MOLEAER NEXUS User manual

- 1 -
Nexus Operation Manual, English
OPERATING MANUAL
MOLEAER NEXUS
NANOBUBBLE GENERATOR
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS

- 2 -
Nexus Operation Manual, English
CUSTOMER SERVICE / TECHNICAL SUPPORT
If you have questions about ordering Moleaer, Inc. replacement parts and products, please use the following
contact information:
Customer Service Website
Monday to Friday: 8 AM to 5 PM PST www.moleaer.com
Phone: [phone]
Email: [email protected]
Table of Contents
1INTRODUCTION.......................................................................................................................... - 3 -
2SAFETY INSTRUCTIONS............................................................................................................... - 3 -
3GENERAL WARNINGS ................................................................................................................. - 4 -
4EQUIPMENT DRAWING .............................................................................................................. - 6 -
5INSTALLATION............................................................................................................................ - 7 -
6GAS – SPECIFICATIONS ............................................................................................................... - 9 -
7NEXUS GENERATOR OPERATION .............................................................................................. - 10 -
8DISSOLVED OXYGEN SENSOR (OPTIONAL WITH THE NEXUS IQ) ................................................ - 10 -
9PUMP MAINTENANCE .............................................................................................................. - 11 -
10 CLEANING & SANITIZING ........................................................................................................ - 11 -
11 GENERAL MECHANICAL CLEANING PROCEDURES.................................................................... - 11 -
12 TROUBLESHOOTING ............................................................................................................... - 12 -
13 LIMITED WARRANTY .............................................................................................................. - 14 -

- 3 -
Nexus Operation Manual, English
1INTRODUCTION
Moleaer (Latin for “tiny air”) is a technology company that integrates nano-scale materials into proprietary technologies to
develop highly efficient and simple solutions for transferring gas into liquids. These solutions enhance the performance and
modify the functionality of liquids for a wide variety of applications.
The Moleaer Nexus product is an inline nanobubble gas-injection technology tailormade for the horticulture and aquaculture
markets. Its principle function is to alter the economics of using oxygen to improve the quality of water, promote plant and fish
growth and suppress disease. With simplicity and near perfect efficiency, the Nexus nanobubble generator saturates water with
dissolved oxygen and trillions of negatively charged nanobubbles. These tiny bubbles, about 100x smaller than a red blood cell,
have several unique physical properties that make them behave very different from normal bubbles. Nanobubbles are neutrally
buoyant and remain stable in solution for prolonged periods of time, creating an oxygen buffer in the water. The combination of
the Nexus’s high oxygen transfer efficiency and stable oxygen enriched nanobubbles enable more readily available oxygen to
reach oxygen dependent organisms to promote healthy growth.
2SAFETY INSTRUCTIONS
IMPORTANT NOTICE
This guide provides installation and operation instructions for this product. Consult Moleaer with any questions
regarding this equipment.
Attention Installer: This guide contains important information about the installation, operation and safe use of this product. This
information should be given to the owner and / or operator of this equipment after installation. This Nexus nanobubble generator
is for use for horticulture and aquaculture installations ONLY.
Attention User: This manual contains important information that will help you in operating and maintaining this product. Please
retain it for future reference. Warnings and safety instructions for Moleaer Nexus nanobubble generators and other related
products are available at: http://www.moleaer.com or call U.S. [phone] for additional free copies of these instructions.
READ AND FOLLOW ALL INSTRUCTIONS. SAVE THESE INSTRUCTIONS
This is the safety alert symbol. When you see this symbol on your system or in this manual, look for one of
the following signal words and be alert to the potential for personal injury.
Warns about hazards that can cause death, serious personal injury, or major property damage if ignored.
Warns about hazards that may or can cause minor personal injury or property damage if ignored.
NOTE indicates special instructions not related to hazards. Carefully read and follow all safety instructions in this manual and on
equipment. Keep safety labels in good condition; replace if missing or damaged.
When installing and using this electrical equipment, basic safety precautions should always be followed, including the following:
RISK OF ELECTRICAL SHOCK. Connect only to a branch circuit protected by a ground-fault circuit- interrupter (GFCI). Contact a
qualified electrician if you cannot verify that the circuit is protected by a GFCI.
This unit must be connected only to a supply circuit that is protected by a ground-fault circuit-interrupter (GFCI). The GFCI should
be provided by the installer and should be tested on a routine basis. To test the GFCI, push the test button. The GFCI should
interrupt power. Push the reset button. Power should be restored. If the GFCI fails to operate in this manner, the GFCI is defective.
If the GFCI interrupts power to the pump without the test button being pushed, a ground current is flowing, indicating the
possibility of an electric shock. Do not use this pump. Disconnect the pump and have the problem corrected by a qualified service
representative before using.

