Motorola CLIQ TM1668 Guide

start guide

II
1
Getting Started
Introducing Your Phone...........................2
Service Activation ....................................4
SIM Card..................................................5
Battery......................................................6
Power .......................................................7
MOTOBLUR™ Account...........................8
Call Functions........................................10
Home Screen.........................................12
Personalize Home Screen.....................20
Social Networking..................................24
Contacts ................................................27
myFaves®...............................................32
Bluetooth®Setup ...................................40
Having Fun
Turn to the Having Fun section (Page 43)
to learn what else your new phone can do.

2
3
INTRODUCING YOUR PHONE
With the MOTOROLA CLIQ™ with
MOTOBLUR™, you can:
nSynchronize, view, and share
contacts, messages, feeds,
and updates from the most
popular social Web sites
on your phone (Facebook® ,
MySpace® , Twitter® , and more).
nAccess full HTML browser using
high-speed 3G and Wi-Fi networks.
nSend text messages, e-mails,
and wall posts using the
QWERTY keyboard.
nSnap photos with the 5 megapixel
camera and post them to
favorite sites, such as Picasa® ,
Photobucket® , and more.
nAnd much more!
Back key
Camera key
Power /
Lock key
Press and
hold to power
on/off.
Quick press
to lock the
phone and
turn off the
display.
Headset jack
Home key
Ringer On /
Off switch
Volume
keys
Charging /
Data port
Menu key

4
5
By activating service, you acknowledge that you have read,
understand, and agree to be bound by each of T-Mobile’s
Terms and Conditions and your Service Agreement.
SIM CARD
Your Subscriber Identity Module (SIM) card
identies you to the wireless network. Your
phone will not work without the SIM card.
To insert the SIM card and battery:
1. Detach your SIM card.
2. Press the battery cover and slide
it off. Lift the tab and remove the
battery.
SERVICE ACTIVATION
If you are a new T-Mobile customer
and your service has not been
activated, simply call Customer Care
at 1-800-937-8997 from your landline
phone and a T-Mobile Activations
representative will assist you.
You will need the following information
when activating service:
nService Agreement and agent
code on your Agreement
nYour name, home address, home
phone, and billing address
NOTE: For business and government accounts,
please provide the name of your company or
government agency, address, and tax ID.
nYour Social Security number, current
driver’s license number, and date
of birth for credit check purposes
nYour choice of T-Mobile rate plan and
services (see www.t-mobile.com for
latest plan information)
nSIM serial number and IMEI number
(located on the box bar code label)

6
7
3. Lift the slot guard. Slide the SIM
card into the SIM card slot with the
gold contacts facing down and the
notched corner aligned as shown.
4. Align the gold contacts on the battery
with the contacts in the battery
compartment. Snap the battery into
place and replace the battery cover.
BATTERY
You can charge your phone using the
charger cable connected to a wall power
outlet or by using the USB cable connected
to your computer.
Charge using a charger cable
Connect the small end of the charger
cable to the micro-USB port on the left side
of your phone. Plug the other end of the
charger into a wall outlet.
Charge using a USB cable
Connect the small end of the USB cable to
the micro-USB port on the left side of your
phone. Plug the other end of the USB cable
to the USB port of your computer.
POWER
Press and hold the Power/Lock key on the
right side of the phone to turn on.

8
9
MOTOBLUR ACCOUNT
Before using your phone, you must rst
create a MOTOBLUR account to get
your contacts, e-mail, messages, and
social networking status on your phone
(MySpace, Facebook, Twitter, etc.).
See the Social Networking section in
this guide for more information on how to
manage your accounts.
Create a MOTOBLUR account
1. Select the language.
2. Tap Start.
3. Tap Register new account.
4. Tap Next.
5. Read the MOTOBLUR Terms
of Service, End User License
Agreement, and Privacy Statement.
6. Tap the check mark next to I agree.
7. Tap Next.
8. Enter your name and the e-mail
address where MOTOBLUR can
send account information.
9. Enter a new MOTOBLUR account
password.
10. Tap Next.
11. Verify the information is correct
and tap Conrm.
12. When account creation is
complete, tap Next.
13. Tap the icon for a
service you use.
14. Enter your logon
information for
that service.
15. Tap Next.
16. Repeat steps
13–15 for all of
your accounts.
17. Tap Done adding
accounts.
18. Tap the Down Arrow icon and
then tap the social networking
site you want to use as the picture
source for your contacts’ picture IDs.
19. Tap Next.

