Motec MVCD1000-x User manual

Mobile Vicinity Scout (MVS)
Operating instruction

2
Mobile Vicinity Scout (MVS)
Operating instruction
01.2018
Translation of original instruction
Manufacturer:
Motec GmbH
Oberweyerer Straße 21
65589 Hadamar-Steinbach
GERMANY
Tel.: [phone]
Fax: [phone]
[email protected]
www.motec-cameras.com
© Copyright 2018 by Motec GmbH
All rights reserved.
This document is protected by copyright. It supports the user in the safe and efficient use of the product.
Reproductions, translations and duplications in any form, including, but not limited to, require the written consent of the publisher.

3
Table of Contents
About this instruction...................................................... 4
Contact..............................................................................5
Design features .................................................................5
Target group of these instructions ...................................6
Applicable documentation ...............................................6
Declaration of Conformity ................................................6
Warranty...........................................................................7
Safety .............................................................................. 8
Introduction ......................................................................8
Intended use .....................................................................8
Inappropriate use .............................................................9
Foreseeable misuse ..........................................................9
Residual risks ..................................................................10
Presentation of warning signs ........................................11
Safety and warning labels on the system components ..12
Obligations of the operating company and the target
group...............................................................................12
Personal protective equipment must be worn...............12
System description ........................................................ 13
System overview.............................................................15
Components ...................................................................16
Video control module ................................................. 16
Camera........................................................................16
Monitor .......................................................................17
Type signs .......................................................................18
Operation...................................................................... 19
Switching on the system.................................................19
Split screen views ...........................................................20
Ultrasound sensors.........................................................21
Troubleshooting ............................................................ 22
Hardware ........................................................................22
Malfunctions during operation ......................................23
Ultrasound sensors.........................................................26
Maintenance ................................................................. 28
Cleaning the monitor......................................................28
Cleaning the camera lenses............................................28
Disposal and environmental protection ......................... 29
Disposal of the packaging...............................................29
Disposal of the product ..................................................29
Index …………………………………………………………………………..30

4
About this instruction
Thank you for your trust in Motec products!
•We develop and produce our products with the greatest
care.
•Our products are subject to continuous development.
Therefore, Motec GmbH reserves the right to make
changes to system components without prior
notification.
•If operated in terms with the product’s intended use,
these operating instructions help you to use the product
safely.
•These operating instructions apply only to the product
indicated on the cover sheet.
•We reserve the right to make changes to these
operating instructions based on technical
advancements.
•This operating manual is part of the scope of delivery.
•These operating instructions are valid starting from the
date of transport to final disposal. Compliance is
mandatory.
•Therefore, always keep the operating instructions in a
legible condition and store it in the cockpit. If the product
is sold, the document must remain with the product.
•The operating company must ensure that the operating
instructions are read and understood by all persons
before starting to work on the product.
•The Safety chapter provides an overview of all important
safety aspects. It provides a summary for the optimum
protection of the personnel as well as for the safe and
trouble-free operation of the product.
•The manufacturer cannot be held liable for damage
resulting from non-compliance with these operating
instructions.

5
Contact
If you have questions about product, the initial set-up or the
operation, or should the product not meet your expectations,
please contact us and we will be happy to assist you.
Motec GmbH
Service
Oberweyerer Str. 21
65589 Hadamar-Steinbach
GERMANY
Tel.:
[phone]
Fax:
[phone]
email:
[email protected]
Website:
www.motec-cameras.com
Design features
Various elements of the operating instructions are provided
with specified design features:
Text
Normal flow text
•
Lists
1.
Steps of action
This is the general hazard indicator.
It warns of dangers to life and limb.
NOTE
The signal word NOTE identifies additional information
about the device or how to use device.

6
Target group of these instructions
These operating instructions are intended only for trained
and authorized drivers / operators.
Only qualified personnel shall be permitted to proceed with
the installation and the electrical connections!
Applicable documentation
Compliance with the following applicable documentation is
mandatory:
•Installation guidelines and applicable standards.
•Technical specifications of the vehicle and the builder of
the vehicle body.
•Data sheets and operating instructions of the system
components.
•Motec System Bus (MSB 2.0) specification for systems
with CAN communication to the vehicle.
Declaration of Conformity
•As European distributor, we have followed the EU
Guidelines and legal rules & regulations and have
implemented a conformity assessment for all our
products. The assessment is compliant with the
requirements of the "Harmonised Standards".
•The CE label can be found on the product as well as on
the applicable product documentation.
•Upon request, we will gladly provide you the EU
Declaration of Conformity.

