) How does this kit compare to similar kits by other manufacturers?
TBetter TAs Good
What is Your Age Group:
T10 & Under T11 - 20 T21 - 30 T31 - 40 T41 - 50 T51 - 60 T61 - 70 T71 +
How Many Years Have You Been in the Hobby?
TLess than 1 T2 - 4 T5 - 7 T8 - 10 T11 - 15 T16 - 20 T20 or More
How Many Models Have You Purchased In the Last Year?
T0 - 1 T2 - 4 T5 - 7 T8 - 10 T10 or More
Please List any Other Modeling Interests or any Additional Information about This Product:
________________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________________
________________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________________
________________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________________
________________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________________
________________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________________
________________________________________________________________________________________________________________________
QC #
Page 42 Page 3
PREFLIGHT CHECK AND SAFETY
O &RPSOHWHO\FKDUJHWKHWUDQVPLWWHUDQGUHFHLYHUEDWWHULHVEHIRUH\RXU¿UVWGD\RIÀ\LQJ
OCheck every bolt and every glue joint in the aircraft to ensure that everything is tight and well-bonded. This should include all of the
control surface hinges as well.
ODouble-check that you've installed and tightened all of the servo horn retaining screws.
ODouble-check that the receiver and battery are properly secured into place. There's nothing worse than the battery coming loose
GXULQJÀLJKW
ODouble-check the balance of the aircraft.
OCheck the control surfaces. They should all move in the correct direction and not bind.
O 0DNHVXUHWKDW\RXYHLQVWDOOHGVLOLFRQHIXHOWXELQJRYHUWKHFOHYLVHVWRSUHYHQWDQ\FKDQFHRIWKHPFRPLQJRSHQGXULQJÀLJKW
O ,I\RXUUDGLRWUDQVPLWWHULVHTXLSSHGZLWKGXDOUDWHVZLWFKHVGRXEOHFKHFNWKDWWKH\DUHRQWKHORZUDWHVHWWLQJIRU\RXU¿UVWIHZÀLJKWV
OCheck to ensure that all of the control surfaces are moving the proper amount in both low and high rate settings.
OCheck the receiver antenna wire. It should be fully extended and not coiled up inside the fuselage.
O Do not cut the receiver antenna wire shorter or the range of your radio control system will be greatly reduced.
OProperly balance the propeller. A propeller that is out of balance will cause excessive vibration, which could lead to engine and/or
DLUIUDPHIDLOXUHDQGLWZLOOUHGXFHHI¿FLHQF\DQGSRZHU
ODouble-check that the propeller nut is tightened securely.
O 'RQRWWHVWÀ\\RXUDLUFUDIWIRUWKH¿UVWWLPHZLWKRXW¿UVWKDYLQJLWVDIHW\FKHFNHGE\DQH[SHULHQFHGPRGHOHU
O 'RQRWÀ\\RXU DLUFUDIWKLJKHUWKDQDSSUR[LPDWHO\ IHHWZLWKLQPLOHVRI DQDLUSRUWZLWKRXWKDYLQJDQ REVHUYHUZLWK\RX7KH
observer should tell you about any full-size aircraft in your vicinity and you should always give the right-of-way to full-scale aircraft.
O :KHQÀ\LQJDWDÀ\LQJ¿HOGZLWKHVWDEOLVKHGUXOHV\RXVKRXOGDELGHE\WKRVHUXOHV<RXVKRXOGQRWGHOLEHUDWHO\À\\RXUDLUFUDIWLQD
reckless and/or dangerous manner.
O :KLOHÀ\LQJ\RXVKRXOGQRWGHOLEHUDWHO\À\EHKLQGWKHÀLJKWOLQH,I\RXUDLUFUDIWVKRXOGLQDGYHUWHQWO\À\EHKLQGWKHÀLJKWOLQH\RXVKRXOG
change course immediately.
O <RXVKRXOGFRPSOHWHDVXFFHVVIXOUDQJHFKHFNRI\RXUUDGLRHTXLSPHQWSULRUWRHDFKQHZGD\RIÀ\LQJRUSULRUWRWKH¿UVWÀLJKWRID
new or repaired aircraft.
O <RXVKRXOGSHUIRUP\RXULQLWLDOWXUQDIWHUWDNHRIIDZD\IURPWKHÀLJKWOLQHDQGRUVSHFWDWRUDUHD
O <RXVKRXOGQRWNQRZLQJO\RSHUDWH\RXU5&UDGLRV\VWHPZLWKLQPLOHVRIDSUHH[LVWLQJPRGHOFOXEÀ\LQJ¿HOGZLWKRXWDIUHTXHQF\
sharing agreement with that club.
REPLACEMENT PARTS LIST
:KHQLWFRPHVWLPHWRRUGHUUHSODFHPHQWSDUWVZHUHFRPPHQGRUGHULQJGLUHFWO\IURP\RXUORFDOKREE\UHWDLOHU
,I\RXUKREE\UHWDLOHUGRHVQRWVWRFN0RGHO7HFKSURGXFWV\RXFDQRUGHUUHSODFHPHQWSDUWVGLUHFWO\
IURP\RXUORFDOGLVWULEXWRUXVLQJWKH&XVWRPHU6HUYLFH,QIRUPDWLRQ6KHHWLQFOXGHGZLWK\RXUNLW
Instruction Manual ....................................................... MT119962
Wing Set ...................................................................... MT119963
Fuselage Set ............................................................... MT119964
Stabiliser Set ............................................................... MT119965
Cowl............................................................................. MT119966
Flying Wires Set (for Top of Wing) ............................... MT119967
Main Landing Gear Set................................................ MT119968
Battery Hatch Frame Set............................................. MT119969
Fuel Tank ..................................................................... MT119970
Tail Wheel Assembly.................................................... MT119971
Decal Set ..................................................................... MT119972
Wing Struts (for Bottom of Wing)................................. MT119973
Hardware Set............................................................... MT119974
Plastic Parts (Pilot, Seat Barrel and Cannon............... MT119975
Wire Spoke Wheels (5" Pair)............................................ 237800
This section describes our recommendations to help you in deciding which types of accessories to purchase for your new aircraft.
Please read through this entire section very carefully. We have provided you with recommendations that, if
IROORZHGZLOOUHVXOWLQDJUHDWÁ\LQJDLUFUDIW)DLOXUHWRIROORZRXUUHFRPPHQGDWLRQVPD\UHVXOWLQDSRRU
Á\LQJDLUFUDIW
QTY. 1 Airtronics RD6000 FM Radio Control System
QTY. 1 Magnum XL .52RFS Four-Stroke Engine
QTY. 4 Airtronics 94102Z Standard Servos (QTY. 3 for Electric)
QTY. 1 Airtronics 12" (305mm) Servo Extension
QTY. 1 Zinger 12 x 6 Wooden Propeller
QTY. 1 Thunderbolt 4-Cycle Glow Plug
QTY. 1 Magnum In-Cowl Fueling Valve
QTY. 1 Global Silicone Fuel Tubing
QTY. 1 Du-Bro 1/4" Foam Rubber
QTY. 1 Assorted Colours of Paint and Paint Thinner
QTY. 1 Small Paint Brush
QTY. 1 KMS Quantum 4120/05 Brushless Outrunner (Electric)
QTY. 1 Castle Creations Phoenix 80 Brushless ESC (Electric)
QTY. 1 Impulse Power 4 Cell 4000mAH 80A (20C) LiPO Battery (Electric)
QTY. 1 APC 13 x 6E Composite Propeller (Electric)
QTY. 1 Pro-Peak Quattro DC LiPO Charger (Electric)
QTY. 1 Pro-Peak 4mm Gold Connector Set (Electric)
QTY. 1 Double-Sided Foam Tape (Electric)
OUR RECOMMENDATIONS
WHAT GLOW ENGINE SHOULD I USE?
HERE'S A LIST OF WHAT WE RECOMMEND TO FINISH THE BLUE MAX V2 ARF
WHAT RADIO CONTROL SYSTEM AND SERVOS SHOULD I USE?
7KH%OXH0D[9$5)FDQEHÀRZQXVLQJHLWKHUDWZRVWURNHRUDIRXUVWURNHHQJLQH
For scale-like looks, sound and performance we suggest using a .52-.61 size four-stroke
engine. If you prefer to use a two-stroke engine, we suggest using a .40-.52 size
two-stroke engine.
Whether you're going to use a two-stroke engine or a four-stroke engine, the engine
should be mounted inverted.
,)<285()/<,1*$7+,*+(5$/7,78'(6:(5(&200(1'86,1*$1(1*,1($77+(+,*+(1'2)7+(6,=(5$1*(
The Blue Max V2 ARF will require the use of a 4-channel or more radio control system. A
standard radio control system or a more sophisticated computer radio control system would
work equally well. At a minimum, the transmitter should feature dual rates and servo reversing.
A standard-size receiver and airborne battery pack can be used as well.
6WDQGDUGVL]HVHUYRVFDQEHXVHGRQDOORIWKHÀLJKWFRQWUROVXUIDFHV<RXZLOOQHHGDWRWDO
of 4 servos (3 servos for the electric version). We suggest using a 12" (305mm) long aileron
servo extension to make is easier to plug the aileron servo into the receiver when you install
the wing,
7KHUHUHDOO\LVQWWRRPXFKHOVHWKDW\RXOOQHHGWR¿QLVK\RXU%OXH0D[9$5)<RXOOQHHGDQLQFRZOIXHOLQJYDOYHLI\RXUHXVLQJD
glow engine. You'll also need typical modeling supplies, such as foam rubber to protect your receiver and battery, and various colours
of paint for the optional pilot and cannon. We've provided a complete list below for both glow and electric versions.
WHAT OTHER ITEMS DO I NEED?
If you would like to electrify your Blue Max V2 ARF, we
recommend using the KMS Quantum 4120/05 brushless
outrunner (or equivalent) with a 13x6E propeller and 80 amp
ESC. We suggest using a 4 cell 2500mAH to 4000mAH LiPO
EDWWHU\)RUOLJKWHUZHLJKWEXWOHVVÀLJKWWLPHXVHDP$+
/L32EDWWHU\7RDGGPRUHÀLJKWWLPHZKLOHVDFUL¿FLQJRQO\D
little weight, use a 4000mAH LiPO battery. It's also important that you used high-quality connectors, such as Dean's Ultra Plugs or
Pro-Peak 4mm Gold Plugs.
WHAT BRUSHLESS POWER SYSTEM SHOULD I USE?
Page 4 Page 41
Please read and understand the warnings listed in this section. Make sure to read any and all warnings included
in the packaging with your battery, too. If used improperly, lithium polymer batteries can be very dangerous,
so please follow these warnings and suggestions at all times.
O 7KLVSURGXFWPD\H[SORGHRUFDWFK¿UH6HULRXVLQMXU\FDQUHVXOWIURPPLVXVH6HULRXVLQMXU\ORVVRISURSHUW\¿UHDQGGHDWKFDQUHVXOW
from misuse of this product.
