Modena BI 1625 F Owner's manual

User
Manual Book
Built-In Induction Hob
BI 1625 F

2
Table of Contents
Part 1: Safety Warnings 4
Electrical Shock Hazard And Cut Hazard 4
Important Safety Instructions 4
Operation And Maintenance Electrical Shock Hazard 5
Electrical Shock Hazard 5
Health Hazard 5
Hot Surface And Cut Hazard 5
Important Safety Instructions 6
Part 2: Name Of Parts 8
Part 3: Installation 9
Before Locating The Fixing Brackets 10
Easy Fit Kits 10
Fix Clips To Hob 11
Fix Hob To Cabinet 11
Installing The Induction Cooker On Kitchen Set Table 11
Connecting The Hob To The Main Power Supply 12
Installing The Electric Cooker On Kitchen Set Table 13
Part 4: How To Use 15
Before Using Your New Hob 15
Using The Touch Controls 15
Choosing The Right Cook Ware 15
To Start Cooking 16
To Turn Hob Off 18
Beware Of Hot Surfaces 18
Using Booster Function –Induction Hob 18
Flexible Areas-Induction Hob 19

3
Activate The Flexible Induction Area 20
Inactivate The Flexible Induction Area 20
Child Lock Safety Control 20
To Lock The Controls 20
To Unlock The Controls 20
Stop & Go Function 21
Activate Stop & Go Function 21
Deactivate Stop & Go Function 22
Using The Timer 22
Time Overview 22
Setting The Timer To Turn Cooking Zone Off 24
Detection Of Pan And Small Articles 25
Residual Heat Warning 26
Auto Shutdown 26
Over-Heat Protection 26
Over-Flow Protection 26
Cooking Guidelines 26
Cooking Tips 26
Simmering, Cooking Rice 27
Searing Steak 27
For Stir-Frying 28
Heat Settings 28
Part 5: Maintenance 29
Part 6: Troubleshooting 30
Part 7: Specification 33

4
Safety Warnings
Your safety is important to us. Please read below information carefully
before installing or using your Hob.
Electrical Shock Hazard And Cut Hazard
•Disconnect the appliance from the mains electricity supply before
carrying out any work or maintenance on it.
•Connection to a good earth wiring system is essential and
mandatory.
•Alterations to the domestic wiring system must only be made by
MODENA Technician.
•Failure to follow this advice may result in electrical shock or death.
•Take care - panel edges are sharp.
•Failure to use caution could result in injury or cuts.
Important Safety Instructions
•No combustible material or products should be placed on the
appliance at any time.
•In order to avoid a hazard, this appliance must be installed according
to these instructions for installation.
•This appliance is to be properly installed and earthed only by
MODENA Technician. By contact MODENA Customer Service.
•This appliance should be connected to a circuit which incorporates
an isolating switch providing full disconnection from the power
supply.
•Failure to install the appliance correctly could invalidate any
warranty or liability claims.
PART 1: SAFETY WARNINGS

5
Operation And Maintenance Electrical Shock Hazard
Electric cooker MODENA is specifically designed for long-term use so it
does not require complex maintenance. However, there are some
things that are recommended to treat your electric stove so that the
quality of the stove is maintained.
Electrical Shock Hazard
•Do not cook on a broken or cracked hob. If the hob surface should
break or crack, switch the appliance off immediately at the mains
power supply (wall switch) and contact MODENA technician.
•Switch the hob off at the wall before cleaning or maintenance.
•Failure to follow this advice may result in electrical shock or death.
Health Hazard
•This appliance complies with electromagnetic safety standards.
•However, persons with cardiac pacemakers or other electrical
implants (such as insulin pumps) must consult with their doctor or
implant manufacturer before using this appliance to make sure that
their implants will not be affected by the electromagnetic field.
•Failure to follow this advice may result in death.
Hot Surface And Cut Hazard
•During use, accessible parts of this appliance will become hot
enough to cause burns.
•Do not let your body, clothing or any item other than suitable
cookware contact the ceramic glass until the surface is cool.
•Beware: Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they can get hot.
•Keep children away.
•Handles of saucepans may be hot to touch. Check saucepan handle
do not overhang other cooking zones that are on. Keep handles out
of reach of children.
•Failure to follow this advice could result in burns and scalds.

