Motorola I710 - SOUTHERNLINC User manual

Nextel
iDEN
Digital Multi-service Data-capable Phone
i710 Phone User’s Guide
@NNTN5720A@
NNTN5720A

i
Contents
Getting Started........................................... 1
Removing the Battery Door...............................3
Locating Your SIM Card....................................3
Battery...............................................................4
Powering On and Off.........................................6
Activating Service..............................................6
Enabling Security ..............................................6
Phone Programming .........................................7
Finding Your Phone Number and Direct
Connect®Number ........................................7
Nextel®Voice Mail.............................................8
Nextel Worldwide®Service ...............................8
Customizing Features .......................................8
Phone Basics ....................................................9
SIM Card Security ...........................................12
Locking the Keypad.........................................16
Accessories.....................................................17
Wireless Local Number Portability: Bringing
Your Phone Number From Another
Carrier.........................................................17
Nextel®Customer Care...................................18
Making Calls .............................................20
Phone Calls.....................................................20
Direct Connect®Calls .....................................20
Receiving Calls ...............................................21
Ways to Enter Calls.........................................22
Missed Phone Calls ........................................24
Using Speakerphone.......................................24
Using Mute......................................................25
Making Emergency Phone Calls.....................25
Call Alerts..................................................27
Sending Call Alerts..........................................27
Receiving Call Alerts.......................................27
Using the Call Alert Queue..............................27
Recent Calls..............................................29
Viewing Recent Calls ......................................29
Storing Recent Calls to Contacts....................29
Deleting Recent Calls......................................30
Entering Text ............................................31
Using Alpha Mode...........................................31
Using Word Mode ...........................................31

ii
Special Function Keys.....................................32
Using Numeric Mode.......................................33
Using Symbols Mode ......................................33
Contacts ................................................... 34
Viewing Contacts.............................................35
Creating Entries...............................................36
Storing Numbers Faster..................................37
Editing Entries.................................................38
Deleting Entries...............................................38
Checking Capacity ..........................................38
Creating Pauses and Waits.............................38
International Numbers.....................................39
Memo ........................................................ 40
Call Forwarding........................................ 41
Forwarding All Calls ........................................41
Turning Off Call Forwarding ............................42
Forwarding Missed Calls.................................42
Viewing Call Forwarding Settings....................43
Advanced Calling Features .....................44
Call Waiting.....................................................44
Switching Between Calls.................................44
Putting a Call on Hold .....................................45
Calling 2 People..............................................45
Creating Pauses and Waits While Dialing.......46
Making International Calls...............................46
Setting One Touch Direct Connect®.................... 46
Setting Flip Actions .........................................47
Group ConnectTM Calls...................................48
Call Timers......................................................49
Using Your Phone as a Modem ......................50
Making TTY Calls............................................51
Special Dialing Codes.....................................52
Nextel®Phone Services...........................54
Caller ID ..........................................................54
Per-Call Blocking.............................................54
Per-Line Blocking............................................54
Alternate Line Service.....................................54
Call Restrictions ..............................................55
Nextel®411.....................................................55

iii
Ring Tones............................................... 56
Setting Your Phone to Vibrate.........................56
Ring and Vibrate..............................................57
Assigning Ring Tones to Contacts ..................57
Viewing Ring Tone Assignments.....................57
Downloading More Ring Tones.......................57
Managing Memory...........................................58
Deleting Custom Ring Tones ..........................58
Message Center....................................... 59
Accessing the Message Center.......................59
Message Center Options.................................59
Receiving Messages................................ 60
Message Notifications .....................................60
Message Center..............................................60
Voice Mail Messages............................... 62
Receiving a Message......................................62
Accessing Voice Mail from
the Message Center ...................................62
Sending Unanswered Calls to Voice Mail.......62
Nextel®Voice Mail....................................63
Setting Up Your Voice Mail Box......................63
Playing Messages...........................................63
Changing Your Password ...............................64
Recording Your Name.....................................64
Recording Your Active Greeting......................65
Advanced Voice Mail Features .......................65
Nextel®Voice Mail Tree..................................70
SMS and Two-Way Messages .................71
SMS Messages...............................................71
Two-Way Messages and Net Alerts................72
Nextel Online®Services...........................75
NOL Services..................................................75
Accessing NOL Services From Your Phone...75
Voice Records ..........................................77
Creating Voice Records ..................................77
Playing Voice Records....................................77
Labeling Voice Records ..................................77
Deleting Voice Records...................................78
Locking Voice Records ...................................78