O $OOLQVWUXFWLRQVZDUQLQJVDQGFDXWLRQVPXVWEHIROORZHGDWDOOWLPHV)DLOXUHWRGRVRFDQOHDGWRVHULRXVLQMXU\RU¿UH
ODo NOT use this product before reading and understanding all directions and warnings.
ODo NOT overcharge. Maximum voltage for each pack must be followed.
ODo NOT over-discharge. NEVER discharge below minimum volts.
ODo NOT discharge at a rate greater than the maximum continuous discharge.
ODo NOT use or charge if the battery is hot.
OONLY use a charger made for Lithium Polymer batteries.
ODo NOT charge at a rate higher than 1C. Example: if the battery’s rating is 340mAH, then the charger’s charge rate must be set at
340mAH or less.
ODo NOT leave in direct sunlight or in a hot car or storage area.
ODo NOT get wet or expose to moisture.
ODo NOT short-circuit the battery.
O 21/<GLVFKDUJHDQGFKDUJHWKHEDWWHU\RXWGRRUVRULQD¿UHVDIHFRQWDLQHU
ODo NOT charge with reverse polarity.
ODo NOT leave the battery connected when not in use.
ODo NOT operate or charge unattended.
ODo NOT solder to the battery directly and do not get the battery hot in any way.
ODo NOT use the product if you do not understand the warnings and proper use of the product.
OAlways let the battery cool and "rest" between uses and charging.
OTo avoid over-discharging, only use a speed control that is made for LiPO batteries.
O :HUHFRPPHQGWKHXVHRID¿UHVDIHFRQWDLQHUZKHQFKDUJLQJRUVWRULQJ
ODo NOT charge inside your car or inside your house.
OInspect the battery before each use for swelling or other malformation. If the cell has ballooned, it MUST be discarded.
O 6HWWKHFKDUJHUWR&FKDUJHDW&RUOHVVIRUWKH¿UVWF\FOHV
OCheck polarity and then connect battery to charger.
OIn use, do not over-discharge or exceed maximum discharge.
OWhen handling the battery, remember not to poke, bend or damage the cells. The cell's outer casing is soft and can be damaged.
ORemember, the cells must never exceed 71º Celcius (160º Fahrenheit) for any reason.
LITHIUM POLYMER BATTERY WARNINGS - PLEASE READ
WARNINGS AND SAFETY PRECAUTIONS FOR ALL BRANDS OF LITHIUM POLYMER BATTERIES
CHARGING WARNINGS AND PRECAUTIONS FOR ALL BRANDS OF LITHIUM POLYMER BATTERIES
C/G AND BALANCING
BALANCE POINT (C/G):
O00%$&.)5207+(/($',1*('*(2)7+(:,1*0($685('$77+()86(/$*(6,'(6
IMPORTANT It is critical that your aircraft be balanced correctly. Incorrectly balancing your aircraft can cause your aircraft to lose
control and crash!
2QFH\RXKDYHÀRZQDQGEHFRPHIDPLOLDUZLWKWKHÀLJKWFKDUDFWHULVWLFVRIWKHDLUFUDIWWKH&*FDQEHPRYHGIRUHRUDIWWRFKDQJH
WKHÀLJKWSHUIRUPDQFH0RYLQJWKH&*EDFNZLOOFDXVHWKHDLUFUDIWWREHPRUHUHVSRQVLYHDQGDHUREDWLFEXWOHVVVWDEOH0RYLQJWKH&*
forward will cause the aircraft to be more stable, but less responsive.
7+(&*5$1*(,60000%$&.)5207+(/($',1*('*(2)7+(:,1*'2127%$/$1&(7+(
$,5&5$)7 )857+(5 7+$1 00 %(+,1' 7+( /($',1* ('*( 2) 7+( :,1* 25 $1 81&21752//$%/( &5$6+
&28/'5(68/7
T 3ODFH\RXU¿QJHUVRQWKHERWWRPRIWKHZLQJDWWKH&*ORFDWLRQDQGFDUHIXOO\OLIWWKHDLUFUDIW,IWKHQRVHRIWKHDLUFUDIWGURSVWKH
aircraft is nose heavy. To correct this, move the battery and/or receiver back far enough to bring the aircraft into balance. If the tail of
the aircraft drops, the aircraft is tail heavy. To correct this, move the battery and/or receiver forward far enough to bring the aircraft into
EDODQFH:KHQEDODQFHGFRUUHFWO\WKHDLUFUDIWVKRXOGVLWOHYHORUVOLJKWO\QRVHGRZQZKHQ\RXOLIWLWXSZLWK\RXU¿QJHUVDWWKH&*
location.
IMPORTANT Balance the aircraft with the fuel tank empty or the LiPO battery installed (if using a brushless electric motor).
CONTROL THROWS
Ailerons: 3/8" (10mm) Up and 3/8" (10mm) Down
Elevator: 1/2" (13mm) Up and 1/2" (13mm) Down
Rudder: 3/4" (19mm) Right and 3/4" (19mm) Left
TEST FLYING
THE CONTROL THROWS ARE
0($685(')5207+(:,'(6732,17
2)7+(&21752/685)$&(6
We recommend initially setting up the aircraft using the Test Flying control throws. These control throws are suggested for initial test
À\LQJEHFDXVHWKH\ ZLOO DOORZWKHDLUFUDIWWRÀ\VPRRWKHUDQG PDNHLWHDVLHUWRFRQWURO)RUVSRUW À\LQJ DQGDHUREDWLFVLQFUHDVHWKH
FRQWUROWKURZVE\PP DWDWLPHXQWLO\RXUHVDWLV¿HGZLWKWKHUHVXOWEXW RQO\$)7(5\RXYHEHFRPHIDPLOLDUZLWKWKHÀLJKW
characteristics of the aircraft using the Test Flying control throws.
IMPORTANT$IWHU\RXDUH¿QLVKHGDGMXVWLQJWKHFRQWUROWKURZVZHVWURQJO\VXJJHVWLQVWDOOLQJPPORQJSLHFHVRIVLOLFRQH
WXELQJRYHUWKHFOHYLVHVDQGVQDSNHHSHUVWRNHHSWKHPIURPFRPLQJRSHQGXULQJÀLJKW
LATERAL BALANCING
Lateral balancing will make the aircraft's controls easier to trim and will make the aircraft track straighter in the air.
TTurn the aircraft upside down and loop one length of string around the propeller shaft, then loop a second length of string around
the tail wheel wire.
TWith someone helping you, carefully lift the aircraft up by the two lengths of string. Watch how the wing reacts. If one side of the wing
drops, that side is heavier than the other. To correct this condition, stick a small piece of self-adhesive lead weight to the bottom of the
lighter wing half (the one that doesn't drop). For best mechanical advantage, place the weight as close to the wing tip as possible, but
PDNHVXUHWRDSSO\WKHOHDGZHLJKWWRDVROLGSRUWLRQRIWKHZLQJVWUXFWXUHVRWKDWLWFDQWULSRIIGXULQJÀLJKW
T 5HSHDWWKHSURFHGXUHDFRXSOHRIPRUHWLPHVWRGRXEOHFKHFN\RXU¿QGLQJV:KHQGRQHSURSHUO\WKHZLQJVKRXOGVWD\OHYHOZKHQ
you lift the aircraft.
Page 40 Page 5
TMake a receiver antenna wire mount out of an extra servo horn.
TDrill a 5/64" (2mm) hole through the bottom of the fuselage, then run the
receiver antenna wire out along the bottom of the fuselage and secure it to the
tail wheel wire, using a rubber band and the antenna mount that you made.
Servo
Horn
Cut
Antenna
To Tail Wheel Wire
0RGL¿HG6HUYR$UP
Rubber Band
Remove This
Portion
67(3,167$//,1*7+((6&5(&(,9(5$1'/,32%$77(5<(/(&75,&9(56,21
IMPORTANT If the ESC that you're using does not provide power to the receiver (feature BEC circuitry) when using a 4 cell LiPO
battery, you will need to install a separate 4 cell receiver battery pack and an On/Off switch into the fuselage as described in this step.
Most ESCs that require the use of a separate 4 cell receiver battery pack must have the positive (+) wire disconnected from the
receiver throttle lead. Please check your ESC user's guide for further information.
TSecure your LiPO battery into the fuselage, using your favorite method. The
recommended 4 cell LiPO battery can be slid forward between the elevator and
rudder servos if necessary to balance the aircraft.
IMPORTANT7KH¿QDOORFDWLRQWKDW\RXPRXQWWKH/L32EDWWHU\GHSHQGV
on where the aircraft balances as described in the next section.
TMake a receiver antenna wire mount out of an extra servo horn.
TDrill a 5/64" (2mm) hole through the bottom of the fuselage, then run the
receiver antenna wire out along the bottom of the fuselage and secure it to the
tail wheel wire, using a rubber band and the antenna mount that you made.
Servo
Horn
Cut
Antenna
To Tail Wheel Wire
0RGL¿HG6HUYR$UP
Rubber Band
Remove This
Portion
TSlide your LiPO battery through the hatch and into the fuselage.
T ,IUHTXLUHGLQVWDOO\RXUFHOOUHFHLYHUEDWWHU\SDFNLQWRWKHIXVHODJH:HPRXQWHGRXUFHOOÀDWUHFHLYHUSDFNXQGHUQHDWKWKHIXHO
tank support tray.
TMount your ESC and receiver into the fuselage, making sure to keep the
ESC as far away from the receiver as possible.
TInstall the switch into a convenient location on the side of the fuselage.
IMPORTANT You should keep any components away from the hatch cover
to allow easier access to your LiPO battery.
TBuilder's Triangle
T220 Grit Sandpaper with Sanding Block
TRotary Tool with Cutting Disc and Sanding Drum
TMasking Tape
TAirplane Stand
TT-Pins
TWax Paper
TPaper Towels
TRubbing Alcohol
TEpoxy Mixing Sticks
TEpoxy Mixing Cups
THeat Gun
THeat Sealing Iron
TSoldering Iron (for Electric Version)
TSolder (for Electric Version)
THeat-Shrink Tubing (Assorted Sizes for Electric Version)
T5 Minute and 30 Minute Epoxy
TThin and Thick C/A
TC/A Debonder
TThread Locking Compound
TFlat Head Screwdriver
T# 1 and # 2 Phillips Head Screwdrivers
T1.5mm and 2.5mm Hex Wrenches
T4mm, 5.5mm and 7mm Nut Drivers
TWire Cutters
TAdjustable Wrench
TNeedle Nose Pliers
TModeling Knife
TScissors
TElectric Drill
TAssorted Drill Bits
TStraight Edge Ruler
TPencil
TOOLS AND SUPPLIES REQUIRED
The covering material used on your aircraft is real iron-on, heat-shrink covering material. It is possible with heat and humidity changes
that the covering material on your aircraft may wrinkle or sag. This trait is inherent in all types of heat-shrink material. To remove any
wrinkles that might be visible you will need to use a heat-sealing covering iron.
TPlug in and turn on the sealing iron to the medium-high temperature setting. Allow the sealing iron to heat up for approximately 5 - 7 minutes.
