Motorola i570 User manual

Dummy Page - To be discarded before printing
TELUS
i570 Mike Phone
User’s Guide

DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola, Inc.
Address: 8000 West Sunrise Boulevard
Plantation, FL 33322 USA
Phone Number: 1 [phone]
Hereby declares that the product:
Product Name: i570
Model Number: H65XAN6RR4CN
Conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a),
15.107(d) and section 15.109(a)
Class B Digital Device
As a personal computer peripheral, this device
complies with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.

1
HELLOMOTO
Introducing your new Mike i570 phone. Here’s a quick anatomy lesson.
Left Soft Key
Perform function
in lower left
display.
4-Way
Navigation Key
Right Soft Key
Perform function
in lower right
display.
End Key
End calls, exit
menu system.
Talk Key
Make &
answer calls.
OK Key
In menus & lists,
press to select
highlighted option.
Menu Key
From home screen,
open main menu.
Speaker On/Off Key Smart Key
PTT Button
Microphone
External Display
Volume Keys
Power Key
Turns phone on.
Audio Jack
Microphone
Bottom Connector

2
check it out
1
2
Customizable O
key
that can be used
to open the
Settings screen
Press and hold the
Power Key
W
for a
few seconds, or until
the screen lights up,
to turn on your phone.
3
4Press the O
key
to select.
Press the Navigation Key
up, down, left or right ( )
to highlight a menu feature.
Home Screen
Main Menu
Main Menu
cde
fo g
aq b

3
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Product Support:
www.motorola.com/iden
Certain mobile phone features are dependent on the capabilities
and settings of your service provider’s network. Additionally,
certain features may not be activated by your service provider,
and/or the provider's network settings may limit the feature’s
functionality. Always contact your service provider about feature
availability and functionality. All features, functionality, and other
product specifications, as well as the information contained in this
user's guide are based upon the latest available information and
are believed to be accurate at the time of printing. Motorola
reserves the right to change or modify any information or
specifications without notice or obligation.
Caution: Changes or modifications made in the radio phone, not
expressly approved by Motorola, will void the user's authority to
operate the equipment.
MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. All other product or service names are
the property of their respective owners. Java and all other Java-
based marks are trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries.
© Motorola, Inc., 2007.
Manual Number: NNTN7322A
Software Version: D8A.00.10
CP Version: 5F.03.00
USR Version: U8AA.06.01
Electrical Requirements:
Lithium Ion Battery 3.7V
Power Adapter: 100-240V ~ 50-60Hz, 0.3A
Output of the Adapter: 5V 850mA

4
contents
check it out . . . . . . . . . . . 2
contents . . . . . . . . . . . . . . 4
menu map . . . . . . . . . . . . 6
Use and Care . . . . . . . . . . 8
essentials . . . . . . . . . . . . . 9
about this guide. . . . . . . 9
activate your Mike
account . . . . . . . . . . . . 10
SIM card . . . . . . . . . . . 10
battery . . . . . . . . . . . . . 12
turn it on & off . . . . . . . 15
enable security . . . . . . 16
make a phone call . . . . 16
answer a phone call. . . 16
make a private call. . . . 16
answer a private call . . 17
store a phone
number or private ID . . 17
call a stored phone
number or private ID . . 18
find your phone
number and private ID. 19
text messages. . . . . . . 19
manage memory . . . . . 22
using your handset
as a modem. . . . . . . . . 23
accessories . . . . . . . . . 24
for more information . . 24
main attractions . . . . . . 25
PTV Features . . . . . . . . 25
one touch PTT . . . . . . . 28
Mike’s wireless
web services . . . . . . . . 29
surveillance profile. . . . 31
basics . . . . . . . . . . . . . . . 33
display . . . . . . . . . . . . . 33
text entry . . . . . . . . . . . 34
navigation key . . . . . . . 37
handsfree speaker. . . . 37
airplane mode . . . . . . . 37
features for the
hearing impaired . . . . . 38
calls. . . . . . . . . . . . . . . . . 40
turn off a call alert . . . . 40
recent calls . . . . . . . . . 40
caller ID . . . . . . . . . . . . 41
call forward . . . . . . . . . 41
voice names . . . . . . . . 42
emergency calls . . . . . 43
international calls. . . . . 43
speed dial . . . . . . . . . . 44
voicemail . . . . . . . . . . . 44
net alerts . . . . . . . . . . . 45
Mike’s Talk Around
TM
. 46