iv
Managing Memory...........................................78
Java Applications.................................... 80
Installing Applications......................................80
Running Applications.......................................80
Suspending Applications.................................80
Resuming Applications....................................81
Ending Applications.........................................81
Downloading Applications...............................81
Deleting Applications.......................................81
Managing Memory...........................................82
Shortcuts on the Main Menu ...........................82
Java Applications and GPS Enabled...............83
GPS Enabled............................................ 86
IMPORTANT: Things to Keep in Mind ............86
Making an Emergency Call .............................87
Viewing Your Approximate Location ...............88
Enhancing GPS Performance.........................89
Updating Satellite Almanac Data.....................91
Setting Privacy Options...................................92
Using GPS with Map Software........................93
Datebook...................................................95
Viewing Datebook...........................................95
Creating Events...............................................96
Editing Events .................................................98
Deleting Events...............................................99
Receiving Reminders......................................99
Making Calls From Datebook........................100
Customizing Datebook Setup........................100
Customizing Your Phone.......................102
Setting the Volume........................................102
Setting Your Phone to Vibrate.......................102
Changing the Look of Your Phone................102
Temporarily Turning Off Calls .......................104
Using Settings...............................................104
Profiles ....................................................109
Viewing Profiles.............................................109
Switching Profiles..........................................109
How Changing Settings Affects Profiles........109
Temporary Profiles........................................110
Creating Profiles............................................111
Editing Profiles ..............................................111

v
Deleting Profiles............................................111
Setting Call Filtering ......................................112
Shortcuts................................................ 113
Creating a Shortcut .......................................113
Using a Shortcut............................................113
Editing a Shortcut..........................................114
Deleting Shortcuts.........................................114
Using a Headset..................................... 115
Attaching a Headset......................................115
UsingaRemotePTT
TM Button .....................115
Nextel®Customer Care......................... 116
Domestic Customer Care..............................116
Nextel Worldwide®Customer Care...............117
Understanding Status Messages......... 118
Nextel®Terms and
Conditions of Service ........................ 120
Safety and General Information............142
RF Operational Characteristics.....................142
Portable Radio Product Operation and EME
Exposure...................................................142
Electro Magnetic Interference/Compatibility..145
Medical Devices............................................145
Operational Warnings ...................................146
Operational Cautions ....................................147
Accessory Safety Information .......................148
MOTOROLA LIMITED WARRANTY.......150
Limited Warranty
Motorola Communication Products
(International)......................................154
Patent and Trademark Information.......158
Index ........................................................159

vi
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola, Inc.
Address: 8000 West Sunrise Boulevard
Plantation, FL 33322 USA
Phone Number: 1 [phone]
Hereby declares that the product:
Product Name: i710
Model Number: H45XAN6RR4AN
Conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a),
15.107(d) and section 15.109(a)
Class B Digital Device
As a personal computer peripheral, this device
complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
•Reorient or relocate the receiving
antenna.
•Increase the separation between the
equipment and receiver.
•Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced
radio/TV technician for help.