TAfter the sealing iron has reached temperature, lightly apply the sealing iron to the wrinkled section of the covering material. Move
the sealing iron slowly over the wrinkled section until the covering material tightens and the wrinkles disappear.
If the colour layer smears from any of the seams the temperature of the sealing iron is too hot. Turn the temperature dial down and
wait about 5 minutes for the sealing iron to adjust to the lower temperature. You can remove any excess colour streaks using a paper
towel soaked with a small quantity of acetone.
A NOTE ABOUT COVERING MATERIAL
ODuring the covering process, sometimes colour may smear slightly from the seams. If you see any smeared colours on the covering
material, they can be quickly removed by simply wiping them off with a paper towel and a small amount of acetone.
O 0DNHVXUHWRWHVW¿WWKHSDUWVWRJHWKHUEHIRUHDSSO\LQJJOXH7KLVZLOOHQVXUHWKDWWKHSDUWV¿WSURSHUO\EHIRUHJOXLQJWKHPWRJHWKHU
OWhen gluing anything that has a smooth surface, it's important to lightly roughen the gluing surfaces with 220 grit sandpaper. This
will allow the glue to stick better. Also, never glue directly to the covering material. Always remove the covering material from the gluing
surfaces prior to gluing the parts together.
OWhen cutting away the covering material from the gluing surfaces, be careful to cut only through the covering material. Try not to cut
down into the balsa structure because that can compromise the integrity of the airframe.
OWe do not suggest storing your aircraft in an extremely hot environment (like the back of your car in direct sunlight) for any length of
time. The extreme heat could cause the covering material to wrinkle or sag and possibly damage the fragile components of the radio
control system and/or battery.
OEpoxy can be cleaned up before it dries using rubbing alcohol, and C/A can be cleaned up before it dries using C/A Debonder.
OTo prevent current loss, use high-quality connectors between the battery and the ESC, and between the ESC and the motor.
OInsulate solder joints with heat-shrink tubing to prevent short circuits and corrosion.
TIPS FROM THE PROS
Page 6 Page 39
Before you begin assembly, group the parts as we list them below. This will ensure that you have all of the parts before you begin assembly
and it will also help you become familiar with each part.
T(1) Fuselage
T(1) Right Wing Panel with Aileron
T(1) Left Wing Panel with Aileron
T(1) Horizontal Stabiliser with Elevator
T(1) Vertical Stabiliser with Rudder
T(1) Main Landing Gear Bracket
T(1) Nose Skid
T(2) Main Gear Wheels
T(2) Nylon Mounting Brackets (Wide Slot)
T(5) Nylon Mounting Brackets (Narrow Slot)
T(2) Nylon Spacers
T(2) Wheel Collars
T(2) M3 x 5mm Machine Screws
T(13) M3 x 12mm Wood Screws
KIT CONTENTS
AIRFRAME ASSEMBLIES
MAIN LANDING GEAR ASSEMBLY
T(1) Tail Wheel Wire with Mounting Bracket
T(1) Tail Wheel
T(1) Nylon Spacer
T(2) M3 x 5mm Machine Screws
T(3) M3 x 12mm Wood Screws
TAIL WHEEL ASSEMBLY
,)<28),1'$1<3$5760,66,1*25'$0$*('3/($6(&217$&7<285/2&$/02'(/7(&+
'($/(5',5(&7/<86,1*7+(6(3$5$7(&86720(56(59,&(6+((7,1&/8'(':,7+<285.,7
T(2) 32" (813mm) Threaded Wires with 90º Bends
T(2) Nylon Control Horns with Backplates
T(2) Nylon Clevises
T(2) Nylon Snap-Keepers
T(4) M2 x 20mm Machine Screws
T(6) C/A-Style Hinges
ELEVATOR AND RUDDER CONTROL SYSTEMS
T(2) 4-1/2" (114mm) Threaded Wires with 90º Bends
T(1) Plywood Servo Tray
T(2) Nylon Adjustable Control Horns
T(2) Nylon Clevises
T(2) Nylon Snap-Keepers
T(8) C/A-Style Hinges
AILERON CONTROL SYSTEM
T(1) 11-1/2" (292mm) Pushrod Wire with Z-Bend
T(1) Adjustable Pushrod Connector with Nut and Machine Screw
THROTTLE CONTROL SYSTEM
TGlue the balsa hatch latch shim to the front of the hatch frame, making sure
that it's centred.
IMPORTANT7KHKDWFKODWFKVKLPZLOO¿OOWKHQDUURZJDSEHWZHHQWKHKDWFK
ODWFKSLQDQGWKHKDWFKIUDPHKHOSLQJWKHKDWFKFRYHUVWD\¿UPO\LQSODFH
TInstall the hatch cover onto the fuselage, checking to make sure that the
KDWFKFRYHULVKHOG¿UPO\LQSODFHE\WKHKDWFKODWFKDWWKHIURQWDQGWKHSO\ZRRG
tab at the rear.
T# 1 Phillips Head Screwdriver
TModeling Knife
TScissors
TElectric Drill
T1/16" (1.6mm) & 5/64" (2mm) Drill Bits
TStraight Edge Ruler
TPencil
T(1) Decal Set
TAirplane Stand
TMasking Tape
THeat-Shrink Tubing (for Electric Version)
THeat Gun (for Electric Version)
TSoldering Iron (for Electric Version)
TSolder (for Electric Version)
FINAL ASSEMBLY
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
67(3,167$//,1*7+(5(&(,9(5%$77(5<$1'6:,7&++$51(66*/2:9(56,21
T $IWHU\RXYHIRXQGWKH¿QDOORFDWLRQRIWKHUHFHLYHUDQGWKHEDWWHU\PRXQW
them into the fuselage using your favorite method. We mounted the receiver
RQWKHIXVHODJHÀRRULQIURQWRIWKHEDOVDVXSSRUWEXONKHDGDQGPRXQWHGWKH
UHFHLYHUEDWWHU\RQWKHIXVHODJHÀRRULQIURQWRIWKHUHFHLYHU
IMPORTANT This step details the installation of the receiver, battery and switch harness if you're using a glow engine. If you're
using a brushless outrunner electric motor, please skip to step 2 on page 40.
TWrap the receiver and battery in foam rubber to protect them from vibration. Use a couple strips of masking tape or rubber bands to
hold the foam rubber in place.
Do not wrap the foam rubber too tightly or the vibration dampening quality will be reduced.
T ,QVWDOO\RXUVZLWFKLQWRDFRQYHQLHQWORFDWLRQRQWKHVLGHRIWKHIXVHODJHRSSRVLWH\RXUHQJLQHVPXIÀHU
Page 38 Page 7
TCarefully apply a light coat of thin C/A to the edges of both the hatch cover
and the hatch. This will secure the edges of the covering material into place
so that it doesn't peel up in the future.
TGlue the reinforcement plate with a notch cut into it to the front of the hatch
cover, making sure that the front edge of the reinforcement plate is 1/8" (3mm)
behind the front edge of the hatch cover and that the reinforcement plate is
centred between the sides of the hatch cover.
TGlue one reinforcement plate to the back of the hatch cover, making sure
that the back edge of the reinforcement plate is 1/8" (3mm) in front of the back
edge of the hatch cover and that the reinforcement plate is centred between
the sides of the hatch cover.
TCut a 1/8" (3mm) wide by 3/4" (18mm) long slot in the centre of the hatch
cover for the hatch latch. Position the front of the slot 9/16" (14mm) behind the
front edge of the hatch cover.
TGlue the hatch latch to the hatch cover, making sure not to get any glue in
the latch mechanism.
STEP 2: INSTALLING THE HATCH COVER
T *OXHWKH SO\ZRRGKDWFKIUDPHWRWKH LQVLGHRIWKHIXVHODJHÀRRUPDNLQJ
sure that it's centred over the hatch cutout.
TGlue the remaining reinforcement plate onto the top of the rear reinforcement
plate, making sure that it overlaps the back edge of the rear reinforcement plate
halfway.
IMPORTANT These two reinforcement plates will create a tab that will hold
the back of the hatch cover in place.
T(2) Engine Mounting Beams
T(4) Plywood Filler Blocks
T(4) M3 x 25mm Socket-Cap Screws
T(4) M3 x 20mm Machine Screws
T(4) M3 Lock Nuts
T(4) M3 Blind Nuts
T(12) M3 Flat Washers
ENGINE MOUNT ASSEMBLY - GLOW VERSION
T(1) Plywood Motor Mounting Box
T(4) Balsa Triangle Supports
T(4) M3 x 16mm Machine Screws
T(4) M3 Blind Nuts
T(4) M3 Flat Washers
MOTOR MOUNT ASSEMBLY - ELECTRIC VERSION
T(1) 240cc Fuel Tank
T(3) Aluminium Tubes
T(1) Rubber Stopper
T(1) Metal Plate - Small
T(1) Metal Plate - Large
T(1) Fuel Pick-up (Clunk)
T(1) Silicone Fuel Tubing
T(1) Metal Support Ring
T(1) M3 x 20mm Machine Screw
FUEL TANK ASSEMBLY
T(1) Right Wing Strut
T(1) Left Wing Strut
T(1) Flying Wires Mounting Post
T(2) Flying Wires
T(10) M3 x 10mm Machine Screws
T(10) M3 Flat Washers
WING STRUT AND FLYING WIRES ASSEMBLIES
T(1) Cowl
T(5) Cowl Mounting Blocks
T(1) Plastic Seat Barrel
T(1) Balsa Seat Barrel Support Plate
T(1) Plastic Seat Barrel Backrest
T(1) Plastic Pilot Figure Body Halves
T(1) Plastic Pilot Figure Head Halves
T(5) M2 x 10mm Flange-Head Wood Screws
T(1) Clear Vinyl Tubing
T(1) Decal Set (Not Pictured)
MISCELLANEOUS FUSELAGE PARTS
Page 8 Page 37
T30 Minute Epoxy
TModeling Knife
TStraight Edge Ruler
TPencil
T220 Grit Sandpaper with Sanding Block
T(1) Right Wing Panel with Aileron
T(1) Left Wing Panel with Aileron
T(2) Hardwood Wing Joiners
TPaper Towels
TRubbing Alcohol
TEpoxy Mixing Sticks
TEpoxy Mixing Cups
WING ASSEMBLY
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
T(1) Plywood Wing-Screw Doubler
T(2) M5 x 65mm Nylon Wing Screws
T(2) Hardwood Wing Joiners
T(1) Cannon Mount
T(1) Plastic Cannon Halves
MISCELLANEOUS WING PARTS
T(1) Plywood Hatch Frame
T(3) Plywood Hatch Cover Reinforcement Plates
T(1) Balsa Hatch Latch Shim
T(1) Hatch Latch
BATTERY HATCH ASSEMBLY - ELECTRIC VERSION
STEP 1: ALIGNING THE WING PANELS
TCut away the excess covering material that overlaps onto the root ribs of
each wing panel, leaving about 1/16" (1.6mm) overlapped so it does not
pull away.
