Motorline professional SIGMA XA5 User manual

Rev. 2.0 15/09/17

9 This instruction booklet is exclusively dedicated to specialized staff
who are aware of the construction criteria and of the accident
prevention protection devices for motorized gates and doors
(according to the current regulations and laws).
1 .Before starting installation and operation or maintenance work, make
sure to cut off power supply.
2 The cabinet must be earthed. And an earth leakage breaker is nec-
essary on the power supply.
3 As for electric cable type and section, we suggest the use of appropriate
cabel according to the local regulations.
4 Do not change the original inside wiring.
5 If power failure, please switch off the power supply first, then open
the door and rotate the handle under the motor manually to open the
boom all.
6 Keep the automatic control (push-button, remote control, etc) out of
the reach of children. The control systems must be installed at a
minimum height of 1.5m from the ground surface.
7 Use transmitters only if you can see the gate.
8 It is forbidden to open the door or the cover of the cabinet when the
machine is working.
.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
NOTE: If the barrier is equiped with control unit MC1 from MOTORLINE ,the
installer should read control unit manual to know how to set additional functions
such as slow start and slow stop.

A. Technical specifications
Max boom length: According to model (Max.5m)
Power supply: 220V/50Hz 90W
R.P.M: 2800r/min
Time for up/down:3~6S
Max.5m

B. Installing and adjusting
1. Install the machine on theground
2. Install boom(Fig.2)
3.Adjust the spring's balance(Fig.3)
boom LENGTH
NUMBER OF SPRING SPRING LENGTH
3m 1 440mm
4m--5m 2 440mm
IMPORTANT:
The barrier is supplied with springs already balanced for the max. boom length (5m)
If the boom is smaller, you must adjust spring force in order to make the barrier stop along its
course when needed.
Procedure:
1º- Turning knob clockwise,disengage barrier (Fig.5)
2º- Move manually boom on opening direction 50cm in 50cm ,where without assistance it must
be fixed.In case of barrier movement you should give or remove spring force (Fig.3)
3º- Repeat the previous steps as many times as needed until boom stay completely balanced
4º-With spring completely balanced,close barrier manually
5º-Engage barrier ,turning knob anti-clockwise.

4.Adjust the limit position
Air wave switch
Barrier
Loop
Photocell
The BARRIERS limit switches, motor and control unit are already connected.
Only the photo cells, the loop detector and the supply voltage have to be connected .
C. Electrical safety devices(Fig.5)
Fig:5
Magnetics (B)Mechanical (A)
Barrier can be supplied with magnetic limits (B) , mechanicals limits (A) or both.
You must adjust first the mecanical ones (A) in order to make the desired route, adjusting then
magentic ones(B) for safety reasons.Since they are connected in serie with the mecanicals ,set
them to act soon after these.
