Morphy Richards ESSENTIALS COOLWALL FRYER User manual

Essentials coolwall fryer
Please read and keep these instructions
getting the best from
your new fryer...
Hot oil
Don’t attempt to move the fryer while it is still hot -
wait three hours after frying for your fryer to cool
Steam
When in use, use oven gloves, and remove the lid
away from you to allow steam to escape
Replacement filters
The anti-odour filter requires replacing after approx
15 frying sessions - available direct from the helpline
www.morphyrichards.co.uk
DF45455M UK 7/5/04 11:13 AM Page 1

Important safety
instructions
The use of any electrical appliance
requires the following of basic common
sense safety rules.
Primarily there is danger of injury or death
and secondly the danger of damage to the
appliance. These are indicated in the text by
the two following conventions:
WARNING: Danger to the person!
IMPORTANT: Damage to the appliance! In
addition we offer the following safety advice.
Location
•Place the appliance on a horizontal, flat
and stable surface away from any heating
source and where it cannot be splashed
by water.
•Allow adequate air space above and on
all sides for air circulation.
•Do not use your fryer under cupboards or
shelves.
•Do not use outdoors.
Mains lead
•The mains lead should reach from the
socket to the base unit without straining
the connections.
•Do not let the cord hang over the edge of
the table or the counter and keep it away
from any hot surfaces.
•Do not let the lead run across an open
space e.g. between a low socket and
table.
Personal safety
•WARNING: Never attempt to move
your fryer until it is completely cool.
This can take up to three hours. Use the
handles at the sides when moving the
fryer.
•WARNING: To protect against
electric shock do not immerse in
water or other liquid.
•WARNING: The fryer must never be
immersed in water.
•WARNING: Do not lift the fryer by the
lid, lift the whole unit when moving.
•Unplug from outlet when not in use and
before cleaning. Allow to cool before
putting on or taking off parts, and before
cleaning the appliance.
•Never leave the fryer unattended when
connected to the electricity supply.
•Never lean over the fryer when in use.
•When opening the lid, stand back and
open the lid away from you to release
steam.
•Always use oven gloves when removing
or replacing lid during use.
Children
•Never allow a child to operate this
appliance. Teach children to be aware of
dangers in the kitchen, warn them of the
dangers of reaching up to areas where
they cannot see properly or should not
be reaching.
Treating scalds
•Run cold water over the affected area
immediately. Do not stop to remove
clothing, get medical help quickly.
Product safety
•Never connect the fryer to the electricity
supply without oil in the tank.
•Never operate with oil level below the
minimum mark (1.6 litres) or above the
maximum mark (1.8 litres).
Other safety considerations
•Do not operate with a damaged cord or
plug or after the appliance malfunctions
or has been damaged in any manner.
There are no serviceable parts in this
product. Contact our Morphy Richards
helpline for advice.
•The use of accessory attachments not
recommended by the manufacturer may
cause injuries.
•Do not use appliance for other than
intended use.
•Always dry food before frying eg. chips
which are too wet can cause the hot oil
to froth excessively.
2
DF45455M UK 7/5/04 11:13 AM Page 2

Electrical
requirements
Check that the voltage on the rating plate
of your appliance corresponds with your
house electricity supply which must be A.C.
(Alternating Current).
If the socket outlets in your home are not
suitable for the plug supplied with this
appliance, the plug should be removed and
the appropriate one fitted.
WARNING: The plug removed from
the mains lead, if severed, must be
destroyed as a plug with bared flexible
cord is hazardous if engaged into a live
socket outlet.
WARNING: This appliance must be
earthed.
Should the fuse in the 13A plug require
changing, a 13A BS 1362 fuse must be
fitted.
Features
⁄Removable filter cover and vents
¤Anti-odour carbon filter (under cover ⁄)
‹Thermostat light
›Vent release tab
fiRim
flBasket
‡Basket rest
·Basket handle
‚Handle locking button
„Lid handle
‰Locking latches
ÂVariable temperature control
3
A
⁄
fi
›
‰
fl
‹
Â
·
‚
„
‡
DF45455M UK 7/5/04 11:13 AM Page 3

