MONSTER MOBILE MST13006 User manual
MST13006 11/07/16
Complies with ASME PALD/2009 Safety Standard
SPECIFICATIONS
Low Height.............................................................................9.06"
Ram Travel .............................................................................4.75"
Screw Adjustment..................................................................4.13"
Max. Height..........................................................................17.94"
Handle Length...........................................................................48"
Overall Length......................................................................22.38"
Overall Width.............................................................................11"
Weight.................................................................................... 77 lb
22 TON AIR/HYDRAULIC
TRUCK JACK
OWNERS MANUAL
MST13006
MST13006 2 11/07/16
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
IMPORTANT: READ THESE INSTRUCTIONS BEFORE OPERATING
BEFORE USING THIS DEVICE, READ THIS MANUAL COMPLETELY AND THOROUGHLY, UNDERSTAND ITS OPERATING
PROCEDURES, SAFETY WARNINGS AND MAINTENANCE REQUIREMENTS.
It is the responsibility of the owner to make sure all personnel read this manual prior to using the device. It is also the responsibility of
the device owner to keep this manual intact and in a convenient location for all to see and read. If the manual or product labels are lost
or not legible, contact Monster for replacements. If the operator is not uent in English, the product and safety instructions shall be
read to and discussed with the operator in the operator's native language by the purchaser/owner or his designee, making sure that
the operator comprehends its contents.
THE NATURE OF HAZARDOUS SITUATIONS
The use of portable automotive lifting devices is subject to certain hazards that cannot be prevented by mechanical means, but only
by the exercise of intelligence, care, and common sense. It is therefore essential to have owners and personnel involved in the use and
operation of the equipment who are careful, competent, trained, and qualied in the safe operation of the equipment and its proper
use. Examples of hazards are dropping, tipping or slipping of loads caused primarily by improperly securing loads, overloading, off-
centered loads, use on other than hard level surfaces, and using equipment for a purpose for which it was not designed.
METHODS TO AVOID HAZARDOUS SITUATIONS
• Read, study, understand and follow all instructions before operating this device.
• Inspect the jack before each use. Do not use jack if damaged, altered, modied, in poor condition, leaking hydraulic uid, or
unstable due to loose or missing hardware or parts. Make corrections before using.
• Lift only on areas of the vehicle as specied by the vehicle manufacturer.
• Wear eye protection that meets ANSI Z87.1 and OSHA standards (users and bystanders).
• Do not use jack beyond its rated capacity.
• This is a lifting device only. Immediately after lifting, support the vehicle with appropriate means.
• No alterations shall be made to this product.
• Use only on a hard level surface.
• Do not use saddle adaptors or saddle extenders between the stock lifting saddle and the load.
• Always lower the jack slowly and carefully.
• This product may contain one or more chemicals known to the State of California to cause cancer and birth defects or other
reproductive harm. Wash hands thoroughly after handling.
• Failure to heed these warnings may result in serious or fatal personal injury and/or property damage.
CONSEQUENCES OF NOT AVOIDING HAZARDOUS SITUATIONS
Failure to read this manual completely and thoroughly, failure to understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS,
MAINTENANCE INSTRUCTIONS and comply with them, and failure to comply with the METHODS TO AVOID HAZARDOUS
SITUATIONS could cause accidents resulting in serious or fatal personal injury and/or property damage.
WARNING: Indicates a hazardous situation
which, if not avoided, could result in death
or serious injury.
WARNING
WARNING
WARNING
WARNING
WARNING INFORMATION
MST13006 3 11/07/16
SETUP
PLEASE REFER TO THE EXPLODED VIEW DRAWING IN THIS MANUAL IN ORDER TO IDENTIFY PARTS.
1. Feed the black hose (#64) and orange hose (#63) coming out of the bottom of the handle assembly (#76) through the handle-1 (#52) while at
the same time lining up the hole in the handle-1 (#52) with the hole in the handle connector (#55). Secure them together with the screw (#54).
2. Thread two nuts (#53) all the way on the bottom of the tie rod (#50). Thread the bottom of the tie rod all the way inside the slotted pin
(#49). Now tighten one nut (#53) down on top of the slotted pin (#49) and tighten. Slip the spring (#51) down on the tie rod (#50). Insert the
tie rod (#50) through the bottom of the bracket that is welded to the handle-1 (#52) so that the spring is trapped between the bracket and
the nuts (#53) that are tightened against the slotted pin (#49). Compress the spring until the cross hole in the tie rod (#50) is visible on the
other side of the welded bracket and install the r-pin (#71) through the hole.