5
customize . . . . . . . . . . . 52
volume . . . . . . . . . . . . 52
ring tones . . . . . . . . . . 52
wallpaper . . . . . . . . . . 53
datebook. . . . . . . . . . . 53
hide or show
location information . . 54
other features . . . . . . . . 56
advanced calling . . . . . 56
contacts . . . . . . . . . . . 57
datebook. . . . . . . . . . . 58
GPS . . . . . . . . . . . . . . 58
handsfree . . . . . . . . . . 59
pc applications . . . . . . 60
personalize . . . . . . . . . 60
TTY . . . . . . . . . . . . . . . 61
security. . . . . . . . . . . . 62
Safety and General
Information . . . . . . . . . . 64
Service & Repairs . . . . . 69
Specific Absorption
Rate Data . . . . . . . . . . . 70
Motorola Limited
Warranty for the United
States and Canada . . . . 72
Hearing Aid
Compatibility . . . . . . . . 77
Information From
the World Health
Organization . . . . . . . . . 79
Patent and Trademark
Information . . . . . . . . . . 81
Privacy and Data
Security . . . . . . . . . . . . . 82
Smart Practices
While Driving . . . . . . . . 83

6
menu map
menu map
main menu
a Browser
q Java Apps.
• Java System
b Settings
• (see next page)
c VoiceRecord
• [New VoiceRec]
d Contacts
• [New Contact]
e Messages
•[CreateMesg]
•VoiceMail
• Inbox
•Drafts
• Sent Items
• Net Alert
•SMS
f Call Forward
• Forward: All Calls/Detailed
• To: On/Off
o Datebook
• [New Event]
g Memo
h Call Timers
•LastCall
• Phone Reset
• Phone Lifetime
• Prvt/Grp Reset
• Prvt/Grp Lifetime
• Circuit Reset
•CircuitLifetime
• Kbytes Reset
i Recent Calls
s Shortcuts
• [New Entry]
• 1)Shortcuts
• 2)Cntcs[New Contact]
• 3)Recent Calls
• 4)Contacts
• 5)Datebook
• 6)Messages
• 7)VoiceRecord
•8)Browser
• 9)Call Forward
j My Info
•MyName
• Line 1
• Line 2
• Private ID
• Group ID:
p Profiles
• New Profile
• Surveillance
• Standard
•Car
• Meeting
• Office
• Outdoors
• Headset
•PRVTOnly
• CONTCS Only
k Call Alert
l GPS
• Position
• Privacy
• Interface
m Ring Tones
M Talk Around
[ My Pictures
This is the standard main menu layout. Your
phone’s menu may be a little different.

7
menu map
settings menu
Display/Info
• Wallpaper
•Palette
• Text Size
• Home Icons
• Backlight
•Clock
• Menu View
• Large Dialing: On/Off
• Contrast Ext
• Language
Phone Calls
• Set Line
•AnyKeyAns
• Auto Redial
• Call Waiting
• Auto Ans
• Flip Activation
• Minute Beep
• Call Duration
• TTY
•HearingAid
• Notifications
2-Way Radio
• Tkgrp Silent
•TkgrpArea
• One Touch PTT
• Alert Type
• PTT Picture: On/Off
Personalize
• Menu Options
•UpKey
•DownKey
• Left Key
•RightKey
• Center Key
• Left Sftkey
• Right Sftkey
•PowerUp
Volume
•Line1
•Line2
• Messages
• Earpiece
• Speaker
•Keypad
• Java Earpiece
• Java Speaker
•Data
Security
• Phone Lock
• Keypad Lock
• SIM PIN
•GPSPIN
• Change Passwords
Advanced
• Alert Timeout:
• Headset/Spkr:
• Connectivity
• Reset Defaults
• Return to Home
• Airplane Mode
• Phone Only
• Baud Rate

8
Use and Care
Use and Care
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to
water, rain, extreme humidity,
sweat, or other moisture.
Don’t expose your phone to
dust, dirt, sand, food, or other
inappropriate materials.
extreme heat or cold cleaning solutions
Avoid temperatures below
-10°C/14°F or
above 45°C/113°F.
To clean your phone, use only a
dry soft cloth. Don’t use alcohol
or other cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a
microwave oven.
Don’t drop your phone.