IMPORTANT It's very important to the integrity of the wing centre-section
joint that you remove as much covering material from the root ribs as
possible. Do not omit this procedure or the wing centre-section joint may
IDLOGXULQJÀLJKW
TLocate and draw a vertical centreline on one side of each of the two wing
joiners.
IMPORTANT There are two wing joiners that support the wing panels. The larger wing joiner is the forward wing joiner and the
smaller wing joiner is the rear wing joiner.
TRemove the aileron and hinges from each of the two wing panels and set them aside for now.
STEP 3: INSTALLING THE CANNON AND PILOT FIGURE
T 7HVW¿W DQG JOXH WKH VHDW EDUUHO RQWR WKH WZR SUHLQVWDOOHG DQJOHG EDOVD
PRXQWLQJEORFNVRQWKHIXVHODJHÀRRU
IMPORTANT You will need to cut a small notch in each side of the seat
barrel backrest to clear the elevator and rudder pushrod guide tubes.
TGlue the cannon into the cannon mount, then align and glue the cannon
mount to the top of the wing. When positioned properly, the back edge of the
cannon mount should be pushed up against the front edge of the wing-screw
doubler and the cannon mount should be centred over the wing's centreline.
IMPORTANT Remember to cut away the covering material from the gluing
surfaces to ensure a strong glue joint.
T *OXHWKHSLORW¿JXUHKHDGWRWKHSLORW¿JXUHERG\WKHQJOXHWKHSLORW¿JXUH
to the top of the seat barrel.
TThin and Thick C/A
TModeling Knife
TStraight Edge Ruler
T(1) Plywood Hatch Frame
T(3) Plywood Hatch Cover Reinforcement Plates
T(1) Balsa Hatch Latch Shim
T(1) Hatch Latch
TPencil
T220 Grit Sandpaper with Sanding Block
TAirplane Stand
BATTERY HATCH INSTALLATION - ELECTRIC VERSION ONLY
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
IMPORTANT This section details the installation of the LiPO battery access hatch. If you are using a glow engine, please skip to
the Final Assembly section on page 39.
STEP 1: ASSEMBLING THE HATCH COVER
TCut out a battery access hatch on the bottom of the fuselage. The hatch
should be 3" (76mm) wide and 3-3/4" (95mm) long. The hatch should be
centred between the fuselage sides and the back edge of the hatch should be
1/2" (13mm) in front of the "step" (A) in each side of the fuselage.
IMPORTANT Use a straight edge ruler and a sharp modeling to ensure
accurate and straight cuts.
A
Page 36 Page 9
STEP 1: ASSEMBLING THE SEAT BARREL
TCut out the seat barrel backrest along the moulded scribe lines, making
sure to leave a 1/4" (6mm) wide lip on the bottom to use as a gluing surface.
TGlue the seat barrel backrest to the seat barrel, making sure that the edges
of the seat barrel backrest are even with the edge of the seat barrel.
STEP 2: ASSEMBLING THE CANNON AND PILOT FIGURE
TAfter the epoxy fully cures, cut away the excess material and carefully sand
the seam smooth. A rotary tool with a small sanding drum works good for this.
IMPORTANT$Q\YRLGVLQWKHVHDPVKRXOGEH¿OOHGZLWKSODVWLFSXWW\DQG
sanded smooth prior to painting.
T 5HSHDWWKHSUHYLRXVSURFHGXUHVWRMRLQWKHWZRSLORW¿JXUHERG\KDOYHVDQG
WKHWZRSLORW¿JXUHKHDGKDOYHV
T 3DLQWWKHVHDWEDUUHO SLORW ¿JXUH KHDG SLORW¿JXUHERG\DQGWKHFDQQRQ
DQ\FRORXU\RXGHVLUH:HVXJJHVWSDLQWLQJWKHVHDWEDUUHODQGWKHFDQQRQÀDW
EODFNWKHSLORW¿JXUHERG\EOXHZLWKVLOYHUEXFNOHVDQGWKHSLORW¿JXUHVIDFH
ÀHVKZLWK EURZQKDLUDQGEHDUG7KHSLORWVKDWFDQ DOVREHSDLQWHGEOXHWR
match his coat.
T $OLJQWKHPRXOGHGHGJHVRIWKHWZRFDQQRQKDOYHVDQGSUHVVWKHP¿UPO\
WRJHWKHU7KHHSR[\VKRXOG¿OODQ\YRLGVLQWKHVHDPEHWZHHQWKHWZRKDOYHV
Use masking tape to hold the two halves together until the epoxy fully cures.
T 7HVW¿WDQGJOXHWKHVHDWEDUUHOVXSSRUWSODWHLQWRWKHVHDWEDUUHO
TAfter the glue completely cures, trim and sand the top of the seat barrel
ÀXVKZLWKWKHWRSRIWKHVHDWEDUUHOVXSSRUWSODWH
IMPORTANT 7KH VHDW EDUUHO VXSSRUW SODWH ¿WV GRZQ LQWR WKH VHDW EDUUHO
<RXZLOOQHHGWRWULPWKHHGJHVRIWKHVHDWEDUUHOÀXVKZLWKWKHWRSRIWKHVHDW
barrel support plate.
TWorking with the cannon halves for now, lightly sand the moulded edges
of each cannon half so that the epoxy will stick to the plastic.
IMPORTANT You must lightly sand the gluing surfaces or the epoxy will not
VWLFN¿UPO\WRWKHSODVWLF
TApply a thick bead of 5 minute epoxy to the moulded edges of each
cannon half.
T 7HVW¿WERWKRIWKHZLQJMRLQHUVLQWRHDFKZLQJSDQHO7KH\ERWKVKRXOGVOLGH
easily into each wing panel, up to the centrelines you drew.
IMPORTANT :KHQ WKH ZLQJ MRLQHUV DUH LQVWDOOHG WKH\ VKRXOG QRW ¿W
tightly into the wing panels. They should actually be slightly loose. This will
ensure that when you glue the wing joiners into place, epoxy can get into
the joints between the wing joiners and the wing joiner mounting boxes. This
will ensure the strongest joint possible.
,IWKHZLQJMRLQHUVGRQRW¿WSURSHUO\XVHJULWVDQGSDSHUZLWKDVDQGLQJEORFNWROLJKWO\VDQGWKHHGJHVDQGWLSVRIHDFKRIWKH
ZLQJMRLQHUVXQWLO\RXDUHVDWLV¿HGZLWKWKH¿W
TCarefully slide both wing panels together with the wing joiners temporarily
installed (without using glue).
T :KLOHKROGLQJWKHWZRZLQJSDQHOVWRJHWKHU¿UPO\PDNHVXUHWKDWWKHZLQJSDQHOVDUHOLQHGXSDWERWKWKHOHDGLQJDQGWUDLOLQJHGJHV
WKHQORRNFDUHIXOO\DWWKHFHQWUHVHFWLRQMRLQWWKHZLQJSDQHOVVKRXOG¿WWRJHWKHUWLJKWO\ZLWKIHZRUQRJDSVLQWKHMRLQW
IMPORTANT,IWKHZLQJSDQHOVGRQRW¿WWRJHWKHUSURSHUO\UHPRYHWKHZLQJMRLQHUDQGXVHJULWVDQGSDSHUZLWKDVDQGLQJ
EORFNWROLJKWO\VDQGWKHHGJHVDQGWLSVRIWKHZLQJMRLQHUVXQWLO\RXDUHVDWLV¿HGZLWKWKH¿W5HPHPEHUZKHQWKHZLQJSDQHOVDUH
pushed together, there should be few or no gaps in the centre-section joint.
IMPORTANT%RWKZLQJMRLQHUVDUHFXWLQWKHVKDSHRIDVKDOORZ9:KHQWHVW¿WWLQJWKHZLQJMRLQHUVLQWRWKHZLQJSDQHOVLQWKH
next procedure, make sure that the "V" shape is toward the TOP of the wing panels.
STEP 2: JOINING THE WING PANELS
T :KHQVDWLV¿HG ZLWKWKH¿WDQGDOLJQPHQW SXOOWKHZLQJSDQHOVDSDUW DQG
remove both wing joiners.
T Apply a strip of masking tape to the top and bottom edges of the root rib on
each wing panel.
The masking tape will prevent excess epoxy from getting onto the wing
panels when you join them.
T Slide each wing joiner into the wing panel up to the centreline mark, then quickly remove any excess epoxy, using a paper towel and
rubbing alcohol, and allow the epoxy to set up before proceeding.
T $IWHUWKHHSR[\KDVVHWXSWHVW¿WERWKZLQJSDQHOVWRJHWKHUDJDLQWRGRXEOHFKHFNWKDWWKH\VWLOO¿WWRJHWKHUSURSHUO\WKHQDSSO\D
thin layer of 30 minute epoxy to the exposed half of each wing joiner, the inside of each wing joiner mounting box in the second wing
panel, and the entire surface of BOTH root ribs0DNHVXUHWRXVHHQRXJKHSR[\WR¿OODQ\JDSV
T Working with only one wing panel for now, apply a thin layer of 30 minute
epoxy inside each wing joiner mounting box and to only half of each wing joiner.
Make sure to cover the top and bottom, as well as the sides, and use enough
HSR[\WR¿OODQ\JDSV
WARNING Use only 30 or 45 minute epoxy to install the wing joiners and
to join the wing panels together. Do not use 5 minute epoxy. It is not strong
HQRXJK,I\RXXVHPLQXWHHSR[\WKHZLQJZLOOIDLOGXULQJÀLJKW
Page 10 Page 35
TSlide the two wing panels together and realign them. Quickly wipe away
any excess epoxy, using a paper towel and rubbing alcohol, and use pieces of
masking tape to hold the two wing panels aligned until the epoxy fully cures.
IMPORTANT It is of the utmost importance to the integrity of the wing centre-section joint that you apply a generous amount of
epoxy to both root ribsDQGHDFKZLQJMRLQHU1RWXVLQJHQRXJKHSR[\FDQUHVXOWLQZLQJIDLOXUHGXULQJÀLJKW
TOnce the epoxy has fully cured, remove the masking tape and double-check the centre-section joint. If any gaps are present, mix a
VPDOOTXDQWLW\RIPLQXWHHSR[\DQGFDUHIXOO\¿OODQ\UHPDLQLQJJDSV
TThin and Thick C/A
TFlat Head Screwdriver
TModeling Knife
T(1) Fuselage
T(1) Plywood Wing-Screw Doubler
T(2) M5 x 65mm Nylon Wing Screws
TStraight Edge Ruler
TPencil
WING MOUNTING
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
STEP 1: INSTALLING THE WING-SCREW DOUBLER
TCut away the covering material from over the top and bottom of the two
predrilled wing-screw mounting holes in the trailing edge of the wing. The holes
are located 5/8" (16mm) in front of the trailing edge and 1-1/4" (32mm) out from
the centre-section joint.
TCut away the covering material from over the predrilled holes in the
wing-screw doubler.
TPlace the wing-screw doubler onto the top of the wing and align the predrilled
holes in the wing-screw doubler with the predrilled holes in the wing.
