Motorola iDEN i305 User manual

Nextel
iDEN
Digital Multi-service Data-capable Phone
i305 Phone User’s Guide
@NNTN5461B@
NNTN5461B

i
Contents
Getting Started........................................... 1
Removing the Battery Door...............................2
Locating Your SIM Card....................................2
Battery...............................................................3
Powering On and Off.........................................5
Activating Service..............................................6
Enabling Security ..............................................6
Phone Programming .........................................6
Finding Your Phone Number and Direct
Connect®Number ........................................7
Nextel®Voice Mail ............................................7
Nextel Worldwide®Service ...............................8
Customizing Features .......................................8
Phone Basics ....................................................8
SIM Card Security ...........................................12
Locking the Keypad.........................................15
Antenna...........................................................16
Accessories.....................................................16
Wireless Local Number Portability: Bringing
Your Phone Number From Another
Carrier.........................................................17
Nextel®Customer Care...................................18
Making Calls .............................................20
Phone Calls.....................................................20
Direct Connect®Calls .....................................20
Receiving Calls ...............................................20
Call Icons ........................................................21
Ways to Enter Calls.........................................21
Using Speakerphone.......................................23
Using Mute......................................................24
Making Emergency Phone Calls.....................24
Call Alerts..................................................26
Sending Call Alerts..........................................26
Receiving Call Alerts.......................................26
Using the Call Alert Queue..............................26
Recent Calls..............................................28
Storing Recent Calls to Contacts ....................28
Deleting Recent Calls......................................29
Entering Text ............................................30
Using Alpha Mode...........................................30
Using Word Mode ...........................................30

ii
Special Function Keys.....................................31
Using Numeric Mode.......................................32
Using Symbols Mode ......................................32
Contacts ................................................... 33
Viewing Contacts.............................................34
Creating Entries...............................................35
Storing Numbers Faster ..................................36
Editing Entries.................................................37
Deleting Entries...............................................37
Checking Capacity ..........................................38
Creating Pauses and Waits.............................38
International Numbers.....................................38
Memo ........................................................ 39
Call Forwarding........................................ 40
Forwarding All Calls ........................................40
Turning Off Call Forwarding ............................41
Forwarding Missed Calls.................................41
Viewing Call Forwarding Settings....................42
Advanced Calling Features..................... 43
Call Waiting.....................................................43
Call Hold..........................................................44
3-Way Calling..................................................44
Creating Pauses and Waits While Dialing.......45
Making International Calls...............................45
Setting One Touch Direct Connect®.................... 45
Group ConnectTM Calls...................................46
Call Timers......................................................48
Using Your Phone as a Modem ......................48
Making TTY Calls............................................49
Special Dialing Codes.....................................51
Nextel®Phone Services...........................52
Caller ID ..........................................................52
Per-Call Blocking.............................................52
Per-Line Blocking............................................52
Alternate Line Service.....................................52
Call Restrictions ..............................................53
Nextel®411.....................................................53
Ring Tones................................................54
Setting Your Phone to Vibrate.........................54
Ring and Vibrate .............................................55
Assigning Ring Tones to Contacts..................55

iii
Viewing Ring Tone Assignments.....................55
Downloading More Ring Tones.......................56
Managing Memory...........................................56
Deleting Custom Ring Tones ..........................56
Message Center....................................... 57
Accessing the Message Center.......................57
Message Center Options.................................57
Receiving Messages................................ 58
Message Notifications .....................................58
Message Center..............................................59
Voice Mail Messages............................... 60
Receiving a Message......................................60
Accessing Voice Mail from
the Message Center ...................................60
Sending Unanswered Calls to Voice Mail .......60
Nextel®Voice Mail ................................... 61
Setting Up Your Voice Mail Box ......................61
Playing Messages ...........................................61
Changing Your Password................................62
Recording Your Name.....................................62
Recording Your Active Greeting......................63
Advanced Voice Mail Features .......................63
Nextel®Voice Mail Tree..................................68
SMS and Two-Way Messages .................69
SMS Messages...............................................69
Two-Way Messages and Net Alerts................70
Wireless Data Services............................73
Wireless Data Services...................................73
Accessing Wireless Data Services From Your
Phone .........................................................74
Navigation Keys ..............................................74
Guides and Demos .........................................75
GPS Enabled.............................................76
IMPORTANT: Things to Keep in Mind ............76
Making an Emergency Call .............................77
Viewing Your Approximate Location ...............78
Enhancing GPS Performance.........................79
Updating Satellite Almanac Data ....................81
Setting Privacy Options...................................81
Using GPS with Map Software........................82

