Accessories,
Antennas
c370/c470 Series
Audio Accessories
Handset
Contains full backlit keypad,
earpiece, microphone and speaker,
3 line 11 character backlit display.
Mounts easily on a hang-up cup.
Handset label sold separately.
HLN6519A Motorola Label
FLN2270A Handset
Desk Microphone
Allows dispatcher to
conveniently dispatch
calls from desktop control
station. For use with
dispatch-only mobiles.
HMN4060B Desk Microphone
Desktop Cradle
Contains built-in microphone, speaker, and PTT. Enables hands-free
operation for phone; enables on-hook dispatch calls. Cradle label
sold separately.
HLN6521A Motorola Label
FLN2320A Desktop Cradle
Control Station Accessories
HPN4004A Control Station
Power Supply provides power to
control station units, supplied
with DC cable; 120/220/240V AC,
50/60 Hz operation
Antennas
Part Number: HAF4002A
Frequency: 806-900 MHz
Power: 100 watts
Gain: Unity
Impedance: 50 ohms
Mounting Kit: Roof Mount with
14’ RG58A/U
Cable and
Mini-UHF
Connector
Nut: Chrome
Part Number: HAF4003A
Frequency: 806-900 MHz
Power: 100 watts
Gain: Unity
Impedance: 50 ohms
Mounting Kit: Trunk Lip Mount
with 14’
RG58A/U Cable
and Mini-UHF
Connector
Nut: Chrome
HAF4002A
FLN2270A
HMN4060B
HPN4004A

10/03
Antennas
c370/c470 Series
Part Number: RRA4914B
Frequency: 806-900 MHz
Power: 100 watts
Gain: 3 dB
Impedance: 50 ohms
Mounting Kit: Roof Mount with
RG58A/U Cable
and Mini-UHF
Connector
Nut: Stainless Steel
Part Number: RRA4990A
Frequency: 806-900 MHz
Power: 100 watts
Gain: 3 dB
Impedance: 50 ohms
Mounting Kit: Roof Mount with
RG58A/U Cable
and Mini-UHF
Connector
Nut: Black Chrome
Part Number: RRA4983A
Frequency: 806-900 MHz
Power: 100 watts
Gain: 3 dB
Impedance: 50 ohms
Mounting Kit: Roof Mount with
Low Loss Cable
and Mini-UHF
Connector
Nut: Stainless Steel
Antennas
Part Number: RRA4986A
Frequency: 806-900 MHz
Power: 100 watts
Gain: 3 dB
Impedance: 50 ohms
Mounting Kit: Roof Mount with
Low Loss Cable
and Mini-UHF
Connector
Nut: Black Chrome
Part Number: RRA4923B
Frequency: 806-900 MHz
Power: 100 watts
Gain: 3 dB
Impedance: 50 ohms
Mounting Kit: Trunk Lip Mount
with RG58A/U
Cable and
Mini-UHF
Connector
Nut: Stainless Steel
Antennas
RRA4914B
RRA4923A

10/03
Antennas,
Service Aids
c370/c470 Series
Service Aids
Cables
Remote Connection Cable supplies all connection for remote
mounted radio; connects accessory connector to hang-up cup;
connects mobile and audio test box to hang-up cup; enables
connection of hands-free mic and external speaker. Includes wires
for ignition sense, external alarm, remote PTT.
FKN5050B Remote Connection Cable, 5 meter
FKN4131B Remote Connection Cable, 7 meter
3080373B42 Mini UHF to N RF Cable; connects antenna port to RF
test equipment
Adapter
5880367B21 Mini UHF Male to N Female Adapter; connects antenna
port to RF test equipment
Test Equipment
RLN4460C Audio Test Box; provides interface to radio to allow
connection to test equipment
R1576A Digital Test Meter; measures AC and DC voltages
Antennas
Part Number: RRA4921C
Frequency: 806-900 MHz
Power: 100 watts
Gain: 3 dB
Impedance: 50 ohms
Mounting Kit: Magnet Mount
with RG58A/U
Cable and
Mini-UHF
Connector
Nut: Stainless Steel
Part Number: RRA4976B
Frequency: 806-900 MH
Power: 100 watts
Gain: 3 dB
Impedance: 50 ohms
Mounting Kit: Magnet Mount
with RG58A/U
Cable and
Mini-UHF
Connector
Nut: Black Chrome
Part Number: RAF4136AMM
Frequency: 806-860 MHz
Power: 15 watts
Gain: 3dB
Impedance: 50 ohms
Mounting Kit: Magnet Mount
with 12’
RG174/U Cable
and Mini-UHF
Connector
RAF4136AMM

10/03
Service Aids,
Manuals
c370/c470 Series
Service Aids
Programming Equipment
FLN2196B Flash/Interface Programming Cable connects mobile
to the RIB
3080369B72 PC Cable: 9 Pin; connects the RIB to 9 pin
computer port
3080369B71 PC Cable: 25 Pin; connects
the RIB to 25 pin computer port
RLN4008E Radio Interface Box (RIB);
provides electrical interface between
the radio and the computer
Service Aids
0180357A57 RIB Power Supply, 110V;
provides a 110V AC power source for
the RIB
0180358A56 RIB Power Supply, 220V;
provides a 220V AC power source for
the RIB
RVN4121K Radio Service Software - US Carriers Only; provides
programming and diagnostic functionality for carriers or carrier
authorized customers only
RVN4122K Radio Service Software - US Dealers Only; provides
programming and diagnostic functionality. Non US customers should
contact their carrier
Manuals
6881083C11 Basic Service Manual for: c370, c470, m100,
LM100, LM2000, LM3000E, m370, m470
6881083C13 Field Service Manual for: c370, c470, m100,
LM100, LM2000, LM3000E, m370, m470