7
Warranty
•If a defect or error has been detected, a warranty claim
must be submitted immediately to your supplier or
service partner.
•The warranty expires also in all cases in which liability
claims cannot be made.
•If the system is misused or used incorrectly, liability
cannot be assumed for any damage that may occur.
•If the device is used outside of the EU, it is the
responsibility of the owner to ensure compliance with
the respective national rules and regulations.
•Any change to the system cannot guarantee compliance
with the conformity, and thus all warranties shall be null
and void.
•No liability can be assumed for damage and operational
malfunctions, which are described below:
•Non-compliance with the instructions.
•Unauthorised changes to the system.
•Operating mistake.
•Neglected maintenance tasks.
•Only qualified and trained personnel in consultation with
Motec shall be permitted to repair, maintain and adjust
the system.
•In the event of a malfunction, and if you cannot repair
the error, immediately contact the supplier or service
partner.
•The information, illustrations and descriptions in this
manual do not constitute any claims for the modification
of systems and components already delivered.
•The information contained in this manual describes the
features of the product without affirming such
characteristics.
•The information, data and notes provided in this manual
were up to date at the time of going to print.
•When using third-party components such as vehicle-
side navigation devices or multifunctional displays, the
liability claim shall become null and void.
•Motec assumes no liability for deviating aspect ratios,
vehicle restrictions and related forms of representation.
Detailed information can be found the relevant
installation/operating instructions.

8
Safety
Introduction
This chapter provides an overview of all important safety
aspects for the protection of the personnel, and for the safe
and trouble-free use of the product from installation to
disposal.
•Non-compliance with these directions and the safety
instructions contained in this manual can lead to
considerable hazards to the user and may damage the
product.
•The product is designed and built according to the state-
of-the-art technology and the recognized safety
guidelines and standards. The operation of the product
is safe.
Intended use
•The Motec MVS System is a driver assistance system
can only be operated with a its system limits.
•The device provides the driver with a 270°/360° all-
round view from a bird's-eye perspective. Images
provided by the wide-angle cameras that are installed
on both sides, the front and rear of the
vehicle/machinery capture the surroundings.
In order to obtain the desired images, the MVS System
must be installed and operated compliant with these
operating instructions.
The driver/operator shall be responsible for the safe
operation of the vehicle at all times. This obligation
applies in particular if personnel remain in the danger
zone of the vehicle/machinery.

9
Inappropriate use
Any use other than the application described in the Chapter
"Intended use" on page 8 and any use going beyond the
intended usage is considered an inappropriate use!
•The manufacturer is not liable for any damage resulting
from inappropriate use. The risk is borne solely by the
user/operating company.
•It is prohibited to change the system in any shape or
form.
•It is prohibited to operate the system by bypassing the
safety devices.
•It is prohibited to use components which are defect and
therefore jeopardise the safety of the system!
•The Motec MVS is not suitable for the protection of
persons in the sense of the applicable standards and
guidelines for machines and vehicles (Machinery
Directive 2006/42 / EU, DIN EN ISO 13849 and ISO
26262).
Foreseeable misuse
The following aspects describe a foreseeable misuse of the
system:
•Personnel who are not or who are insufficiently qualified
shall not be permitted to proceed with any tasks or the
operation of the system.
•Improper installation.
•Non-compliance with operating data and maintenance
intervals.
•Operation without or with damaged components, which
are intended for the safety of the persons and the
system.

10
Residual risks
Folge
Residual hazards may occur under the following
circumstances:
•If the system is not used as intended, if the system is
modified or altered improperly.
•If the system is operated improperly by untrained or
unskilled personnel.
•If the system is cleaned, serviced or maintained
improperly and/or if non-compliant with scheduled
service intervals.
The following residual hazards must also be observed:
•Electrical currents during assembly or cleaning tasks
may result in injury or death. Only trained specialist shall
be permitted to work on the electrical system and only if
all components are disconnected from the power
supply!
•When working in narrow spaces, there is an inherent
risk of crushing injuries as well as risk of cutting caused
by sharp edges and corners.
•Improper handling can damage the vehicle body,
components or cables.
•Any type of welding on tank components is prohibited!
•Non-compliance with the installation guidelines and the
technical specifications of the vehicle manufacturer and
the manufacturer of the vehicle body.
•Tree branches or other objects above the cameras are
not recorded! In this case, the use of the rear-view
mirrors or the assistance of a banksman is mandatory!
•The higher an object from the ground, the more this
object is displayed on the monitor as bending outward.
This representation, which is not true to scale, must be
taken into account by the driver.
•The display in the monitor is true to scale only on the
footprint of the vehicle and only in the undistorted
mode.
•The image quality decreases with corresponding
environmental conditions: In this case, a banksman
must be available during the manoeuvring of the
vehicle.
•However, the reality may slightly deviate from this
composed image. Objects outside the image cones are
not captured.