10
11
Check Visual Voicemail
Visual Voicemail allows you to play and
replay messages in any order, save voice
messages to your phone, choose how you
want to respond to messages, share special
audio messages via e-mail, and create
personalized greetings.
1. On the Home screen, tap the
Application tab.
2. Scroll down and tap Voicemails.
3. Tap a contact and do the following:
nTap the Up or
Down Arrow icons
to scroll through
multiple voicemails.
nTap the Play
icon to listen to a
voicemail.
nTap the Trash
icon to delete a
voicemail.
nTap Call Contact to call the contact.
nTap Send Text to send a text
message to the contact.
20. To complete setup and download
your contacts, tap Next.
21. Tap Done.
Congratulations on creating your new
MOTOBLUR account! Now you are ready to
make calls or continue on with this guide to
learn more about your phone.
CALL FUNCTIONS
Make and end calls
1. On the Home screen, tap the green
Phone icon.
2. Tap the Dialer tab, if necessary.
3. Enter the number and tap Call.
4. To end the call, tap End call.
Answer calls
Tap Answer. When the screen is locked,
touch Answer and swipe your nger left.

12
13
HOME SCREEN
Your Home screen is wider than you’d think.
Simply swipe your nger to the left or right to
view any of the ve panels.
Slide your nger
to the right to see
the left side of your
Home screen.
Slide your nger to
the left to see the
right side of your
Home screen.
You can customize each panel with widgets,
shortcuts to your favorite applications, or
folders that contain shortcuts and les.

14
15
Social Status widget
Tap this widget on the
Home screen to
display your most
recent status updates
to your social networks.
You can then update
your status on one
or all of your social
networks.
Status indicators
Social Status
widget
Tap to update
your status.
Messages
widget
Tap to
view recent
messages.
Happenings
widget
Tap to view
your contacts’
recent posts.
Contact list
Shortcuts
Tap to launch
the application.
Notications
Application
tab
Tap to
view your
applications.
Phone
Tap to
access the
dialer and
call history.
Widgets
Widgets bring the content you want right
to your Home page. Weather, news,
messages, and updates from your social
networking contacts are pushed to your
widgets as the updates happen.

16
17
Messages widget
Tap this widget on the
Home screen to display
your recently received
text messages, e-mails,
and social network-
ing direct messages.
Swipe your nger left
or right to scroll through
multiple messages or
tap the title bar to see
the full list.
Happenings widget
Tap this widget on the
Home screen to display
the most recent photos,
events, and other items
posted by your social
networking contacts.
Swipe your nger left
or right to scroll through
multiple happenings or
tap the title bar to see
the full list.
Shortcuts
There are two default shortcuts on your
center Home screen (Messages and
Browser) to allow you to quickly access
your messages and to open up the
browser.
See the Personalize Home Screen
section of this guide for more information
on how to delete and add shortcuts.

18
19
Notification drawer
The Notication drawer runs across the
top of your screen. Icons appear to let you
know when information is waiting for you.
Application tray
Tap the Application
tab to open the
Application Tray.
Touch and slide your
nger up or down the
screen to scroll through
your applications.
New applications are
automatically added
to your drawer in
alphabetical order.
Touch and slide
the drawer down
with your nger.
Tap the desired
Notier icon.

20
21
PERSONALIZE HOME SCREEN
Swipe left or right to personalize each of the
ve panels of your Home screen.
Add widgets to Home screen
1. On the Home screen, touch and
hold an empty space until you see
the Add to Home screen menu.
2. Tap Widgets.
3. Tap the desired widget.
4. If necessary, complete additional
setup steps and tap Done.
Arrange widgets
1. On the Home screen, touch and
hold the widget you want to move.
The Application tab will turn red
when the widget is active.
2. Drag the widget to the desired
location and release your nger
from the screen.
Delete widgets
1. On the Home screen, touch and
hold the widget you want to delete.
The Application tab will turn red
when the widget is active.
2. Drag the widget to the Trash icon on
the Application tab and release your
nger from the screen.
Create shortcuts on the Home screen
1. On the Home screen, tap the
Application tab.
2. Touch and hold the desired
application.
3. Drag the application icon to the
desired location on the desired
panel and release your nger from
the screen.