6
•The razor-sharp blade of a hob scraper is exposed when the safety
cover is retracted. Use with extreme care and always store safely
and out of reach of children.
•Failure to use caution could result in injury or cuts.
Important Safety Instructions
•Never leave the appliance unattended when in use. Boil over causes
smoking and greasy spillovers that may ignite.
•Never use your appliance as a work or storage surface.
•Never leave any objects or utensils on the appliance.
•Do not place or leave any magnet sable objects (e.g. credit cards,
memory cards) or electronic devices (e.g. computers, MP3 players)
near the appliance, as they may be affected by its electromagnetic
field.
•Never use your appliance for warming or heating the room.
•After use, always turn off the cooking zones and the hob as
described in this manual (i.e. by using the touch controls). Do not
rely on the pan detection feature to turn off the cooking zones when
you remove the pans.
•Do not allow children to play with the appliance or sit, stand, or climb
on it.
•Do not store items of interest to children in cabinets above the hob.
Children climbing on the hob could be seriously injured.
•Do not leave children alone or unattended in the area where the
appliance is in use.
•Do not repair or replace any part of the appliance unless specifically
recommended in the manual. All other service should be done by
MODENA technician.
•Do not use steam cleaner to clean hob.
•Do not place or drop heavy objects on hob.
•Do not stand on your hob.

7
•Do not use pans with jagged edges or drag pans across the ceramic
glass surface as this can scratch the glass.
•Do not use scourers or any other harsh abrasive cleaning agents for
cleaning, as these can scratch the ceramic glass.
•If the power supply cable is damaged, it must only be replaced by
MODENA technician.
•This appliance is intended to be used in household and similar
applications such as: -staff kitchen areas in shops, offices and other
working environments; -farm houses; -by clients in hotels, motels
and other residential type environments; -bed and breakfast type
environments.
•This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
WARNING!
Unattended cooking on a hob with fat or oil can be dangerous and
may result in fire. Never try to extinguish a fire with water, but
switch off the appliance and then cover flame e.g. with a lid or a
fire blanket.

8
BI 1625 F
Control Panel
PART 2: NAME OF PARTS
1. 1500W boost 2000W Cooking Zone
2. 2000W boost 2600W Cooking Zone
3. 3000W boost 3600W Flexi area-Left
4. 2000W boost 2600W Cooking Zone
5. 1500W boost 2000W Cooking Zone
6. 3000W boost 3600W Flexi area-Right
7. Glass plate
8. Control panel
1. Cooking Zone selection button
2. Booster function control
3. Stop & Go control button
4. Timer control button
5/6. Left/Right Flexi zone control button
7. Heating level/Timer slider control
8. Child Lock control button
9. ON/OFF button

9
• Cut out the work surface according to the sizes shown in the
drawing.
• For the purpose of installation and use, a minimum of 5 cm space
shall be preserved around the hole.
• Be sure the thickness of the work surface is at least 30mm. Please
select heat-resistant work surface material to avoid larger
deformation caused by the heat radiation from the hotplate. As
shown below:
Model
L
(mm)
W
(mm)
H
(mm)
D
(mm)
A
(mm)
B
(mm)
X
(mm)
BI 1625 F
590
520
56
52
555+5-0
495+5-0
50
min
PART 3: INSTALLATION
NOTE:
The safety distance between the hotplate and the cupboard above
the hotplate should be at least 760mm.
he safety distance between the hotplate and the cupboard
above the hotplate should be at least 760mm.

10
Before Locating The Fixing Brackets
The unit should be placed on a stable, smooth surface (use the
packaging). Do not apply force on to the controls protruding from the
hob.
Easy Fit kits
There is one easy fit kits package for each hob, include fixing clips and
screws (for ceramic hob there are total 2 pcs clip and 2 pcs screw, for
induction hob there are total 4pcs clip and 4pcs screw). Find the easy
fit kit package first.
A (mm)
B (mm)
C (mm)
D
E
760 mm
50 mm minimal
20 mm minimal
Air Intake
Air exit 5 mm
ATTENTION
•If the induction cooker is installed with an oven below it,
separator panel must be placed between the bottom of the
stove and the frame below it at a minimum distance of 10 cm.
•If the induction cooker is installed without oven on the bottom,
the minimum distances to put the separator pan
•Electrical cable from both equipments must be installed
separately to avoid short circuit.

