Monte Carlo Fan Company 5GL52 Series Instruction manual

Owner’s Guide and Installation Manual
Attach sales receipt to this card and retain as your proof of purchase
DATE OF PURCHASE:
MODEL NUMBER:
RETAILER NAME:
RETAILER ADDRESS:
To re ister your fixture, please visit our website www.montecarlofans.com
5GL52XX Series Fan
Total fan wei ht
UL Model No. : AC-552
17.8 kgs
39.16 lbs

© 2011 Monte Carlo Fan Company 5/5/2012
2
WAR I G: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR I JURY TO PERSO S, OBSERVE THE FOLLOWI G
READ A D SAVE THESE I STRUCTIO S
Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (A SI/ FPA
70-1999), including fire-rated construction.
Use this unit only in the manner intended by the manufacturer. If you have any questions contact the manufacturer.
After making the wire connections, the wires should be spread apart with the grounded conductor and the equipment-grounding conductor
on one side of the outlet box and ungrounded conductor on the other side of the outlet box. The splices, after being made, should be
turned upward and pushed carefully up into the outlet box.
WARNING: Before you begin installing the fan, servicing or cleaning unit, Switch power off at Service panel and lock service disconnecting
means to prevent power from being switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a
prominent warning device, such as a tag, to the service panel.
Be cautious! Read all instructions and safety information before installing your new fan. Review the accompanying assembly diagrams.
When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.
Make sure the installation site you choose allows the fan blades to rotate without any obstructions. Allow a minimum clearance of 7 feet
from the floor to the trailing edge of the blade.
WARNING: To Reduce The Risk Of Fire, Electric Shock, or Personal Injury, Mount To Outlet Box Marked “Acceptable for Fan Support of
31.8 kg (70 lbs) or less” And Use Mounting Screws Provided With The Outlet Box.
CAUTION: For Compliance with Local Codes and Regulations, If Installing The Secondary Support Safety Cable in the U.S., Do ot Re-
move Knockouts In The Outlet Box. Mount the secondary support safety cable through the reserved nail/screw hole on the outlet box to
the building structure (or the ceiling joist).
WARNING: To reduce the risk of personal injury, do not bend blade holders during installation to motor, balancing or during cleaning. Do
not insert foreign object between rotating blades.
Attach the mounting bracket using only the hardware supplied with the outlet box.
WARNING: To reduce the risk of fire or electric shock, this fan must be installed with an isolating wall control/switch.
WARNING: To reduce the risk of fire or electric shock, do not use this fan with any solid state fan speed control device, or variable speed
control.
If this unit is to be installed over a tub or shower, it must be marked as appropriate for the application.
ever place a switch where it can be reached from a tub or shower.
The combustion airflow needed for safe operation of fuel-burning equipment may be affected by this unit’s operation. Follow the heating
equipment manufacturer’s guideline safety standards such as those published by the ational Fire Protection Association ( FPA), and the
American Society for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE) and the local code authorities.
CAUTION: To Reduce the Risk of Electric Shock, Disconnect the electrical supply circuit to the fan before installing the light kit.
All set screws must be checked and tightened where necessary before installation.
Customer Service
800-969-3347
Customer Service Center
7400 Linder Ave.
Skokie, IL 60077
www.montecarlofans.com
Tools Required for Assembly (not included): Electrical Tape, Phillips Screwdriver, Pliers, Safety Glasses,
Stepladder and Wire Strippers.

© 2011 Monte Carlo Fan Company 5/5/2012
3
Before you begin installing the fan, Switch power off
at Service panel and lock service disconnecting means
to prevent power from being switched on accidentally.
When the service disconnecting means cannot be
locked, securely fasten a prominent warning device,
such as a tag, to the service panel.
1
Remove Safety bar from mounting bracket by
loosing screws, sliding bar to side, and lifting it
off the 2 screws.
3
Warning-Risk of fire, electric shock, or personal
injury. The fan in this box may be either directly sup-
ported from a structural framing member of a build-
ing and/or may be mounted to an outlet box marked
acceptable for fan support of of 31.8 kg(70lbs) or
less. Most outlet boxes commonly used for the sup-
port of lumminaires may not be acceptable for fan
support and may need to be replaced. Consult a
qualified electrician if in doubt.
2OUTLET BOX METHOD
Remove the 6screws attaching the Mounting
neck the mounting plate. Retain the 6 screws
for re-assembly.
4
Remove keeper from pin and then
remove pin. Replace keeper in pin
and save.
9
Lift mounting neck to mounting Plate
and align screws.
7
Secure mounting neck to the mount-
ing plate with 6screws to become
a complete mounting bracket.
8
Secure mounting plate directly to a joist from
the buliding structure via the two knock out
holes on the outlet box. Use only the appropri-
ate wood screws and washers included with
your fan.
Cautio : Wood screws must go through into
the building joist.
Note:If Installing It In The U.S., Do Not Re-
move Knockouts In The Outlet Box
5
Outlet box
Mounting
late
Wood
Screws
BUILDING STRUCTURE METHOD
Install the mounting late to approved fan
brace and box combination use only the hard-
ware provided with the fan brace and box.
6FAN BRACE AND OUTLET BOX METHOD
For Installation in The U.S. only