Lid operation
To ensure safe and easy removal, turn
anti-clockwise using the handles on top of
the lid, then lift using the centre handle B.
WARNING When in use, steam may
be emitted from the edge of the lid or
from the vents in the lid. Stand back as
there may be a build up of steam.
To replace the lid, position it using the
centre handle with the vents away from you
at the back, align the arrows and turn
clockwise using the side handles until it is
locked firmly in position.
•The centre handle should only be used to
lift and replace the lid.
Preparing for the
first time
Turn to the section ‘Emptying, cleaning’,
and clean the fryer thoroughly, to remove
any manufacturing residues, dust etc.
Filling
IMPORTANT: Do not connect the fryer to
the electricity supply yet.
Remove the lid and take out the basket
and handle.
Pour oil into the tank up to the maximum
level indicated C(approx. 1.8 litres of oil).
•Use good quality liquid vegetable oil.
Don’t use butter, margarine or olive oil.
Cooking
1Replace the lid.
2Plug into the mains supply and switch on.
3The red heating light will illuminate.
4Set the variable temperature control to
the required setting, see ‘frying times and
temperature’ section.
The fryer is now preheating the oil, the
red heating light may go out and come on
once or twice. After approx 15 minutes the
oil is at the correct temperature and cooking
results will be all the better. The indicator
light may go off and on several times to
indicate that the thermostat is maintaining
the correct temperature.
5Remove the lid.
6Fix the handle to the basket by pulling
the lock button back and slide the handle
into the slot on the basket. Let go of the
lock button, so that the handle locks into
place and the bar is located D.
There are two methods of cooking in your
fryer; one general method for most food
types and another for home battered
products.
4
C
OPEN
CLOSED
B
DF45455M UK 7/5/04 11:13 AM Page 4

General cooking method
1Place the basket in the raised position by
locating the basket clip on the fryer rim.
The basket should always be in the
raised position when it is to be filled with
food.
2Place the food into the raised basket.
3Lower the basket into the oil and remove
the handle by pulling the lock button
towards you and lifting it out.
4Replace the lid.
•You can time the cooking process or
remove the lid occasionally to observe
progress.
5When the food is cooked, remove the lid,
attach the removable handle to the
basket and lift the basket out of the oil
and onto its raised position for a few
seconds to drain.
6Remove the basket and put the fried food
in a dish with fat absorbing kitchen paper.
7After use, disconnect from the mains
supply. Allow 3 hours for the oil to cool
down. Remove any condensation from
the underside of the lid with kitchen
paper and wipe any spilt oil from the fryer
body.
•You can store the basket in the oil.
8Replace the lid for storage.
Cooking home-battered foods
This method allows for the fact that if wet
batter is placed in the basket prior to
cooking the food may stick. This method of
cooking requires extreme care. Follow the
general cooking method, except as follows.
1Leave the basket in the down position.
2Coat the raw food in the batter and allow
it to drain slightly to get rid of the excess
coating.
3Very carefully and slowly lower the coated
food into the hot oil, using a suitable
implement or tongs. This allows the
batter to become solid and prevents it
sealing to the mesh of the basket.
WARNING: Take care as the oil may
spit as the food is added.
Cooking more
food?
If you want to cook more food right away,
wipe the underside of the lid with kitchen
paper, so that it soaks up any condensation.
This water must be removed before the lid is
replaced again, as water falling into the hot
oil will make it spit, possibly ejecting hot oil.
Getting the best
from your fryer
Oil
•Always ensure that you use a good
quality oil for deep frying. We recommend
liquid vegetable oils. Alternatively use
corn, groundnut or rapeseed oil. Avoid
mixing oils of different types and quality.
•Solid fat (lard) and solid oil can be used,
this should first be melted in a pan until
softened, then carefully transferred into
the fryer bowl.
•Change the oil when it becomes brown or
cloudy in colour.
•Change the oil after frying 15 times.
IMPORTANT: Do not switch the fryer on
until the fryer bowl is filled with oil or solid oil
lard.
5
D
Bar located
DF45455M UK 7/5/04 11:13 AM Page 5

Cooking
•Your food must always be completely dry
in order to avoid overflowing, to prolong
the use of the oil and to give a crisper
finish to the food.
•Cook one type of food at a time.
•Pieces of food should be of the same
size and thickness.
•Do not overload the basket as it may
cause a drop of the temperature that may
leave the food greasy.
•Cook your food thoroughly. Remember
that your food may begin to turn golden
brown before it is cooked through.
•Avoid leaving food to drain for too long in
the basket as the food may become soft
and lose its crunchiness.
•Select your cooking utensils with care.
Do not use utensils that may melt. Metal
utensils become hot and therefore should
have insulated handles.
Chips
Old potatoes are ideal for making chips.
Your chips should be evenly sized so that
they cook evenly. They should be rinsed in a
colander under a cold tap and dried using a
kitchen towel or absorbent paper. For best
results shake the basket at intervals to
ensure the chips get an overall browning.
•For best results we recommend no more
than 800g of frozen chips or 1000g of
fresh chips are fried.
Filter removal and
replacement
The lid is fitted with a replaceable
charcoal and grease filter which collects oil
from passing steam. The filter can be used
for about 15 frying sessions, it must then be
changed to maintain the effectiveness of the
odour filter system.
1Lift the filter panel from the lid by
pressing the tab and lifting upwards E,
remove the black charcoal and white
cotton filter and discard.
2Insert the new white grease filter first
then the black charcoal filter, replace
panel.
Contact the customer helpline for
replacement filter packs. Note the filter is a
consumable replacement item therefore it is
not covered under the guarantee.
Emptying, cleaning
WARNING: Cleaning should only be
carried out with the plug removed from
the socket. The fryer should have
completely cooled. Allow three hours
for the oil to completely cool.
1Remove the lid and wipe the underside to
remove condensation.
2Remove the filter from the lid E.
3Lift the fryer by the side handles and pour
out the oil through fine muslin or
absorbent paper placed in a suitable
funnel into a container.
4Wash the lid, filter cover, basket, basket
handle and the inside of the tank by hand
with hot soapy water.
5Clean the outside of the fryer with a
damp cloth and/or paper tissue.
IMPORTANT: Never immerse the fryer in
water.
6Dry all parts of your fryer thoroughly and
reassemble all parts.
6
E
DF45455M UK 7/5/04 11:13 AM Page 6

