Motion CM-01 User manual

MANUAL CM-01/02
CM-01
Li-ion battery powered tube motors
with pull operation
MANUAL CM-01/02
MOTION CM-01/02 LI-ION TUBULAR MOTOR

Happy programming
Favorite position
MOTION CM-01/02 LI-ION TUBULAR MOTOR
Pull Control
Operate with
pull control
Li-ion Battery
Integrated
lithium-ion battery
Motor features
Control options
Support
USB Rechargeable
Rechargeable with
micro USB
Wireless
Cable free
installation
Happy Programming
Dummy proof
programming using
pull control
Favourite Position
Preset a favourite
position
Video
How to install,
program and operate
rtube.nl/red983
CM-01/02
Tube motor
Li-ion battery powered tube motors
with pull operation

English
Conforms to
UL Std. 325
Certified to
CSA Std. C22.2#247
MOTION CM-01/02 LI-ION TUBULAR MOTOR
English
WARNING
Read the instructions carefully
before assembling and
using the product. Assembly
can be completed by non-
professionals. For indoor use
only.
Young children can strangle
themselves with the loop
of pull cords, chains and
tapes, and cords that operate
window coverings.
To avoid strangulation and
entanglement, keep cords out
of reach of young children.
Cords may ensnare a child’s
neck.
Move beds, cots and furniture
away from window covering
cords.
Do not tie cords together.
Make sure cords do not twist
together and form a loop.
Cleaning
Follow these general rules when cleaning the
outside of the device and its components:
Use a damp, soft, lint-free cloth. Avoid getting
moisture in openings.
Do not use aerosol sprays, solvents, alcohol,
or abrasives.
Service & Support
Do not perform repairs yourself. Do not attempt
to open the device or disassemble it. You run
the risk of electric shock and voiding the limited
warranty. No user-serviceable parts are inside.
Warranty Service
First follow the advice in this manual. If the
product appears to be damaged or does not
function properly, go to your local dealer for
instructions on how to obtain warranty service.
English

MOTION CM-01/02 LI-ION TUBULAR MOTOR
Important Safety instructions
WARNING: To reduce the risk of severe injury or
death, it is important to follow these instructions for
personal safety. Save these instructions.
Read and follow all installation instructions.
This appliance can be used by children aged
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved. Children should not play with
the appliance. Cleaning and user maintenance
should not be performed by unsupervised
children.
Do not allow children to play with fixed controls.
Keep remote controls away from children.
Frequently examine the installation for imbalance
and signs of wear or damage to cables and
springs. Do not use if repair or adjustment is
necessary.
This instruction manual is also available on the
website.
The drive shall be disconnected from its power
source during cleaning, maintenance and when
replacing parts.
The A-weighted emission sound pressure level of
the drive is equal to or less than 70dB(A).
Indoor and household use only.
Disconnect the drive from the supply or switch off
the automatic controls when maintenance, such
as window cleaning, is being carried out in the
vicinity.
When operating a biased switch, make sure that
other persons are kept away.
Do not operate when maintenance, such as
window cleaning, is being carried out in the vicinity.
The tube motor must only be supplied with safety
extra low voltage corresponding to the marking on
the appliance.
This appliance contains batteries that are non-
replaceable.
Important Installation instructions
WARNING: Important safety instructions. Follow all
instructions, since incorrect installation can lead to
severe injury.
This motor can only be used with soft material for
driven parts.
Hazardous unprotected moving parts of the drive
must be installed higher than 2.0m above the
floor or any other level surface that could provide
access to it.
Install the actuating member of a manual release
at a height less than 1.8m.
The actuating member of a biased switch is to be
located within direct sight of the driven part but
away from moving parts. It is to be installed at a
minimum height of 1.5m and not accessible to the
public.
The mass and the dimension of the driven part
must be compatible with the rated torque and
rated operating time.
Fixed controls have to be clearly visible after
installation.
The driven part must be compatible with the rated
torque (0.2N.m/0.65N.m) and rated operating
time (12min).
Minimum tube diameter: Ø25mm.
The drive is intended to be installed at a height
of at least 2.0m above the floor or any other
accessible level surface.
All-pole disconnection switches must be
incorporated in the fixed wiring in accordance with
the wiring rules.

