Motorola MBP50 User manual

User’s Guide
Digital Video Baby Monitor
The features described in this user’s guide are subject to modifications
without prior notice.
Models: MBP50, MBP50-2, MBP50-3, MBP50-4

Welcome...
to your new Motorola Digital Video Baby
Monitor!
Thank you for purchasing your new Motorola Digital Video
Baby Monitor. Now you can see and hear your baby sleeping
in another room or you can monitor your older children in their
playroom.
Please retain your original dated sales receipt for your records.
For warranty service of your Motorola product, you will need to
provide a copy of your dated sales receipt to confirm warranty
status. Registration is not required for warranty coverage.
For product related questions, please call:
[phone] (UK only)*
[phone] (ROI)
(*Calls cost 7p per minute plus your telephone company's access charge)
Email: [e-mail]
This User’s Guide provides you with all the information you need
to get the most from your product.
Before you can use the Baby Monitor, we recommend you fully
charge the battery in the Parent Unit, so that it continues to
work if you disconnect it from the power supply to carry it to
another location. Please read the Safety Instructions on page 8
before you install the units.
Got everything?
• 1 x Parent Unit
• 1 x Baby Unit (Camera)
• 1 x Power adapter for the Parent Unit
• 1 x Power adapter for the Baby Unit
In multi-camera packs, you will find one or more additional camera
and power adapter units.

Overview of the Parent Unit
2
4
5
6
3
112
7
8
9
10
11
18
19
13 14 15 16 17
20
V
1. Display (LCD screen)
2. VIDEO ON/OFF button V
Press to turn the LCD screen
ON/ OFF
3. TALK button T
Press and hold to speak to
your baby
4. RESET button (recessed -
use small pin)
5. UP button +
Normal Mode: Tilt up Up
Menu Mode: Up
6. DOWN button -
Normal Mode: Tilt Down
Menu Mode: Down
7. MENU button M
Press to open the Menu
options
8. OK button O
9. Power adapter socket
10. LEFT button <
Normal Mode: Pan Left
Menu Mode: Left
11. RIGHT button >
Normal Mode: Pan Right
Menu Mode: Right
12. Power Adapter LED:
BLUE when mains power
connected.
13. Unit ON/OFF LEDs (Green)
14. Audio Level LEDs (Green,
Orange, Red, Red)
15. Volume buttons
Press -/+ to decrease/
increase Volume level on
Parent Unit
16. Power button 0
Press and Hold to turn the
unit ON/OFF
17. Microphone
18. Stand
19. Speaker
20. Antenna

Parent Unit menu icons
Signal Level (5 Levels)
Night Vision Mode (Screen changes to Black/White)
Talk Mode
Battery Level Indication (4 Levels)
Pan Left
Pan Right
Tilt Up
Tilt Down
Zoom Level Control (1X, 2X)
Temperature scale select (oC / oF)
Lullaby Control (5 Sound Selections)
Alarm Setting (6h, 4h, 2h, O)
Temperature scale select (oC / oF)
Readings display in BLUE, but turn RED > 29ºC / 84ºF, or <
14ºC / 57ºF Displays HH oC / oF if >36oC / 97oF.
Displays LL oC / oF if < 1oC / 34oF.
Camera Control (scan, view, add, delete)
VSet Screen O Timer (O , 5 min, 30 min, 60 min)
Indicates the screen o timer is set
Time Setting (Date, Time format 12/24 Hour and Time)
Volume Level Control (8 Levels)
No Baby Unit detected
View multiple cameras on screen. Available when you have
more than 1 Baby Unit (Camera).

