This guide book explains everything you need to know about your new
product. Please contact our Customer Care should you need further
assistance through www.modena.com

3
Your safety is important to us. Please read the following information
carefully before installing or using your Hob
Electrical Shock Hazard
•Disconnect the appliance from the electricity supply before carrying
out any work or maintenance on it.
•Make sure that grounding system is installed properly.
•Alterations to the domestic wiring system must only be made by
MODENA Technician.
•Failure to follow this advice may result in electrical shock or death.
Cut Hazard
•Take care - panel edges are sharp.
•Failure to be cautious could result in injury or cuts.
Operation and Maintenance
•Electrical Shock Hazard
•Do not cook on a broken or cracked hob. If the hob surface break or
crack, switch the appliance off immediately at the mains power
supply (wall switch) and contact MODENA technician.
•Switch the hob off at the wall before cleaning or maintenance.
•Failure to follow this advice may result in electrical shock or death.
Health Hazard
•This appliance complies with electromagnetic safety standards.
•However, persons with cardiac pacemakers or other electrical
implants (such as insulin pumps) must consult with their doctor or
implant manufacturer before using this appliance to make sure that
their implants will not be affected by the electromagnetic field.
•Failure to follow this advice may result in death.
PART 1 : SAFETY WARNINGS

4
Hot Surface Hazard
•During usage, accessible parts of this appliance will become hot
enough to cause burns.
•Do not let your body, clothing or any item other than suitable
cookware contact the ceramic glass until the surface is cooled
down.
•Keep children away from the appliance.
•Handles of saucepans may be hot to touch. Check saucepan
handles, do not overhang other cooking zones that are on. Keep
handles out of reach of children.
•Failure to follow this advice could result in burns and scalds.
Important Safety Instructions
•No combustible material or products should be placed on the
appliance at any time.
•In order to avoid a hazard, this appliance must be installed according
to these instructions for installation.
•This appliance is to be properly installed and grounded only by
MODENA Technician by contacting MODENA Customer Service.
•This appliance should be connected to a circuit which incorporates
an isolating switch providing full disconnection from the power
supply.
•Failure to install the appliance correctly could invalidate any
warranty or liability claims.
•Never leave the appliance unattended when in use. Boil over causes
smoke and greasy spillovers may ignite fire.
•Never use your appliance as a work or storage surface.
•Never leave any objects or utensils on the appliance.
•Do not place or leave any magnetisable objects (e.g. credit cards,
memory cards) or electronic devices (e.g. computers, MP3 players)
near the appliance, as they may be affected by its electromagnetic
field.
•Never use your appliance for warming or heating the room.
•After use, always turn off the cooking zones and the hob as
described in this manual (i.e. by using the touch controls). Do not
rely on the pan detection feature to turn off the cooking zones when
you remove the pans.
•Do not allow children to play with the appliance or sit, stand, or climb
on it.

5
•Do not store items of interest to children in cabinets above the hob.
Children climbing on the hob could be seriously injured.
•Do not leave children alone or unattended in the area where the
appliance is in use.
•Do not repair or replace any part of the appliance unless specifically
recommended in the manual. All other repairing process should be
done by MODENA technician.
•Do not use steam cleaner to clean hob.
•Do not place or drop heavy objects on hob.
•Do not stand on your hob.
•Do not use pans with jagged edges or drag pans across the ceramic
glass surface as this may scratch the glass.
•Do not use scourers or any other harsh abrasive cleaning agents for
cleaning, as these can scratch the ceramic glass.
•If the power supply cable is damaged, it must only be replaced by
MODENA technician.
•This appliance is intended to be used in household and similar
applications such as: staff kitchen areas in shops, offices and other
working environments; farm houses; by clients in hotels, motels and
other residential type environments; bed and breakfast type
environments.
•This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be done
by children without supervision.
NOTES :
• Unattended cooking on a hob with fat or oil can be dangerous
and may result in fire. NEVER try to extinguish fire with water,
but switch off the appliance and then cover flame with a lid
or a fire blanket.
• The appliance is not intended to be operated by means of an
external timer or separate remote-control system.

