Mono Epsilon User manual

EPSILON
IMPORTANT INFORMATION
and
INSTALLATION INSTRUCTIONS
MONO EQUIPMENT
Queensway
Swansea West Industrial Estate
Swansea. SA5 4EB UK
COMPLETE OPERATION AND MAINTENANCE INSTRUCTIONS
ARE AVAILABLE AT www.monoequip.com
Tel. [phone]
email:[e-mail]
Spares Tel.[phone]
Fax. [phone]
NOTE: THIS MACHINE IS FOR USE WITH SOFT DOUGH ONLY
The use of templates and/or accessories not produced or supplied by
MONO Equipment will invalidate the machine’s warranty
FILE 4
Enter Serial No. here._____________________________________
In the event of an enquiry please quote this serial number.
www.monoequip.com

SAFETY SYMBOLS
The following safety symbols are used throughout this product documentation and
manual (available at www.monoequip.com).
Before using your new equipment, read the instruction manual carefully and pay special
attention to information marked with the following symbols.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
will result in electric shock.
Indicates a hazardous situation which, if not avoided,
will result in minor or moderate injury.
WARNING
WARNING
CAUTION
CAUTION
CAUTION
Indicates a hazardous situation if hand is placed in this
area, if not avoided, will result in minor or moderate
injury.
Indicates a hazardous situation if hand is placed under
hopper nozzles, if not avoided, will result in minor or
moderate injury.

ELECTRICAL SAFETY AND ADVICE REGARDING
SUPPLEMENTARY ELECTRICAL PROTECTION:
Commercial bakeries, kitchens and foodservice areas are environments where electrical
appliances may be located close to liquids or operate in and around damp conditions or
where restricted movement for installation and service is evident.
The installation and periodic inspection of the appliance should only be undertaken by a
qualified, skilled and competent electrician, and connected to the correct supply suitable
for the load as stipulated by the appliance data label.
The electrical installation and connections should meet the necessary requirements of
the local electrical wiring regulations and any electrical safety guidelines.
We Recommend:
−Supplementary electrical protection with the use of a residual current device
(RCD)
−Fixed wiring appliances incorporate a locally situated switch disconnector to
connect to, which is easily accessible for switching off and safe isolation purposes.
The switch disconnector must meet the specification requirements of IEC 60947.
The supply to this machine must be protected by a 30mA RCD

Thank you for purchasing the MONO EPSILON tabletop confectionary depositor.
A combination of clean industrial design and the latest technology.
The following information should get your purchase running without any
problems
If you have a problem with your purchase please contact MONO EQUIPMENT at:
MONO EQUIPMENT
Queensway
Swansea West Industrial Estate
Swansea. SA5 4EB UK
Tel. [phone]
1Never use a machine in a faulty condition and always report any damage.
2Only trained engineers may remove parts from this machine if a tool is required.
3Always ensure hands are dry before touching any electrical appliance (including cable, switch and
plug). NEVER move machinery by pulling on the power cords or cables.
4Ensure that the floor area around the Epsilon is clean to avoid slipping –especially if carrying
heavy hopper and template components to and from the machine.
5All operatives must be fully trained.
Use of the machine can prove dangerous if:
❑the machine is operated by untrained or unskilled staff
❑the machine is not used for its intended purpose
❑the machine is not operated correctly
All safety devices applied to the machine during manufacture and the operating instructions
in this manual are required to operate this machine safely. The owner and the operator are
responsible for operating this machine safely.
6People undergoing training on the machine must be under direct supervision.
7Do not operate the machine with any panels or guards removed.
8No loose clothing or jewellery should be worn while operating the machine.
9Switch off power at the mains isolator when machine is not in use and before carrying out any
cleaning or maintenance.
10 The bakery manager or the bakery supervisor should carry out daily safety checks on the
machine.
11 Do not operate machine without the hopper template fitted correctly
12 Due to the essential requirement for handling heavy components during cleaning, it is
recommended that protective footwear be worn when carrying out such procedures.
SAFETY

