modway MOD-6271 User manual

Thank you for purchasing the MODWAY BED!
Before you start, here are some helpful advice:
1. We suggest you spend a short time reading through this leaflet and then follow the simple step instructions.
3. Please do not use any tools other than those provided or recommended in these instructions.
4. Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5. Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save tools that have been provided.
6. Please keep all fitting out of reach of children.
Hardware:
1WOOD SCREW M4 x 20mm 4 PCS
2WOOD SCREW M3.5 x 16mm 12 PCS
3PVC BLACK WASHER 4 PCS
4BED SLAT SIDE FITTER 26 PCS
5
M5 ALLEN KEY (BALL SHAPE)
26 PCS
6
BED SLAT CENTER FITTER
1 PC
Component:
A. HEADBOARD
C. SIDE RAIL (L/R)
D. CENTER RAIL
E. CENTER RAIL LEG
F. CENTER RAIL SUPPORT
G. BED SLAT
H. BED LEG
01 of 05
MOD - 6271
x 1
x 2
x 2
x 6
x 3
x 39
x 4
B. FOOTBOARD x 1
G
E
FA
B
C
H
D
2. Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time: 35 minutes.

STEP 1
02 of 05
STEP 2
H
3
A
B
D
E
3. PVC BLACK WASHER x 4pcs 7. PROTECTIVE DISC (BLACK) x 4pcs
MOD - 6271
2.1 Fasten Center Rail Leg (E) to Center Rail (D) attach by screwing the protruding nut
into the corresponding holes.
1.1 Insert and secure the Bed leg (H) to the Headboard (A) and Footboard (B) using hardware
parts PVC Black Washer (3).

STEP 3
03 of 05
STEP 4
A
C
6
A
B
CA
B
6
6. M5 ALLEN KEY (BALL SHAPE) x 1pcs
6. M5 ALLEN KEY (BALL SHAPE) x 1pcs
MOD - 6271
3.1 Loosen the pre-inserted bolt on the Headboard (A) & Footboard (B) using hardware part
Allen Key (6).
4.1 Attach the Side Rails (C) to the Headboard (A) & Footboard (B) using hardware part
Allen Key (6).

STEP 5
STEP 6
04 of 05
2. WOOD SCREW M3.5 x 16mm x 12pcs
1. WOOD SCREW M4 x 20mm x 4pcs
D
A
F
C
2
x 4
D
A
x 2
1
A
Screw Driver
Screw Driver
B
D
B
C
F
D
A
MOD - 6271
5.1 Locate Center Rail (D) into the corresponding brackets inside of Headboard (A) and
Footboard (B).
5.2 Insert and secure the Center Rail Support (F) to the Center Rail (D) & Side Rail (C) using
hardware parts Wood Screw (2).
6.1 Locate Center Rail (D) into the corresponding brackets inside of Headboard (A) and
Footboard (B) using hardware parts Wood Screw (1).

05 of 05
STEP 7
G
Assembly is complete. The bed is ready to use now!
NOTE: Hardware may loosen over time. Periodically check that all connections are tight.
STEP 8
8.1 Carefully position the assembled bed to the desired location by four adults.
4. BED SLAT SIDE FITTER x 26pcs 5. BED SLAT CENTER FITTER x 26pcs
Palm
Palm
G
4
G
G
5
STEP 7.2
STEP7.1
5
4
4
G5
G
MOD - 6271
7.1 Insert the Slats (G) into the end Slat cap (4) & (5) and fix it to the corresponding holes
on the Side Rail (C).