Frying times &
temperature chart
These frying times are intended as a
guide only and should be adjusted to suit
quantity or thickness of food and your own
taste.
Fresh cut chips 1kg
190ºC 10-12min
Frozen chips 800g
190ºC 12-15min
Fresh Cod or Haddock
300/400g 2 or 3 pieces
190ºC 8-10 min
Frozen Cod or Haddock
300/400g 2 or 3 pieces
170ºC 10-15 min
Frozen Plaice
1x150g piece
190ºC (5-6 min)
Whitebate just enough to cover base of
basket
190ºC 1-2 min
Scampi frozen in crumbs
170ºC (3-5 min)
Just enough to cover base
of basket
Beefburgers*
150 or 170ºC
2oz/55g 4 pieces 4-6 min
4oz/110g 2 pieces 5-10 min
Fresh or defrosted chicken portions in
crumbs* 2x200g pieces
170ºC 20-25 min
Frozen chicken portions in crumbs*
2x200g pieces
170ºC 25-30 min
Mushrooms 200g
190ºC 2-3 min
Weights stated are maximum advised.
*Chicken and Beef burgers can taint the
oil leaving a taste you may not want when
frying other foods, if so change the oil.
Helpline
If you have any difficulty with your
appliance, do not hesitate to call us. We’re
more likely able to help than the store from
where you bought it.
Please have the following information
ready to enable our staff to deal with your
query quickly:
•Name of the product
•Model number as shown on the
underside of the appliance
•Serial number.
7
DF45455M UK 7/5/04 11:13 AM Page 7

DF45455 M UK Rev 1 0104
The After Sales Division,
Morphy Richards Ltd, Mexborough,
South Yorkshire, England, S64 8AJ
Helpline (office hours)
UK 0870 060 2613
Republic of Ireland 1800 409119
Morphy Richards products are
intended for household use only
Morphy Richards has a policy of
continuous improvement in product
quality and design. The Company,
therefore, reserves the right to change
the specification of its models at any
time.
Two-year guarantee
•It is important to retain the retailers
receipt as proof of purchase. Staple
your receipt to this back cover for future
reference.
Please quote the following information if
the product develops a fault. These numbers
can be found on the base of the product.
Model no. Serial no.
All Morphy Richards Products are
individually tested before leaving the factory.
In the unlikely event of any appliance proving
to be faulty within 28 days of purchase it
should be returned to the place of purchase
for it to be replaced.
If the fault develops after 28 days and
within 24 months of original purchase, you
should contact the helpline number quoting
model number and serial number on the
product, or write to Morphy Richards at the
address shown. You will be asked to return
the product (in secure, adequate packaging)
along with a copy of proof of purchase.
Subject to the exclusions set out below
(1-5), the faulty appliance will then be
repaired or replaced and dispatched usually
within seven working days of receipt.
If for any reason this item is replaced
during the two-year guarantee period, the
guarantee on the new item will be calculated
from original purchase date. Therefore it is
vital to retain your original receipt or invoice
to indicate the date of initial purchase.
To qualify for the two-year guarantee the
appliance must have been used according to
the manufacturers instructions. For example
kettles should have been regularly descaled.
Morphy Richards shall not be liable to
replace or repair the goods under the terms
of the Guarantee where:
EXCLUSIONS
1The fault has been caused or is
attributable to accidental use, mis-use,
negligent use or used contrary to the
manufacturers recommendations or
where the fault has been caused by
power surges or damage caused in
transit.
2The appliance has been used on a
voltage supply other than that stamped
on the products.
3Repairs have been attempted by persons
other than our service staff (or authorised
dealer).
4Where the appliance has been used for
hire purposes or non-domestic use.
5Morphy Richards are not liable to carry
out any type of servicing work, under the
guarantee.
This guarantee does not confer any rights
other than those expressly set out above
and does not cover any claims for
consequential loss or damage. This
guarantee is offered as an additional benefit
and does not affect your statutory rights as a
consumer.
•This guarantee is valid in the UK and
Ireland only.
DF45455M UK 7/5/04 11:13 AM Page 8