Overview of the Baby Unit
Important guidelines for installing your Baby Monitor
• To use your Video Monitor Baby and Parent Units together, you
must be able to establish a radio link between them, and the range
will be aected by environmental conditions.
• Any large metal object, like a refrigerator, a mirror, a filing cabinet,
metallic doors or reinforced concrete between the Baby and
Parent Unit may block the radio signal.
• The signal strength may also be reduced by other solid structures,
like walls, or by radio or electrical equipment, such as TVs,
computers, cordless or mobile phones, fluorescent lights or
dimmer switches.
• Use of other 2.4 GHz products, such as wireless networks (Wi-
Fi®routers), Bluetooth™ systems, or microwave ovens, may cause
interference with this product, so keep the Baby Monitor away at
least 1 metre from these types of products, or turn them o if they
appear to be causing interference.
• If the signal is weak, try moving the Parent and/or the Baby Unit
to dierent positions in the room(s).
ON / OFF
PAIR
1
3
2
4
5
6
7
8
10
9
1. Photo Sensor (Night Vision
Mode)
2. Camera Lens
3. Infrared LEDs (x 8, for night
vision)
4. Power LED
5. Microphone
6. POWER ON/OFF switch
7. Speaker
8. PAIR button
9. Power Adapter Socket
10. Temperature Sensor

6Table of contents
Table of contents
1. Safety Instructions..........................................................................7
2. Getting Started.............................................................................. 10
2.1 Baby Unit Power Supply......................................................................10
2.2 Parent Unit Power Supply...................................................................10
2.3 Registration (Pairing)............................................................................12
3. Using the Baby Monitor............................................................... 13
3.1 Setting up..................................................................................................13
3.2 Pan and Tilt ...............................................................................................13
3.3 Night Vision Mode..................................................................................13
3.4 Talk Mode...................................................................................................13
3.5 Video ON/OFF ........................................................................................13
3.6 Temperature Display (HH °C / °F or LL °C / °F)........................14
4. Parent Unit Menu Options........................................................... 15
4.1 Volume........................................................................................................15
4.2 Brightness .................................................................................................15
4.3 Lullaby ........................................................................................................15
4.4 Zoom ...........................................................................................................15
4.5 Alarm...........................................................................................................15
4.6 Camera Control.......................................................................................16
4.6.1 Add (pair) a camera..........................................................................16
4.6.2 View a camera.....................................................................................16
4.6.3 Delete a camera..................................................................................17
4.6.4 Scan camera.........................................................................................17
4.7 Temperature .............................................................................................17
4.8 Power Saving mode...............................................................................18
4.9 Time Setting .............................................................................................18
4.10 View multiple cameras on screen...................................................18
5. Disposal of the Device (environment) ........................................... 19
6. Cleaning.......................................................................................... 20
7. Help .................................................................................................. 21
8. General Information......................................................................23
9. Technical Specifications ............................................................. 28

7
ENGLISH
Safety Instructions
1. Safety Instructions
WARNING::
Strangulaton Hazard: Chldren have
STRANGLED n cords. Keep ths cord
out of the reach of chldren (more than
1m (3ft) away). Never use extenson
cords wth AC Adapters. Only use the AC
Adapters provded.

8Safety Instructions
Baby Unit SET UP & USE:
Choose a location for the Baby Unit that will provide the
best view of your baby in their cot.
Place the Baby Unit on a flat surface, such as a dresser,
desk, or shelf or mount the Unit to a wall securely using
the keyhole slots on the underside of the stand.
NEVER place the Baby Unit or cords inside your child’s
cot.
Do not place the Baby Unit or cords in the cot or within
reach of the baby (the unit and cords should be more than
1 metre away).
WARNING
This digital video Baby Monitor is compliant with all relevant
standards regarding electromagnetic fields and is, when handled as
described in the User's Guide, safe to use. Therefore, always read the
instructions in this User's Guide carefully before using the device.
• Adult assembly is required. Keep small parts away from children when
assembling.
• This product is not a toy. Do not allow children to play with it.
• This Baby Monitor is not a substitute for responsible adult supervision.
• Keep this User’s Guide for future reference.
• Do not place the Baby Unit or cords in the cot or within reach of the
baby (the unit and cords should be more than 1 metre away)
• Keep the cords out of reach of children.
• Do not cover the Baby Monitor with a towel or blanket.
• Never use extension cords with power adapters. Only use the power
adapters provided.
• Test this monitor and all its functions so that you are familiar with it prior
to actual use.
• Do not use the Baby Monitor near water.
• Do not place the Baby Monitor near a heat source.