EnglishEnglishEnglish
MOTION CM-01/02 LI-ION TUBULAR MOTOR
English

Click!
Click!
Click!
1
2
3
4
5
MOTION CM-01/02 LI-ION TUBULAR MOTOR
Charge before first use. (See step 17)
A green LED will flash.
The motor can be used during charging.
Installing the blind
Charge to activate the motor

8
6
7
MOTION CM-01/02 LI-ION TUBULAR MOTOR
Pull and hold the chain until the blind has
reached the bottom limit.
If the blind moves in the opposite direction,
release the chain and pull and hold again.
Adjust until the desired bottom limit
has been reached.
Save the position by pushing the button
until the blind moves up and down.
Pull and hold the chain until the blind has reached
the upper limit. If the blind moves in the opposite
direction, release the chain and pull and hold again.
Adjust until the desired
upper limit has been
reached
English
Set upper limit
Set bottom limit

9
10
11
MOTION CM-01/02 LI-ION TUBULAR MOTOR
Save the position by pushing the button until
the blind moves up and down.
Pull the chain shortly to start or stop the blind.
Pull the chain shortly to
start or stop the blind.
Operating the blind
Optional: set favourite position

12
13
14
MOTION CM-01/02 LI-ION TUBULAR MOTOR
Pull and hold the chain for approximately
7 seconds until the blind moves up and down.
Go to any position other than the saved
favourite position.
Hold the chain for 5 seconds
The blind moves to the favourite position.
English
Move to favourite position

16
15
MOTION CM-01/02 LI-ION TUBULAR MOTOR
The favourite position can only be deleted when
the blind is placed in the favourite position.
Hold the button for approximately 10 seconds.
After 5 seconds, the blind will move up and
down. Keep pushing the button until the blind
moves up and down again.
Repeat steps 6 - 9 to save new end limits.
Pull and hold the chain for approximately
7 seconds untill the blind moves up and down.
Go to step 11 to program a new favourite
position.
Delete end limits
Delete favourite position

17
18
18.1
MOTION CM-01/02 LI-ION TUBULAR MOTOR
Blinking red during
operation;
Charge the battery
Blinking green;
battery is charging
Continuously green;
battery is fully charged
English
Recharge battery
+or
Activate / deactivate the motor
Hold the program button and pull twice to activate or deactivate the motor.
The motor can also be activated by charging it with a micro USB cable.
To prevent the blind from getting damaged, the motor has a transport
mode that makes sure the blind will not be activated before installation.

MOTION CM-01/02 LI-ION TUBULAR MOTOR
Frequently Asked Questions
Problem Cause Solution
Motor is not responding.
Motor is in transport mode. Activate the motor. See step 18.
Motor battery is empty. Charge the motor. See step 17.
Motor LED flashes red. The battery of the motor is empty. Charge the motor. See step 17.
Motor is not charging. Charger is not plugged in or does
not work.
Try a different charger or make sure the
charger is plugged into the outlet.
Blind lowers too far. End limits are programmed
incorrectly. Reprogram end limits. See step 6 - 9.
Unable to program end
limits.
End limits have already been
programmed.
Reset the motor and reprogram end limits.
See step 16 and step 6-9.

MOTION CM-01/02 LI-ION TUBULAR MOTOR

MOTION CM-01/02 LI-ION TUBULAR MOTOR

Disclaimer:
© Copyright Coulisse
All rights reserved. No part of this publication may be reproduced,
stored in a retrieval system, or transmitted, in any form, by any
means, electronic, mechanical, photocopying, recording, digital or
otherwise without the written permission of the publisher.
Although this manual has been composed with the utmost
care, Coulisse B.V. does not accept any responsibility for damage
due to mistakes and/or faults in this manual.
Coulisse B.V. reserves the right to revise the manual and to revise
and/or change its content at any time, without obligation to
notify any person or entity of such revisions or changes.
The most recent version replaces older versions of this manual.
The most recent version is available at my.coulisse.com or by
contacting your Coulisse contact person.
We invite you to send remarks and comments about this manual
to Coulisse at [email protected].
For the latest information and updated
manuals, visit rtube.nl/cm-01
English
MOTION CM-01/02 LI-ION TUBULAR MOTOR

