modway MOD-6304 User manual

Thank you for purchasing the MODWAY BED!
Before you start, here are some helpful advice:
1. We suggest you spend a short time reading through this leaflet and then follow the simple step instructions.
2. Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time: 20 minutes.
3. Please do not use any tools other than those provided or recommended in these instructions.
4. Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5. Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save tools that have been provided.
6. Please keep all fitting out of reach of children.
Component:
MOD-6304
01 of 03
Customer Service 609-256-9000 www.modway.com
HEADBOARD
SUPPORT WOOD
BED FRAME
(DOES NOT INCLUDE
WITH THE PURCHASE)
1 PC
2 PCS
A
B
C-
BBT 6930 A2 HB (W1560xH700xT75mm)

02 of 03
Customer Service 609-256-9000 www.modway.com
STEP 1
1.1 Open the zip at the headboard backing and take out all the parts.
1.2 Align pre-drilled support stand holes over the pre-drilled headboard holes according to your
desired headboard height
1.3 Secure each support stand by using 2x JCBB Bolt (1) and 2x M8 Flat Washer (2).
Tighten with supplied Allen Key (3).
Repeat the same procedure to secure the other side.
JCBB BOLT M8 x 60mm
M8 FLAT WASHER
M5 ALLEN KEY
JCBB BOLT M6 x 60mm
4 PCS
4 PCS
1 PC
JCBB BOLT M6 x 35mm
M6 FLAT WASHER
M6 SPRING WASHER
M6 HEX NUT
M4 ALLEN KEY
4 PCS
4 PCS
8 PCS
4 PCS
4 PCS
1 PC
HARDWARE BED FRAMEHARDWARE HEADBOARD
4
5
6
7
8
9
1
2
3
Note: Hardware may loosen over time.
Periodically check that all connections are tight.
A
B3
1
2
MOD-6304

03 of 03
Customer Service 609-256-9000 www.modway.com
STEP 2
2.1 Line up the bed frame board's
pre-drilled holes to match those of
the headboard.
2.2 Secure the headboard to the
bed frame by using 2x bolt (4) for
the thicker bed frame, and 2x bolt
(5) for the thinner bed frame. Before
inserting each bolt, place a spring
washer (7) and flat washer (6) on
each bolt. Then fit a flat washer (6)
on the screw as it protrudes through
the other side of the bed frame.
2.3 Place a Hex Nut (8) after the
flat washer (6) at the end of each
screw. Then tighten by using the
Allen key (9).
2.4 Repeat the same procedure for
each screw and each side of the
bed frame.
B8
STEP 3
6
6
7
4
9
C
MOD-6304