9
ENGLISH
Safety Instructions
• Only use the chargers and power adapters provided. Do not use other
chargers or power adapters as this may damage the device and battery
pack.
• Do not touch the plug contacts with sharp or metal objects.
CAUTION
The Parent Unit includes a built-in, lithium-ion rechargeable battery
pack, which is not a user-accessible item. If you think the battery
needs replacing, please contact the helpline. Do not try to replace it
yourself.
Risk of explosion if battery is replaced by an unapproved battery type.
Dispose of used batteries according to their instructions.
The Unit should be set up and used so that parts of the user’s body
other than the hands are maintained at a distance of approximately
8 inches (20 cm) or more.

10 Getting Started
2. Getting Started
2.1 Baby Unit Power Supply
1. Connect the small plug of the power adapter to the Baby Unit
(camera) and the other end to a suitable mains power socket.
NOTE
Only use the enclosed power adapter (5V DC /1000mA).
2. Slide the POWER ON/OFF switch to the ON position. The power LED
will light up in red.
3. Slide the POWER ON/OFF switch to the OFF position to turn the Baby
Unit o.
2.2 Parent Unit Power Supply
IMPORTMANT
The Parent Unit is assembled with a built-in rechargeable battery pack (Lithium-
ion battery 3.8V 2000mAh), please charge it for 16 hours before initial use. The
battery is not a user-accessible item. Please contact the helpline if you think it
needs replacing.replacing.

11
ENGLISH
Getting Started
1. Connect the plug of the power adapter to the Parent Unit and the other
end to a suitable mains power socket. Only use the enclosed power
adapter (5V DC / 1000mA).
2. Press and hold the 0POWER ON/OFF button for 3 seconds to turn ON
the Parent Unit.
3. Once the Baby and Parent Units are switched on, the display on the
Parent Unit will show the video captured by the Baby Unit.
4. If there is no connection or you are out of range, the unit will beep
every few seconds. Move the Parent Unit closer to the Baby Unit until
the link is re-established.
5. Press and hold the 0POWER ON/OFF button, until the progress bar
finishes scrolling, to turn OFF the Parent Unit.
NOTE
The battery icon turns RED to indicate that the battery is low,
and the parent unit will beep about every 15 seconds. The battery
needs to be recharged; it will take 16 hours to charge fully.
When charging
1. If the Parent Unit is turned OFF with the adapter plugged in, a 2-pin
plug logo will appear on-screen for about 5 seconds, and then a flashing
battery logo will display for 15 seconds. The Blue LED at the top left
will light up; indicating that the adapter is plugged in and charging is
continuing.
2. Whilst the power is ON, and the adapter is plugged in, the battery
icon at the top right corner of the screen will show that the battery
is charging. The Blue LED at the top left will light up to indicate
that the adapter is plugged in.

12 Getting Started
2.3 Registration (Pairing)
The Baby Monitor is pre-registered to your Parent Unit. You do not
need to register it again unless the Baby Unit loses its link with the
Parent Unit.
To re-register your Baby Unit, or register a new Baby Unit, follow the
procedures below:
1. Press the Mbutton of the Parent Unit and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted, the
del/ add/ view/ scan menu will pop up.
3. Press the +UP button or -DOWN button to select add, and press
the Obutton to confirm.
4. Camera / / / will pop up, press the +UP button or -
DOWN button to select the desired Camera and press the Obutton to
start searching for a camera unit.
Note: If a camera is currently paired with the Parent Unit, its camera
location (with a * against it) cannot be selected for a new registration.
5. Press the Obutton to confirm.
6. Press and hold the PAIR button underneath the Baby Unit until the
Parent Unit finds the camera, beeps and PAIR OK appears on the
screen. The video from the camera will then appear.
NOTE
If a particular Baby Unit was registered previously, registering this current
Baby Unit again will cancel its old registration.