1
Getting Started
volume
controls
PUSH TO TALKTM
(PTTTM) button
accessory connector
audio jack
speaker
(in back)
antenna
microphone
light sensor
option keys
earpiece display
screen
space key
back key
power
button

2
Getting Started
To start using your i710 phone:
•Make sure your SIM card is in place.
•Charge the battery.
•Activate your service.
•Enable security.
pPower button.
Navigation key — press the arrows to
scroll through menus and lists.
OOK key — selects highlighted item;
answers calls.
mMenu key — accesses context-sensitive
menus.
AOption key — selects the option
appearing above it on the display.
Note: Throughout this User’s Guide,
theoptionkeyswillbe
represented by A.
sSend key — places phone calls.
eEnd key — ends phone calls; returns to
idle screen; in browser mode, returnsto
Net main menu.
tActs like swhentheflipisclosed;turns
Direct Connect®/ Group ConnectTM
speaker on and off; used with voice
namesand voice records.
.Acts like ewhen the flip is closed.

3
Removing the Battery Door
Removing the Battery Door
1Make sure the phone is powered off. See
“Powering On and Off” on page 6.
2Slide the release buttonbackuntilit releasesthe
battery door.
3Allow the battery door to pop up, slide it forward,
and remove it from the back of your phone.
Locating Your SIM Card
Your SIM (Subscriber Identity Module) card is a
small piece of plastic located in the SIM card
holder in the back of your phone, underneath the
battery.
If there is no SIM card in your phone, contact
Nextel Customer Care at 1-800-639-6111.
speaker
SIM card

4
Getting Started
Battery
Inserting the Battery
Your phone comes with a Standard Lithium Ion
Battery.
1Remove the battery door.
2Insertthe top of the battery into the battery area.
Press the bottom of the battery to secure it.
3Replace the battery door and press it gently until
you hear a click.
Charging the Battery
Your phone comes with a standard travel charger.
1Plug the charger into an electrical outlet.
2Open the connector cover.
3Plug the other end of the charger into the
accessory connector.
connector
cover

5
Battery
Charger Attached appears on the display.
Tip: To remove the charger from the accessory
connector: Pressthe buttons on the sides
of the plug. Pull the plug straight out.
4If you have purchased optional batteries or
chargers, see “Charging Times”.
Charging Times
Check your battery and charger type against the
below grid to determine appropriate charging
times.
Recommended charging times:
For best results, charge the batteries within the
temperature range of 50°F to 104°F (10°C to
40°C).
Prolonged charging is not recommended.
Removing the Battery
1With the phone powered off, remove the battery
door.
2Remove the battery by pushing the battery
toward the antenna and lifting it out.
Battery Use and Maintenance
•The Motorola iDEN Approved Lithium Ion
chargers provide optimum performance. Other
chargers may not fully charge the iDEN Lithium
Ion battery or may yield a reduced number of
lifetime charge cycles.
•Extreme temperatures degrade battery
performance. Do not store the battery where
temperatures exceed 140°F (60°C) or fall below
4°F (-20°C).
•Lithium Ion batteries have a self discharge rate
and without use, lose about 1% of their charge
per day.
Battery Charger
Rapid Standard
Slim Lithium
Ion 2hours 3hours
Standard
Lithium Ion 2hours 4hours

6
Getting Started
•The battery capacity isdegraded if the battery is
stored for long periods while fully charged. If
long term storage is required, store at half
capacity.
Powering On and Off
To power your phone on:
1Open the flip.
2Press p.
As your phone connects to the network, you will
see a connecting message. When the idle screen
appears, the phone is ready to use.
To power your phone off:
1Open the flip.
2Press and hold p.
Activating Service
The first time you power on your phone, your
service is activated.
A screen then appears prompting you to select Ok
to update your browser information. This screen
will only appear during initial activation. See
“Enabling Security”.
Enabling Security
You must enable security the first time you power
on yourphone or within 20 days offirst activation of
your phone.
1Press Aunder Ok.
Note: If you press Aunder Later, the idle
screen will appear. The next time you
select Net from the main menu, you will
be prompted to enable security before you
can use Nextel Online services.
2You are prompted to enable security. Press A
under Yes. A series of screens and then the
default homepage displays.
3Press eto return to the idle screen.