9
essentials
essentials
Caution: Before using the phone for the first
time, read the Important Safety and Legal
information included in the gray edged pages
at the back of this guide.
about this guide
This guide shows how to locate a menu
feature as follows:
Find it: M > Settings
This means that, from the home screen:
1 Press the menu key M to open the
menu.
2 Press the navigation key to scroll to
Settings , and press the center key O to
select it.
symbols
This means a feature is network/
subscription dependent and may
not be available in all areas. Contact
your service provider for more
information.
This means a feature requires an
optional accessory.
OK

10
essentials
activate your Mike
account
Before you can begin using your i570
handset, you need to activate your Subscriber
Identity Module (SIM) card on The Mike
Network. Your SIM card holds the information
required to enable your handset to connect to
The Mike Network. It also stores your user
information, language preference and contact
list entries.
• If you purchased your handset through
an Authorized Mike Dealer, your SIM
should already be active.
• If you purchased your handset at
another location, follow the “Getting
Activated” instructions in the Mike
Services User’s Guide.
SIM card
insert the SIM card
Turn off your phone and remove your battery
before you install or remove a SIM card.
1 Slide the latch and open the SIM card
holder.

11
essentials
Warning: To avoid loss or damage, do not
remove your SIM card from your phone
unless absolutely necessary.
SIM card security
Your SIM card stores all your Contacts
information. Since this information is stored
on your SIM card, not in your handset, you
can remove the information by removing your
SIM card.
Note: Except for making emergency calls,
your handset will not function without the
SIM card.
To prevent unauthorized use of your handset,
your SIM card can be protected by a PIN that
you enter each time the handset is powered
on. You can change the PIN or turn off the
requirement that it be entered.
Note: Your PIN is set to OFF by default.
entering the PIN
You may be required to enter a SIM PIN when
you first use your handset.
2 Carefully slide your SIM card into the
SIM card holder.
3 Close the SIM card holder.

12
essentials
When you receive your handset, the SIM PIN
is 0000. Change your PIN to prevent
fraudulent use of the SIM card. See
“security” on page 61.
1 When the Enter SIM PIN Code screen appears,
enter your SIM PIN. An asterisk appears
for each character entered.
2 Press - under Ok .
Warning: If you enter your PIN incorrectly 5
times, your SIM card is blocked. To unblock
your SIM card, you must contact TELUS
Client Care.
battery
Battery Use & Battery Safety
• Motorola recommends you always
use Motorola-branded batteries and
chargers.
The warranty does not cover
damage caused by non-Motorola
batteries and/or chargers.
Caution: Use of an unqualified battery
or charger may present a risk of fire,
explosion, leakage, or other hazard.
Improper battery use, or use of a
damaged battery, may result in a fire,
explosion, or other hazard.
• Battery usage by children should be
supervised.
• Important : Motorola mobile devices
are designed to work best with
qualified batteries. If you see a
message on your display such as
Invalid
Battery
or Unable to Charge , take the
following steps:
• Remove the battery and inspect it to
confirm that it bears a Motorola
“Original Equipment” hologram;

