modway MOD-5468 User manual

Customer Service 908-368-1025︱www.modwayfurniture.com Page 1 of 3
MOD-5468 FULL BED FRAME
Hardware:
Component:
A Bolt M8x25mm x16
B
C Bolt M8x20mm x4
D Allen Wrench M5 x1
1 Long Board x2
Thank you for purchasing the MODWAY FULL BED FRAME！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the bed frame, we recommend that it is assembled by two adults, on a carpeted
or padded area, in the room that it is intended for. Approx assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.
Bolt M8x35mm x4
E Open Wrench x1
F Side Plastic Cover x24
2 Short Board x2 3 Leg x4
5 Support Leg x2
3
4 Stretcher x1 6 Slat x24
G Center Plastic Cover x12
H Nut M8 x4
1
1
2
2
3
3
3
5
4

Customer Service 908-368-1025︱www.modwayfurniture.com Page 2 of 3
MOD-5468 FULL BED FRAME
STEP 1:
1
Hardware & Tool required
STEP 2:
1
2
2
3
3
3
3
Place Long Boards (1), Short Boards (2) and Legs (3) upside down on a carpeted or padded area.
Insert the end of 1 piece of Long Board (1) and Short Board (2) into 1 piece of Leg (3) as shown.
Repeat the same steps for remaining of Legs (3).
Insert 4 pieces of Bolt (A) into the pre-dilled holes on Leg (3) through the pre-drilled holes on the end of Long Board (1) and
Short Board (2) as shown.
Repeat the same step for remaining 3 pieces of Legs (3).
Tighten all Bolts (A) by using Allen Wrench (D) clockwise until secure.
Ax16 Dx1
2
1
1
3
3
3
3
3
2
1
A A
A
A
D

Customer Service 908-368-1025︱www.modwayfurniture.com Page 3 of 3
MOD-5468 FULL BED FRAME
STEP 4:
Insert 2 piece of Side Plastic Cover (F) into each end of 2 pieces of Slat (6) as shown.
Insert the other end of the Slats (6) into 1 piece of Center Plastic Cover (G) as shown.
Insert the assembled Side Plastic Covers (F) into the corresponding holes on Long Board (1), and the assembled Center
Plastic Cover (G) into the corresponding holes on Center Rail (4) as shown.
Repeat the same steps for the remaining 22 pieces Slat (6).
Fx24 Gx12 Hardware & Tool required
1
3
F 2
4
2
Bx4 Cx4 Dx1 Ex1 Hx4
STEP 3:
Place Stretcher (4) to the assembled Long Board (2).
Secure each end of Stretcher (4) by using 2 pieces of Bolt (C) as shown.
Tighten Bolts (C) by using Allen Wrench (D) clockwise until secure.
Place 2 pieces of Support Leg (5) under the assembled Stretcher (4).
Secure each Support Leg (5) by using 2 piece of Bolt (B) and 2 pieces of Nut (H) as shown.
Tighten Bolts (B) and Nuts (H) by using Allen Wrench (D) and Open Wrench (E) until secure.
Hardware & Tool required
B
5
2
2
1 E
1
5 4
3
4
2
6
Assembly is complete. Your bed frame is ready to be enjoyed now!
1
3
3
3
F
G
6
3 3
3
5
C
C
D
B
H H
E
D
4