7
Phone Programming
Phone Programming
Within 24 hours of enabling security, you will
receive an alert notification containing your
Personal Telephone Number (PTN), Nextel
Customer Care number, Direct Connect number,
and Talkgroup lists for Group Connect calls.
1When you receive an alert notification saying
New Browser Message - Receive
Programming Info,pressAunder Goto.
2You are prompted to accept changes to your
lists. Press Aunder Ok.
3You are prompted again to accept changes to
your lists. Press Aunder Ok.
4A confirmation screen displays. Press Aunder
Ok.
5Press eto return to the idle screen.
Finding Your Phone Number
and Direct Connect®Number
My Info lets you view your phone number, Direct
Connect number, and other phone information.
1Press mto access the main menu.
2Scroll to My Info.
3Press O.
4Scroll to see your information:
•Name— Enter your name. See “Entering
Text”onpage31.
•Line1and Line 2 — your phone numbers for
phone lines 1 and 2. These are filled in when
you receive your alert notification after
enabling security on your phone.
• Direct Connect — Your Direct Connect
number is the number that others use to
contact you using Direct Connect®service. It
is filled in when you receive your alert
notification after enabling security on your
phone. To view your Direct Connect number,
scroll to Direct Connect and press O.
•GroupID— the number of the Talkgroup you
have joined.
• Carrier IP — the IP address assigned to
Nextel. It is filled in when you register for
packet data services. To view your Carrier IP
address, scroll to Carrier IP and press O.
• IP1 Address and IP2 Address —theIP
addresses assigned to you for using the
Internet with your phone. To view your IP
addresses, scroll to the IP address you want
to view and press O.

8
Getting Started
•Ckt— Your circuit data number is the number
youuseifyouwanttouseyourphoneto
transfer circuit data. See “Using Your Phone
as a Modem” on page 50. You receive this
number from Nextel.
Note: If you request equipment related
transactions on your account, Nextel
Customer Care may require you to
provide specific information about your
phone. By pressing manytime while in
My Info, a context-sensitive menu will
appear that includes your phone's service
status, unit information, and phone
identification numbers including IMEI, SIM
ID, and Serial Number (SN). Please be
prepared to supply the representative with
this information when requesting these
types of transactions.
Nextel®Voice Mail
You must set up your voice mail box before you
canretrievemessages.See“SettingUpYour
VoiceMailBox”onpage63.
Nextel Worldwide®Service
You can use your phone to make calls
internationally in select cities using other iDEN®
networks by calling Nextel Customer Care to
activate international dialing on your account.
Countries in which you can use your phone include
Argentina, Brazil, Canada, Philippines, Singapore,
Israel, Mexico and Peru*.
* Credit approval may be required. Other conditions may apply.
Customizing Features
You can control many features of your phone,
including the size ofthe text on the display, the way
youaccessmainmenuitems,andthevolumeof
incoming sound, rings, and other tones. See
“Customizing Your Phone” on page 102.

9
Phone Basics
Phone Basics
Any time your phone is powered on, the display
provides you with information and options.
The screen shown above is the idle screen. The
idle screen appears when your phone is on, but not
engaged in any activity.
Text Area
This area displays menus, messages, names,
phone numbers, and other information.
Display Options
Two display options appear at the bottom of most
screens. You select a display option by pressing
theoptionkeybelowit.
Menus and Lists
Your phone’s features are arranged in menus,
submenus, and lists.
Toaccesstheitemsinamenuorlist,scrollusing
the navigation key at the top of your keypad. This
key lets you scroll up, down, left, or right. Holding
down the appropriate part of the navigation key
speeds up scrolling.
In this guide, this symbol >tells you to select a
menu or list item. For example, Settings >
Security means:
1Scroll to Settings on the main menu.
2Press Oto see the Settings screen.
3Scroll to Security.
4Press Oto see the Security screen.
Quick Access to Main Menu Items
Each arrow in the navigation key and Ocan be
used to access a main menu item from the idle
screen. Each of these keys is assigned to a main
menu item when you receive your phone. To
assign different main menu items, see “Personalize
Features” on page 106.
status icons
text area
menu icon
display options