1Ensure that the depositor is connected to the correct electric supply as specified on
the serial number plate on the side of the machine.
2 Ensure that the correct fuse rating is fitted in the electrical supply.
3 The support table should be level and strong enough to support the machine and
loaded hopper.
4 This machine should be lifted by more than one person.
CAUTION:
The feed hopper and pump assembly exceeds 25kg and will need to be lifted off by
two people, or dismantled into smaller components while still on the machine.
ISOLATION
IN AN EMERGENCY, SWITCH OFF AT THE MAINS
WALL ISOLATOR, OR PUSH EMERGENCY
STOP BUTTON.
To release the emergency stop button, turn clockwise.
INSTALLATION
STOP BUTTONS
The supply to this machine must be protected by a 30mA RCD

BEST OPERATING CONDITIONS
To obtain the best product results and consistent operation,
✓Make sure the depositor is used on a level surface.
(Adjust feet if required)
✓Ensure flat trays are used.
✓Ensure undamaged nozzles and templates are used.
✓Keep the machine clean.
✓Do not leave any components in the hopper.

❑FITTING THE HOPPER
CAUTION SHOULD BE TAKEN WHEN FITTING HOPPER AND PUMP ASSEMBLY
AS WEIGHT EXCEEDS 25KGS ON SOME MODELS
It will need to be lifted off by two people, or
dismantled into smaller components while still on the machine.
MAKE SURE FLOOR AREA AROUND MACHINE IS CLEAN
To reduce weight and bulk fit the complete hopper assembly in two stages - first the
pump assembly onto the support bars, then the feed hopper body onto the pump
assembly.
1 By hand, align pump assembly drive gear roller with drive shaft on machine.
2 Fit hopper to pump assembly and secure with wing nuts.
3 Slide hopper on support bars until fully up against machine.
4 Screw hopper locking knob hand tight.
PUMP ASSEMBLY
FEED HOPPER
DO NOT OPERATE MACHINE WITHOUT TEMPLATE FITTED
FEED HOPPER
WINGNUTS
(EACH END)
SUPPORT BARS
HOPPER
LOCKING KNOB

FG080 Epsilon quickstart RevA19 29-01-19
1. Select template and nozzles required and fit (as section 9a & 9b on web manual).
Fill hopper with mix and close hopper guard.
2. Connect power cable to the correct electrical supply.
Make sure stop button is in released position (turn clockwise if required).
3. Select an existing program or create a new program through the on-screen menus.
(see section 10 on manual cd )
PREPARING FOR OPERATION
TEMPLATE
HOPPER
REMOVE GUARD TO FILL
HOPPER.
REPLACE CORRECTLY.
(MACHINE WILL NOT OPERATE WITHOUT
THE GUARD IN POSITION)
SCREEN
STOP BUTTONS
It is recommended that when heavy mixes are used, the inside of the hopper should be
coated with vegetable oil; for lighter mixes such as meringue, dampen with water. The oil
or water will help the mix to settle down the hopper walls and prevent air being sucked in.
NOTE: THIS MACHINE IS FOR USE WITH SOFT DOUGH ONLY
The use of templates and/or accessories not produced or supplied by MONO Equipment
will invalidate the machine’s warranty

FG080 Epsilon quickstart RevA19 29-01-19
4. TABLE ADJUSTMENTS
It is important that the table is parallel with the hopper.
(If this is not correct the nozzles will not be the same distance from the trays and the deposits
will differ across the tray).
Measure the distance at “A” and “B” below and check that they are the same.
This should be checked with the hopper bars positioned at both the full left position and the
full right position.
If not the same, an adjustment can be made by raising or lowering the adjusters under the
table. There is one each side to allow the table to be adjusted evenly.
Lift the front edge of the table and, with a suitable spanner, release the locking nut. Screw
the adjuster bolt up or down and then lock it in position with the locking nut.
5. TRAY GUIDE ADJUSTMENT
“A”
“B”
This allows different width trays to be accommodated.
To adjust the position of the back guide, remove the
table and turn it over. Loosen the thumb nuts and slide
the sheet across to the desired position. Tighten the
nuts and replace the table.
NUTS