3. Thread another nut (#53) all the way on the tie rod (#56). Hold the handle lock (#58) down and away from the t-handle-2 (#60) while
simultaneously threading the tie rod (#56) nut onto the tie rod (#50).
4. Raise the handle lock (#58) up so the slotted pin (#49) does not come in contact with any of the three holes in the handle position
seat assembly (#7). Remove the screw (#73) from the handle socket (#11). Insert the handle-1 (#52) in the handle socket (#11) while
simultaneously inserting the slotted pin (#49) in the handle socket (#11) guide holes. Make sure the hole in the lower portion of the
handle-1 (#52) aligns with the threaded hole in the handle socket (#11) and secure them together with the screw (#73). Move the handle
up and down while simultaneously pulling the handle lock down so the slotted pin (#49) will engage with any of the three locking holes in
the handle position seat assembly (#7). Make sure the slotted pin will engage all three holes. It might be necessary to adjust the threaded
connection between tie rods (#50 and #56) in order to get proper engagement. After nal adjustment, tighten the nut (#53) to secure the
connection.
5. There are two air hoses that must be rmly inserted into the couplers (#48). The orange hose (#63) ts in the higher located coupler while
the black hose (#64) ts in the lower located coupler.
6. Install the air quick disconnect of your choice in the cross valve (#65). Put at least two wraps of pipe dope tape around the disconnect
threads before installation to prevent air leaks.
7. Install the bracket assembly (#72) on the handle-1 tube in the position as shown on the cover of the Owner’s Manual and secure the
adaptors in the bracket holes using the r-pins (#69).
8. Due to the vacuum release system design of this jack, the jack’s hydraulic system very rarely becomes air bound. Indication of an air
bound system is a ram that does not rise smoothly. In some extreme case of an air bound system, air can be purged by following this
procedure:
PURGING AIR FROM THE HYDRAULIC SYSTEM
a. Raise the ram (#32) to maximum height and then lower it all the way down following the activation directions on top of the handle.
b. Repeat step “a” several times until all air is purged from the system.
OPERATING INSTRUCTIONS
This is the safety alert symbol used for the OPERATING INSTRUCTIONS section of this manual to alert you to potential
personal injury hazards. Obey all instructions to avoid possible injury or death.
IMPORTANT: Before attempting to raise any vehicle, check vehicle service manual for recommended lifting surfaces.
1. Become familiar with the identication and function of the operating jack components.
a. The ram
(#32)
is the shaft that comes out of the jack when you rotate the air lever to the right.
b. The ram
(#32)
is equipped with an extension screw which can be unscrewed to extend from the ram if there is not enough hydraulic
stroke to raise the load to the desired height. If additional height is required, extension adapters can be inserted in the hole on top of
the extension screw.
c. Larger diameter saddles can be inserted in the extension screw when requiring a larger diameter saddle surface.
2. Chock the vehicle's tires that will not be lifted off the ground prior to lifting the vehicle and if available, apply the emergency brake or any
other method of braking.
3. Position the jack at the designated lift point. Estimate the required ram travel to raise the vehicle to the desired height. If the desired
vehicle height exceeds the entire ram travel, unscrew the extension screw to make up the difference and add an extension adapter if
necessary.
4. Lock the handle in a position that will not interfere with the vehicle when raised or lowered. Keep the handle in that locked position until
the work is completed and you are ready to remove the jack from use.
5. With the jack in the lowered position, push the jack under the vehicle. IMPORTANT: Use the vehicle manufacturer's recommended lifting
procedures and lifting points before lifting loads.
6. In most cases 100 psig input air pressure (do not exceed 200 psig) will lift the maximum capacity load not to exceed 22 tons. Rotate the
air lever to the right until the top of the ram comes close to the designated lift point. Make sure the designated lift point is at, parallel
to the ground and free from grease, any kind of lubricant, and debris. Proceed with pumping the jack in order to lift the vehicle to the
desired height. During lifting, inspect the position of the jack in relation to the ground and the ram in relationship to the load to prevent any
unstable conditions from developing. If conditions look like they are becoming unstable, slowly lower the load and make appropriate setup
corrections after the load is fully lowered.
