Modern Flames DWLS-40/15 User manual

Log Installation Step 1
Locate screws holding in the glass and remove

Log Installation Step 2
Carefully remove glass panel by pulling on the tabs located
on the left and right side of the firebox lean the glass
towards you and lift glass out. Make sure not to drag glass
as alignment pegs on bottom may damage module finish.

Log Installation Step 3
Open the Driftwood Log Set and locate the following:
Log set, Smoked Glacier Crystals, LED bulbs
Log Configurations:
LFV40/15 & LFV2-40/15: (1)-40” Log Set
LFV60/15 & LFV2-60/15: (1)-60” Log Set
LFV80/15 & LFV2-80/15 : (2)-40” Log Sets(ONE INSTALLED REVERSED)
LFV100/15 & LFV2- 100/15: (1)-40” Log Set & (1)-60” Log Set(ONE INSTALLED REVERSED)
LFV120/15 & LFV2-120/15: (2)-60” Log Sets(ONE INSTALLED REVERSED)
LOG SET
MEDIA LEDs

Log Installation Step 4
Locate and remove media tray strips.
Both the Clear strip and Colored strip.
LFV COLOR STRIP
LFV &LFV2 CLEAR STRIP
LFV2 COLOR STRIP

Log Installation Step 5
EXAMPLE OF LOCATION OF CONNECTORS FOR LOGS
(80” AND ABOVE WILL HAVE TWO CONNECTIONS)
*REMOVING MODULE TO LOCATE WIRES WILL MAKE IT
EASIER AND SOMETIMES NECESSARY FOR LH CONNECTION*

Log Installation Step 6
After you locating the wires inside the fireplace and the
end of the driftwood logs. Plug in wires to each other.

Log Installation Step 7
Place the driftwood logs in the center of the firebox so
that it sits flush in the designated channel.

Log Installation Step 8
Locate your LEDs inside the shipping box. Remove 1 log at a
time and note orientation. Install the LEDs in the sockets,
simply align the probes from the LEDs to the holes in the
socket and insert until fully seated. Replace the removed log
and repeat for the remaining logs.
LED EXAMPLE

Log Installation Step 9
Add the smoked glacier crystals around the logs. Then
replace glass in the front of the unit where it was first
removed from.

*CAN BE REVERSED FOR BIGGER UNITS*
*CAN BE REVERSED FOR BIGGER UNITS*