TWhile holding the wing-screw doubler in place, draw an outline around it
onto the wing.
IMPORTANT The back edge of the wing-screw doubler may hang past
the trailing edge of the wing. This is normal.
TCut away the covering material from over the two wing strut mounting holes
in the bottom of the fuselage. Each hole is located 3/4" (19mm) behind the
main landing gear bracket and 1/2" (13mm) in from the fuselage sides.
TCut away the covering material from over the four wing strut mounting holes
in the bottom of the wing. Two holes are located in each half of the wing, 20"
(508mm) out from the centreline of the wing. The two forward holes are
located 7" (178mm) in front of the aileron hinge line and the two rear holes
are located 2-3/4" (70mm) in front of the aileron hinge line.
TInstall the wing onto the fuselage.
TMount the two wing struts onto the fuselage, using two M3 x 10mm machine
VFUHZVDQGWZR0ÀDWZDVKHUV'RQWWLJKWHQWKHPDFKLQHVFUHZV\HW/HDYH
them loose until after you secure the wing struts to the wing.
TAlign the two holes in each wing strut with the two holes in each half of the
wing, then secure the wing struts to the wing, using four M3 x 10mm machine
VFUHZVDQGIRXU0ÀDWZDVKHUV
IMPORTANT After tightening the four wing strut mounting screws in the wing, tighten the two wing strut mounting screws in
the fuselage.
T5 Minute Epoxy
TModeling Knife
TScissors
T220 Grit Sandpaper with Sanding Block
TRotary Tool with Sanding Drum (Optional)
T(1) Plastic Seat Barrel
T(1) Balsa Seat Barrel Support Plate
T(1) Plastic Seat Barrel Backrest
T(1) Plastic Pilot Figure Body Halves
T(1) Plastic Pilot Figure Head Halves
T(1) Cannon Mount
T(1) Plastic Cannon Halves
TMasking Tape
TPaper Towels
TRubbing Alcohol
TEpoxy Mixing Sticks
TEpoxy Mixing Cups
PLASTIC PARTS INSTALLATION
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
Page 34 Page 11
T &XWDZD\WKHFRYHULQJPDWHULDOIURPRYHUWKHVORWLQRQHHQGRIWKHÀ\LQJ
wires mounting post.
T *OXHWKHÀ\LQJZLUHVPRXQWLQJSRVWLQWRWKHZLQJPDNLQJVXUHWKDWLWVDOLJQHG
straight when viewed from both the front and the side, and that the slot in the top
RIWKHÀ\LQJZLUHVPRXQWLQJSRVWLVSDUDOOHOZLWKWKHOHDGLQJHGJHRIWKHZLQJ
IMPORTANT:KHQ\RXLQVWDOOWKHÀ\LQJZLUHVPRXQWLQJSRVWWKHVORWLQWKH
WRSRIWKHÀ\LQJZLUHVPRXQWLQJSRVWVKRXOGEHSDUDOOHOZLWKWKHOHDGLQJHGJH
of the wing.
STEP 2: INSTALLING THE FLYING WIRES
T &XWDZD\WKHFRYHULQJ PDWHULDO IURP RYHU WKHIRXUÀ\LQJZLUHV PRXQWLQJ
holes in the top of the wing. Two holes are located in each half of the wing,
20" (508mm) out from the centreline of the wing. The two forward holes are
located 7" (178mm) in front of the aileron hinge line and the two rear holes
are located 2-3/4" (70mm) in front of the aileron hinge line.
T 0RXQWHDFKHQGRIWKHVKRUWHUÀ\LQJZLUHWRWKHIRUZDUGKROHLQHDFKKDOI
RIWKHZLQJXVLQJWZR0[PPPDFKLQHVFUHZVDQGWZR0ÀDWZDVKHUV
T 0RXQWHDFKHQGRIWKHORQJHUÀ\LQJZLUHWRWKHUHDUKROHLQHDFKKDOIRIWKH
ZLQJXVLQJWZR0[PPPDFKLQHVFUHZVDQGWZR0ÀDWZDVKHUV
IMPORTANT7ZRGLIIHUHQWOHQJWKÀ\LQJZLUHVDUHLQFOXGHG7KHORQJHUÀ\LQJZLUHLVLQVWDOOHGEHWZHHQWKHWZRUHDUKROHVLQWKHZLQJDQG
WKHVKRUWHUÀ\LQJZLUHLVLQVWDOOHGEHWZHHQWKHWZRIRUZDUGKROHVLQWKHZLQJ
T &DUHIXOO\SXOOHDFKRIWKHÀ\LQJZLUHVXSDQGLQWRWKHVORWLQWKHWRSRIWKH
À\LQJZLUHVPRXQWLQJSRVW
STEP 3: INSTALLING THE WING STRUTS
IMPORTANT7KHZLQJVWUXWVZLOO¿WRQO\RQHZD\:KHQLQVWDOOHGWKHVKRUWHUOHQJWKSRUWLRQRIHDFKZLQJVWUXWVKRXOGEHWRZDUG
the leading edge of the wing and the longer length portion of each wing strut should be toward the trailing edge of the wing.
TCut away the covering material from inside the outline you drew, then glue
the wing-screw doubler onto the wing using thick C/A.
STEP 2: MOUNTING THE WING
TApply a couple of drops of thin C/A into each of the two threaded wing-screw
mounting holes in the fuselage. Allow the C/A to fully cure before proceeding.
IMPORTANT The C/A will soak into the plywood, strengthening the threads. Do not omit this procedure. Allow the C/A to fully cure
before proceeding.
TPlace the wing into the wing saddle, push it forward completely, then push
the trailing edge down into place.
TAlign the holes in the wing with the threaded holes in the wing mounting
block inside the fuselage.
TSecure the wing into place, using two wing mounting screws.
Don't overtighten the screws. You don't want to crush the wing or break
the screws off.
T(1) Horizontal Stabiliser with Elevator T(1) Vertical Stabiliser with Rudder
STABILISER INSTALLATION
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
T30 Minute Epoxy
TModeling Knife
TStraight Edge Ruler
TPencil
TBuilder's Triangle
T220 Grit Sandpaper with Sanding Block
TPaper Towels
TRubbing Alcohol
TEpoxy Mixing Sticks
TEpoxy Mixing Cups
Page 12 Page 33
TMeasure and draw a centreline on the trailing edge of the stabiliser.
TSet the stabiliser onto the stabiliser mounting platform, push it forward as far as
possible, then line up the centreline you drew on the stabiliser with the centreline
of the back of the fuselage and hold only the trailing edge of the stabiliser in
position, using a T-Pin.
IMPORTANT The front of the stabiliser should be able to pivot slightly
IURPVLGHWRVLGHDQGWKHEDFNVKRXOGVWD\¿UPO\LQSODFHDQGDOLJQHG7KH
trailing edge should not be allowed to move from side to side.
TWith the wing mounted to the fuselage, use a ruler to measure the distance
between the tips of the stabiliser and the tips of the wing. Pivot the front of the
stabiliser until both of these measurements are equal.
When both of these measurements are equal, you're assured that the
stabiliser is square to the wing.
T :KHQ\RXUHVDWLV¿HGWKDWWKHVWDELOLVHULVVTXDUHWRWKHZLQJXVHD73LQ
WRKROGWKHIURQWRIWKHVWDELOLVHU¿UPO\LQSODFHDQGDOLJQHG
TCut away the covering material from the top of both sides of the stabiliser
mounting platform.
67(3$/,*1,1*7+(+25,=217$/67$%,/,6(5
TRemove the elevator and its hinges from the horizontal stabiliser and set them aside for now.
TLook from the front of the aircraft at both the wing and the stabiliser. When
aligned properly, the stabiliser should be parallel to the wing. If the stabiliser
is not parallel to the wing, you'll need to remove the stabiliser and sand down
WKHKLJKHUVLGHRIWKHVWDELOLVHUPRXQWLQJSODWIRUPXQWLO\RXUHVDWLV¿HGZLWKWKH
alignment.
STEP 4: INSTALLING THE COWL
T :LWKWKHFRZOKHOG¿UPO\LQDOLJQPHQWGULOO¿YHPPGLDPHWHUSLORW
holes through the cowl and into the centre of the cowl mounting blocks.
T 5HPRYHWKHFRZODQGDSSO\DFRXSOHRIGURSVRIWKLQ&$LQWRWKH¿YHSLORW
holes and allow the C/A to fully cure.
IMPORTANT The C/A will harden the surrounding wood, making the
mounting area stronger. Do not omit this procedure.
TMark and cut out the areas of the cowl necessary to give you access to
\RXUHQJLQHVKLJKDQGORZVSHHGQHHGOHYDOYHVDQGWKHPXIÀHU<RXVKRXOG
also install an in-cowl fueling valve in a convenient location on the side of
WKHFRZOVRWKDW\RXFDQ¿OOWKHIXHOWDQN
T ,QVWDOOWKHFRZOXVLQJ¿YH0[PPÀDQJHKHDGZRRGVFUHZVWKHQLQVWDOO
your propeller.
T# 2 Phillips Head Screwdriver
TModeling Knife
T(1) Right Wing Strut
T(1) Left Wing Strut
T(1) Flying Wires Mounting Post
T(2) Flying Wires
T(10) M3 x 10mm Machine Screws
T(10) M3 Flat Washers
TStraight Edge Ruler
TAirplane Stand
WING STRUTS AND FLYING WIRES INSTALLATION
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
STEP 1: INSTALLING THE FLYING WIRES MOUNTING POST
T &XWDZD\WKHFRYHULQJPDWHULDOIURPRYHUWKHÀ\LQJZLUHVPRXQWLQJSRVWKROH
in the top of the wing. The mounting post hole is located on the wing's centreline,
4-1/2" (114mm) behind the leading edge of the wing.
IMPORTANT,I\RXZRXOGOLNHWRPRXQWWKHFDQQRQRQWRWKHZLQJ\RXZLOOQRWEHDEOHWRLQVWDOOWKHÀ\LQJZLUHV2QO\LQVWDOOWKHÀ\LQJ
wires if you don't plan on installing the cannon. Both cannot be mounted at the same time.
Page 32 Page 13
STEP 3: ALIGNING THE COWL
STEP 1: INSTALLING THE HATCH COVER
TDrill two 1/16" (1.6mm) pilot holes through the front of the hatch cover and
into the plywood mounting blocks inside the fuselage. Position each pilot hole
3/16" (5mm) in from the sides of the hatch cover and 3/16" (5mm) behind the
front of the hatch cover.
T 6HFXUHWKHKDWFKFRYHULQWRSODFHXVLQJWZR0[PPÀDQJHKHDGZRRGVFUHZV
STEP 2: INSTALLING THE COWL MOUNTING BLOCKS
IMPORTANT Five cowl mounting blocks are provided to mount the cowl. Two cowl mounting blocks D-62 are installed on the
bottom of the fuselage sides, two cowl mounting blocks D-61 are installed on the middle of the fuselage sides, and the single cowl
mounting block D-60 is installed centred on the top of the fuselage (the hatch cover).