7. When the vehicle or load is lifted to its desired height, immediately place safety support stands (jack stands) in their designated
locations and adjust the stands' support columns up as close to the designated vehicle support points as possible. Although jack
stands are individually rated, they are to be used in a matched pair to support one end of the vehicle only. Stands are not to be used
to simultaneously support both ends or one side of a vehicle. Rotate the air lever to the left to lower the vehicle onto the safety support
stands (jack stands). Make sure the vehicle is safely supported by the safety support stands' (jack stands) saddles and not the locating
lugs of the saddles. Inspect the relationship of the safety support stands (jack stands) with the ground and the safety support stand (jack
stand) columns and saddles with the vehicle to prevent any unstable conditions. If conditions look unstable, rotate the air lever to the right
to raise the vehicle off the safety support stands (jack stands). Make the appropriate setup changes and slowly and carefully lower the
vehicle onto the safety support stand saddles.
8. After the work is done, rotate the air lever to the right until the jack is high enough to remove the vehicle or load from the safety support
stand saddles. Be sure load is stable. If it is not, lower load back onto safety support stands. Make appropriate setup corrections and
repeat the step again. Remove the safety support stands from under the vehicle, being very careful not to move the vehicle.
9. Rotate the air lever to the left to lower the vehicle or load down to the ground.
MST13006 4 11/07/16
PREVENTATIVE MAINTENANCE
This is the safety alert symbol used for the PREVENTATIVE MAINTENANCE section of this manual to alert you to
potential personal injury hazards. Obey all instructions to avoid possible injury or death.
IMPORTANT: The number one cause of jack failure in air/hydraulic jacks is dirt and moisture in the air motor and/or hydraulic system.
The shop air supply should be equipped with water and dirt lter traps that should be emptied or cleaned according to a monthly
maintenance schedule. An in line oil lubricator will extend the life of air/hydraulic jacks. Inoperable jacks caused by poorly equipped or
maintained shop air systems are not eligible for warranty consideration. Contaminants can also enter the air/hydraulic system when
the shop air line is disconnected from the jack air line and the line is dropped on the oor. Contaminants in the air couplers, once
reconnected, will be driven into the system.
1. Always store the jack in a well protected area where it will not be exposed to inclement weather, corrosive vapors, abrasive dust, or
any other harmful elements. The jack must be cleaned of
water, snow, sand, grit, oil, grease or other foreign matter before using
.
2. The jack must be lubricated periodically in order to prevent premature wearing of parts. A general purpose grease must be applied
to the threads on the extension screw. Do not lubricate any portion of the lift saddle and make sure the saddle is free from grease,
any kind of lubricant, or debris before using the jack. Jacks found to be defective due to worn parts resulting from inadequate or no
lubrication are not eligible for warranty consideration.
3. It should not be necessary to rell or top off the reservoir with hydraulic uid unless there is an external leak. An external leak
requires immediate repair which must be performed in a dirt-free environment by qualied hydraulic repair personnel who are
familiar with this equipment. Authorized Service Centers are recommended. IMPORTANT: In order to prevent seal damage and jack
failure, never use alcohol, hydraulic brake uid, or transmission oil in the jack. Use hydraulic jack oil, Chevron Hydraulic Oil AW ISO
32 or its equivalent Unocal Unax AW 150.
4. Every jack owner is responsible for keeping the jack label clean and readable. Use a mild soap solution to wash external surfaces
of the jack but not any moving hydraulic components.
5. Inspect the jack before each use. Do not use the jack if any component is cracked, broken, bent, shows sign of damage or leaks
hydraulic uid. Do not use the jack if it has loose or missing hardware or components, or is modied in any way. Take corrective
action before using the jack again.
6. Do not attempt to make any hydraulic repairs unless you are a qualied hydraulic repair person that is familiar with this equipment.
TROUBLESHOOTING
PROBLEM: UNIT WILL NOT LIFT RATED LOAD.
ACTION: Purge air from hydraulic system by following procedure under SETUP.
PROBLEM: UNIT WILL NOT SUSTAIN RATED LOAD OR FEELS “SPONGY” UNDER RATED LOAD.
ACTION: Purge air from hydraulic system as above.
PROBLEM: UNIT WILL NOT LIFT TO FULL HEIGHT.
ACTION: Purge air from hydraulic system as above or check oil level in reservoir.
PROBLEM: UNIT STILL DOES NOT OPERATE.
ACTION: Contact your place of purchase for details on handling warranty.
MST13006 5 11/07/16
Monster warrants that all and jacks and service related equipment will be free from defects in material and workmanship for a period
of 2 years following the original date of purchase. This warranty is extended to the original retail purchaser only. If any jack or
service-related item proves to be defective during this period, it will be replaced or repaired, at Monster’s option, without charge.
