modway EEI-6355 User manual

EEI-6355
V1.02.02.23
Questions? Contact us!
609.256.9000 [email protected]
www.modway.com
PAGE 1 OF 12

Furniture components:
Provided hardware:
1
2
3
4
5
6
7
A
B
C
D
E
G
H
x2
x2
x1
x1
x1
x1
x1
Leg front
Leg back
Side panel left
Side panel right
Back panel
Bottom panel
Front frame
What you need:
Phillips
Phillips head screwdriver.
You may also need:
+ Power Drill
+ Level
+ Silicone Adhesive or caulk
+ Drywall Anchors and Screws
+ Other Wall-Mounting Hardware
PAGE 2 OF 12
Cam bolt M6 x 40mm
Wood dowel Ø8 x 40mm
x26
x36
Cam lock Ø15mm x26
Handle x3
Screw M4 x 20mm x4
Screw M4 x 16mm x16
Metal bracket x4
8x1
Drawer side panel left
9 x1
Drawer side panel right
10 x1
Drawer back panel
12 x1
Front side panel left
13 x1
Drawer middle
partition left
14 x1
Drawer middle
partition right
15 x1
Front side panel right
x1
Drawer bottom
16
IScrew M4 x 30mm x4
FScrew M4 x 37mm x2
11 x1
Drawer front panel
JScrew M4 x 25mm x6
Furniture components:
Let s get started!
Read through all of
the instructions
befor starting
Approx. 60 minutes
assembly time
2 people recommended
for assembly
Make sure you have all
parts and components
before discarding any
packing materials
Care instructions are
listed in the last step
of this manual
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screw completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screw and bolts to avoid stripping the hardware or
cracking the item.
For vanity and plumbing installation, we suggest hiring a professional
contractor and plumber.
Assemble your item on a flat carpeted area, with plenty of space to work.
this will prevent damage and scratches to your floors or the item while
you're assembling the product.
Keep all components and packaging out of reach of children or animals
to avoid risk of choking or suffocation.
1
3
1
2
4
5
6
7
12
13
14
15
2
Missing parts or hardware? Need assistance?
Contact us before returning your items. We're here to help!
609.256.9000 . [email protected]
Wait!
LLeveler (pre assembled) x4
8
10
11
9
16
KDrawer channel
(pre assembled) x2
MFelt (pre assembled) x4

Step 1
PAGE 3 OF 12
C
7
H
G
12
13
HARDWARE
Cam bolt M6 x 40mm
Wood dowel Ø8 x 40mm
COMPONENTS
x36
x26
x2
x2
x1
x1
x1
x1
Leg front
Leg back
Side panel left
Side panel right
Back panel
Bottom panel
Drawer middle partition left
x1
Drawer middle partition right
x1
Screw M4 x 16mm x2
Metal bracket x2
x1
Front frame
Drawer side panel left x2
x2
Drawer side panel right
x2
Drawer back panel
x1
Drawer front panel
11
Front side panel left x1
x1
Front side panel right
3
4
6
5
1
2
14
15
8
9
10
A
x2

HARDWARE
COMPONENTS
Step 2
x2
x2
x1
x1
Leg front
Leg back
Side panel left
Side panel right
PAGE 4 OF 12
x8
Cam lock Ø15mm
3
2
1
1
2
3
1
2
4
4
2
1
B
B

Step 3
PAGE 5 OF 12
B
HARDWARE
COMPONENTS
x4
x1
Leg front
Back panel x1
Cam lock Ø15mm
x1
Bottom panel
3
2
1
5
6
3
2
1
5
6
x1
Leg back
x1
Side panel left

Step 4
PAGE 6 OF 12
B
3
2
1
5
6
2
1
HARDWARE
COMPONENTS
x4
Cam lock Ø15mm
x2
x2
x1
x1
Leg front
Leg back
Side panel left
Side panel right
Back panel x1
x1
Bottom panel
3
2
1
5
6
2
1
4
4

Step 5
PAGE 7 OF 12
HARDWARE
COMPONENTS
J
B
15
13
14
12
15
15
13
13
12
14
x6
Cam lock Ø15mm
x1
Front side panel left
x1
Front side panel right
Drawer middle partition left
x1
Drawer middle partition right
x1
x6
Screw 4 x 25mm
14
12

7
Step 6
PAGE 8 OF 12
HARDWARE
Screw M4 x 16mm x16
Metal bracket x2
COMPONENTS
x1
Front frame
7
15
I
H
G
D
D
E
Screw M4 x 30mm x4
Handle x2
Screw M4 x 20mm x4
Note:- Full tighten all cam lock and screw
here.

Step 7
PAGE 9 OF 12
HARDWARE
COMPONENTS
x4
Cam lock Ø15mm
Screw M4 X 37mm x2
x1
Drawer side panel right
x1
Drawer back panel
x1
Drawer bottom panel
x1
Drawer front panel
Handle x1
Drawer side panel left x1
8
11
10
Note:- Full tighten all cam lock and screw
here.
16
8
10
11
B
8
11
910
16
8
11
910
16
F
D

Step 8
Apply a thin bead of silicone compound around the vanity base and set the vanity
top carefully in place. Remove any excess silicone compound with a wet rag
Step 9
PAGE 10 OF 12
Silicone not included
SILICONE
L
Note: Wall plugs, screws and tools are not
included.
MOUNTING THE CABINET TO THE WALL
The cabinet may pose a danger if not properly
mounted or secured to the wall.
Please ensure the correct hardware is used for
your particular wall type.
It is recommended to engage a professional
installer.

PAGE 11 OF 12
Overflow Ring
A quick note...
Your sink basin comes complete with a silver overflow ring.
If you'd like to remove this overflow ring, you can do so by hand.
Missing parts or hardware? Need assistance?
Contact us before returning your items. We're here to help!
609.256.9000 . [email protected]
Wait!

PAGE 12 OF 12
Great job!
Vanity assembly is complete.
C A R I N G F O R Y O U R I T E M
Indoor use only.
Not contract grade.
Clean using a non-abrasive cloth
and a mild cleaner.
Never use harsh chemicals,
as they could damage the finish
or integrity of the item.
CONNECT WITH US!
Tag us @modway_furniture and #modway
for a chance to be featured.