- 4 -
Nexus Operation Manual, English
3GENERAL WARNINGS
The Nexus system can come with and without a pump. When a pump is included with the system, never open the inside of the
pump drive motor enclosure. There is a capacitor bank that holds a 230 VAC charge even when there is no power to the unit.
The Nexus pump is capable of high flow rates; use caution when installing and programming to limit pump’s performance
potential with old or questionable equipment.
Code requirements for the electrical connection differ from state to state. Install equipment in accordance with the current
National Electrical Code and all applicable local codes and ordinances.
Before servicing the pump switch OFF power to the pump by disconnecting the main circuit to the Nexus generator.
This appliance is not intended for use by persons (including children) of reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a
person responsible for their safety.
FAILURE TO FOLLOW ALL INSTRUCTIONS AND WARNINGS CAN RESULT IN SERIOUS BODILY INJURY OR
DEATH. THIS PUMP SHOULD BE INSTALLED AND SERVICED ONLY BY A QUALIFIED SERVICE PROFESSIONAL.
INSTALLERS, OPERATORS AND OWNERS MUST READ THESE WARNINGS AND ALL INSTRUCTIONS IN THE
OWNER’S MANUAL BEFORE USING THIS PUMP. THESE WARNINGS AND THE OWNER’S MANUAL MUST BE LEFT WITH THE
PRODUCT OWNER.
SUCTION ENTRAPMENT HAZARD: STAY OFF THE MAIN DRAIN AND AWAY FROM ALL SUCTION OUTLETS!
THIS GENERATOR PRODUCES HIGH LEVELS OF SUCTION AND CREATES A STRONG VACUUM AT THE MAIN DRAIN AT THE BOTTOM
OF THE BODY OF WATER. THIS SUCTION IS SO STRONG THAT IT CAN TRAP ADULTS OR CHILDREN UNDER WATER IF THEY COME
IN CLOSE PROXIMITY TO A DRAIN OR A LOOSE OR BROKEN DRAIN COVER OR GRATE.
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION: PUMPS REQUIRE HIGH VOLTAGE WHICH CAN SHOCK,
BURN, OR CAUSE DEATH.
BEFORE WORKING ON THE Nexus PUMP! Always disconnect power to the pump at the circuit breaker
from the pump before servicing the pump. Failure to do so could result in death or serious injury to service
person, system users or others due to electric shock.
NOTE: ALL SUCTION PLUMBING MUST BE INSTALLED IN ACCORDANCE WITH THE LATEST NATIONAL AND LOCAL CODES,
STANDARDS AND GUIDELINES.
A clearly labeled emergency shut-off switch for the pump must be in an easily accessible, obvious place.
Make sure users know where it is and how to use it in case of emergency.
Install all electrical equipment, such as on/off switches, timers, and control systems, etc. to allow the
operation (startup, shut-down, or servicing) of any pump or filter so the user does not place any portion of
his/her body over or near the pump strainer lid, filter lid or valve closures. This installation should allow
the user enough space to stand clear of the filter and pump during system start-up, shut down or servicing
of the system filter.
This generator has been evaluated for use with water only.
Before operation, be sure to completely rinse the pump volute with water.

