modway Render EEI-4263 User manual

Customer Service 908-368-1025︱www.modway.com Page 1 of 8
Thank you for purchasing the MODWAY CABINET !
Before you start, here are some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step
instructions.
2.it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time: 60 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or instructions until you have checked all the components and
hardware and the furniture is fully assembled.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all pieces out of reach of children.
Owing to the size and weight of the Cabinet, we recommend that
Q)
L)
x 4
G)
x 8
B) CamLock/Metal
Ø 15 mm x 9
M)
x 1
H)
x 4
C) Dowel/Wood
Ø 8 x 30 mm x 32
P)
x 4
K)
x 1
F)
x 8
A) Cambolt/Metal
Ø 6 x 35 mm x 9
N)
x 6
I)
x 2
D)
x 5
O)
x 5
J)
x 2
E)
Screw/Metal
x 1
Hardware :
M 7 x 50 mm
Screwdriver (Not Include)
x 1
L 4
Hex /Allen Key/Metal
M 3.5 x 15.5 mm M 6.4 x 25 mm
Screw/Metal Screw/Metal
Ø 8 x 19 mm
Pin Sliding Top/Plastic
Ø 8 x 16 mm
Pin Sliding Bottom/Plastic
9 x 14 x 10 mm
Wedge/Plastic
Ø 8 mm
Bumper/Silicone
25 x 25 x 2 mm
Floor Protector/Sponge/Felt
42 x 14 x 8 mm
Stoper/Plastic Divider wire/Metal
Ø 15 mm
Screw Cap/Plastic
Screw/Metal
M 6.4 x 53 mm
CABINETEEI-4263

Customer Service 908-368-1025︱Page 2 of 8www.modway.com
Components:
5
1 2 3
67
4
8
10
9
Top Board x1
Assembly Leg x2
Frame Door x1
Support 1 x2 Support 2 x2
Back Board x1
Center Board x1
Bottom Board x1 Side Board Left x1 Side Board Right x1
CABINETEEI-4263

Customer Service 908-368-1025︱Page 3 of 8www.modway.com
STEP 1:
Hardware required.
Screwdriver not included
Bx5 Ox5 Qx1
Hardware required.
Screwdriver not included
Ax5Cx12 Qx1
STEP 2:
CABINETEEI-4263

Customer Service 908-368-1025︱Page 4 of 8www.modway.com
STEP 3:
STEP 4:
Hardware required.
Dx5Ex1
Hardware required.
Screwdriver not included
Ax4Cx16 Qx1
CABINETEEI-4263

Customer Service 908-368-1025︱Page 5 of 8www.modway.com
STEP 5:
STEP 6:
Hardware required.
Screwdriver not included
Hardware required.
Bx4Qx1
Cx4
CABINETEEI-4263

Page 6 of 8Customer Service 908-368-1025www.modway.com
STEP 7:
STEP 8:
Hardware required.
Screwdriver not included
EHx4Lx4 Px4 Qx1
TOP VIEW
Hardware required.
Nx6
P
P
PP
P
HH
HH
CABINETEEI-4263

Customer Service 908-368-1025︱ Page 7 of 8 www.modway.com
STEP 9:
STEP 10:
Ix2Jx2Hardware required. Mx1
Kx1Hardware required.
CABINETEEI-4263

Customer Service 908-368-1025︱Page 8 of 8www.modway.com
STEP 11:
STEP 12:
Hardware required.
Screwdriver not included
Fx8Gx8Qx1
Assembly is complete. The Cabinet is ready to enjoy now !