This warranty does not apply to damage from accident, overload, misuse or abuse, nor does it apply to any equipment which has
been altered or used with special attachments other than those recommended. This warranty does not cover repairs made by
anyone who is not a Monster Professional Lifting Equipment Authorized Repair Center.
All other jacks or service-related equipment will be replaced or repaired at Monster’s option during the 2 year warranty period.
During the 2 year warranty period, all alleged defective products must be shipped, freight prepaid, along with proof of date-of-
purchase, to your nearest Monster Professional Lifting Equipment Authorized Warranty Center. Be certain to include your name,
address and phone number along with proof-of-purchase information, and a brief description of the alleged defect. The product will
be returned to the customer, freight prepaid.
Many alleged defectives may simply be handled by calling your nearest Service Center for parts. See pages 18-20 for a listing of
authorized warranty service centers.
In no event shall Monster be liable for incidental or consequential damages. The liability on any claim for loss or damage arising out
of the sale, resale or use of a jack or related service equipment, shall in no event exceed the purchase price. SOME STATES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION
MAY NOT APPLY TO YOU.
THIS WARRANTY IS THE SOLE AND EXCLUSIVE WARRANTY PROVIDED IN CONNECTION WITH THE SALE OF MONSTER
PROFESSIONAL LIFTING EQUIPMENT. ALL OTHER WARRANTIES, INCLUDING ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXCLUDED.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE
TO STATE.
WARRANTY HANDLING PROCEDURES & GUIDELINES MONSTER LIFTING
MST13006 6 11/07/16
EXPLODED DRAWING
22 TON AIR/HYDRAULIC
TRUCK JACK
MST13006
MST13006 7 11/07/16
*Available in MS13006HRK - Hydraulic Repair Kit
Only numbers identified by Part No. are available separately.
PARTS LIST
REF. # PART # DESCRIPTION QTY. REF. # PART # DESCRIPTION QTY.
1 Bolt 8 41 Block 2
2 Bolt 2 42 MS1300642 Coupler 4
3 Bolt 4 43 MS1300643 Coupler 1
4 MS1300604 Nut 2 44 Short Orange Hose 1
5 MS1300605 Washer 2 45 MS1300645 Short Black Hose 1
6 MS1300606 Wheel 2 46 MS1300646 Orange Hose 1
7 Handle Position Seat Assy 1 47 Coupler 1
8 Base Plate 1 48 Coupler 2
9 Left Side Plate 1 49 Slotted Pin 1
10 Right Side Plate 1 50 Tie Rod 1
11 MS1300611 Handle Socket 1 51 * Spring 1
12 MS1300612 Cover Plate 1 52 Handle-1 1
13 Bolt 4 53 Nut 7
14 Pump Body Welded Components 1 54 Screw 2
15 MS1300615 Connecting Block Assembly 1 55 Handle Connector 1
16 Screw 2 56 Tie Rod 1
17 Copper Washer 2 57 Pin 1
18 * Spring 1 58 Handle Lock 1
19 * Steel Ball 3 59 Screw 2
20 Screw 4 60 Handle-2 1
21 * O-Ring 4 61 Screw 2
22 * Steel Ball 1 62 Handle Sleeve 2
23 * Copper Ring 1 63 MS1300663 Orange Hose 1
24 * Steel Ball 1 64 MS1300664 Black Hose 1
25 Regulating Ball Seat 1 65 MS1300665 Cross Valve & Air Lever 1
26 * Spring 1 66 MS1300666 Adaptor 1
27 Screw 1 67 MS1300667 Adaptor 1
28 Screw 1 68 MS1300668 Adaptor 1
29 MS1300629 Release Plate 1 69 MS1300669 R-Pin 3
30 MS1300630 Release Valve 1 70 U Bolt 2
31 MS1300631 Air Motor 1 71 R-Pin 1
32 MS1300632 Ram 1 72 Bracket Assembly 1
33 Nylon Washer 1 73 Screw 1
34 Washer 1 74 MS1300674 Steel Ball Block Slice 1
35 * O-Ring 1 75 O-Ring 1
36 MS1300636 Ring For Ram 1 76 MS1300676 Handle Assembly Complete 1
37 * O-Ring 1 77 MS1300677 Bracket Assembly and Hardware 1
38 * O-Ring 1 78 MS1300678 Air Lever 1
39 Circlip 1 Not Shown MS13006LK Product Label Kit 1
40 Oil Plug 1
22 TON AIR/HYDRAULIC
TRUCK JACK
MST13006
Table of contents
Other MONSTER MOBILE Jack manuals