- 5 -
Nexus Operation Manual, English
RISK OF ELECTRICAL SHOCK.
This pump is supplied with a grounding conductor and grounding type attachment plug. To reduce the risk
of electric shock, be certain that it is connected only to a properly grounded, grounding-type receptacle.
Pumps improperly sized or installed or used in applications other than for which the pump was intended
can result in severe personal injury or death. These risks may include but not be limited to electric shock,
fire, flooding, suction entrapment or severe injury or property damage caused by a structural failure of the
pump or other system component.
The pump can produce high levels of suction within the suction side of the plumbing system. These high
levels of suction can pose a risk if a person comes within close proximity of the suction openings. A person
can be seriously injured by this high level of vacuum or may become trapped and drown. It is absolutely
critical that the suction plumbing be installed in accordance with the latest national and local codes for
aquaculture systems.
HAZARDOUS PRESSURE: STAND CLEAR OF PUMP AND FILTER DURING STARTUP
Circulation systems operate under high pressure. When any part of the circulating system (i.e. locking ring,
pump, valves, etc.) is serviced, air can enter the system and become pressurized. Pressurized air can cause
the pump housing cover and valves to violently separate which can result in severe personal injury or death.
Stand clear of all circulation system equipment when turning on or starting up pump. Before servicing
equipment, make note of the filter pressure. Be sure that all controls are set to ensure the system cannot
inadvertently start during service. Turn off all power to the pump.
General Installation Information
•All work must be performed by a qualified service professional, and must conform to all national, state, and local codes.
•Install to provide drainage of compartment for electrical components.
•The Nexus generator will function correctly only if it is properly sized to the specific application and properly installed.

- 6 -
Nexus Operation Manual, English
4EQUIPMENT DRAWING
1. Nanobubble Generator
9. Diffused Gas Pressure
2. Bypass Flow Valve
10. Rotameter
3. Discharge – Isolation Valve (Flange Mount)
11. Pump Pressure
4. Inlet – Isolation Valve (Flange Mount)
12. CIP Valve
5. Terminal Box
13. Metric Adapter CIP (Optional – Not Shown)
6. Gas Solenoid
14. Metric Flange Adapter (Optional – Not Shown)
7. Mechanical Pressure Switch
15. Control Panel (Optional)
8. Gas Inlet
16. DO Probe (Optional)
1
2
3
8
9
10
11
7
6
5
15
13
12
16
4
14

- 7 -
Nexus Operation Manual, English
5INSTALLATION
Only a qualified plumbing professional should install the Moleaer Nexus nanobubble generator. Refer to “Warning and Safety
Instructions” on pages 3-5 for additional installation and safety information.
LOCATION
Be sure the Nexus generator location meets the following requirements:
1. Provide short, direct suction piping returns (reduces friction loss). For suction lifts over 10' (3 m) and liquid temperatures
over 120º F (49ºC), consult pump performance curve for net positive suction head required (NPSH R).
2. The Nexus should be installed downstream and on the pressure side of the pump.
3. Install the Nexus generator in a sheltered, well ventilated area to protect from excess moisture (i.e., rain, splashing,
etc.) and flooding.
4. Install and secure the Nexus generator on level concrete slab or firm surface (reduces vibration noise).
5. The Nexus generator location should allow access for servicing and maintenance.
PIPING - INTAKE
1. Be sure all plumbing connections are clean and tight to avoid possible air leaks and entrainment of air on the suction
side of the pump.
2. Use larger pipe sizes for improved plumbing. Suction pipe diameter should be the same or larger than the pump inlet.
3. Plumbing on the suction side of the pump should be short as possible.
4. Install piping as close to the water level as possible.
5. Run straight, horizontal piping for the suction side of the pump. The length of the piping should be equal to five (5) pipe
diameters.
6. Install screen filter on the intake pipe when using the Nexus generator in recirculating systems where debris can enter
the system. Ensure mesh size does not restrict flow at the generator’s designed flow rate.
Example: If system is plumbed with 3 in. diameter PVC pipe, then a straight section of pipe 15 in. long should be used
for suction side of the pump.
If the Nexus generator is installed above the liquid source, the following MUST be provided:
7. Slope piping upward from liquid source.
8. Use a foot valve or check valve ONLY if necessary, for priming or to hold prime during intermittent duty.
9. The suction strainer or suction bell MUST be at least 3 times the suction pipe diameter area.
10. Ensure that the size and minimum submergence over suction inlet is sufficient to prevent air from entering through a
suction vortex.
PIPING - DISCHARGE
1. Install a check valve suitable to handle the flow and liquids, and to prevent backflow. After the check valve, install an
appropriately sized gate valve to be used to regulate the pump capacity, pump inspection, and for maintenance. When
required, the pipe increaser should be installed between the check valve and the pump discharge.
2. Install discharge pipe at least 2’ below the water surface.
LEAVING AIR VALVE OPEN WHEN PUMP IS NOT OPERATIONAL MAY CAUSE LOSS OF PRIME.
FITTINGS
1. Install fittings (valves, elbows, tees, etc.) in the suction line no closer than five (5) times the pipe diameter to the front
of the pump (e.g. 3” pipe = 15 in).
2. Do not install 90° elbows directly into pump inlet.
VALVES
1. Install gate or ball valves on suction and discharge pipes for maintenance of flooded suction systems - install no closer
than five (5) times the suction pipe diameter.
2. Use a check valve in the discharge line when using this pump for any application where there is significant height to the
plumbing after the pump.

