Motorline Mc61 Instruction Manual

V 1.1

REV. 07/2016

MC61

24AC + BAT - LAMP MOT LOCK

1 2 3 4 5 6 7 8 9 10

V+ FAP FCH

11 12 13 14 15

PUL BL DS

16 17 18 19

USER/INSTALLER MANUAL

A B

ENEN

STANDARDS TO FOLLOW

COMPONENTS CONNECTION TO THE CONTROL BOARD

01. SAFETY INSTRUCTIONS

TECHNICAL SPECIFICATIONS

03. CONTROL BOARD

02. CONNECTIONS SCHEME

PROGRAMMING REMOTE CONTROLS

ERASE REMOTE CONTROLS

04. REMOTE CONTROLS

Function’s board

PROGRAMMING AUTOMATIC CLOSING

OPENING AND CLOSING COURSE PROGRAMMING

ENABLE/DISABLE SERVICE DOOR

AUTOMATION FORCE PROGRAMMING

ENABLE/DISABLE CONDOMINIUM FUNCTION

ENABLE/DISABLE SAFETY PHOTOCELLS

INCREASE OR DECREASE DECELERATION

ENABLE/DISABLE FOLLOW ME

05. FUNCTIONS

INSTRUCTIONS FOR FINAL CONSUMERS/TECHNICIANS

06. TROUBLESHOOTING

00. CONTENT 01. SAFETY INSTRUCTIONS

INDEX STANDARDS TO FOLLOW

A B

ATTENTION:

Importance of the Manual:

• It is important for your safety that these instructions are followed.

• Keep these instructions in a safe place for future reference.

Responsibility:

• Electrocelos S.A. is not responsible for the improper use of the product, or other use than

that for which it was designed.

• Electrocelos S.A. is not responsible if safety standards were not taken into account when

installing the equipment, or for any deformation that may occur.

• Electrocelos S.A. is not responsible for insecurity and malfunction of the product when used

with components that were not sold by the them.

Mechanism use:

• This product was designed and manufactured strictly for the use indicated in this manual.

• This control board is not appropriate for inflammable or explosive environments.

• Any other use not expressly indicated may damage the product and / or can cause physical

and property damages, and will void the warranty.

• Do not make any changes to the automation components and / or their accessories.

• Central for indoor use with 230V connection.

• Keep remote controls away from children, to prevent the automated system from being

activated involuntarily.

• The customer shall not, under any circumstances, attempt to repair or tune the automatism.

Must call qualified technician only.

To Installer:

• The installer must have certified professional knowledge at the level of mechanical

assemblies in doors and gates and control board programmation. He should also be able to

perform electrical connections in compliance with all applicable regulations.

• The installer should inform the customer how to handle the product in an emergency and

provide him the manual.

A

24AC + BAT - LAMP MOT LOCK

1 2 3 4 5 6 7 8 9 10

V+ FAP FCH

11 12 13 14 15

PUL BL DS

16 17 18 19

COM

2 1 3 4 5 6 7



Transformer connections

Limit Switches Connections

Maneuvering board

Lock

STOP

Button PUL

02. CONNECTIONS SCHEME

COMPONENTS CONNECTION TO THE CONTROL BOARD

A B

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

ENEN

 • Press the SEL and SET bu-

ttons simultaneously for 

sec. to access the program-

ming menu.

 • Press the SET button once

to save this option.

 • The display will show F.

Press SET button to access

the submenu.

 • The display will show F

and the conﬁguration is suc-

cessfully done.

 • The display will show a

value between  and , indi-

cator level of force currently

conﬁgured. Use SEL button

to choose desired option.

 • To exit the programming

mode wait  sec. until (–)

appears.

The control board MC has a menu that allows access to all automatic conﬁgurations.

This menu allows to set the level of force that you want in the motor operation.

Minimum force -  | Maximum force - 

The control board MC has the capacity to memorize  remote controls (Rolling Code).

• Programming

 • Press the CMD button 

second and the LED display

point turns on.

 • Press a button of your choice from the remote control

to program and the display point will ﬂash twice. Remote

control will be memorized after  seconds.

• Erase remote controls

Press CMD for  seconds (during this

time the LED display point will stay

ON).

After this time, LED display point will

ﬂash twice and all codes have been

deleted from memory.

Automation force programming

Opening and closing course programming

Enable / disable safety photocells

Programming automatic closing

Enable/disable condominium function

Enable/disable service door

Increase or decrease deceleration

Enable/disable Follow Me

P B P B

P A P A

P B P B

P A P 

A B

• Power supply AC 230V 50/60Hz

• Battery output 24V DC - 7AH max.

• Lamp output 24V AC - 3W max.

• Motor output 24V DC -50W max.

• Lock output 12V DC - 10W max.

• Auxiliary accessories output 24V DC - 3W max.

