Motorola solutions ATS 2500p Reference guide

English
m
ATS 2500p
Digital Portable Radios
Quick Reference Card
RF Energy Exposure and Product Safety
Guide for Portable Two-Way Radios
ATTENTION!
This radio is restricted to Occupational use only. Before using
the radio, read the RF Energy Exposure and Product Safety
Guide for Portable Two-Way Radios which contains important
operating instructions for safe usage and RF energy awareness
and control for Compliance with applicable standards and
Regulations.
Radio Controls
Turning the Radio On/Off
Selecting Zones and Channels
Receiving and Transmitting
Sending an Emergency Alarm
* Default timer of Emergency button press to
activate Emergency is 300 milliseconds. This
timer is programmable, see Emergency
Operation in the user guide for details.
To exit emergency at any time, press and hold
the Emergency button.
Top (Orange)
Button
Main Display
Keypad
Menu Select
Buttons
4-Way Navigation
Button
Home Button
Back Button
Side
Button 2
Side
Button 1
PTT
Button
Speaker
Microphone
Top Side
(Select) Button
Status
Indicator
•On – Rotate the On/Off/Volume knob
clockwise.
•Off – Rotate the On/Off/Volume knob
counterclockwise.
•Zone – Select the required zone using the
radio menu.
•Channel – Turn the Channel knob or select the
required channel using the radio
menu.
Battery
On/Off/Volume
Control Knob
16-Position
Select Knob
__________
Antenna
Accessory
Connector
1Select zone or channel.
2Listen for a transmission.
OR
Press and hold the Volume Set button.
OR
Press the Monitor button and listen for
activity.
3Adjust the volume, if necessary.
4Press the PTT button to transmit; release to
receive.
1Press and hold the Emergency button*.
2The display shows Emergency and the
current zone/channel. Radio sounds a short,
medium-pitched tone, and the LED blinks red
momentarily.
3When acknowledgment is received, you hear
four beeps; alarm ends; and radio exits
emergency.
*PMLN7937A*
PMLN7937A
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M logo are trademarks orregistered trademarks of Motorola Trademark Holdings, LLC and are used under license.
All other trademarks are the property of their respective owners. © 2018 by Motorola Solutions, Inc. All Rights Reserved. 07/18
1303 East Algonquin Road, Schaumburg, Illinois 60196, U.S.A.

English
Sending an Emergency Call
To exit emergency at any time, press and hold
the Emergency button.
Sending a Silent Emergency Call
To exit emergency at any time, press and hold
the Emergency button.
Display Status Icons
1Press the Emergency button.
2Press and hold the PTT button. Speak clearly
into the microphone.
3Release the PTT button to end call.
1Press the Emergency button.
2The display does not change; the LED does
not light up, and there is no tone.
3Silent emergency continues until you:
Press and hold the Emergency button to exit
emergency state.
OR
Press and release the PTT button to exit the
Silent Emergency Alarm mode and enter
regular dispatch or Emergency Call mode.
Receiving a call or data.
Transmitting a call or data.
Blinks when the battery is low.
Direct radio to radio communication or
connected through a repeater.
On = Direct
Off = Repeater
This channel is being monitored.
L= Radio is set at Low power.
H= Radio is set at High power.
Scanning a scan list.
Blinking dot = Detects activity on the
Priority-One Channel
during scan.
Steady dot = Detects activity on the
Priority-Two Channel
during scan.
u
t
8
O
M
HOR .
i
j
The vote scan feature is enabled.
On steady = View mode
Blinking = Program mode
k
Menu Navigation
Press <or >to Menu Entry.
Press {or |directly below
Menu Entry to select.
Press Hto exit.
Press Uor Dto scroll through sub-list.
Press {or |directly below
Menu Entry to select.