- 8 -
Nexus Operation Manual, English
3. Be sure to install check valves when plumbing in parallel with another pump. This helps prevent reverse rotation of the
impeller and motor.
4.
NOTICE: DO NOT USE THE ISOLATION VALVE TO THROTTLE PUMP. THIS MAY CAUSE LOSS OF PRIME, EXCESSIVE
TEMPERATURES AND DAMAGE TO PUMP, VOIDING WARRANTY.
ELECTRICAL
1. Install all equipment in accordance with the National Electrical Code and all applicable local codes and ordinances.
2. A means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules.
3. If the supply cord is damaged, it must be replaced to avoid a hazard. The supply cord can be purchased separately from
the manufacturer, its service agent or a qualified electrician.
•Solenoid needs to be operated by onsite controls in parallel with the pump circuit.
•If pump is on, the solenoid should be open, allowing gas to pass through.
•If pump is off, Solenoid needs to be closed/off.
ELECTRICAL WIRING INSTALLATION
PRESSURE SWITCH
1. If pump is on but the solenoid is not open, adjustment to the mechanical pressure switch may be necessary.
(Please see the note below)
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION. This Nexus nanobubble generator must be installed by
a licensed or certified electrician or a qualified service professional in accordance with the National
Electrical Code and all applicable local codes and ordinances. Improper installation will create an electrical
hazard which could result in death or serious injury to users, installers, or others due to electrical shock,
and may also cause damage to property.
Always disconnect power to the Nexus generator at the circuit breaker before servicing the pump. Failure
to do so could result in death or serious injury to service people, users or others due to electric shock.
Readall s ervicinginstructions before workingon the Nex us generator and pum p.