22
23
Delete shortcuts
1. On the Home screen, touch and hold
the shortcut you want to delete. The
Application tab will turn red when
the shortcut is active.
2. Drag the shortcut to the Trash icon
on the Application tab and release
your nger from the screen.
Change wallpapers
1. On the Home screen, touch and hold
an empty space until you see the
Add to Home screen menu.
2. Tap Wallpapers.
3. Tap one of the following:
nPicture gallery: Tap to view
a picture. Touch and drag the
Circle and Arrow icons to
adjust the crop box. Tap the
Check Mark icon when done.
nWallpaper gallery: Touch
and drag to scroll through the
wallpapers. Tap Set wallpaper.
Create folders on the Home screen
1. On the Home screen, touch and hold
an empty space until you see the
Add to Home screen menu.
2. Tap Folders.
3. Tap New folder.
4. Tap to open the new folder.
5. Touch and hold the top bar to
rename the folder.
6. Enter a name for your folder.
7. Tap OK when done.
Add shortcuts to a folder
1. On the Home screen, touch and hold
the shortcut you want to add to a
folder. The Application tab will turn
red when the shortcut is active.
2. Drag the shortcut on top of the folder
and release your nger from the
screen.
Note: You cannot move widgets into a folder.

24
25
SOCIAL NETWORKING
Your phone automatically delivers and
organizes your conversations, friends and
favorite content from so many sources
directly to your phone in easy-to-manage
streams.
It syncs contacts, posts, feeds, messages,
e-mails, photos and much more—from
sources like Facebook, Twitter, MySpace,
Gmail® , Yahoo!® , your work e-mail, Picasa,
Photobucket, Last.fm®—and automatically
serves it up just the way you want it. No
opening and closing apps and menus, it’s
all front and center on your Home screen
and integrated throughout the entire phone
so you can communicate anyway you like.
Add accounts
You can add your Facebook, MySpace,
Twitter, or other accounts to your phone any
time. To set up social networking accounts,
visit their Web sites.
1. On the Home screen, tap the
Application tab.
2. Tap Accounts.
3. Tap Add account.
4. Tap the icon for the desired account.
5. Enter your logon information.
6. Tap Next.
View accounts
1. On the Home screen, tap the
Application tab.
2. Tap Accounts.
Delete accounts
1. On the Home screen, tap the
Application tab.
2. Tap Accounts.
3. Tap the account you want to delete.
4. Tap Delete account.
5. Tap Yes to conrm.

26
27
Update your status
You can update and see your current status
in the Social Status widget on your Home
screen. To update:
1. On the Home screen, tap the
Social Status widget.
2. Enter your status.
If you have more than one account,
you can use the pull-down menu to
limit which accounts are updated.
3. Tap Post.
If you don’t see a Social Status widget,
swipe your Home screen left or right to
check all panels. To add the Social Status
widget:
1. On the Home screen, touch and hold
an empty space until you see the
Add to Home screen menu.
2. Tap Widgets.
3. Scroll to and tap Social Status. The
widget will appear in the empty spot
and will show your status the next
time your phone updates from the
network.
CONTACTS
There are several important things to know
when managing contacts on your phone:
n
New contacts are saved in
the phone memory, and also
updated in your MOTOBLUR and
T-Mobile®Mobile Backup accounts
at www.motorola.com/mymotoblur
and www.my.T-Mobile.com.
n
If you edit one of your social
networking contacts on the
Web site, your changes will be
synchronized to your phone
automatically.
n
You cannot save new contacts
to your SIM card.
n
Contacts downloaded from
Facebook, MySpace, Twitter,
Gmail, and Corporate Sync
are not backed up to T-Mobile
Mobile Backup.