13
essentials
• If there is no hologram, the battery
is not a qualified battery;
• If there is a hologram, replace the
battery and retry charging it;
• If the message remains, contact a
Motorola Authorized Service Center.
• New batteries or batteries stored for a
long time may take more time to
charge.
• Charging precautions: When
charging your battery, keep it near
room temperature. Never expose
batteries to temperatures below 0°C
(32°F) or above 45°C (113°F) when
charging. Always take your mobile
device with you when you leave your
vehicle.
• When storing your battery, keep it in a
cool, dry place.
• It is normal over time for battery life to
decrease, and for the battery to exhibit
shorter runtime between charges or
require more frequent or longer
charging times.
• Avoid damage to battery and mobile
device.
Do not disassemble, open,
crush, bend, deform, puncture, shred,
or submerge the battery or mobile
device. Avoid dropping the battery or
mobile device, especially on a hard
surface. If your battery or mobile
device has been subjected to such
damage, take it to a Motorola
Authorized Service Center before
using. Do
not attempt to dry it with an
appliance or heat source, such as a hair
dryer or microwave oven.
• Use care when handling a charged
battery
: particularly when placing it
inside a pocket, purse, or other
container with metal objects. Contact

14
essentials
with metal objects (e.g., jewelry, keys,
beaded chains) could complete an
electrical circuit (short circuit), causing
the battery to become very hot, which
could cause damage or injury.
Promptly dispose of used batteries in
accordance with local regulations.
Contact your local recycling center for
proper battery disposal.
Warning: Never dispose of batteries in a fire
because they may explode.
battery installation
1 Slide the release button back until it
releases the battery door.
2 Remove the battery door.
3 Push the battery down until it snaps in
place.
4 Replace the battery door and press it
gently until you hear a click.

15
essentials
battery charging
New batteries are not fully charged.
1 Insert the charger
into the connector
on your phone as
shown.
2 Plug the other end
of the charger into
the appropriate
electrical outlet.
When you charge the
battery, the battery level
indicator at the upper
right of the screen shows charging progress.
At least one segment of the indicator must be
visible to ensure full phone functionality while
charging.
Tip: Motorola batteries have circuitry that
protects the battery from damage from
overcharging. Of course, unplugging the
charger from the wall will avoid current drain.
turn it on & off
To turn on your phone,
press and hold
W for a
few seconds or until the
display turns on. If
prompted, enter your
four-digit unlock code.
To turn off your phone,
press and hold
W for
two seconds.
enable security
You must enable security the first time you
power on you phone or within 10 days of first
activation.
1 Press - under Ok .

16
essentials
2 You are prompted to enable security.
Press
- under Yes .
3 Press o to return to the idle screen.
make a phone call
Enter a phone number and press O to make
a call or use a voice name. See “voice
names” on page 42.
Tip: For best performance avoid touching the
antenna with your fingers during the call.
To hang up, close the flip or press
o .
answer a phone call
When your phone rings and/or vibrates, you
have the following options to answer the call:
1 If you want to talk on speaker phone,
press the speaker key
t without
opening the flip. To hang up press the
smart key
. .
2 If you want to answer the call using the
ear speaker, just open the flip and press
O . To hang up, close the flip or press
o .
Note: You must have the Flip Activation feature
On. See “advanced calling” on page 56.
make a private call
With Private calls service, you use your phone
as a long-range, digital 2-way radio using one-
to-one Private calls or one-to-many group
calls.
Your Private ID is the number at which you
receive one-to-one Private calls.
Talkgroup numbers are numbers through
which you receive one-to-many group calls.

17
essentials
1 To make a private call enter the Private ID
you want to call.
2 Push and hold the PTT button. Begin
talking after your phone emits a chirping
sound.
3 Release the PTT button to listen.
To end the call press
o , or press -
under
Exit .
A Private call ends automatically if there is
no activity on the call for a few seconds.
Tip: To let someone know you want to talk to
them on a Private call, press
- under Alert .
answer a private call
1 When your phone emits a chirping sound
or vibrates to indicate you are receiving a
Private call, wait for the caller to finish
speaking.
2 Push and hold the PTT button and begin
talking after your phone emits a chirping
sound.
3 Release the PTT button to listen.
To end the call press
- under Exit .
store a phone number
or private ID
You can store a phone number or Private ID in
Contacts :
Find it: M > Contacts > [New Contact] .
1 Enter a name for the new entry. Each
entry’s name can contain 20 characters.
2 Select a specific Ringer
.
3 Select a type for the entry ( Mobile , Private ,
Work1 , Work2 , Home , Fax , Pager , or Other ).
4 Enter the number for the entry.