T *OXHHDFKRIWKH¿YHFRZOPRXQWLQJEORFNVWRWKHIXVHODJHDWWKHSRVLWLRQV
described above, making sure that the front of each cowl mounting block is
even with the front of the fuselage.
IMPORTANT The narrower edge of the two lower cowl mounting blocks
D-62 should be installed even with the bottom of the fuselage. The wider edge
should be toward the top of the fuselage.
TIf you're using a glow engine, carefully elongate the precut hole in the front
of the cowl for your engine's crankshaft. The top of the elongated hole should
be approximately 1-3/8" (35mm) down from the top of the cowl.
TIf you're using a brushless outrunner electric motor, carefully cut out the
portion of the cowl directly below the precut hole in the front of the cowl.
TLine up the front of the cowl, using your engine's drive washer as a guide.
When aligned properly, the front of the cowl should be approximately 1/4"
(6mm) behind the drive washer and the front of the cowl should be centred
from side-to-side when viewed from the front. The cowl should also be straight
when viewed from the side.
T :KHQVDWLV¿HGZLWKWKHDOLJQPHQWXVHSLHFHVRIPDVNLQJWDSHWRKROGWKH
cowling securely to the fuselage.
IMPORTANT Make sure to cut away the covering material from the gluing surfaces before gluing the cowl mounting blocks into place.
IMPORTANT If you're using a glow engine, the precut hole in the front of the cowl must be elongated upward to line up with your engine's
FUDQNVKDIW7KLVLVEHFDXVHWKHJORZHQJLQHLVLQVWDOOHGKLJKHURQWKH¿UHZDOOWKDQWKHEUXVKOHVVRXWUXQQHUHOHFWULFPRWRUWRDFFRPPRGDWH
its inverted position. If you're using a brushless outrunner electric motor, you will need to cut the section of the cowling out below the precut
hole to allow clearance for your motor's propeller shaft.
Elongate up if using
a glow engine.
Cut away if using a
brushless outrunner
electric motor.
67(3,167$//,1*7+(+25,=217$/67$%,/,6(5
T 2QFH\RXUHVDWLV¿HGZLWKWKHDOLJQPHQWGUDZDOLQHRQHDFKVLGH RIWKH
bottom of the stabiliser where it meets the fuselage.
WARNING When cutting through the covering to remove it in the next procedure, cut with only enough pressure to cut through only
WKHFRYHULQJLWVHOI&XWWLQJGRZQLQWRWKHEDOVDVWUXFWXUHFRXOGZHDNHQWKHVWDELOLVHUDQGFDXVHLWWRIDLOGXULQJÀLJKW
TRemove the stabiliser from the fuselage, then carefully cut away the
covering material from inside the lines you drew.
PRO TIP Use a heat-sealing iron to adhere the covering material down
where you cut it. This will prevent it from loosening up and wrinkling.
TApply a generous amount of 30 minute epoxy to the gluing surfaces on both the stabiliser and the stabiliser mounting sides.
TSet the stabiliser into place and realign it, double-checking all of your measurements once more before the epoxy sets up. Quickly
remove any excess epoxy and use T-Pins to hold the stabiliser in place and aligned until the epoxy has fully cured.
STEP 3: ALIGNING AND INSTALLING THE VERTICAL STABILISER
TRemove the rudder and its hinges from the vertical stabiliser and set them
aside for now.
TPush the vertical stabiliser into the mounting slot in the horizontal stabiliser.
Use a straight edge to ensure that the trailing edge of the vertical stabiliser is
even with the back edge of the fuselage. This will ensure that the rudder will
line up correctly when it's hinged later.
TDraw a line on each side of the vertical stabiliser where it meets the top of
the mounting slot.
TCut away the covering material from below both the lines that you drew on
the stabiliser and from the base of the stabiliser, too.
Page 14 Page 31
TGlue the stabiliser into place, using a generous amount of 30 minute epoxy.
IMPORTANT It's important that the trailing edge of the vertical stabiliser
be even with the back edge of the fuselage and that the vertical stabiliser be
perpendicular to the horizontal stabiliser. Double-check this while the epoxy
is setting up and curing.
T(1) Tail Wheel Wire with Mounting Bracket
T(1) Tail Wheel
T(1) Nylon Spacer
T(2) M3 x 5mm Machine Screws
T(3) M3 x 12mm Wood Screws
T(14) C/A-Style Hinges
HINGING THE CONTROL SURFACES
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
T5 Minute Epoxy
TThin C/A
TC/A Debonder
T# 2 Phillips Head Screwdriver
TModeling Knife
TElectric Drill
T5/54" (2mm) and 3/32" (2.4mm) Drill Bits
TStraight Edge Ruler
TPencil
T220 Grit Sandpaper with Sanding Block
TT-Pins
TWax Paper
TPaper Towels
TRubbing Alcohol
TEpoxy Mixing Sticks
TEpoxy Mixing Cups
TCut away the covering material from over the precut slot in the root end of
one aileron.
Notice that there is a predrilled hole in the slot to accept the aileron torque
rod wire.
STEP 1: HINGING THE AILERONS
IMPORTANT C/A-style hinges are used to hinge the control surfaces. These hinges are designed to be glued into place using thin
C/A. Do not glue the hinges into place using any other type of glue, such as thick C/A or epoxy. Use of any adhesive other than thin
&$FRXOGUHVXOWLQIDLOXUHRIWKHKLQJHVGXULQJÀLJKW
)RUÀXWWHUIUHHFRQWUROVXUIDFHVDQGFULVSFRQWUROUHVSRQVHLWLVLPSHUDWLYHWKDWWKHKLQJHVEHJOXHGLQSURSHUO\7KLVLVDFKLHYHGE\
having a tight hinge gap (no more than 1/32" (1mm) wide) and using plenty of thin C/A glue. Poor hinge installation can lead to control
VXUIDFHÀXWWHUZKLFKFDQUHVXOWLQDFDWDVWURSKLFIDLOXUHRIWKHDLUIUDPH
PRO TIP The T-Pins will keep the hinges centred and square to the hinge
line while you are hinging the aileron.
TPush two T-Pins through the centre of four aileron hinges.
STEP 2: INSTALLING THE AILERON CONTROL LINKAGE ASSEMBLIES
TThread one adjustable control horn onto each threaded aileron torque
rod. When positioned properly, both adjustable control horns should be even
with the top of the torque rods.
TCut away two arms from a "4-point" servo horn, then enlarge the hole in
each servo arm that is 5/8" (16mm) out from the centre of the servo horn, using
a 5/64" (2mm) diameter drill bit.
TInstall the 90º bend in each pushrod wire into the hole that you enlarged in
the servo arms, using two snap-keepers.
The pushrod wires should be orientated on top of the servo arms.
TUse a couple of pieces of masking tape, taped between the ailerons and
the wing, to hold the ailerons centred.
TWith both the aileron servo and the ailerons centred, thread a clevis onto
each pushrod wire and snap the clevises into the adjustable control horns.
TRemove the masking tape and double-check that both the aileron servo horn and both ailerons are still centred. If necessary, thread
the clevises in or out to centre the ailerons, then move the ailerons up and down several times to ensure proper movement. Both ailerons
should move smoothly and not bind in any way.
TThin and Thick C/A
T# 1 Phillips Head Screwdriver
TAdjustable Wrench
TModeling Knife
TElectric Drill
T1/16" (1.6mm) and 5/64" (2mm) Drill Bits
T(1) Cowl
T(5) Cowl Mounting Blocks
T(7) M2 x 10mm Flange-Head Wood Screws
TStraight Edge Ruler
TPencil
TRotary Tool with Cutting Disc and Sanding Drum
T220 Grit Sandpaper with Sanding Block
TMasking Tape
COWL INSTALLATION
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
TCentre the aileron servo, then install the servo horn onto the servo, making
sure that the servo horn is centred.
TInstall the servo horn retaining screw to secure the servo horn to the servo.
Page 30 Page 15
T5 Minute Epoxy
T# 1 Phillips Head Screwdriver
TNeedle Nose Pliers
TModeling Knife
TStraight Edge Ruler
T(2) 4-1/2" (114mm) Threaded Wires with 90º Bends
T(1) Plywood Servo Tray
T(2) Nylon Adjustable Control Horns
T(2) Nylon Clevises
T(2) Nylon Snap-Keepers
TMasking Tape
TPaper Towels
TRubbing Alcohol
TEpoxy Mixing Sticks
TEpoxy Mixing Cups
AILERON CONTROL SYSTEM INSTALLATION
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
STEP 1: INSTALLING THE AILERON SERVO
TCut a shallow notch on the inside of one end of the servo tray large enough
for the aileron servo lead to pass through next to the servo.
TCarefully cut a notch in the back of the servo mounting opening in the wing
large enough so that when your servo is installed the servo lead won't be
pinched or otherwise damaged.
IMPORTANT Before gluing the aileron servo tray into place in the next procedure, remember to cut away the covering material
IURPRYHUWKHJOXLQJVXUIDFHVDQGWRXVHDJHQHURXVDPRXQWRIJOXHWR¿OOWKHQDUURZJDSVFDXVHGE\WKHZLQJVGLKHGUDODQJOH
TGlue the servo tray onto the wing, making sure that the servo tray is centred
over the mounting hole in the wing.
IMPORTANT When gluing the servo tray in place, use a generous bead of
PLQXWHHSR[\RQWKHVLGHVRIWKHVHUYRWUD\WR¿OOWKHQDUURZJDSVFDXVHG
by the wing's dihedral angle.
T ,QVWDOOWKHUXEEHUJURPPHWVDQGEUDVVFROOHWVRQWR\RXUDLOHURQVHUYRPDNLQJVXUHWRLQVWDOOWKHFROOHWVZLWKWKHÀDQJHVWRZDUGWKH
bottom of the servo.
TInstall the aileron servo into the servo tray, making sure to drill 1/16" (1.6mm)
diameter pilot holes for the mounting screws.
IMPORTANT Note the orientation of the servo. When installed, the servo
output shaft should be toward the trailing edge of the wing.
Cut
TSlide one hinge into each of the four hinge slots in the aileron, making sure
that you push each hinge in up to the T-Pins.
IMPORTANT Don't glue the hinges into the aileron yet.
T 7HVW¿WWKHDLOHURQWRWKHZLQJE\SXVKLQJWKHDLOHURQDQGLWVKLQJHVLQWRWKH
hinge slots in the trailing edge of the matching half of the wing, making sure
WKDWWKHWRUTXHURGZLUHLV¿UPO\VHDWHGZLWKLQWKHSUHFXWVORWLQWKHDLOHURQ
IMPORTANT You may need to cut the slot in the aileron for the torque rod
wire deeper, so that the aileron can be pushed forward enough to ensure
a tight hinge gap.
TCut out a 1-3/4" (44mm) square piece of wax paper and slide the wax paper
between the torque rod wire and the trailing edge of the wing.
The wax paper will prevent epoxy from gluing the torque rod wire to the
trailing edge of the wing.
TLightly sand the end of the torque rod wire to roughen the gluing surface.