- 9 -
Nexus Operation Manual, English
PUMP (OPTIONAL)
To connect the pump to an AC power source (for non-cord connected pumps):
1. Be sure all electrical breakers and switches are turned off before wiring the Nexus generator.
2. Be sure that the supply line voltage matches the motor voltage listed on the motor plate (example 230 VAC or 115
VAC). If they do not match, permanent motor damage may occur.
3. Size wiring for the Nexus generator according to the National Electrical Code. When in doubt, use a heavier gauge
(larger diameter) wire. Heavier gauge will allow the motor to run cooler and more efficiently.
4. Use strain relief and be sure all electrical connections are clean and tight.
5. Cut the wires to the appropriate length so they do not overlap or touch when connected.
6. Permanently ground the Nexus generator using the green ground wire, as shown below. Use the correct wire size and
type specified by National Electrical Code. Make sure the ground wire is connected to an electrical service ground.
7. Bond the motor to the structure in accordance with the National Electrical Code. UL requires use of a solid copper
bonding conductor not smaller than 8 AWG. Run a wire from the external bonding screw or lug to the bonding structure.
Connect the wire from the accessible wire connector on the motor to all metal parts of the structure and to all electrical
equipment, metal conduit, and metal piping within 5 feet (1.5 m) of the inside walls of the structure. For Canada, a 6
AWG or larger solid copper bonding conductor is required.
UNIT ROTATION IS CLOCKWISE, WHEN VIEWED FROM THE MOTOR END. INCORRECT ROTATION MAY
CAUSE DAMAGE TO THE PUMP AND VOIDS THE WARRANTY.
6GAS – SPECIFICATIONS
The Moleaer Nexus nanobubble generator is designed for use with compressed oxygen.
DO NOT MIX GASES WITH THIS SYSTEM.
ALL GAS FITTINGS AND HOSES MUST BE MAINTAINED FREE FROM OIL AND LUBRICANTS.
Do not permit smoking or open flames in any areas where liquid oxygen is stored or handled. The Nexus
generator must be separated from flammables and combustibles by at least 20 feet or a half-hour fire wall.
GAS CONNECTION
Moleaer Nexus generators come with a standard ¼” NPT connection. Connect the oxygen supply hose to the unit, with a ¼” male
NPT fitting.
GAS FLOW & PRESSURE
1. Adjust the gas regulator on the feed gas tank or oxygen concentration (PSA) to supply the Nexus generator with a
minimum gas pressure of 100 PSI (6.89 bar).
DO NOT EXCEED 140 PSI (9.65 BAR) IN GAS PRESSURE. EXCESSIVE GAS PRESSURE MAY COMPROMISE
SEALS INSIDE THE GENERATOR AND RESULT IN A SUDDEN DROP IN PRESSURE. IF THIS OCCURS, CLOSE
THE GAS FLOW METER COMPLETELY, REDUCE THE GAS PRESSURE FEEDING THE GENERATOR, AND THEN
SLOWLY REOPEN THE VALVE AGAIN TO THE DESIRED GAS FLOW SET POINT.
2. Apply soapy water to gas fittings and connectors to ensure there are no gas leaks. If leaks are detected, then tighten
fittings and / or connectors.

- 10 -
Nexus Operation Manual, English
3. Gas flow rates can be adjusted depending on application and desired effect. The Nexus generators are designed to
deliver a spectrum of nano and / or microbubbles to meet the requirements of the process or application. Low gas flow
rates produce more nanobubbles and have a higher gas transfer efficiency, whereas higher gas flow rates produce both
nano and microbubbles that have a lower gas transfer efficiency but higher mass transfer rate. Refer to the
specification table for suggested gas flow rates for the different size units.
7Nexus GENERATOR OPERATION
PUMP MUST BE FULLY PRIMED BEFORE OPERATION.
OPERATION AT OR NEAR ZERO FLOW CAN CAUSE EXTREME HEAT, PERSONAL INJURY OR PROPERTY
DAMAGE.
1. Open intake and discharge valves to flood piping and prime the pump.
Note, if the pump and the Nexus generator is located above the water line of the tank or water body, it is important
to install a check valve just above the intake screen.
2. Turn on pump starter switch and run pump at normal operating conditions and check the piping for visible leaks. If
necessary, adjust the pipe supports.
NOTICE: NORMAL OPERATING PRESSURE RANGE ON THE PUMP IS BETWEEN 13-25 PSIG. PUMP FLOW RATES SHOULD
BE +/- 10% OF THE SYSTEM’S DESIGNED FLOW. PUMP FLOW RATES LOWER THAN THE SYSTEM SPECIFICATIONS WILL
RESULT IN LARGER BUBBLES AND LOWER OXYGEN TRANSFER EFFICIENCIES – IT IS NOT RECOMMENDED.
DO NOT EXCEED 35 PSI (2.4 BAR) ON PUMP PRESSURE
3. Open the needle valve on the Gas Flow Meter (item 6 on the diagram); the 200 can inject up to 20 CFH, the 500 can
inject 60 CFH and the 1000 up to 100 CFH, as indicated on the rotameter. The optimal gas flow rate is 16 CFH on the
200 Nexus, 32 CFH on the 500 Nexus and 72 CFH on the 1000 Nexus. Use the center of the indicating ball on the flow
meter as the index. Running the gas flow higher than this range will result in an increase in larger bubbles and a lower
gas transfer efficiency.
8DISSOLVED OXYGEN SENSOR (OPTIONAL WITH THE Nexus IQ)
Manual supplied separately