© 2011 Monte Carlo Fan Company 5/5/2012
4
Insert downrod into yoke. Align hole
in the downrod with the hole in the
yoke. Insert cross pin through yoke
and downrod. Insert cotter pin in to
cross pin to secure.
Tighten yoke set screws securely and
evenly.
Loosen the 2 set screws in yoke for
downrod to slip into yoke.
10
14
12
13
Place canopy and yoke cover on
downrod. Thread leadwires through
the downrod.
11
Make wire connections to power source using
wire nuts provided. Make sure that no filiments
are outside of the wirenut. After making the
wire connections, the wires should be spread
apart with the grounded conductor and the
equipment-grounding conductor on one side of
the outlet box and ungrounded conductor on
the other side of the outlet box.
17
Hang assembled fan from the mounting bracket
installed to ceiling in previous step. Make sure
the fan is hanging straight. Rotate fan until the
tab on the Mounting bracket engages the slot
on the Downrod Ball. This must be done to
prevent the fan body from rotating when the
blades are in motion.
Re-install safety bar removed in
step. 3 by placing safety bar on
screws, sliding into place, and tight-
ening the 2 screws.
15
For pullchain controls, follow diagram above.
Make sure that all exposed wiring is secured
inside wire nuts. Note: Wires from house may
vary in color and may not include ground wire.
After wiring is complete, gently push wires into
junction box with wire nuts pointing upward.
Refer to point 3 of safety tips.
18 House Fan
Black
White
Green
Black
White
Green(downrod)
Green(Bracket)
Blue
For Canadian installation and for USA fan and light
kit ombinations over 35 lbs, in both flush and
downrod modes the safety able must be installed
into the house stru ture beams using 3” lag
s rews, washers and lo k washers provided. Make
sure that when the safety able is fully extended
the lead wires are longer than the able and no
stress is pla ed on the lead wires.
Note:If Installing The Se ondary Support Safety
Cable in the U.S., Do Not Remove Kno kouts In
The Outlet Box.
16 Safety able installation
Safety Cable
Lag Screw
safety
able
3” lag
s rew
lo k
washer
washer

© 2011 Monte Carlo Fan Company 5/5/2012
5
Attach blade brackets to blades using
the blade bracket screws and wash-
ers provided.
20
Check the motor for plastic shipping stabilizer
tabs, and remove them if they are present.
Attach blade assembly to motor using the
motor screws and washers provided. Tighten
screws securely.
21
Remove switch housing screws.
22
After attaching blade; reinstall the switch hous-
ing using the three screws previously removed.
23
Loosen one and remove one preassem-
bled screw from mounting bracket. Save
screw. Lift canopy up, aligning its keyhole
slot with the preassembled screw on
mounting bracket and twist clockwise to
lock in place. Re-install the removed
screw and tighten all screws securely.
19

© 2011 Monte Carlo Fan Company 5/5/2012
6
1.Check main and branch circuit fuses or circuit breakers.
2.Check line wire connections to fan and switch wire connections in switch housing.
CAUTION: Make sure main power is turned off
1.Check to make sure all screws in motor housing are snug (not over tightened).
2.Check to make sure the screws which attach the fan blade holder to the motor are tight.
3.Check to make sure wire nut connectors in switch housing are not rattling against each
other or against the interior wall of the switch housing.
CAUTION: Make sure main power is turned off before entering switch housing.
4.Some fan motors are sensitive to signals from Solid State variable speed controls. DO
NOT USE a Solid State variable speed control.
5.Allow "break-in" period of 24 hours. Most noises associated with a new fan will disappear
after this period.
1.Make sure that the ridge of the canopy engages the notch in the downrod ball.
2.Check that all blades are screwed firmly into blade holders.
3.Check that all blade holders are tightened securely to motor.
4.Make sure that canopy and mounting bracket are tightened securely to ceiling junction box
and junction box is mounted firmly to ceiling joist.
5.Most fan wobble problems are caused when blade levels are unequal. Check this level by
selecting a point on the ceiling above the tip of one of the blades. Measure this distance
from blade tip to ceilng. Keeping measure within 1/8", rotate the fan until the next blade is
positioned for measurement. Repeat for each blade. If all blade levels are not equal, you can
adjust blade levels by the following procedure. To adjust a blade tip down, insert a washer
(not supplied) between the blade and blade holder at the screw closest to the motor. To
adjust a blade tip up, insert washer (not supplied) between the blade and blade holder at
the two screws farthest from the motor. Reverse the position of the washer if blades mount
from top of blade.
6.If blade wobble is still noticeable, interchanging two adjacent (side by side) blades can
redistribute the weight and possibly result in smoother operation.
1.Check wire from fan to make sure it is connected to hot wire from house.
2.Check for loose or disconnected wires in fan switch housing.
3.Check for loose or disconnected wires in light kit.
4.Check for faulty light bulbs.
CAUTION: Make sure main power is turned off before entering switch housing.
2. If fan sounds noisy:
1. If fan does not start:
3. If fan wobbles:
4. If light does not work:
Trouble Shooting
If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation,
or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults,
please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty
in installation, please call our Customer Service Center at the number printed on your parts list insert sheet.
Warning: Before servicing or cleaning unit, Switch power off at Service panel and lock service dis-
connecting means to prevent power from being switched on accidentally. When the service dis-
connecting means cannot be locked, securely fasten a prominent warning device, such as a tag,
to the service panel.
Trou le Suggested Remedy

Jul.2013 Update for CUL regulation