• Working temperature -10°C to +55°C

• Incorporated Radio Receiver 433,92 Mhz

• Accepted codestype Rolling Code

• Central dimensions 99x104,5 mm

03. CONTROL BOARD

FUNCTION’S BOARDTECHNICAL SPECIFICATIONS

05. FUNCTIONS

04. REMOTE CONTROLS

PROGRAMMING/ERASE REMOTE CONTROLS

AUTOMATION FORCE PROGRAMMING

A B

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

ENEN

When photocells enabled, if any obstacle interrupt them (if the door is closing), the door will

reverse the direction.

 - Disable |  - Enable

 • Press the SEL and SET bu-

ttons simultaneously for 

sec. to access the program-

ming menu.

 • Press the SEL and SET bu-

ttons simultaneously for 

sec. to access the program-

ming menu.

 • The display will show the

value  or , which identiﬁes

the option in which the con-

trol board is currently conﬁ-

gured. Use the SET button to

choose the desired option.

 • The door will open until reaches detetar the opening limit switch and stop.

 • After a few seconds, the door will closed until reaches the closing limit switch.

 • The course is memorized and Pturns off.

When you start the opening display shows U.

When you start the closing display shows d.

Opening indicator Closing indicator

 • The display will show F.

Press the SEL button as many

times as necessary until the

display shows P.

 • The display will show F.

Press the SEL button as many

times as necessary until the

display shows C.

 • The display shows Cand

the conﬁguration is succes-

sful.

 • Press the SET button to

start the course recognition.

 • Press the SET button to

access the submenu.

 • To exit the programming

mode wait  sec. until (–)

appears.

A B

During the course recognition, display shows P.

To make the opening and closing course programmation, the mechanical limit switches

must always be in tune.

º Unlock the motor;

º Manually, put the gate in closing position and adjust the closing limit switch;

º Manually, put the gate at the opening position you want and adjust the opening limit

switch.

05. FUNCTIONS

OPENING AND CLOSING COURSE PROGRAMMING ENABLE / DISABLE SAFETY PHOTOCELLS

05. FUNCTIONS

A B

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

ENEN

Option  disables the automatic closing, and the gate will close only if it receives an order

from a conﬁgured device.

Any option between  and , multiplied by , sets the automatic closing time, the minimum

is  seconds (number ) and the maximum is  seconds (number ).

-Disabled

• If you send an order to the gate completely open, it will close.

• If pressing during the closure, the gate reverses direction (it will open).

When disabled, you can control the opening or closing of the gate whenever you want, and

their behavior is:

open-stop-close-stop-open-stop - (...) for each time you press a remote control key.

 - Enabled

• This function makes the control board ignore all the orders sent by conﬁgured devices during the

course of opening and during the pause time.

• Pressing the remote control during the opening, the order is declined and the gate continues to open.

 • Press the SEL and SET bu-

ttons simultaneously for 

sec. to access the program-

ming menu.

 • Press the SEL and SET bu-

ttons simultaneously for 

sec. to access the program-

ming menu.

 • Use the SEL button to put

on the desired option. Press

the SET button once to save

this option.

 • The display will show the

value  or , which identiﬁes

the option in which the con-

trol board is currently conﬁ-

gured. Use the SEL button to

put on the desired option.

Press the SET button once to

save this option.

 • The display will show F.

Press the SEL button as many

times as necessary until the

display shows A.

 • The display will show F.

Press the SEL button as many

times as necessary until the

display shows L.

 • The display will show A

and the conﬁguration was

successful.

 • The display will show L

and the conﬁguration was

successful.

 • Press the SET button to

access the submenu.

 • To exit the programming

mode wait  sec. until (–)

appears.

 • To exit the programming

mode wait  sec. until (–)

appears.

A B

05. FUNCTIONS

ENABLE/DISABLE CONDOMINIUM FUNCTION

05. FUNCTIONS

A B

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

ENEN

• When this function is activated, the control board will only work if the service door isclosed.

If the door is open, the control board reject any opening or closing order.

 - Disable |  - Enable

The deceleration reduce the motor speed in the ﬁnal part of the course (opening or closing).

Without deceleration - select the value 

Minimum deceleration –  second

Maximum deceleration –  seconds

 • Press the SEL and SET bu-

ttons simultaneously for 

sec. to access the program-

ming menu.

 • The display will show the

value  or , which identiﬁes

the option in which the con-

trol board is currently conﬁ-

gured. Use the SEL button to

put on the desired option.

Press the SET button once to

save this option.

 • The display will show F.

Press the SEL button as many

times as necessary until the

display shows E.

 • The display will show E

and the conﬁguration was

successful.

 • Press the SET button to

access the submenu.

 • Press the SEL and SET bu-

ttons simultaneously for 

sec. to access the program-

ming menu.