iv
Customizing Your Phone........................ 85
Setting the Volume..........................................85
Setting Your Phone to Not Ring ......................85
Seeing the Display Better................................86
Using Settings.................................................86
Optional Features............................................88
Using a Headset....................................... 89
Attaching a Headset........................................89
Using a Remote PTT Button ...........................89
Nextel®Customer Care........................... 90
Domestic Customer Care................................90
Nextel Worldwide®Customer Care.................91
Understanding Status Messages........... 92
Nextel®Terms and
Conditions of Service.......................... 94
Safety and General Information ........... 116
RF Operational Characteristics.....................116
Portable Radio Product Operation and EME
Exposure...................................................116
Electro Magnetic Interference/Compatibility..120
Medical Devices............................................120
Operational Warnings ...................................121
Operational Cautions ....................................122
Accessory Safety Information .......................123
MOTOROLA LIMITED WARRANTY.......125
Patent and Trademark Information.......129
Index ........................................................130

v
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola, Inc.
Address: 8000 West Sunrise Boulevard
Plantation, FL 33322 USA
Phone Number: 1 [phone]
Hereby declares that the product:
Product Name: i305
Model Number: H62XAH6RR1AN
Conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a),
15.107(d) and section 15.109(a)
Class B Digital Device
As a personal computer peripheral, this device
complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.

1
Getting Started
audio jack
accessory connector
volume
controls
speaker
(in back)
Push-to-talk
(PTT) button
microphone
space key
back key
DIRECT
CONNECT®/
GROUP CONNECTTM
speaker on/off
option keys power button
retractable
antenna
pPower button.
Navigation key — press the arrows to
scroll through menusand lists.
mMenu key — accesses context-sensitive
menus.
AOption key — selects the option
appearing above it on the display.
Note: Throughout this User’s Guide,
the option keys will be
represented by A.
sSend key — places phone calls.
eEnd key — ends phone calls; returns to
idle screen; in Wireless Data Services,
returns to Net main menu.

2
Getting Started
To start using your i305 phone:
•Make sure your SIM card is in place.
•Charge the battery.
•Activate your service.
•Enable security.
Removing the Battery Door
1Make sure the phone is powered off. See
“Powering On and Off” on page 5.
2Slide the release button forward until it releases
the battery door.
3Remove the battery door from the back of your
phone.
Locating Your SIM Card
Your SIM (Subscriber Identity Module) card is a
small piece of plastic located in the SIM card
holder in the back of your phone, underneath the
battery.
If there is no SIM card in your phone, contact
Nextel Customer Care at 1-800-639-6111.
release
button
speaker
SIM card
holder
SIM card

3
Battery
If want to use a SIM card other than the one that is
in your phone, please contact Nextel Customer
Care to verify that the SIM card you want to use is
compatible with your phone.
Battery
Inserting the Battery
Your phone comes with an Extended Capacity
Lithium Ion battery.
1Remove the battery door.
2Insert the top of the battery into the battery area.
Press the bottom of the battery to secure it.
3Replace thebattery door andpress it gentlyuntil
you hear a click.
Charging the Battery
Your phone comes with a standard travel charger.
1Plug the charger into an electrical outlet.
2Open the connector cover.
connector cover

4
Getting Started
3Plug the other end of the charger into the
accessory connector.
ChargerAttached orDeviceAttached appears
on the display.
Tip: To remove the charger from the accessory
connector: Press the buttons on the sides
of the plug. Pull the plug straight out.
4If you have purchased optional batteries or
chargers, see “Charging Times”.
Note: While the phone is charging, the keypad
backlight will not illuminate.
Charging Times
Check your battery and charger type against the
below grid to determine appropriate charging
times.
Recommended charging times:
For best results, charge the batteries within the
temperature range of 50°F to 104°F (10°C to
40°C).
Prolonged charging is not recommended.
Battery Charger
Rapid Standard
Standard
Lithium Ion 2 hours 4 hours
Extended
Capacity
Lithium Ion
2.25 hours 6 hours
High
Capacity
Lithium Ion
3.5 hours 7.5 hours

5
Powering On and Off
Removing the Battery
1With the phone powered off, remove the battery
door.
2Remove the battery by pushing the battery
toward the antenna and lifting it out.
Battery Use and Maintenance
•The Motorola iDEN Approved Lithium Ion
chargers provide optimum performance. Other
chargers may not fully charge the iDEN Lithium
Ion battery or may yield a reduced number of
lifetime charge cycles.
•Extreme temperatures degrade battery
performance. Do not store the battery where
temperatures exceed 140°F (60°C) or fall below
4°F (-20°C).
•Lithium Ion batteries have a self discharge rate
and without use, lose about 1% of their charge
per day.
•The battery capacity is degraded if the battery is
stored for long periods while fully charged. If
long term storage is required, store at half
capacity.
Powering On and Off
To power your phone on:
Press p.
As your phone connects to the network, you will
see a connecting message. When the idle screen
appears, the phone is ready to use.
To power your phone off:
Press and hold p.