Happy programming
Favorite position
Pull-Steuerung
Bedienen mit
Pull-Steuerung
Li-ion-Batterie
Integrierte
Lithium-ion-Batterie
Motoreigenschaften
Steuerungsoptionen
Support
USB wiederaufladbar
Wiederaufladbar mit
Mikro-USB
Kabellos
Kabellose
Installation
Frohes
Programmieren
Idiotensicheres
Programmieren dank
Pull-Funktion
Lieblingsposition
Stellen Sie Ihre
Lieblingsposition ein
Video
Installation,
Programmierung und
Bedienung
rtube.nl/red983
CM-01/02
Rohrmotor
Li-ionbatteriebetriebene
Rohrmotoren mit Pullbetrieb
MOTION CM-01/02 LI-ION ROHRMOTOR

EnglishEnglish
Conforms to
UL Std. 325
Certified to
CSA Std. C22.2#247
MOTION CM-01/02 LI-ION ROHRMOTOR
Deutsch
Reinigung
Befolgen Sie bei der Reinigung des Systems und
der einzelnen Komponenten diese allgemeinen
Regeln:
Verwenden Sie ein feuchtes, weiches und
fusselfreies Tuch. Achten Sie darauf, dass
keine Feuchtigkeit in Öffnungen eindringt.
Verwenden Die keine Sprays, Lösungsmittel,
Alkohol oder Scheuermittel.
Service & Support
Führen Sie Reparaturen nie selbst durch.
Versuchen Sie nicht das System zu öffnen oder
auseinanderzunehmen. Sie riskieren einen
Elektroschock und setzen gegebenenfalls die
Garantie außer Kraft. Es befinden sich keine
durch den Benutzer zu wartenden Teile im
Inneren des Systems.
Garantieservice
Folgen Sie zunächst den Hinweisen dieser
Bedienungsanleitung. Sollte das Produkt
beschädigt sein oder nicht korrekt funktionieren,
wenden Sie sich bitte an einen Vertragshändler
vor Ort, um gegebenenfalls die Produktgarantie
in Anspruch zu nehmen.
ACHTUNG
Lesen Sie die Gebrauchs-
anweisung sorgfältig vor der
Montage und Verwendung des
Produkts. Montage kann durch
Nicht-Profis gemacht sein. Nur
für den Innenbereich.
Kleine Kinder können durch
Schlingen in Zugschnüren,
Ketten, Gurten und innen
befindlichen Schnüren zum
betätigen des Produktes
stranguliert werden.
Schnüre sind aus der reich-
weite von Kindern zu halten,
um Strangulierung und Ver-
wicklung zu vermeiden.
Der Hals eines Kindes kann in
Schnüre Verwickelt werden.
Betten, Kinderbetten und Mö-
bel sind Entfernt von Schnüren
für Fensterdekorationen auf-
zustellen.
Schnüre dürfen nicht mit-
einander verknüpft werden.
Es ist sicherzustellen, dass
sich Schnüre nicht verwickeln
und eine Schlinge bilden.

Click!
Click!
Click!
1
2
3
4
5
Vor dem ersten Start aufladen. (siehe Schritt 17)
Eine grüne LED blinkt.
Motor kann während des Ladens verwendet
werden.
Installation des Rollos
Aufladen, um den Motor zu starten
MOTION CM-01/02 LI-ION ROHRMOTOR

8
6
7
Ziehen und halten Sie die Kette, bis das Rollo
die gewünschte untere Grenze erreicht hat.
Wenn sich das Rollo in die entgegengesetzte
Richtung bewegt, lassen Sie die Kette los,
dann ziehen und halten Sie sie erneut.
Justieren, bis die gewünschte untere Grenze
erreicht ist.
Zum Einspeichern der Position Knopf gedrückt halten,
bis sich das Rollo nach oben und unten bewegt.
Ziehen und halten Sie die Kette, bis das Rollo die
gewünschte obere Grenze erreicht hat. Wenn sich das Rollo
in die entgegengesetzte Richtung bewegt, lassen Sie die
Kette los, dann ziehen und halten Sie sie erneut.
Justieren, bis die
gewünschte obere
Grenze erreicht ist.
Obere Grenze bestimmen
Untere Grenze bestimmen
MOTION CM-01/02 LI-ION ROHRMOTOR
Deutsch

9
10
11
MOTION CM-01/02 LI-ION ROHRMOTOR
Zum Einspeichern der Position Knopf gedrückt halten,
bis sich das Rollo nach oben und unten bewegt.
Kurz an der Kette ziehen, um das Rollo zu
starten oder zu stoppen
Kurz an der Kette ziehen, um das Rollo zu
starten oder zu stoppen
Bedienung des Rollos
Optional: Gewünschte Position einstellen
