3-in-1 Wireless Charging Stand
P/N 43794
User's Manual
2
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future reference.
•This device is intended for indoor use only.
•Do not expose this device to water or moisture of any kind. Do not place drinks or
other containers with moisture on or near the device. If moisture does get in or on
the device, immediately remove it from its power source and allow it to fully dry
before reapplying power.
•Do not expose this device to excessive vibration or extreme force, shock, or
fluctuations in temperature or humidity.
•Do not expose this device to excessively high temperatures. Do not place it in, on,
or near a heat source, such as a fireplace, stove, radiator, etc. Do not leave it in
direct sunlight.
•Do not place or install this device in an area where it can be exposed to excessive
amounts of dust, humidity, oil, smoke, or combustible vapors.
•Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
•This device has no user serviceable parts. Do not attempt to open, service, or
modify this device.
INTRODUCTION
This 3-in-1 Wireless Charging Stand allows you to simultaneously charge an iOS® or
Android™ mobile phone, an Apple Watch®, and a pair of AirPods®. It features a small
footprint to save desk space and requires only a single USB power source. The Charging
Stand uses the Qi® wireless charging standard.
3
CUSTOMER SERVICE
The Monoprice™ Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
support times and links.
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice™ Customer Service for
a replacement.
1x 3-in-1 Wireless Charging Stand
1x USB Charging Cable (Type-A to Type-C®)
1x USB Wall Charger with Qualcomm® Quick Charge™ 3.0
PRODUCT OVERVIEW
4
PREPARATION FOR USE
1. Place the 3-in-1 Wireless Charging Stand in its intended location.
2. Using the included USB Charging Cable, plug one end into the Type-C® port on the
3-in-1 Wireless Charging Stand, then plug the other end into the included USB
charger. For best results, the power source should have a variable output power of
at least 5 VDC/3A or 9 VDC/2A or 12 VDC/1.5A. The LED Intelligent Light will
illuminate green, indicating that the Charging Stand is in standby mode.
3. If you will be charging an Apple Watch®, insert your Apple Watch magnetic charger
into the Original Charger Card Watch Charging Area on the Charging Stand, then
plug the magnetic charger into a USB power source. You can use the original
charger included with the Apple Watch and original cable or you can plug it into the
USB Type-A port on the side of the Charging Stand
CHARGING
Phone With Wireless Charging
If your phone supports the Qi® wireless charging standard, simply place it on the Charging
Stand. Your phone can be charged in both the vertical and horizontal orientations. The LED
Intelligent Light will breathe blue, indicating that the Charging Stand is actively charging a
device. When charging is complete, the LED Intelligent Light will illuminate green,
indicating that the Charging Stand is in standby mode.
5
Phone Without Wireless Charging
If your phone does not support the Qi® wireless charging standard, using the phone's USB
charging cable, plug one end into the phone, then plug the other end into the USB port on
the Charging Stand. The LED Intelligent Light will breathe blue, indicating that the
Charging Stand is actively charging a device. When charging is complete, the LED
Intelligent Light will illuminate green, indicating that the Charging Stand is in standby
mode.
Apple Watch
Place your Apple Watch® on the Apple Watch magnetic charger in the Original Charger
Card Watch Charging Area on the Charging Stand.
AirPods
Place your AirPods® in their charging case, then place the charging case on the Charge
AirPods Area on the Charging Stand. The LED Intelligent Light will breathe blue, indicating
that the Charging Stand is actively charging a device. When charging is complete, the LED
Intelligent Light will illuminate green, indicating that the Charging Stand is in standby
mode.
LED INDICATIONS
LED Intelligent Light
Description
Solid Green
The Charging Stand is in standby mode.
Breathing Blue
The Charging Stand is actively charging a device.
Flashing Blue and Green
A foreign object has been detected on the charging area or
the phone is misaligned.
6
COMPATIBLE DEVICES
The following devices are known to be compatible with the 3-in-1 Wireless Charging Stand.
Other devices may be compatible. Newer devices from the named brands will most like be
compatible. Note that any device with USB charging can be charged when plugged into
the USB port on the Charging Stand.
Phones
Apple®: iPhone® 13, iPhone 13 Pro, iPhone 13 Pro Max, iPhone 13 Mini, iPhone 12, iPhone 12
Pro, iPhone 12 Pro Max, iPhone 12 Mini, iPhone 11, iPhone 11 Pro, iPhone 11 Pro Max,
iPhone XS, iPhone XR, iPhone XS MAX, iPhone X, iPhone 8, iPhone 8Plus
Samsung®: Galaxy S®21, Galaxy S21 Plus, Galaxy S20, Galaxy S20+, Galaxy S10, Galaxy S10+,
Galaxy S9, Galaxy S9+, Galaxy S8, Galaxy S8+, Galaxy S7, Galaxy S7 Edge, Galaxy S6
Edge Plus, Galaxy Note® 10, Galaxy Note® 10+, Galaxy Note® 9, Galaxy Note® 8,
Galaxy Note® 7
Google™: Pixel™3, Pixel 3XL
Huawei®: P30 Pro, Mate 20 Pro, Mate 20 RS Porsche Version, Mate RS Porsche Version
Xiaomi: Mix 2s, Mix 3
Watches
Apple: Apple Watch® series 7, Apple Watch series 6, Apple Watch series SE, Apple Watch
series 5, Apple Watch series 4, Apple Watch series 3, Apple Watch series 2
Earphones
Apple: AirPods® Pro, AirPods 3, AirPods 2, AirPods 1
7
TECHNICAL SUPPORT
Monoprice™ is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website www.monoprice.com
support times and links.
To download the latest drivers, firmware, manuals, etc., go to www.monoprice.com and
type the P/N into the search bar. If available, support files are linked at the bottom of the
product page.
SPECIFICATIONS
P/N
43794
Input Connection
USB Type-C®
Input Power
5 VDC, 3A or 9 VDC, 2A or 12 VDC, 1.5A
Phone Output Power
15W or 10W or 7.5W or 5W
Apple Watch® Output Power
2.5W
Earphones Output Power
2.0W
Phone Wireless Charging Distance
≤ 8mm
Dimensions
7.2" x 4.3" x 3.6" (184 x 109 x 92 mm)
8
REGULATORY COMPLIANCE
Notice for FCC
FCC ID: 2A4XQ-V5
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Modifying the equipment without Monoprice's authorization may result in the equipment
no longer complying with FCC requirements for Class B digital devices. In that event, your
right to use the equipment may be limited by FCC regulations, and you may be required to
correct any interference to radio or television communications at your own expense.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
9