T :KHQVDWLV¿HGZLWKWKH¿WDQGDOLJQPHQWUHPRYHWKHDLOHURQIURPWKHZLQJEXWOHDYHWKHKLQJHVFHQWUHGLQWKHDLOHURQ
TMix a small quantity of 5 minute epoxy and apply a thin layer to the end of
the torque rod wire and into the predrilled hole and the precut slot in the leading
edge of the aileron.
TRemove the T-Pins and push the aileron up against the trailing edge. There
should be no more than a 1/32" (1mm) wide hinge gap.
TWhile holding the aileron tight against the trailing edge, pivot the aileron
down 45º and apply 5-6 drops of thin C/A to the exposed area of each hinge,
then turn the wing over and repeat for the other side of the hinges.
TAllow the C/A and epoxy to dry for about 15 minutes, then pivot the aileron up and down several times to free up the hinges.
IMPORTANT Check the integrity of the hinges after the C/A fully cures by gently pulling on the aileron. If one or more hinges
feels loose, apply more C/A to the hinge(s) and allow it to completely cure. The last thing you want is for a hinge to come loose
GXULQJÀLJKW
TRepeat the previous procedures to hinge the aileron to the other half of the wing.
TPush the aileron and hinges into the corresponding four hinge slots in the trailing edge of the wing.
IMPORTANT Roughening the metal will allow the epoxy to stick better to it. Do not omit this procedure.
Page 16 Page 29
STEP 2: HINGING THE ELEVATOR
IMPORTANT After allowing the C/A to fully cure, pull on the elevator to check the integrity of the hinges. Apply more C/A to the
hinge(s) if necessary.
THinge the elevator to the horizontal stabiliser, using the same techniques
that you used to hinge the ailerons to the wing. The elevator is hinged using four
hinges. When hinging the elevator, the tips of the elevator should be even with
the tips of the stabiliser and there should not be more than a 1/32" (1mm)
wide hinge gap.
STEP 3: INSTALLING THE TAIL WHEEL ASSEMBLY
TCut away the covering material from over the notch in the leading edge of
the rudder. The notch is located 2-1/4" (57mm) up from the bottom of the rudder.
TCarefully drill a 3/32" (2.4mm) pilot hole into the leading edge of the rudder.
Position the pilot hole 1/2" (13mm) up from the bottom of the rudder and drill
the pilot hole 1/2" (13mm) into the rudder.
TCut a slot in the leading edge of the rudder from the base of the pilot hole
WRWKHERWWRPRIWKHUXGGHUWR¿WWKHWDLOZKHHOZLUHLQWR
IMPORTANT The slot should be deep enough so that when the tail wheel wire is installed, the front edge of the tail wheel wire
LVÀXVKZLWKWKHOHDGLQJHGJHRIWKHUXGGHU
T 7HVW¿WDQGJOXHWKHWDLOZKHHOZLUHLQWRWKHUXGGHUXVLQJDJHQHURXVDPRXQW
of 5 minute epoxy. Be careful not to get any epoxy between the tail wheel wire
and the mounting bracket.
IMPORTANT Remember to roughen the gluing surfaces of the tail wheel
wire to ensure a strong glue joint.
TRemove the masking tape and double-check that both the elevator servo horn and the elevator are still centred. If necessary, thread
the clevis in or out to centre the elevator, then move the elevator up and down several times to ensure proper movement. The elevator
should move smoothly and not bind in any way.
TCut away the covering material from over the rudder pushrod exit hole in
the left side of the fuselage. The pushrod exit hole is located 2" (50mm) in front
of the rudder hinge line and 7/8" (22mm) below the stabiliser.
STEP 4: INSTALLING THE RUDDER PUSHROD ASSEMBLY
TCarefully slide the pushrod wire into the rudder pushrod wire guide tube.
TCentre the rudder servo, then install the servo horn onto the servo, making
sure that the servo horn is centred and points toward the side of the fuselage.
TInstall the servo horn retaining screw to secure the servo horn to the servo.
TCut away all but one arm from a "4-point" servo horn, then enlarge the hole
that is 5/8" (16mm) out from the centre of the servo horn, using a 5/64" (2mm)
diameter drill bit.
TInstall the 90º bend in the pushrod wire into the hole that you enlarged in
the servo arm, using one snap-keeper.
The pushrod wire should be orientated on top of the servo arm.
STEP 5: INSTALLING THE RUDDER CONTROL HORN AND CLEVIS
TInstall the control horn onto the right side of the rudder, using the same
techniques that you used to install the elevator control horn. The centreline
of the control horn should be 1-1/2" (38mm) up from the bottom of the rudder
(measured at the hinge line) and the clevis attachment holes should be lined
up over the hinge line. The base of the control horn should be parallel to the
hinge line, too.
TUse a couple of pieces of masking tape, taped between the rudder and the
stabiliser, to hold the rudder centred.
TWith both the rudder servo and the rudder centred, thread a clevis onto
the pushrod wire and snap the clevis into the third hole out from the base
of the control horn.
TRemove the masking tape and double-check that both the rudder servo horn and the rudder are still centred. If necessary, thread the
clevis in or out to centre the rudder, then move the rudder right and left several times to ensure proper movement. The rudder should
move smoothly and not bind in any way.
Page 28 Page 17
TPosition and mark the mounting hole locations for the control horn on the
bottom, left side of the elevator. When aligned properly, the centreline of the
control horn should be 3/4" (19mm) out from the fuselage side (measured at
the hinge line) and the clevis attachment holes should be lined up over the
hinge line. The base of the control horn should be angled slightly toward the
fuselage side so that it will line up with the pushrod wire.
TDrill 5/64" (2mm) diameter pilot holes through the elevator for the control
horn mounting screws, then apply a couple of drops of thin C/A into the pilot
holes and allow the C/A to fully cure.
The C/A will harden the surrounding wood, making the mounting area
stronger.
TInstall the control horn and backplate, using two M2 x 20mm machine
screws, then use wire cutters to cut the top of the screws off flush with
the control horn backplate.
TCarefully slide the pushrod wire into the elevator pushrod wire guide tube
(the guide tube on the left side of the fuselage).
TCentre the elevator servo, then install the servo horn onto the servo,
making sure that the servo horn is centred and points toward the side of the
fuselage.
TInstall the servo horn retaining screw to secure the servo horn to the servo.
TCut away all but one arm from a "4-point" servo horn, then enlarge the hole
that is 5/8" (16mm) out from the centre of the servo horn, using a 5/64" (2mm)
diameter drill bit.
TInstall the 90º bend in one pushrod wire into the hole that you enlarged in
the servo arm, using one snap-keeper.
The pushrod wire should be orientated on top of the servo arm.
STEP 3: INSTALLING THE ELEVATOR CONTROL HORN AND CLEVIS
TUse a couple of pieces of masking tape, taped between the elevator and the
stabiliser, to hold the elevator centred.
TWith both the elevator servo and the elevator centred, thread one clevis
onto the pushrod wire, then snap the clevis into the third hole out from the
base of the control horn.
IMPORTANT After allowing the C/A to fully cure, pull on the rudder to check the integrity of the hinges. Apply more C/A to the
hinge(s) if necessary.
THinge the rudder to the vertical stabiliser, using the same techniques that
you used to hinge the elevator to the horizontal stabiliser. The rudder is hinged
using two hinges. When hinging the rudder, the tips of the rudder should be
even with the tip of the vertical stabiliser and there should not be more than
a 1/32" (1mm) wide hinge gap.
STEP 4: HINGING THE RUDDER
TMount the tail wheel bracket to the bottom of the fuselage, using three
0[PPZRRGVFUHZVPDNLQJVXUHWR¿UVWGULOOWKUHHPPGLDPHWHU
pilot holes for the wood screws.
T(1) Main Landing Gear Bracket
T(1) Nose Skid
T(2) Main Gear Wheels
T(2) Nylon Mounting Brackets (Wide Slot)
T(5) Nylon Mounting Brackets (Narrow Slot)
T(2) Nylon Spacers
T(2) Wheel Collars
T(2) M3 x 5mm Machine Screws
T(13) M3 x 12mm Wood Screws
MAIN LANDING GEAR INSTALLATION
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
T# 2 Phillips Head Screwdriver
TElectric Drill
T5/54" (2mm) Drill Bit
TStraight Edge Ruler
TPencil
TAirplane Stand
TSecure the tail wheel to the axle, using the wheel collar and one M3 x 5mm
machine screw. After tightening the machine screw, make sure that the tail
wheel spins freely.
TPush the wheel collar on the tail wheel wire up against the tail wheel mounting
bracket, then install and tighten the remaining M3 x 5mm machine screw into
the wheel collar.
STEP 1: INSTALLING THE MAIN LANDING GEAR BRACKET
IMPORTANT The main landing gear bracket is constructed from two different diameters of wire. Install the landing gear bracket
with the larger diameter toward the back of the fuselage. Also note that two different sizes of nylon mounting brackets are provided
to match the different wire diameters.
TSlide the nylon spacer onto the axle, followed by the tail wheel.
Page 18 Page 27
TPlace the main landing gear bracket onto the bottom of the fuselage. The
front of the landing gear bracket (the smaller diameter wire) should be positioned
PPEHKLQGWKH¿UHZDOOPHDVXUHGDWWKHFHQWUHRIWKH¿UHZDOODQGWKH
landing gear bracket should be centred between the fuselage sides.
IMPORTANT7KH¿UHZDOOKDVULJKWWKUXVWEXLOWLQWRLWVRPDNHVXUHWRWDNH
WKHPHDVXUHPHQWIURPWKHFHQWUHRIWKH¿UHZDOO
TPosition four nylon mounting brackets over the landing gear wires. Centre
each nylon mounting bracket between the main landing gear legs and the centre
support structure.
TWhile holding the nylon mounting brackets and the main landing gear bracket
in place, mark the locations of the mounting screws onto the fuselage.
TDrill eight 5/64" (2mm) diameter pilot holes through the fuselage at the
marks you drew, then install the four nylon mounting brackets, using eight
M3 x 12mm wood screws, to hold the main landing gear bracket in place.
STEP 2: INSTALLING THE MAIN GEAR WHEELS
TPush one nylon spacer completely onto each axle.
TSlide one main gear wheel onto each axle and secure the wheels into place,
using one wheel collar and one M3 x 5mm machine screw.
7LJKWHQWKHPDFKLQHVFUHZV¿UPO\WKHQGRXEOHFKHFNWKDWERWKZKHHOV
spin freely.
TLoop a single # 64 or similar rubber band (not included) several times around
the two hooks on the main landing gear bracket.
The rubber band will act as a shock absorber for the landing gear.
TConnect your radio system and check that the throttle servo output shaft is rotating in the correct direction, then position the throttle
control stick and the throttle trim lever to their lowest positions.
TSlide the adjustable pushrod connector assembly onto the pushrod wire,
then install the servo horn onto the servo, making sure that the servo horn is
angled approximately 30 degrees from centre.
TWhile holding the carburetor fully closed, install and tighten the machine
screw in the top of the adjustable pushrod connector.