13
ENGLISH
Using the Baby Monitor
3. Using the Baby Monitor
3.1 Setting up
• Place the Baby Unit in a convenient location (e.g. on a table) and point
the camera lens towards the area you want to monitor.
• Adjust the angle of the Baby Unit’s camera by moving it up, down, left
and right until you are satisfied with the image shown on the Parent Unit.
NOTE
Do not place the Baby Unit within the baby’s reach! If there is interference
with the picture or sound, try moving the units to dierent locations, and
ensure they are not close to other electrical equipment.
3.2 Pan and Tilt
The camera can be remotely controlled from the Parent Unit when in
a camera viewing mode.
1. Press the +UP button or -DOWN button to tilt up or down.
2. Press the <LEFT button or >RIGHT button to pan left or right.
3.3 Night Vision Mode
The Baby Unit has 6 high-intensity infrared LEDs for picking up clear
images in the dark. When the built-in photo sensor on the front of the
unit detects a low level of ambient light, the LEDs will automatically
activate and the screen on the Parent Unit will display in black and
white. The icon will be displayed at the top of the screen.
3.4 Talk Mode
Press and hold the TTALK button on the Parent Unit to talk to
your baby through the Baby Unit’s loudspeaker. The Ticon will be
displayed at the top of the LCD screen.
3.5 Video ON/OFF
Press VVIDEO ON/OFF button to turn the LCD screen on or off,
whilst still leaving the audio monitor on.

14 Using the Baby Monitor
3.6 Temperature Display (HH °C / °F or LL °C / °F)
The temperature reading from the temperature sensor at the back
of the Baby Unit will be displayed at the top of the LCD screen. The
readings will turn RED if the temperature goes above 29°C / 84°F
or below 14°C / 57°F. The reading will change to HH °C / °F if the
temperature goes above 36°C / 97°F. The reading will change to LL
°C / °F if the temperature goes below 1°C / 34°F.

15
ENGLISH
Parent Unit Menu Options
4.Parent Unit Menu Options
4.1 Volume
1. Press the Volume button -or +to adjust the volume level, the icon
will pop up and you can select the desired volume level from level 0~8.
(The default volume level setting is level 5, and level 0 is OFF.)
4.2 Brightness
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
3. Press the +UP button or - DOWN button to select the desired
brightness level from level 1 ~ 8. (The default brightness level setting is
level 4.)
4.3 Lullaby
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
3. Press the +UP button or - DOWN button to select from the 5 sounds
available. If a sound is selected, it will repeat continually until it is
unselected. (The default setting is lullaby OFF.)
4. Press Othen +UP button or -DOWN button, when a sound is
selected, to adjust the playing volume at the Baby Unit Camera.
4.4 Zoom
1. Press the Mbutton and the menu bar will pop up with highlighted.
2. Press the +UP button or -DOWN button to select 1X or 2X Zoom. (The
default setting is 1X.)
4.5 Alarm
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
3. Press the +UP button or -DOWN button to select the alarm time (6h,
4h, 2h). (The default setting is Alarm OFF.)
4. If an alarm time is selected, the Parent Unit will beep for about 45
seconds after every 6, 4 or 2 hour period.

16 Parent Unit Menu Options
4.6 Camera Control
4.6.1 Add (pair) a camera
1. Press the M button and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted, and
the del/ add/ view/ scan menu will pop up.
3. Press the +UP button or -DOWN button to select add, and press
the Obutton to confirm.
4. Camera / / / will pop up, press the +UP button or -
DOWN button to select the desired Camera, and press the Obutton
to start searching for a camera unit.
Note: If a camera is currently paired with the Parent Unit, its
camera location (with a * against it) cannot be selected for a new
registration.
5. Press and hold the PAIR button on the side of the Baby Unit until
the Parent Unit finds the camera, beeps and PAIR OK appears on
the screen. The video from the camera will then appear.
NOTE
A camera can only be registered to one Parent Unit at any one time.
4.6.2 View a camera
1. Press the M button and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted, and
the del/ add/ view/ scan menu will pop up.
3. Press the +UP button or -DOWN button to select view, and press
the Obutton to confirm.
4. Camera / / / will pop up, press the +UP button or -
DOWN button to select the desired Camera, and press the O
button to view the picture from that camera.
Note: Only camera locations with a * can selected.
TIP
Quick Method to View Cameras instead of entering into the menu bar.
Directly press the Obutton repeatedly to select the available Camera
options from / / / , scan.