28
29
Add contacts using your phone
1. On the Home screen, tap the blue
Contacts icon.
2. Tap the green Plus icon.
3. Enter the contact’s name.
4. Under Phone, tap the green Plus
icon and enter the phone number.
5. Repeat step 4 for other sections, if
desired.
6. Tap Save when done.
Call contacts
1. On the Home screen, tap the blue
Contacts icon.
2. Scroll to and tap the contact you wish
to call.
3. Tap the desired phone number.
Link contacts
If one of your contacts is stored in multiple
social networking sites, it may result in
duplicate entries. You can easily link a
contact’s multiple entries into one.
1. On the Home screen, tap the blue
Contacts icon.
2. Tap the contact entry you want to link.
3. Press the Menu key.
4. Tap Link contact.
5. Scroll to and tap the contact entry you
want to link with previous entry.
Group lter: Tap to choose
which group to display, such
as Facebook, MySpace, or
All contacts.
Add new contacts: Tap to
enter a new contact.
Contact list: Tap to view a
contact. Touch and hold to
edit, delete, and more.
Views: Tap to view your
contact list in different ways:
History: Recently used
A-Z: View without status
Status: View with status

30
31
Filter contacts
To view where a contact is stored, such as
on Facebook or in T-Mobile Mobile Backup,
you can easily lter your contacts.
1. While in your contact list, tap
Contacts in the top left corner of
the screen.
2. Tap All contacts, MOTOBLUR
address book, T-Mobile Network
Address Book, or the desired linked
account.
Contact list views
You have three options for viewing the
contacts in your contact list.
History view:
To view the contacts
you have sent or
received messages
from, beginning
with the most recent.
A-Z view:
To view your contacts
in alphabetical order.
Status view:
To view your contacts’
status updates,
beginning with the
most recent.

32
33
myFaves®is an optional calling plan.
Benets of signing up to myFaves:
nUnlimited nationwide calling to
any ve U.S. numbers, on any
network (even landlines)*
nCalling, text messaging,
and photo sharing**
nNo domestic roaming or domestic
long-distance charges
nPersonalize contacts with favorite
pictures and downloadable icons**
* myFaves only applies to calls directly between two
people and allows unlimited nationwide calling to ve
U.S. numbers. You can change myFaves numbers
once/month.
** Separate charges may apply.
Subscribe to myFaves
To subscribe, go to www.T-Mobile.com.
When you have subscribed to myFaves,
you will see ve circles on the main screen
a few minutes after you power on your
phone.

34
35
Add myFaves contacts
1. On the Home screen, swipe your
nger to the left to view the rst panel
to the right .
2. Tap the myFaves shortcut.
3. Tap an unassigned circle.
4. Tap one of the following:
nCreate new: Enter the contact’s
name and phone number.
nGet from Phonebook:
Select a contact.
5. Tap Save or continue to Step 6 to
assign an icon.
Assign an icon
6. Tap the icon circle in the top left
corner of the screen.
7. Tap one of the following:
nmyFaves icons: Tap the
desired myFaves icon.
nPhotos: Tap the desired
photo. Touch and drag the
crop circle to the desired
location and size. Tap Crop.
nTake picture: Frame your subject
and press the Camera key.
8. Tap Save.
9. Tap OK.
An hourglass displays in the circle while the
contact is being added to your contacts.
You can use your phone during this time.
Once the contact is added, you will receive
a conrmation message and the hourglass
is replaced by your new contact.

36
37
Assign a ringtone
1. On the Home screen, swipe your
nger to the left to view the rst panel
to the right.
2. Tap the myFaves shortcut.
3. Tap the myFaves contact’s circle.
4. Tap Edit.
5. By Contact Details, tap Edit.
6. Scroll down to Ringtone.
7. Tap No ringtone specied.
8. Tap the desired ringtone.
9. Tap OK.
10. Tap Save.
Edit a myFaves contact
Names, icons, and ringtones: You can
change names, icons, and ringtones at any
time.
Phone numbers: You can only change
a contact’s phone number once per
calendar month. If a number change is not
allowed, you will receive an error message
explaining why.
1. On the Home screen, swipe your
nger to the left to view the rst panel
to the right.
2. Tap the myFaves shortcut.
3. Tap the myFaves contact’s circle.
4. Tap Edit.
5. By Contact Details, tap Edit.
6. Scroll down and edit the contact’s
information, such as name, phone
number, e-mail address, mailing
address, birthday, anniversary, and
ringtone.
7. Tap Save.
