modway Tracy MOD-5241 User manual

A
B
C
JCBC SCREW M6 X 30MM
SPRING WASHER 1/4''
M4 ALLEN KEY (BALL SHAPE)LONG
MOD-5241
Hardware for Dresser
Component :
1- DRESSER
2- DRESSER LEGS
Page 1/4
x8
x8
x1
1
2
Customer Service 908-368-1025 www.modway.com
D
E
F
WALL SCREW M4 x 18MM x1
WALL SCREW M4 x 50MM x1
G
L- BRACKET x2
BELT x1
HFELT PROTECTOR x4
Thank you for purchasing the MODWAY DRESSER(WITH MIRROR SUPPORT) !
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step
instructions.
2.Owing to the size and weight of the nightstand, we recommed that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time :30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components
and hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe and
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten
the components from time to time, so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.

DM5 x 32MM WOOD SCREW
Hardware for Dresser(with
mirror support)
Component :
3- DRESSER
4- MIRROR
5- SUPPORT RAIL
Page 2/4
x10
3
4
5
MOD-5241
Customer Service 908-368-1025 www.modway.com

Place
Place
A x 8 B x 8 C x 1
Hardware & Tool required
STEP 1 :
1. Place Dresser(1) on a carpeted surface. Attach Dresser Legs(2) into Dresser(1) by inserting JCBC SCREW M6 x 30mm (A)
and Spring Washer 1
4''(B).Tighten with M4 Allen Key(Ball Shape)Long(C).
STEP 2 :
Page 3/4
C
BA
1
2
MOD-5241
H
H x 4
Customer Service 908-368-1025 www.modway.com

Place
Place
D x 10
Hardware & Tool required
STEP 3 :
1. Align Support Rails(5) and Mirror(4) with Dresser(3) together.Then, insert M5 x 32mm Wood Screw (D) through the
Support Rails(5).Tighten with Screw Driver.
STEP 4 :
Assembly is completed.
The Dresser(with mirror support) is ready to enjoy now !
D
4
3
5
Page 4/4
F
D
E
G
D x 1 E x 1 F x 2
Hardware & Tool required
G x 1
MOD-5241
F
Customer Service 908-368-1025 www.modway.com