6
BM 8722 AABK
1. Induction Zone 2000 W
2. Burner
3. Pan Support
4. Knob
5. Control Panel for Induction Zone
•The image is a general overview and is not necessarily the same as
the product you receive. Features and completeness depends on
the type of products
PART 2 : NAME OF PARTS

7
The appliance must be installed and connected in accordance with
current regulations.
After unpacking the appliance, ensure there is no visible damage. If it
has been damaged during transit, DO NOT USE, contact where you buy
immediately.
Please contact MODENA Call Center for instalation
Selecting Installation Equipment
•Cut out the work surface according to the measurements shown in
the picture.
•For the purpose of installation and use, a space minimum of 5 cm
shall be preserved around the hole.
•Be sure the thickness of the work surface is at least 30mm. Please
select heat-resistant work surface material to avoid larger
deformation caused by the heat radiation from the hotplate. As
shown below:
Model
L (mm)
W (mm)
A (mm)
B (mm)
BM 8722 AABK
730
420
670
370
•If the cooker is installed with an oven below it, separator panel must
be placed between the bottom of the stove and the frame below it
at a minimum distance of 10 cm.
•If the induction cooker is installed without oven on the bottom, the
minimum distances to put the separator panel is 15 cm.
PART 3 : INSTALLATION

8
•Electrical cable from both equipments must be installed separately
to avoid short circuit.
Make sure the appliance has good air ventilation, not tightly closed.
And make sure the device is working properly. As in the image below :
A ( mm )
B ( mm )
C ( mm )
D
E ( mm )
760
50 ( Minimum )
20 ( minimum )
Air Intake
Air Exit ( 5 )
CATATAN:
The Safety distance between the appliance and the kitchen
cupboard above the appliance ( A ) is at least 760 mm

9
Installing the Induction Cooker on Kitchen Set Table
To install an induction cooker on the kitchen counter niche, follow these
instructions:
•The cable is directly plugged into a power supply through a circuit
breaker.
•Post the seal adhesive along the sides of the stove's bottom part to
maintain humidity in the bottom area of the induction cooker.
Connecting the Hob to the Power Supply
•If the cable is damaged or needs replacement, this should be done
by MODENA technician using the proper tools, so as to avoid any
accidents.
•If the appliance is being connected directly to the mains supply, an
omnipolar circuit breaker must be installed with a minimum gap of
3mm between the contacts.
•The installer must ensure that the correct electrical connection has
been made and that it complies with safety regulations.
•The cable must not be bent or compressed.
ATTENTION :
Do not use a power plug, if it is branched/paralleled with other
appliances.

10
•The cable must be checked regularly and only replaced by MODENA
technician
•The hob must be installed by MODENA technicians. Please never
conduct the operation by yourself.
•The electric hob shall not be mounted next to to cooling equipment,
dishwashers and tumble dryers.
•The electric hob shall be installed properly to ensure better heat
radiation and enhance its reliability.
•The wall and induced heating zone above the work surface shall
withstand heat.
•To avoid any damage, the sandwich layer and adhesive must be
heat resistant.
•Do not use steam cleaners.
Before Using Your New Hob
•Read this guide, taking special note on the ‘Safety Warnings’ section.
•Remove any protective film that may still be on your new electric
hob.
Using the Touch Controls
•The controls respond to touch, so you don’t need to apply any
pressure.
•Use the ball of your finger, not its tip.
•You will hear a beep each time a touch is registered.
•Make sure the controls are always clean, dry, and that there is no
object (e.g. a utensil or a cloth) covering them. Even a thin film of
water may make the controls difficult to operate.
PART 4: HOW TO USE

11
Choosing the Right Cookware
Only use cookware with a base suitable for induction cooking. Look for
the induction symbol on the packaging or on the bottom of the pan.
•You can check whether your cookware is suitable by carrying out a
magnet test. Move a magnet towards the base of the pan. If it is
attracted, the pan is suitable for induction hob.
•If you do not have a magnet:
1. Put some water in the pan you want to check.
2. If does not flash in the display and the water is heating, the
pan is suitable.
•Cookware made from the following materials is not suitable for an
induction hob: pure stainless steel, aluminium or copper without a
magnetic base, glass, wood, porcelain, ceramic, and earthenware.
•Induction hob are made from smooth, ceramic glass, the heat comes
from a magnetic induction coil which heats the cookware but not the
cooking surface. The heat from the cookware is transferred to the
food.
It’s important that you use only metal pans specifically designed and/or
approved for use on induction hobs. Never allow melamine or plastic
containers to come in contact with the heat zones
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass,
and is the same size as the cooking zone. If you use smaller pot
efficiency could be less than expected. Always centre your pan on the
cooking zone.
Always lift pans off the electric hob–do not slide, or they may scratch
the glass.