 • The display will show the

value  or . Use the SEL bu-

tton to put on the desired

option. Press the SET button

once to save this option.

 • The display will show F.

Press the SEL button as many

times as necessary until the

display shows H.

 • The display will show H

and the conﬁguration was

successful.

 • Press the SET button to

access the submenu.

 • To exit the programming

mode wait  sec. until (–)

appears.

 • To exit the programming

mode wait  sec. until (–)

appears.

A B

For this function, you must have installed a safety device N.C at the door.

05. FUNCTIONS

ENABLE/DISABLE SERVICE DOOR INCREASE OR DECREASE DECELERATION

05. FUNCTIONS

A

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

CMD

SET

SEL

With the “Follow Me” function activated, whenever the photocells detect the passage of a

user/obstacle, the control board triggers the closing maneuver  seconds later.

 - Disable |  - Enable

 • Press the SEL and SET bu-

ttons simultaneously for 

sec. to access the program-

ming menu.

 • The display will show the

value  or , which identiﬁes

the option in which the con-

trol board is currently conﬁ-

gured. Use the SEL button to

put on the desired option.

Press SET to save the option.

 • The display will show F.

Press the SEL button as many

times as necessary until the

display shows b.

 • The display will show b

and the conﬁguration was

successful.

 • Press the SET button to

access the submenu.

 • To exit the programming

mode wait  sec. until (–)

appears.



ENABLE/DISABLE FOLLOW ME

05. FUNCTIONS

A

Anomaly Procedure Behavior Procedure II Discovering the origin of the problem

• Motor

doesn't work • Make sure you have

230V power supply

connected to

automation and if

the fusible working

properly.

• Still not working • Consult a qualiﬁed

MOTORLINE technician. 1• Remove the motor top cover;

2• Measure the V output of the transformer to detect the fault location;

A) Has 24V:

1• Verify the control board supplies of the motor to detect if the fault is in the motor or in the control board. Replace the damaged component or send it

to the services for diagnosis and repair.

B) Has not 24V:

1• Verify the 230V input of the transformer. If have 230V the problem is in the transformer. If haven't 230V, the problem should be in the fusible, electric

cables or in the power supply. Verify all the systems.

• Make sure the

pedestrian service

door is properly

closed.

• Still not working • Consult a qualiﬁed

MOTORLINE technician. • Take a start in remote control to open and verify the behavior of the LEDs;

• Check the LED signs (page ) and the limit switches connections.

If everything is corrected and there is no micro acted, the LEDs have to be on. Check all the photocells circuit connections to the motor;

• In the E menu, make sure the service port is enabled (page A). If enabled and the circuit is not closed, the motor will not work.

• Motor

doesn’t move

but makes

noise

• Unlock motor and

move the gate by

hand to check for

mechanical problems

on the gate.

• The gate is stuck? • Consult an experienced

gate expert. • Check all motion axis and associated motion systems related with the gate and automatisme (rails, pulleys, bolts, hinges, etc) to ﬁnd out what is the

problem. Also check that the springs are in good condition and can support the gate.

• The gate moves

easily? • Consult a qualiﬁed

MOTORLINE technician • Turn off the motor from control board and test it on directly to a V battery to ﬁnd out if it is damaged;

• If the motor runs, the problem is in the control board. Remove it and send it to the technical services for diagnosis;

• If the motor does not work, remove it and send to the technical services for diagnosis.

• Motor opens

but doesn’t

1 • Check if there is any

obstacle in front of the

photocells;

2 •

Make sure if the

photocells are

working. Put your

hand in front and

check that the relay

makes the same noise

3 • Check if any of the

control devices (key

selector, push button,

video intercom, etc.) of

the gate are jammed

and sending permanent

signal to control unit;

• Gate opened but

didn’t close again. • Consult a qualiﬁed

MOTORLINE technician • Verify if the display is connected to conﬁrm the existence of power supply;

• Verify if the photocells are powered in control board output;

• Access the menu on the display and disable the photocells and the service door;

• Check limit switch connections. If the  LEDs are turned off, it means that the motor can not operate because have the limit switches actuated.

• Try to close;

A) Closed:

• Problem is in one of these two systems. Activate the photocells and check that the gate closes. If close, problem will be in service door. Ative tin

the menu and try to close the door to be sure.

B) Doesn't closed:

• Problem is in the motor or in the control board. Give an order to the gate close while measuring the control board power output to the motor. If

you have V, the control board is working and the problem is in the motor.

• If it has not current, the problem is in the control board.

• Gate doesn’t

make

complete

route

• Unlock motor and

move gate by hand to

check for mechanical

problems on the gate.

• Encountered

problems? • Consult an experienced

gate expert. • Check all motion axis and associated motion systems related with the gate and automatisme (rails, pulleys, bolts, hinges, etc) to ﬁnd out what is the
