Mosselman iTRONIC User manual

Installation Manual
iTRONIC
Version: 160320
BMW M2/M3/M4 S55
Installation manual for BWM models:
Important note:
Premium Fuel (Octane 98 or higher*) is highly recommended for performance increase and reliability!
*Octane 93 or higher in Brazil, Canada and The United States
• F8x
• F8x
• F8x
• F8x
• F8x
• F8x
• F8x
M2 Competition
M3
M3 Competition
M4
M4 Competition
M4 GTS
M4 CS
1
• iTronic engine controller
• iTronic wiring harness
• Installation manual (digital)
• Installation hardware
Before starting the installation of this product, please read this installation manual
carefully to prevent possible damage or injuries.
!
Box Contents
2
1. Preparing for installation 3
2. Overview 4
3. Installation 6
4. Using the iTronic 17
Table of Contents
3
Preparing for Installation
1
1. Tools recommended for installation:
- Screwdriver set - Socket set
- T50 torx
2. Find a suitable place for installation, preferably inside, to prevent the open connectors from getting
wet.
3. Prepare an empty space to place the parts that you temporarily have to remove from your engine bay,
like the engine cover or other parts. Once installation is finished, this makes it easy to confirm visually
that all removed parts made their way back into the engine bay.
4. Do not make any changes or modifications to the iTronic Module, including changing the length
of the wiring harness.
5. Open the hood, make sure the ignition is switched off, then remove the key and close the doors.
Now wait 5 minutes before starting installation, this ensures the car has gone into sleep mode.
4
Overview
2.1
5
Overview
2.2
1.1
6
Installation
3
3.1 Remove the windshield covers.
• Remove the windshield covers located in fig. 1.1
• 1 & 8: Remove the rivets (fig. 1.2)
• 2 t/m 7: Turn the bolts 90º CCW (fig. 1.2)
1.2
2.1
3.2 Remove rubber mats.
• Remove the rubber mats and connectors located in fig. 2.1,
fig. 2.2 and fig. 2.3.
7
Installation
3
2.2 2.3
8
Installation
3
3.3 Remove the carbon strut brace. 3.1
• Remove the carbon strut brace located in fig. 3.1.
3.2 3.3
4.1
9
Installation
3
3.4 Remove the strut brace.
• Remove the strut brace located in fig. 4.1.
4.2
5.1
3.5 Remove plastic cover.
• Remove the plastic cover located in fig. 5.1.
10
Installation
3
5.2 5.3
6
7
Installation
3
3.7 Mass airflow sensor.
• Disconnect the connector from the mass airflow sensor.
• Attach the mass airflow sensor connector to the iTronic
wiring harness.
• Connect the connector of the iTronic wiring harness to the
mass airflow sensor.
3.6 Mass airflow sensor.
• Disconnect the connector from the mass airflow sensor.
• Attach the mass airflow sensor connector to the iTronic
wiring harness.
• Connect the connector of the iTronic wiring harness to the
mass airflow sensor.
11
8
9
Installation
3
3.9 Manifold pressure sensor.
• Disconnect the connector from the manifold pressure
sensor.
• Attach the manifold pressure sensor connector to the
iTronic wiring harness.
• Connect the connector of the iTronic wiring harness to the
manifold pressure sensor.
3.8 Connect the rail pressure sensor.
• Disconnect the connector from the rail pressure sensor.
• Attach the rail pressure sensor connector to the iTronic
wiring harness.
• Connect the connector of the iTronic wiring harness to the
rail pressure sensor.
12
10
11
Installation
3
3.11 CAN-bus connection - Connector.
The necessary CAN wires are located inside wiring
loom shown in fig. 11.
• Locate the CAN-bus wiring loom.
• Open the wiring loom.
3.10 Chargepipe pressure sensor.
• Disconnect the connector from the chargepipe pressure
sensor.
• Attach the chargepipe pressure sensor connector to the
iTronic wiring harness.
• Connect the connector of the iTronic wiring harness to the
chargepipe pressure sensor.
13
12
Installation
3
3.12 CAN-bus connection - Cables.
The necessary CAN wires are blue/red (high) and red (low),
and are located inside the wiring loom of the CAN-bus. The
wires are twisted in a pair.
The wires of the iTronic have the same colors, blue/red
(high) and red (low), and should be connected parallel on the
existing CAN wires.
• Connect the high and low wires from the canbus to the
iTronic wiring harness, using the red clip* provided in the box.
Shown in fig. 12.
• Close the wiring loom.
The blue/red wire = high *
The red wire = low
14
Installation
3
15
13
3.13 Supply Voltage.
• Remove the windshield cover to acces the supply voltage.
• Remove the round nut of the supply voltage, using a torx.
• Connect the red +wire from the iTronic wiring harness.
• Replace the round nut on the supply voltage, and tighten
sufficiently.
14
3.14 Ground.
• Remove the round nut of the ground point, using a torx.
• Connect the black -wire from the iTronic wiring harness.
• Replace the round nut on the ground point, and tighten
sufficiently.
Installation
3
16
15
3.15 Place iTronic.
• Use the double sided tape, provided in the box, and place
the iTronic on top of the fusebox cover (fig. 15).
• Connect the two main connectors from the wiring harness
to the iTronic.
The iTronic is installed.
• Secure the iTronic wiring harness using the tyraps provide in
the box. Make sure that it can’t reach hot or moving parts.
• Reassemble all the covers.
Using the iTronic
4
The iTronic can be controlled, after installing it into the car, with the steering wheel buttons.
This chapter will describe how to use all the iTronic.
17
Using the iTronic
4
1
2
4.1 Turn the iTronic On/Off.
Turn the iTronic On:
• Press and hold the RES button (fig. 1) for a couple of
seconds. When the iTronic is turned on the turn signals on
your dashboard will light up for 3 seconds. (fig. 2)
Note: The iTronic can only be controlled when the cruise control is turned off. When
using the cruise control the buttons will keep their normal functions.
Turn the iTronic Off:
• Press and hold the RES button (fig. 1) for a couple of
seconds. When the iTronic is turned off the turn signals on
your dashboard will light up for 0.5 - 1 second. (fig. 2)
Note: When the iTronic is turned off the car will run without any tuning. The iTronic
will save the on/off settings when the engine is turned off.