12
To Start Cooking
1. After the hob be connected to electricity and power on.
Press and hold the ON / OFF control button for about 1-3 seconds
until you hear a “beep” to turn the hob on.
2. The hob enters Standby mode, all heat setting indicators and Timer
setting indicators shows “-ON-”.
3. Place a suitable pan on the cooking zone that you
wish to use.
Make sure the bottom of the pan and the surface of
the cooking zone are clean and dry.
4. Set heating level of cooking zone
You can adjust heat setting by touching “ + “ or “ –“
Turn Off Induction Hob
You can turn off by touching ON / OFF button.

13
Beware of Hot Surfaces
After turn off, the letter will show in the power setting indicator if
cooking zone is hot to touch. It will disappear when the surface has
cooled down to a safe temperature.
Using Booster Function on Induction Hob
For induction hob models which with Booster function, you can use the
“Booster” function to boost power of relevant cooking zone for a
maximum power rating for 5 minutes. This function could reduce the
cooking time, which convenience for cooking when in hurry!
To use booster function when induction hob is working, follows below:
1. Turn on the hob by touch ON / OFF control button.
2. Touch the Booster function control button ,
the heating zone indicator will show “ b ” .Then
Booster function is activated, the power reach
Maximum strength for 5 minutes, and then return to
the pre-set heat setting.
3. To turn off Booster function:
4. When in Booster function, touch the “Booster” control button again,
you can deactivate Booster fuction
NOTES :
• If there is power outage during cooking, all programmed
settings will be cancelled, you need to reset the programme
again.
• The cooling fan of induction hob will remain on for several
minutes after the hob is turned off.
NOTES:
This can also be used as an energy saving function: if you want to
heat further pans, use the hotplate that is still hot.

14
Child Lock
•You can lock the controls to prevent unintended use (for example
children accidentally turning the cooking zones on) by activate Child
Lock function.
•When the controls are locked, all other touch control buttons will be
disabled except the ON/OFF control button and Child Lock control
button.
To lock the controls
Touch the Child Lock control button once . The timer indicator will
show “Lo“, and Child Lock function is activated.
To unlock the controls
1. Make sure the electric hob is turned on.
2. Touch and hold the Child Lock control button for several
seconds, the buzzer beeps once and “ - Lo - ” disappears in timer
indicator, the Child Lock is deactivated. You can now start using your
electric hob.
Stop & Go Function
•Make cooking easy! When cooking, your doorbell rings, phone rings,
or kid shouts from another door. Need to step out of kitchen? These
WARNING:
Under the child lock mode, all controls button are disabled except
the ON/OFF and child lock .
NOTES:
After booster finish, the cooking zone will return to previously
power level setting before booster.

15
means dinner could burn, or take longer time to ready if you switch
everything off.
•The Stop & Go function can turn off all zones. When you back, with
touching of the button once more , hob restarts where they were,
to continue cooking.
Activate Stop & Go function
To activate Stop & Go function, you can press the Stop & Go function
button once. Then all programmed setting be hold on and hob stop
heating, indicators will show ” - ǁ - “ on display
Deactivate Stop & Go function
To cancel Stop & Go function, you can press the Stop & Go function
again, after come back. Then all programmer setting will return to what
they were, Stop & Go indicator ” - ǁ - “ disappear from display.
Using Timer
When the hob is turned on, you can set the timer up to 240 menit.
To Set The Timer:
•Touch the button to set the timer. And then touch the plus
icon and minus icon to set the cooking timer.
•When the minute minder is set, it will begin to count down
immediately, the display will show the remaining time.
Detection of Pan and Small Articles
For induction hob, if the display flashes “ ” in heat setting indicator, it
means that:
• you have not placed a pan on the correct cooking zone, or
• the pan you’re using is not suitable for induction cooking, or
• the pan is too small or not properly centered on the cooking zone.

