iCarPlay®Direct Connect 2000
User Guide & Warranty Information
Manuel utilisateur et informations
sur la garantie
Guía del usuario e información de garantía

ENGLISH
Technical Specifications
•Input: 12 VDC
•Output: 5 VDC at 2.1 Amps for 10 Watts of Total Power

ENGLISH
iCarPlay®Direct Connect 2000 Features
•Direct Cable Connection
1m (3.28ft) cable with line-level audio output for
superior sound quality
•10 Watts of Total Power
For faster charging of mobile devices, like iPad*
•Convenient Playback Control
Built-in controls for easy operation
• Smart Digital Charger
™Technology
Reduces current when charge is done
•Built-In Cable Manager
Eliminates tangles and clutter
*Some devices limit charging speed

ENGLISH
iCarPlay®Direct Connect 2000 Features
(cont.)
•Charges iPod, iPhone, or iPad
Car charger with 10 watt output quickly charges
iPod, iPhone, or iPad
•24K Gold Contacts
For maximum signal transfer and corrosion resistance
NOTE: Not all car audio systems feature an auxiliary port.
Please consult your car’s owner’s manual.

ENGLISH
Installing iCarPlay®Direct Connect 2000
1. Connect to Power
Simply plug into your car’s 12V cigarette lighter adapter.
Be sure that it is pushed in as far as it will go.
(1)

ENGLISH
Installing iCarPlay®Direct Connect 2000
(cont.)
2. Connect to Auxiliary Port
NOTE: iCarPlay Direct Connect 2000 features a spool-style
cable management system, which can be used to adjust the
length of the 3.5 mm auxiliary jack cable.
a. Twist iCarPlay Direct Connect 2000 until the
cable management spool is facing upward
and easily accessible.
b. Wind the 3.5 mm auxiliary cable around
the spool, leaving enough cable to reach your
car audio system’s auxiliary port. Push the
cable into clip.
c. Plug the 3.5 mm jack into your car audio
system’s auxiliary port.

ENGLISH
(b)
(a)
(c)

ENGLISH
Connecting your iPod,
iPhone, or iPad to iCarPlay
Direct Connect 2000
•Connecting your iPod, iPhone, or iPad gives you audio
over your car’s speakers, charging, and playback
control, using the iCarPlay Direct Connect 2000’s
control pad.
•To connect, simply plug in the 30-pin dock connector
into your iPod, iPhone, or iPad.
NOTE: Be sure that your car audio system’s output is set
to auxiliary. Consult your audio system’s owner’s manual.

ENGLISH
Controlling iPod, iPhone, or
iPad Playback from iCarPlay
Direct Connect 2000
The control pad on iCarPlay Direct Connect 2000 controls
the playback on a connected iPod, iPhone, or iPad.
[!] DO NOT BECOME DISTRACTED BY THIS DEVICE.
USE ONLY WHEN IT’S SAFE TO DO SO. PLEASE KEEP
YOUR EYES ON THE ROAD WHILE DRIVING.

ENGLISH
Controlling iPod, iPhone, or
iPad Playback from iCarPlay®
Direct Connect 2000 (cont.)
•Play/Pause
-Push and release to pause.
-Repeat to resume play.
•Next/Previous track
-Push and release to skip to the next track.
-Push and release to play the previous track.

ENGLISH
•Scan forward/back
-Push and hold to scan forward through a track.
Release to resume normal playback.
-Push and hold to scan backward through a track.
Release to resume normal playback.
•Go to playlist
-Press and release NEXT to go to the next playlist.
-Press and release PREV to go to the previous playlist.

ENGLISH
LIMITED WARRANTY FOR CONSUMERS
Monster Cable Products, Inc., 455 Valley Drive, Brisbane,
CA 94005, USA, [PLEASE NOTE THAT MONSTER DOES
NOT ACCEPT PRODUCTS SHIPPED TO THIS ADDRESS –
FOLLOW INSTRUCTIONS IN “HOW TO MAKE A CLAIM”
BELOW] [phone] (“Monster”) extends You
this Limited Warranty. Statutory or common law may
provide You with additional rights or remedies, which
shall not be affected by this Limited Warranty.
DEFINITIONS
“Adequate Use” means use of the Product (i) within a home
or dwelling, (ii) for private (as opposed to commercial) purposes,
(iii) in conformance with all applicable local, state or federal
law, code or regulations (including without limitation building
and/or electrical codes), (iv) in accordance with manufacturer
recommendations and/or instructions in the materials and
documentation that accompany the Product, and (v) if applicable,
with proper electrical grounding.

ENGLISH
“Authorized Dealer” means any distributor, reseller or retailer
that (i) was duly authorized to do business in the jurisdiction where
it sold the Product to You, (ii) was permitted to sell You the Product
under the laws of the jurisdiction where You bought the Product,
and (iii) sold You the Product new and in its original packaging.
“Formal Warranty Claim” means a claim made in accordance
with the section “Formal Warranty Claims” herein.
“Product” means a Product (i) that is listed in the Specifications
Table below, (ii) that You bought from an Authorized Dealer new
and in its original packaging, and (iii) whose serial number, if any,
has not been removed, altered, or defaced.
“Product Defect” means an inadequacy of the Product that
existed at the time when You received the Product from an
Authorized Dealer and that causes a failure of the Product
to perform in accordance with Monster’s documentation
accompanying the Product, unless such failure has been caused
completely or partly by (a) any use other than Adequate Use, (b)
transportation, neglect, misuse or abuse by anyone other than
Monster’s employees; (c) alteration, tampering or modification