10
Getting Started
OK Key
Pressing O:
•Selects the highlighted menu item or list item
•Sets options
•Confirms actions
•Places and answer calls
•From the idle screen, accesses ring tones list.
This is the default setting. You can assign a
different main menu item to O.
Menu Key
Many features provide context-sensitive menus
that let you access related features and actions.
This icon Sappears any time a context-sensitive
menu is available. Press mto access the menu.
Main Menu
All your phone’s features can be accessed through
the main menu. You can set the main menu to
appear as a list or as large icons (see “Setting the
Menu View” on page 103).
aNet Access to Nextel Online
services. See page 75.
qJava Apps Java applications on your
phone. See page 80.
bSettings Customize your phone.
See page 102.
mRing Tones Assign ring tones and turn
ringer off. See page 56.
cVoiceRecord Record and play audio
messages. See page 77.
jMy Info View personal phone
information, including
phone number and Direct
Connect number. See
page 7.

11
Phone Basics
Status Icons
Status icons appear at the top of the display. Some
appear at all times. Others appear only when your
phone is engaged in certain activities or when you
have activated certain features.
nDownloads Provides a catalog of ring
tones, wallpaper, games
and Java applications that
you can download directly
to your phone. Items in this
catalog change frequently,
so check regularly for fresh
content. See page 57.
lGPS Find your approximate
geographical location. See
page 86.
dContacts Create, view, store, edit
contacts. See page 34.
eMessages Access messages. See
page 59.
fCall Forward Setcallforwarding options.
Seepage41.
oDatebook Schedule appointments.
Seepage95.
gMemo Store a number to access
later.Seepage40.
hCall Timers Phone usage information.
Seepage49.
iRecent Calls Lists recent calls. See
page 29.
sShortcuts Create shortcuts to
screens. See page 113.
pProfiles Groups of settings you
apply together. See
page 109.
kCall Alert Lists call alerts. See
page 27.
abcd
efgd
Battery Strength — A fuller battery
indicates a greater charge.
opqr
s
Signal Strength — More bars next
to the antenna indicate a stronger
signal.
APhone In Use — Your phone is
active on a phone call.
BDirect Connect In Use —Your
phone isactive on a DirectConnect
call.

12
Getting Started
SIM Card Security
Your SIM card stores all your Contacts and
protects your personal information. Since this
information is stored on your SIM card, not in your
phone, you can remove the information by
removing your SIM card.
CTalkgroup In Use — Your phone is
active on a Group Connect call.
12 Active Phone Line —1indicates
phoneline1isreadytomakecalls;
2 indicates phone line 2 is ready to
make calls.
GL
IJ
HK
Call Forward — Your phone is set
to forward calls. See “Call
Forwarding” on page 41.
QRM Ringer Off — Your phone is set not
to ring. See “Setting Your Phone to
Vibrate” on page 56.
u Speaker Off — Sets Direct Connect
and Group Connect sound to come
through the earpiece rather than
through the speaker.
wxT
yz
Messages — You have one or
more messages. See page 59.
ljik
mXnW
T9 Text Input — You are using T9
Text Input to enter text. See
“Entering Text” on page 31.
DE Internet — You are ready to
browse the internet or are browsing
theinternetusingasecure
connection.
UAirplane Mode — Your phone is
set to Airplane Mode. See
“Temporarily Turning Off Calls” on
page 104.
YZ Packet Data — You are ready to
transfer packet data or are
transferring packet data. See “Using
Your Phone as a Modem” on page
50.
N O TTY — You are ready to use your
phonetomakecallsusinga
teletypewriter device. See “Making
TTY Calls” on page 51.