16
Residual Heat Warning
When the hob has been operated for some time, there will be
some residual heat. The letter “ H ”appears to warn you to keep
away from it.
Over – Heat Protection
The equipped temperature sensor can monitor the temperature inside
the hob. When an excessive temperature is sensed, the hob will stop
the operation automatically.
Cooking Guidelines
Cooking Tips
•When food comes to the boil, reduce the power setting.
•Using a lid will reduce cooking times and save energy by retaining
the heat.
•Minimize the amount of liquid or fat to reduce cooking times.
•Start cooking on a high setting and reduce the setting when the food
has heated through.
Simmering, cooking rice
•Simmering occurs below boiling point, at around 85˚C, when bubbles
are just rising occasionally to the surface of the cooking liquid. It is
the key to delicious soups and tender stews because flavors develop
without overcooking the food. You should also cook egg-based and
flour thickened sauces below boiling point.
•Some tasks, including cooking rice by the absorption method, may
require a setting higher than the lowest setting to ensure the food is
cooked properly in the time recommended.
Searing steak
To cook juicy flavorsome steaks:
•Stand the meat at room temperature for about 20 minutes before
cooking.
•Heat up a heavy-based frying pan.
•Brush both sides of the steak with oil. Drizzle a small amount of oil
into the hot pan and then lower the meat onto the hot pan.

17
•Only turn the steak once during cooking. The exact cooking time will
depend on the thickness of the steak and doneness. Times may vary
from about 2 – 8 minutes per side. Press the steak to check how
cooked it is – the firmer it feels the more ‘well done’ it will be.
•Leave the steak to rest on a warm plate for a few minutes to allow it
to relax and become tender before serving.
For stir-frying
•Please use compatible cookware for induction hob
•Have all the ingredients and equipment ready. Stir-frying should be
quick. If cooking large quantities, cook the food in several smaller
batches.
•Preheat the pan briefly and add two tablespoons of oil.
•Cook any meat first, put it aside and keep it warm.
•Stir-fry the vegetables. When they are hot but still crisp, turn the
cooking zone to a lower setting, return the meat to the pan and add
your sauce.
•Stir the ingredients gently to make sure they are heated through.
•Serve immediately.
Heat Settings
The settings below for induction hob are guidelines only. The exact
setting will depend on factors including your cookware and the amount
of food you are cooking. Experiment with the induction hob to find the
settings that suit you best.

18
Heat setting Suitability
1 - 2
•delicate warming for small amounts of
food
•melting chocolate, butter, and foods that
burn quickly
•gentle simmering
•
slow warming
3 - 4
•reheating
•rapid simmering
•cooking rice
5 - 6
•
pancakes
7 - 8 •sautéing
•cooking pasta
9
•stir-frying
•searing
•bringing soup to the boil
•boiling water

19
BM 8722 AABK
How to using Induction Hob
Display
Description
Details
Booster
Press the Booster to turn on booster mode for
maximum 5 minutes and “
” will show on
display, Power level will resume to normal power
level after 5 minutes.
Child Lock
•Tekan tombol child lock untuk mengaktifkan
fitur child lock
•
Press the Child Lock Button to activate Child
Lock mode.
•
All on button ( except On / Off ) button will be
disabled.
•
Press and hold Child Lock button to non active
Child Lock Mode.
Stop & Go
•Press Stop & Go button to stop induction hob
program.
•
Press Stop & Go button again to resume
cooking process
Minus To decrease power level and timer.
Plus To increase power level and timer.
Program In stand by mode, press
to set the heating
power.
Timer
•Set the timer by pressing the timer button,
“0:00” will shown by default
•Press or to adjust the time you want.
•Can set timer 4 hours ( 240 Minutes )

20
•Timer will stop start automatically after 5
seconds and timer will stop blinking.
•
Timer dapat di atur sampai 4 jam ( 240 menit )
•
Timer will start automatically after 5 seconds
and timer will stop blinking.
•For Reset timer, just press the or
when
the display is showing time set.
•
To cancel timer, press and hold the timer
button.
On / Off To turn On / Off induction Hob.
How to Operate Gas Hob
•Press and hold the knob for 3 -5 seco
nds
before turning the knob.
•After flame ignited, press and hold for
the
knob for 5 more
seconds before release
to avoid flame out.
•In the event of the burner flames being
accidentally ext
inguished, turn off the
burner control and do not attempt to
re
ignite the burner for atleast 1 min.
•Remarks : when
you start to use the
cooker for the first time o
r the cooker has
not been used for a l
ong time period of
time. This is because the gas need
to fill
up the gas hose before reac
hing to the
burners.
•In this case, repeat turning on the igni
tion
knob a few times until it lids.