11
Fix Clips To Hob:
Insert the fixing clips into fixing holes reserved on 2 sides of housing,
fix clip to housing with screw, then insert hob into cabinet/work surface.
Fix Hob To Cabinet
Insert the hob into the cabinet/work surface as below diagrams, the
mounted clips on the sides can secure your hob sturdily.
Installing the Induction Cooker on Kitchen Set Table
To install an induction cooker on the
kitchen counter niche, follow these
instructions:
The cable is directly plugged into a power
supply through a circuit breaker.

12
Post the seal adhesive along the sides of
the stove's bottom part to maintain
humidity in the bottom area of the
induction cooker.
Place the induction cooker on the kitchen
counter niche, and use the available clamp
from the induction cooker packaging to
fasten the screws.
Make sure all parts have been installed
and fastened and plug the stove power
cord into the power outlet.
Connecting The Hob To The Main Power Supply
The power supply should be connected incompliance with the relevant
standard,or a single-pole circuit breaker. The appliance has a large
power rating and must be connected to electricity by MODENA
Technician.
ATTENTION:
Do not use a power plug, if it is branched/paralleled with other
appliances.

13
Installing The Electric Cooker On Kitchen Set Table
The connection method shown below:
NOTES:
•If the cable is damaged or needs replacement, this should be
done by MODENA technician using the proper tools, so as to
avoid any accidents.
•If the appliance is being connected directly to the mains
supply, an omnipolar circuit breaker must be installed with a
minimum gap of 3mm between the contacts.
•The installer must ensure that the correct electrical connection
has been made and that it complies with safety regulations.
•The cable must not be bent or compressed.
•The cable must be checked regularly and only replaced by
MODENA technician.

14
CAUTION:
1. The hob must be installed by MODENA technicians. Please never
conduct the operation by yourself.
2. The electric hob shall not be mounted to cooling equipment,
dishwashers and rotary dryers.
3. The electric hob shall be installed such that better heat radiation
can be ensured to enhance its reliability.
4. The wall and induced heating zone above the work surface shall
with stand heat.
5. To avoid any damage, the sandwich layer and adhesive must be
heat resistant.
6. A steam cleaner is not to be used.
7. This electric hob can be connected only to a supply with system
impedance no more than 0.427 ohm. In case necessary, please
consult your supply authority for system impedance information.

15
Before Using Your New Hob
• Read this guide, taking special note of the Safety Warning section.
• Remove any protective film that may still be on your new electric
hob.
Using The Touch Controls
• The controls respond to touch, so you don’t need to apply any
pressure.
• Use the ball of your finger, not its tip.
• You will hear a beep each time a touch is registered.
• Make sure the controls are always clean, dry, and that there is no
object (e.g. a utensil or a cloth) covering them. Even a thin film of
water may make the controls difficult to operate
Choosing The Right Cook Ware
•Only use cookware with a base suitable for induction cooking. Look
for the induction symbol on the packaging or on the bottom of the
pan
•You can check whether your cookware is suitable by carrying out a
magnet test. Move a magnet towards the base of the pan. If it is
attracted, the pan is suitable for induction hob.
•If you do not have a magnet:
1. Put some water in the pan you want to check.
2. If does not flash in the display and the water is heating, the pan
is suitable.
•Cookware made from the following materials is not suitable for an
induction hob: pure stainless steel, aluminum or copper without a
magnetic base, glass, wood, porcelain, ceramic, and earthen ware.
PART 4: HOW TO USE

16
•Induction hob are made from smooth, ceramic glass, the heat comes
from a magnetic induction coil which heats the cook ware but not
the cooking surface. The heat from the cook ware is transfer red to
the food.
•It’s important that you use only metal pans specifically designed
and/or approved for use on induction hobs.
•Never allow melamine or plastic containers to come in contact with
the heat zones
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the
glass, and is the same size as the cooking zone. If you use smaller pot
efficiency could be less than expected. Always centre your pan on the
cooking zone.
Always lift pans off the electric hob –do not slide, or they may scratch
the glass.
To Start Cooking
1. After the hob be connected to electricity and power
on Press and hold the ON/OFF control button for
about 3 seconds till you hear a “beep” to turn the
hob on. Now the hob enters into Standby mode, all

