modway MOD-5347 User manual

are
that
Short Board x2
Support Legs x2
Long Board x2
Legs x4
Center Rail x1
Roll Slats x13
Components:
WWW.MODWAY.COM

Secure the 2 pieces of Wooden Leg (5) to the Short Board (1) as shown. Repeat the same steps for the
remaining 1 piece of Short Board (1). Tighten the Leg (5)clockwise until secure.
Place 1 piece of Long Board (2) to the assembled 2 pieces Short Board (1) by two adults.
Attach them by using 4 pieces of Bolt (A) as shown.
Use Allen Wrench (C) to tighten the Bolts (A) clockwise until secure.
Repeat the same steps for the remaining 1 piece of Long Board (2).
WWW.MODWAY.COM
C
A x 8 C x 1

Insert Center Rail (3) to the bracket (provided) on Short Board (1) and then secure with 1 piece
Screw (B) per each end. Tighten the Screws (B) with Phillips Head Screw Driver (not provided).
Secure 2 pieces of
Support leg (4) clockwise until secure.
Support Leg (4) to the Center Rail (3) with pre-set T-nut as shown. Tighten the
WWW.MODAWAY.COM
B
B x 2

Hardware may loosen over time. Periodically check that all connections are tight.
Assembly is complete. The bed frame is ready to use now!
Place the Roll Slats (6) to the Long Board (2) as shown.
Secure 4 pieces of Roll Slats (6) which have countersink holes on each end into the Long Board (2)
by using 8 pieces of Screw (B) as shown.
Tighten the Screws (B) with Phillips Head Screw Driver (not provided).
Secure 4 pieces of Screw (B) into the Slat (6) on the top of Center Rail (3) as shown.
Tighten the Screws (B) with Phillips Head Screw Driver (not provided).
WWW.MODWAY.COM
B
B
B x 8
B x 4

CONNECTING BED FRAME TO HEADBOARD
Reminder: All the hardware packed in the
Headboard you bought. Please use only the above
hardware from Headboard Hardware Package to
assemble the Bed Frame and Headboard.
WWW.MODWAY.COM

CONNECTING BED FRAME TO HEADBOARD