TCut away the excess pushrod wire, then install and tighten the servo horn
retaining screw to hold the servo horn securely to the servo.
TOpen and close the throttle several times to ensure that the carburetor opens and closes completely and without binding or hitting
the side of the fuel tank. You may need to adjust your transmitter EPA settings to achieve perfect settings.
TThin C/A
T# 1 Phillips Head Screwdriver
TWire Cutters
TNeedle Nose Pliers
TModeling Knife
T(2) 32" (813mm) Threaded Wires with 90º Bends
T(2) Nylon Control Horns with Backplates
T(2) Nylon Clevises
T(2) Nylon Snap-Keepers
T(4) M2 x 20mm Machine Screws
TElectric Drill
T1/16" (1.6mm) and 5/64" (2mm) Drill Bits
TStraight Edge Ruler
TPencil
TMasking Tape
ELEVATOR AND RUDDER CONTROL SYSTEMS INSTALLATION
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
STEP 1: INSTALLING THE ELEVATOR AND RUDDER SERVOS
TInstall the elevator and rudder servos into the sides of the servo tray, making sure
to drill 1/16" (1.6mm) diameter pilot holes for the servo mounting screws.
IMPORTANT Note the orientation of the servos. When installed, both servo
output shafts should be toward the back of the fuselage.
TCut away the covering material from over the elevator pushrod exit hole in
the right side of the fuselage. The pushrod exit hole is located 2" (50mm) in
front of the rudder hinge line and 5/8" (16mm) below the stabiliser.
STEP 2: INSTALLING THE ELEVATOR PUSHROD ASSEMBLY
T ,QVWDOOWKHUXEEHUJURPPHWVDQGEUDVVFROOHWVRQWR\RXUHOHYDWRUDQGUXGGHUVHUYRVPDNLQJVXUHWRLQVWDOOWKHFROOHWVZLWKWKHÀDQJHV
toward the bottom of the servos.
Page 26 Page 19
STEP 2: INSTALLING THE THROTTLE PUSHROD WIRE
T 0DUNWKHORFDWLRQRIWKHWKURWWOHSXVKURGH[LWKROHRQWKH¿UHZDOO)RURXU
Magnum XL .52RFS 4-stroke engine, we positioned the pushrod exit hole
1-1/2" (38mm) up from the bottom of the fuselage and 5/8" (16mm) in from the
fuselage side.
IMPORTANT Mark the position of the hole as close to the same height as
the throttle arm as possible and as close to the throttle arm as possible, but
still far enough away to keep from hitting the fuel tank.
PRO TIP To ensure that your throttle pushrod is installed properly, it's important the your engine's throttle arm be positioned on the
OHIWVLGHRIWKHHQJLQHÀLS\RXUHQJLQHVFDUEXUHWRUDURXQGLIQHFHVVDU\7KHWKURWWOHSXVKURGZLUHDOVRKDVWRFOHDUWKHVLGHRIWKH
IXHOWDQNVRDEHQGZLOOQHHGWREHPDGHZKHUHWKHSXVKURGZLUHH[LWVWKH¿UHZDOODQGEHIRUHWKHVHUYR
T 'ULOODPPGLDPHWHUKROHWKURXJKWKH¿UHZDOOIRUWKHSXVKURGZLUH
You may need to remove the engine and motor mounting beams to make
it easier to drill the hole accurately.
TMake several bends in the throttle pushrod wire to clear the fuel tank and line
up with both your engine's throttle arm and the servo arm.
IMPORTANT The measurements of the bends shown are for a Magnum
XL .52RFS 4-stroke engine. You may need to make slightly different bends
depending on the engine you're using.
TRemove the throttle arm from your engine, install the Z-Bend in the pushrod
wire into the outermost hole in the throttle arm, then slide the pushrod wire
WKURXJKWKHKROHERWKLQWKH¿UHZDOOUHLQVWDOOWKHWKURWWOHDUP
TOpen and close the carburetor several times to ensure that the pushrod
wire does not bind.
STEP 3: INSTALLING THE ADJUSTABLE PUSHROD CONNECTOR
IMPORTANT7RSUHYHQWWKHQXWIURPORRVHQLQJGXULQJÀLJKWDSSO\DGURSRIWKLQ&$WRLW
TCut away all but one arm from a "4-point" servo horn, then enlarge the hole
in the servo arm that is 5/8" (16mm) out from the centre of the servo horn, using
a 5/64" (2mm) diameter drill bit.
TInstall the adjustable pushrod connector onto the servo arm, making sure
not to tighten the nut too tightly. You don't want the pushrod connector loose,
but it should be able to rotate without binding.
1-1/4" (32mm)
5-1/8" (130mm)
1/2"
(13mm)
STEP 3: INSTALLING THE NOSE SKID
TTemporarily place one nylon mounting bracket onto the horizontal section
of the nose skid.
TCut one tab off of one nylon mounting bracket and place it over the vertical
section of the nose skid, with the remaining mounting tab toward the centre of
the nose skid.
T 3ODFHWKHQRVHVNLGRQWRWKH¿UHZDOODQGDOLJQLW7KHHGJHRIWKHKRUL]RQWDO
nylon mounting bracket (A) should be even with the bottom of the fuselage and
the edge of the vertical nylon mounting bracket (B) should be 1/4" (6mm) in from
the fuselage side.
T :KHQVDWLV¿HGZLWKWKHDOLJQPHQWPDUNWKHORFDWLRQVRIWKHWKUHHPRXQWLQJ
KROHVRQWRWKH¿UHZDOO
T 'ULOOWKUHHPPGLDPHWHUSLORWKROHVWKURXJKWKH¿UHZDOODWWKHPDUNV
you drew, then install the two nylon mounting brackets, using three M3 x 12mm
wood screws, to hold the nose skid in place.
TInstall the remaining nylon mounting bracket, using two M3 x 12mm wood
screws to secure the nose skid to the bottom of the fuselage. Again, make sure
to drill two 5/64" (2mm) pilot holes through the fuselage for the wood screws.
T5 Minute Epoxy
T# 2 Phillips Head Screwdriver
TStraight Edge Ruler
TPaper Towels
T(1) Plywood Motor Mounting Box
T(4) Balsa Triangle Supports
T(4) M3 x 16mm Machine Screws
T(4) M3 Blind Nuts
T(4) M3 Flat Washers
TRubbing Alcohol
TEpoxy Mixing Sticks
TEpoxy Mixing Cups
MOTOR INSTALLATION - ELECTRIC VERSION
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
IMPORTANT This section details the installation of a brushless outrunner electric motor. If you will be using a glow engine, please
skip to the Engine Installation - Glow Version section on page 21.
A
B
Page 20 Page 25
TInstall the propeller adapter (included with your motor) onto your brushless
outrunner motor, following the procedures in your motor's user guide.
TInstall the backplate mount (included with your motor) onto your brushless
outrunner motor, following the procedures in your motor's user guide.
STEP 1: INSTALLING YOUR MOTOR MOUNT AND PROPELLER ADAPTER
IMPORTANT Two sets of motor mounting holes are predrilled through the motor mounting box. One set is for a four-hole radial
backplate mount and one set is for mounting directly into the back of the motor. If your motor or its backplate mount uses a different
mounting hole pattern, you will need to drill new mounting holes through the motor mounting box to match.
TInstall your motor to the motor mounting box, using four M3 x 16mm machine
VFUHZV IRXU 0 ÀDW ZDVKHUV DQG IRXU 0 EOLQG QXWV 7LJKWHQ WKH PDFKLQH
VFUHZV¿UPO\WRGUDZWKHEOLQGQXWVLQWRWKHEDFNRIWKHPRWRUPRXQWLQJER[
STEP 2: INSTALLING THE MOTOR
STEP 3: INSTALLING THE MOTOR MOUNTING BOX ASSEMBLY
TTemporarily install the propeller onto your motor.
TTo ensure that the cowling will line up properly with the crankshaft, the back
edge of the propeller (at the hub) should be 4-1/2" (114mm) in front of the back
edge of the motor mounting box. If the distance is shorter you will need to install
a shim behind the motor to space it to the correct distance.
T 7HVW¿WDQGJOXHWKHPRWRUPRXQWLQJER[DVVHPEO\RQWRWKH¿UHZDOOXVLQJ
a generous amount of 5 minute epoxy.
IMPORTANT The motor mounting box assembly should be installed with
WKH ÀDQJHV KRUL]RQWDO DV VKRZQ 7KLV ZLOO HQVXUH WKDW WKH QRVH VNLG
mounting brackets don't interfere with the motor mounting box.
STEP 3: INSTALLING THE FUEL TANK
TCut two pieces of silicone fuel tubing (not included) to a length of 4" (102mm)
and install them to the aluminium tubes at the front of the fuel tank.
PRO TIP Mark the ends of the silicone tubing "vent" and "pick-up" so you
don't confuse them when it comes time to connect them to the engine
later on.
TCut out a piece of 1/4" (6mm) thick foam rubber and place it on top of the fuel tank mounting platform in the fuselage.
T )HHGWKHHQGVRIWKHIXHOWXELQJWKURXJKWKHSUHGULOOHGKROHLQWKH¿UHZDOO
and slide the fuel tank into position, making sure that the stopper assembly
OLQHVXSZLWKDQGLV¿UPO\SXVKHGLQWRWKHSUHGULOOHGKROHLQWKH¿UHZDOO
TGlue one scrap piece of balsa or light plywood directly above the fuel tank
and directly behind the fuel tank to hold the fuel tank securely in place.
IMPORTANT When you install the fuel tank in the next procedure, make sure that the top of the fuel tank is toward the top of
the fuselage.
TThin C/A
T# 1 Phillips Head Screwdriver
TWire Cutters
TNeedle Nose Pliers
TModeling Knife
T(1) 11-1/2" (292mm) Pushrod Wire with Z-Bend T(1) Adjustable Pushrod Connector with Nut and Machine Screw
TElectric Drill
T1/16" (1.6mm), 5/64" (2mm) and 5/32" (4mm) Drill Bits
TStraight Edge Ruler
TPencil
THROTTLE CONTROL SYSTEM INSTALLATION - GLOW VERSION
YOU'LL NEED THE FOLLOWING PARTS FROM THE KIT:
YOU'LL NEED THE FOLLOWING TOOLS AND SUPPLIES:
IMPORTANT This section details the installation of the throttle control system for a glow engine. If you are using a brushless
outrunner electric motor, please skip to the Elevator Control System Installation section on page 27.
STEP 1: INSTALLING THE THROTTLE SERVO
T ,QVWDOOWKHUXEEHUJURPPHWVDQGEUDVVFROOHWVRQWR\RXUWKURWWOHVHUYRPDNLQJVXUHWRLQVWDOOWKHFROOHWVZLWKWKHÀDQJHVWRZDUGWKH
bottom of the servo.
TInstall the throttle servo into the centre of the plywood servo tray, making sure
to drill 1/16" (1.6mm) diameter pilot holes for the servo mounting screws.
IMPORTANT Note the orientation of the servo. When installed, the servo
output shaft should be toward the back of the fuselage.
