Moons' TSM34P Series User manual

TSM
TSM34P Quick Setup Guide
Requirements:
You will need these items to setup the TSM34P:
• A 24-70VDC power supply
• A 12-48VDC auxiliary power supply (if needed)
• Asmallatbladescrewdriverfortighteningthe
connectors(included)
• APCrunningMicrosoftWindowsXP,orWindows7/8/10
withanRS-232serialcommunicationport,otherwisea
USBtoRS-232serialportconverterisneeded.
• Software:Step-ServoQuickTuner
• aprogrammingcable(included)
Step 1
Step 2
Install Software
• Downloadthe"Step-ServoQuickTuner"fromMOONS'website.
• Installthe“Step-ServoQuickTuner”softwareapplication.
• ConnectthedrivetothePCusingtheprogrammingcable.(See"CommunicationWiring"below)
• ChoosethecorrectCOMport.(See"ChoosingtheRightCOMPort"below)
• Runthesoftwareapplication.
• Applypowertothedrive.
• Thesoftwarewillcommunicatewiththedriveanddisplaythemodel&rmwareversion.
• Followthestepsinthe“Step-ServoQuickTuner”tosetup.
Connect the Power Supply
• Connectthemainpowersupply“+”terminaltothedrive”+”terminal&thepowersupply“-”terminaltothedrive“-”
terminalusing16to20-gaugewire.
• Connecttheauxiliarypowersupply“+”terminaltothedrive”AUX+”terminal&thepowersupply“-”terminalto
thedrive“AUX-”terminal
Becarefulnottoreversethewires.Reversingtheconnectionmayopentheinternalfuseandvoidthewarranty
• Ifaregulatedpowersupplyisbeingused,theremaybeaproblemwithregenerationthatcanbesolvedwiththe
useofaMOONS'RC880RegenerationClamp.SeeMOONS'websiteortheTSM34PHardwareManualformore
information.
NOTE:Whenusingtheoptionalauxiliarypowersupply,themainpowermustbeappliedpriortotheauxiliarypower.
• Onlyqualiedpersonnelshouldassemble,
install,operateormaintainthisequipment.
• Readallavailabledocumentationbefore
assemblyandoperation.
• Itisvitaltoensurethatallsystem
componentsareconnectedtoearthground.
• Thisproductcontainselectrostatically
sensitivecomponentsthatcanbedamaged
byincorrecthandling.
2016/02/06
RC880
TSM
V-
V+
AUX-
Vin
+
-
to Earth
Ground Main Power Supply
24-70VDC
AUX Power Supply
12-48VDC
AUX+
V-
V+
V-
V+
Vout
+
-
Safety Instructions:

2016/02/06
Step 3
Configure the drive
a)Applypowertothedrive
b)Thesoftwarewillrecognizethedrive&displaythe
model&rmwareversion
c)Setupdrivecontrolmode,andcontrolmodesettings
d)SetupI/Ofunction
Headquarters
No.168MingjiaRoadIndustrialParkNorth
MinhangDistrictShanghai201107,P.R.China 
Tel:[phone]4688
Fax:[phone]8682
Web:www.moonsindustries.com
E-mail:[email protected]
TSM34P
Quick Start Guide
Communication Wiring
RS-232 Communication
AllTSM34Pproductscomewitha1.5mcommunicationcable.Makesurethewiring
distancebetweentheTSM34PandthePCislessthan1.5m.
Connectthelargerconnector(DB9)ofthecabletothePCserialcommunicationport,
andthesmallersidetotheTSM34Pmotor(white4pinconnector).
NOTE:IfyourPCdoesnothaveanRS-232port,youwillneedaUSBtoserialport
converter.
PleasecheckMOONS'websiteforpurchaseinformation.
DonottrytopluginorremovethecommunicationcablewhendrivepowerisON.
a
c
b
d
Ifyouhaveanyquestionsorcomments,pleasecallMOONS'CustomerSupportat[phone],orvisitusonlineat
www.moons.com.cn.
GND
TXD
+5V
RXD
Openthe“DeviceManager”onthePC.IfthePChasanbuilt-inRS-232serialport,“Ports(COM&LPT)”will
bedisplayed.ConnectthePCanddrivewiththeincludedRS-232communicationcable.Choosetheconnected
COM(n)portintheStep-ServoQuickTunersoftware.
IfthePCdoesnothaveanRS-232serialport,aUSBtoRS-232serialportadapterwillbeneeded.
Openthe“DeviceManager”onthePC.Theremayormaynotbea"Ports”selection.Connecttheadapterto
thePC,thisUSBadapterCOMportshouldthenbedisplayed.ChoosethisnewCOM(n)portintheStep-Servo
QuickTunersoftware.
Choosing the Right COM Port