17
heat setting indicators and Timer setting indicators
shows “-”.
2. Place a suitable pan on the cooking zone you wish
to use. Make sure the bottom of the pan and the
surface of the cooking zone are clean and dry.
3. Set heating level of cooking zone Before adjust
heating level, need to touching the heating zone
selection control button to select and active the
cooking zone you wish to use. The heat setting
indicator of the selected zone flashing when be
active, then you could adjust its heat level by below:
-Slider touch control control model
Adjust heat setting by sliding the slider control.
CAUTIONS:
•After connecting to electricity, when power on, the buzzer of
hob beeps once, all indicators lights up for 1 second then off.
•You can modify the heat setting at any time during cooking. The
heating element will turn off under power level 0, with indicator
shows “-”
•The heat setting indicator of the selected zone will flash when
adjusting. After adjusting, the number in indicator will flash for
5 seconds and then stop flash, then the setting has been
confirmed.
•When the hob is in Standby mode, if there is no actions within 1
minute, the electric hob will auto turn off, with buzzer beeps
once.

18
To Turn Hob Off
1. You can turn the cooking zone off by adjust heat
setting to level 0, which indicator shows“-“.
2. You can also turn the whole hob off by touching the
ON/OFF control button.
Beware Of Hot Surfaces
After turn off, the will show in the power setting indicator if cooking
zone is hot to touch. It will disappear when the surface has cooled down
to a safe temperature. When in Standby mode, if the surface of cooking
zone is hot to touch, the letter “H” and “-” will show in its heat setting
indicator alternately.
Using Booster Function –Induction Hob
For induction hob models which with Booster function, you can use the
“Booster” function to boost power of relevant cooking zone for a
maximum power rating for 5 minutes. This function could reduce the
cooking time, which convenience for cooking when in hurry!
To use booster function when induction hob is working, follows below:
1. Turn on the hob by touch ON / OFF control button.
NOTES:
•If there is power outage during cooking, all programmed settings
will be cancelled, you need to reset the programme again.
•The cooling fan of induction hob will remain on for about 1
minute after the hob is turned off.

19
2. Touch the Booster function control button, the heating
zone indicator will show b and flashing for 5 seconds
then stop flashing. Then Booster function is activated,
the power reach Maximum strength for 5 minutes, and
then return to the pre-set heat setting.
3. To turn off Booster function:
•When in Booster function, touch the “Booster” control button
again, you can deactivate Booster fuction.
•You can also cancel Booster function by adjusting power level
setting.
Flexible Areas-Induction Hob
Some of models might have one or several Flexible cooking areas.
These Flexible cooking areas can each be used as a single zone or as
two independent zones, accordingly to the cooking needs anytime.
Flexible areas are each made of two independent inductors that can be
controlled separately. When working as a single zone, a cookware is
moved from one zone to the other one within the flexible area keeping
the same power level of the zone where the cookware originally was
placed, and the part that is not covered by cookware is automatically
switched off.
NOTES:
After booster finish, the cooking zone will return to previously
power level setting before booster.
NOTES:
Make sure to place the cookwares centered on the single cooking
zone. In case of big pot,oval,rectangular and elon- gated pans make
sure to place the pans centered on the cooking zone covering both
cross.

20
Activate The Flexible Induction Area
To activate a flexible area as a single big zone, first press either of the
two cooking zone selection buttons of this flexible area, then press the
flexible area control button. When flexible area works, the indicator
above corresponding flexible area control button lighting, the power
level indicator flashing, you can adjust power level of the flexible area
by slide the slider.
Inactivate The Flexible Induction Area
inactivate the flexible area when it works, press either of the two
cooking zone selection buttons of this flexible area, when power level
indicator flashing, press the flexible control button again. The indicator
will off after inactive it.
Child Lock Safety Control
• You can lock the controls to prevent unintended use (for example
children accidentally turning the cooking zones on) by active Child
Lock function.
• When the controls are locked, except the ON/OFF control button and
Child Lock control button, all other touch control buttons are
disabled.
To Lock The Controls
Touch the Child Lock control button once. The timer indicator will
show “Lo“, and Child Lock function is activated.
To Unlock The Controls
1. Make sure the electric hob is turned on.