- 11 -
Nexus Operation Manual, English
9PUMP MAINTENANCE
See pump manual. Supplied separately.
10 CLEANING & SANITIZING
In normal operation, the internal elements of the Nexus generator can become fouled by mineral scale, biological matter, colloidal
particles and insoluble organic constituents. Deposits can build up on the internal surfaces during operation and can cause
diminished operation. Best practices include routine preventative cleaning with acid and alkali chemicals. In some instances, if
large solids are allowed to pass into the generator, blockages can occur.
GENERAL CLEANING PROCEDURES
1. Prepare the cleaning solution
2. Introduce the cleaning solution
3. Recycle
4. Soak
5. Conduct high-flow pumping
6. Flush out
7. Restart
SAFETY PRECAUTIONS
1. Maximum temperature 100o C or 212oF
2. pH tolerance range 2-14
3. Each cleaning situation is different; therefore, specific cleaning recommendations are dependent on the type of foulant.
Consult the general cleaning instructions for information that is common to all types of cleaning such as suggested
equipment, pH and temperature limits and recommended flow rates; then apply the specific recommendation as
needed.
4. When using any chemical indicated here or in subsequent sections, follow accepted safety practices. Consult the
chemical manufacturer for detailed information about safety, handling and disposal.
5. When preparing cleaning solutions, ensure that all chemicals are dissolved and well mixed before circulating the
solutions through the elements.
11 GENERAL MECHANICAL CLEANING PROCEDURES
Should blockage occur from single or multiple oversized solids being pumped into the generator, immediately stop operation.
Disconnect the pump from generator block and backwash water through the unit until the blockage is removed.

- 12 -
Nexus Operation Manual, English
12 TROUBLESHOOTING
Problem Possible Cause Corrective Action
Pump will not prime
•
Air circulating in system
• Gas valve open when pump not
running
• No water in the pump strainer
pot
•
Check suction piping and valve on any suction gate
valves.
• Secure lid on pump strainer pot and be sure lid
gasket is in place. Check water level to make sure
suction port is not drawing air.
• Be sure suction lines, pump strainer, and pump
volute are full of water. Be sure valve on suction line
is working and open (some systems do not have
valves).
Pump motor not running
• Motor thermal protector tripped
• Open circuit breaker or blown
fuse
• Impeller binding
• Motor improperly wired
• Defective motor
• Reset overload.
• Reset Breaker or replace fuse.
• Clear the impeller.
• Check the motor is wired correctly.
Pump gasket defective
• Defective gasket.
• Replace gasket.
Reduced capacity and/or
head
• Air pockets or leaks in suction line
• Pump will not prime — too much
air
• Check suction piping and valve on any valve suction
gate valves.
• Secure lid on pump strainer pot and make sure lid
gasket is in place. Check water level to make sure
suction port is not drawing air.
• Clean pump strainer pot.
• Check to see if impeller or diffuser are clogged.
Clogged Impeller
• Debris in impeller
• Switch OFF electrical power at the circuit breakers to
the pump. Remove the nuts that secure the volute
to the seal plate.
• Slide the motor and seal plate away from the volute.
Clean debris from impeller.
• If debris cannot be removed, complete the following
steps.
• Remove impeller reverse screw and O-ring.
• Remove, clean and reinstall impeller.
• Reinstall anti-spin bolt.
• Reinstall diffuser and O-ring. Reinstall motor
and seal plate into volute. Reinstall hardware
around seal plate and volute and tighten
securely.
Pump strainer clogged
•
Debris in pump strainer basket
•
Clean suction trap.
Insufficient dissolved
oxygen saturation
• Vacuum leaks in suction line
• Gas flow too low
• Check plumbing connections and suction piping.
Check to be sure suction port is not drawing air into
the system.
• Increase gas flow.
• Increase system run time.
Excessive power
consumption
•
Impeller binding
• NPSH too low – excessive suction
lift or losses
• Discharge head too low –
excessive flow rate
•
Clear the impeller.
• Check the pump curve for NPSH requirements.
• Check the flow.
Pump flow too low
• Voltage too low
• Check and correct the voltage.