ENGLISH
of the product by anyone other than a Monster employee;
(d) accident (other than a malfunction that would otherwise
qualify as a Product Defect); (e) maintenance or service of the
Product by anyone other than a Monster employee; (f) exposure
of the Product to heat, bright light, sun, liquids, sand or other
contaminants; or (g) acts outside the control of Monster, including
without limitation acts of God, fire, storms, earthquake or flood.
“Warranty Period” means the time period during which
Monster must have received Your Formal Warranty Claim. The
different Warranty Periods related to Product Defects are defined
in the Specifications Table below. The Warranty Period commences
on the date when You purchased or received (whichever occurs
later) the Product from an Authorized Dealer as evidenced by the
Authorized Dealer’s invoice, sales receipt or packing slip. If You do
not have written proof of the date of purchase or receipt, then the
Warranty Period commences three (3) months after the date when
the Product left Monster’s or its factory as evidenced by Monster’s
records. The Warranty Period ends after the time defined in the
Specifications Table has expired or after You have transferred
ownership of the Product, whichever occurs earlier. Also, You

ENGLISH
must call Monster and obtain a Return Authorization Number (as
described under “How to Make a Claim”) within two (2) months
after You discover a Product Defect (or should have discovered it,
if such Product Defect was obvious).
“You” means the first individual person that purchased the
Product in its original packaging from an Authorized Dealer.
This Limited Warranty does not apply to persons or entities that
bought the Product (i) in used or unpackaged form, (ii) for resale,
lease or other commercial use, or (iii) from someone other than an
Authorized Dealer.
SCOPE OF THIS LIMITED WARRANTY
Products. If a Product contained a Product Defect when You
bought it from an Authorized Dealer and Monster receives a
Formal Warranty Claim from You within two (2) months after
You discover such Product Defect (or should have discovered it,
if such Product Defect was obvious) and before the end of the
Warranty Period for Product Defects applicable to the affected
Product, then Monster will provide You with one of the following
remedies: Monster will (1) repair or, at Monster’s sole discretion,

ENGLISH
replace the Product, or (2) refund to You the purchase price You
paid to the Authorized Dealer for the affected Product if repair or
replacement is not commercially practicable or cannot be timely
made. NOTE: MONSTER DOES NOT ASSUME ANY LIABILITY FOR
ANY INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES
UNDER THIS LIMITED WARRANTY.
GENERAL PROVISIONS
Choice of Law/Jurisdiction. This Limited Warranty and any
disputes arising out of or in connection with this Limited Warranty
(“Disputes”) shall be governed by the laws of the jurisdiction
where You bought the Product.
Other Rights. THIS LIMITED WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS,
WHICH VARY FROM STATE TO STATE AND JURISDICTION TO
JURISDICTION, AND WHICH SHALL NOT BE AFFECTED BY THIS
LIMITED WARRANTY. THIS WARRANTY EXTENDS ONLY TO YOU
AND CANNOT BE TRANSFERRED OR ASSIGNED. If any provision
of this Limited Warranty is unlawful, void or unenforceable, that
provision shall be deemed severable and shall not affect any

ENGLISH
remaining provisions. In case of any inconsistency between the
English and other versions of this Limited Warranty, the English
version shall prevail.
REGISTRATION
Please register Your Product at MonsterCable.com.
Failure to register will not diminish Your warranty rights.
SPECIFICATIONS TABLE
Product Model Warranty Period for Product
iCarPlay®Direct Connect 2000 One (1) Year
FORMAL WARRANTY CLAIM
How To Make A Claim. In the event damage has occurred to
Products, You must follow these instructions: (1) Call Monster
within two (2) months after You discover a Product Defect (or
should have discovered it, if such Product Defect was obvious);
(2) Give a detailed explanation of how the damage occurred; (3)
Obtain a Return Authorization Number; (4) Return the Products,
shipping prepaid by You (to be refunded if You are entitled to a
remedy under the Scope of this Limited Warranty), to Monster

ENGLISH
for verification of damage, along with a copy of Your original
sales receipts and proof of purchase (UPC label or packing slip)
for such Products, the completed claim form, and printed Return
Authorization Number on the outside of the return package (the
claim form will include instructions for return).
Telephone Numbers. If you bought the product in the United
States, Latin America (Mexico 011-882-800-8989), or Asia Pacific
(China 400-820-8973), contact Monster Cable Products, Inc.
(455 Valley Drive, Brisbane, CA 94005) at 1 877 800-8989. If you
bought the product anywhere else, contact Monster Technology
International Ltd., Ballymaley Business Park, Ennis, Co. Clare,
Ireland. You can write or use one of the following telephone
numbers: Canada 866-348-4171, Ireland 353 65 68 69 354,
Austria 0800296482, Belgium 0800-79201,Czech Republic
800-142471, Denmark 8088-2128, Finland 800-112768, France
0800-918201, Germany 0800-1819388, Greece 00800-353-
12008, Italy 800-871-479, Netherlands 0800-0228919, Norway
800-10906, Russia 810-800-20051353, Spain 900-982-909,
Sweden 020-792650, Switzerland 0800834659, United Kingdom
0800-0569520.

ENGLISH
Further Proceedings. Monster will determine whether a
Product Defect existed. Monster may, at its discretion, direct You
to obtain a repair estimate at a service center. If a repair estimate
is required, You will be instructed on how to properly submit the
estimate and the resulting invoice to Monster for payment. Any
fees for repairs may be negotiated by Monster.
Timing. If You bring a Formal Warranty Claim and fully comply
with all terms and conditions of this Limited Warranty, Monster
will use its best efforts to provide You with a remedy within
thirty (30) days after receipt of Your Formal Warranty Claim
(if You reside in the United States – forty-five (45) days if You
reside elsewhere), unless obstacles outside Monster’s control
delay the process.
Ver.021710 – GLOBAL
©2003-2011 Monster Cable Products, Inc.
