modway EEI-3681-NAT-TAU User manual

A
C
Screw M6x60mm x 2
Bolt M6x70mm x 4
Allen Wrench M4 x 2
x1
x2
Hardware:
Component:
Page 1 of 3
Thank you for purchasing the MODWAY CHAIR!
Before you start, here are some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the chair, we recommend that it is assembled by two adults, on a
carpeted or padded area, in the room that it is intended for. Approximate assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or instructions until you have checked all the components and
hardware and the furniture is fully assembled.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all pieces out of reach of children.
Customer Service 609-256-9000 www.modway.com
x1
1
2
3
1. Back
2. Seat
3. Leg Frame
4. Brace Rail
x1
B
Nut M6 x 4
Screw M6x40mm x 4
D
E
EEI-3681-NAT-TAU CHAIR
4
6
5. Back Cushion x1
6. Seat Cushion x1
5

3
1
E
A
4
EEI-3681-NAT-TAU CHAIR
Page 2 of 4
Hardware & Tool required
Hardware & Tool required
Customer Service 609-256-9000 www.modway.com
E
B
C
E
EC
B
E
x1
B
x2
E
x1
C
x1
A
x1
B
x2
E
x1
C
STEP 1:
Attach Leg Frame (3) to Back (1) as shown.
Insert Nut (C) into Back (1), then insert 1 piece of Bolt (A) and 1 piece of Screw (A) through Leg Frame (3)
into Back (1).
Tighten with 2 pieces of Allen Wrench (E).
STEP 2:
Attach Brace Rail (4) to Leg Frame (3) as shown.
Insert Nut (C) into Brace Rail (4), then insert 1 piece of Bolt (B) through Brace Rail (4) into Leg Frame (3).
Tighten with 2 pieces of Allen Wrench (E).

3
EEI-3681-NAT-TAU CHAIR
Page 3 of 4
Hardware & Tool required
Hardware & Tool required
Customer Service 609-256-9000 www.modway.com
E
A
E
B
C
E
EC
B
E
x1
B
x2
E
x1
C
x1
A
STEP 4:
Insert 1 piece of Bolt (B) through Leg Frame (3) into Brace Rail (4).
Tighten with 2 pieces of Allen Wrench (E).
x1
B
x2
E
x1
C
STEP 3:
Attach Legs Frame (3) to Back (1), Brace Rail (4) as shown.
Insert Nut (C) into Back (1), then insert 1 piece of Bolt (B) and 1 piece of Screw (A) through Legs Frame (3)
into Back (1) and Brace Rail (4).
Tighten with 2 pieces of Allen Wrench (E).

x4
D
Carefully position the assembled chair to the desired location.
Put 1 piece of the Back Cushion (5) and 1 piece of the Seat Cushion (6) into the assembled chair as shown.
Page 4 of 4
STEP 5:
Hardware & Tool required
STEP 6:
Assembly is complete. Your chair is ready to be used now!
Customer Service 609-256-9000 www.modway.com
x1
EE
D
6
EEI-3681-NAT-TAU CHAIR
2
5
Attach Seat (2) to Back (1), Legs Frame (3) as shown.
Then insert 4 pieces of Screws (D) through Seat (2) into Back (1), Legs Frame (3).
Tighten with Allen Wrench (F).