- 13 -
Nexus Operation Manual, English
Pump back pressure too
high
• Discharge nozzle or piping
obstructed
• Discharge valve engaged too
much
• Check for blockage in piping.
• Ensure all valves are fully open.
Low gas pressure on
system gauge
• Feed gas pressure too low
• Internal fouling
• Follow specified “clean-in-place” procedures to
internal cleaning.
• Increase flow rate.
Gas flow meter not
working
•
Moisture in the rotameter
• Blockage in needle valve
•
Clean Rotameter
Too many large bubbles
• Gas flow too high
• Reduce gas flow.
Insufficient gas transfer
• Feed gas pressure too low
• Delta gas pressure out of range
• Excessive moisture and / or
contaminant in the gas line
• Internal system fouling
• Increase feed gas pressure at the gas regulator.
• Clean rotameter, gas lines and fittings.
• Follow specified “clean-in-place” procedures for
internal cleaning.
Excessive noise &
vibration
• Impeller binding
• Pump is not primed fully - air or
gases in pump cavity
• NPSH too low – e
xcessive suction
lift or losses
• Incorrect rotation (3 phase only)
• Defective motor
• Discharge, suction plugged or
valve closed
• Impeller worn or plugged
• Replace impeller if damaged.
• Completely flood intake piping to prime fully.
• Repair or replace motor if damaged.
• Open discharge valve or reduce restriction.

- 14 -
Nexus Operation Manual, English
13 LIMITED WARRANTY
WARRANTY. Moleaer warrants that the Goods will be free from defects in material and workmanship for a period of twelve (12)
months from delivery. Moleaer shall in no event be liable for defects or damage attributable to modifications performed or repair
work done other than by Moleaer personnel or to abuse, accident, catastrophe, force majeure event, shipment, improper use,
maintenance, storage or application or any other external cause. EXCEPT FOR ANY WRITTEN PERFORMANCE WARRANTY THAT
MOLEAER HAS EXPRESSLY INCORPORATED IN THIS CONTRACT, MOLEAER DISCLAIMS ALL OTHER WARRANTIES, WHETHER
EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NON-
INFRINGEMENT.
CLAIMS; EXCLUSIVE REMEDY. Any warranty claim must be made to Moleaer in writing within ten (10) days of discovery of the
alleged defect. After obtaining prior written authorization from Moleaer, Buyer shall return all allegedly defective Goods, freight
pre-paid, for examination by Moleaer. If Moleaer finds that the Goods are defective and covered by the warranty, Moleaer’s sole
obligation shall be, at Moleaer’s option, to repair or replace the Goods, or to refund the purchase price therefor, and to reimburse
Buyer’s reasonable shipping costs. Buyer shall be responsible for all charges for handling of returned items not found defective.
The remedy set forth in this paragraph 4 is Buyer’s sole and exclusive remedy for any breach of warranty or claim related to the
Goods other than pursuant to any written performance warranty that Moleaer has expressly incorporated in this Contract.
LIMITED LIABILITY. MOLEAER SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, CONSEQUENTIAL OR INCIDENTAL DAMAGES,
INCLUDING DAMAGES FOR LOST OR PROSPECTIVE PROFITS OR OTHER ECONOMIC DAMAGES, ARISING OUT OF OR RELATED TO
THIS CONTRACT OR THE GOODS. MOLEAER’S TOTAL LIABILITY, WHETHER IN CONTRACT OR TORT OR OTHERWISE, SHALL NOT
EXCEED THE PORTION OF THE PRICE PAID BY BUYER ALLOCABLE TO THE GOODS GIVING RISE TO THE LIABILITY. THE LIMITATIONS
IN THIS PARAGRAPH WILL APPLY NOTWITHSTANDING THE FAILURE OF ESSENTIAL PURPOSE OF ANY LIMITED REMEDY. This
limitation shall not apply to claims for personal injury directly caused by Moleaer’s willful or reckless acts.
Moleaer, Inc.
20800 Belshaw Ave
Carson, CA 90746
+ 1 [phone]
[email protected]
www.moleaer.com

- 15 -
Nexus Operation Manual, English
REVISION HISTORY
Revision
Description
ECO#
Assignee
Date Finished
A
Initial Release
x
x
x
B
Revised content. Added rev and formatting. Dropped datasheet
1114
PM
8/25/2020
C
New base plate
1144
DN
10/12/2020