17
ENGLISH
Parent Unit Menu Options
4.6.3 Delete a camera
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted, and
the del/ add/ view/ scan menu will pop up.
3. Press the +UP button or -DOWN button to select del, and press
the Obutton to confirm.
4. Camera / / / will pop up, press the +UP button or -
DOWN button to select the desired Camera, and press the Obutton.
5. Press the +UP button or -DOWN button to select , then press the
Obutton to delete that registration.
NOTE
You are not allowed to delete the camera if there is only one registered
camera in the system.
4.6.4 Scan camera
This function is only available when you have more than 1 Baby Unit
(Camera).
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted, and
the del/ add/ view/ scan menu will pop up.
3. Press the +UP button or -DOWN button to select scan, and press
the Obutton to confirm.
4. The screen will then display images from dierent registered cameras in
a loop of Camera / / / , changing about every 12 seconds.
TIP
Quick Method to View Cameras instead of entering into the menu bar.
Directly press OK repeatedly to select the available Camera options from
/ / / , scan.
4.7 Temperature
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
3. Press O, then +UP / -DOWN to select °C or °F.

18 Parent Unit Menu Options
4.8 Power Saving mode
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until Vis highlighted.
3. Press the +UP button or -DOWN button to select auto video o after
5 mins, 30 mins or 60 mins.
NOTE
will stay on and you can press any key to switch the video back on.
4.9 Time Setting
4. Press M, then < LEFT button or > RIGHT button until is highlighted
and press the Obutton.
5. Press the <LEFT button or >RIGHT button to move between the
settings.
6. Press the +UP button or - DOWN button to alter Date, Time format
and Time, then press the Obutton to confirm the setting.
4.10 View multiple cameras on screen
This function is only available when you have more than 1 Baby
Unit (Camera). When the Split Screen function is On, you can view
multiple cameras on the screen.
1. Press the Mbutton and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button until is highlighted.
3. Press+ UP button or - DOWN button to select Split Screen On /
O .
4. When the Split Screen function is On, you can press the <LEFT button/
5. > RIGHT button/ +UP button/ -DOWN button to switch between
cameras to hear the audio from the selected camera.

19
ENGLISH
Disposal of the Device (environment)
5. Disposal of the Device (environment)
At the end of the product life cycle, you should not
dispose of this product with normal household waste.
Take this product to a collection point for the recycling of
electrical and electronic equipment. The symbol on the
product, user’s guide and/or box indicates this.
Some of the product materials can be re-used if you take them to a
recycling point. By reusing some parts or raw materials from used
products you make an important contribution to the protection of
the environment.
Please contact your local authorities in case you need more
information on the collection points in your area.
The internal battery should be disposed of with the Parent unit in an
environmentally-friendly manner according to your local regulations.

20 Cleaning
6.Cleaning
Clean the Baby Monitor with a slightly damp cloth or with an anti-
static cloth. Never use cleaning agents or abrasive solvents.
Cleaning and care
• Do not clean any part of the product with thinners or other solvents and
chemicals – this may cause permanent damage to the product which is
not covered by the warranty.
• Keep the Baby Monitor away from hot, humid areas or strong sunlight,
and don’t let it get wet.
• Every effort has been made to ensure high standards of reliability for
your Baby Monitor. However, if something does go wrong, please do not
try to repair it yourself – contact Customer Service for assistance.