6
Getting Started
Activating Service
The first time you power on your phone, your
service is activated.
A screen then appears prompting you to select Ok
to update your browser information. This screen
will only appear during initial activation. See
“Enabling Security”.
Enabling Security
You must enable security the first time you power
on yourphone or within 10 days of first activation of
your phone.
1Press Aunder Ok.
Note: If you press Aunder Later, the idle
screen will appear. The next time you
select Net from the main menu, you will
be prompted to enable security before you
can use Wireless Data Services.
2You are prompted to enable security. Press A
under Yes. A series of screens and then the
default homepage displays.
3Press eto return to the idle screen.
Phone Programming
Within 24 hours of enabling security, you will
receive a Net alert containing your Personal
Telephone Number (PTN), Nextel Customer Care
number, Direct Connect®number, and Talkgroup
lists for Group ConnectTM calls.
1When you receive a Net alert saying New
Browser Message - Receive Programming
Info, press Aunder Goto.
2You are prompted to accept changes to your
lists. Press Aunder Ok.
3You are prompted again to accept changes to
your lists. Press Aunder Ok.
4A confirmation screen displays. Press Aunder
Ok.
5Press eto return to the idle screen.

7
Finding Your Phone Number and Direct Connect®Number
Finding Your Phone Number
and Direct Connect®Number
My Info lets you view your phone number, Direct
Connect number, and other phone information:
1Press mto access the main menu.
2Scroll to My Info.
3Press Aunder Select.
4Scroll to see your information:
•Name— Enter your name. See “Entering
Text” on page 30.
• Line 1 and Line 2 — your phone numbers for
phone lines 1 and 2. These are filled in when
you receive your first Net alert after enabling
security on your phone.
•DirectConnect— Your Direct Connect
number is the number that others use to
contact you using Direct Connect®service.It is
filled in when you receive your first Net alert
after enabling security on your phone. To view
your Direct Connect number, scroll to Direct
Connect and press Aunder View.
• Group ID — the number of the Talkgroup you
have joined.
• Carrier IP — the IP address assigned to
Nextel. It is filled in when you register for
packet data services. To view your Carrier IP
address, scroll to Carrier IP and press A
under View.
• IP1 Address and IP2 Address — the IP
addresses assigned to you for using the
Internet with your phone. To view your IP
addresses, scroll to the IP address you want
to view and press Aunder View.
•Ckt— Your circuit data number is the number
you use if you want to use your phone to
transfer circuit data. See “Using Your Phone
as a Modem” on page 48. You receive this
number from Nextel.
Nextel®Voice Mail
You must set up your voice mail box before you
can retrieve messages. See “Setting Up Your
Voice Mail Box” on page 61.

8
Getting Started
Nextel Worldwide®Service
You can use your phone to make calls
internationally in select cities using other iDEN®
networks by calling Nextel Customer Care to
activate international dialing on your account.
Countries in which you can useyour phone include
Argentina, Brazil, Canada, Israel, Jordan, Mexico,
Peru, the Philippines, and Singapore*.
* Credit approval may be required. Other conditions may apply.
Customizing Features
You can control many features of your phone,
including the volumeof incoming sound, rings, and
other tones. See “Customizing Your Phone” on
page 85.
Phone Basics
Display
Any time your phone is powered on, the display
providesyou with information and options.
The screen shown above is the idle screen. The
idle screen appears when your phone is on, but not
engaged in any activity.
Text Area
This area displays menus, messages, names,
phone numbers, and other information.
status icons
text area
menu icon
display options

9
Phone Basics
Display Options
Two display options appear at the bottom of most
screens. You select a display option by pressing
the option key below it.
Menus and Lists
Your phone’s features are arranged in menus,
submenus, and lists.
To access the items in a menu or list, scroll using
the navigation key at the top of your keypad. This
key lets you scroll up, down, left, or right. Holding
down the appropriate part of the navigation key
speeds up scrolling.
In this guide, this symbol >tells you to select a
menu or list item. For example, Settings >
Security means:
1Scroll to Settings on the main menu.
2Press Aunder Select to see the Settings
screen.
3Scroll to Security and press Aunder Select to
see the Security screen.
Menu Key
Many features provide context-sensitive menus
that let you access related features and actions.
The Sicon appears any time a context-sensitive
menu is available. Press mto access the menu.
Main Menu
All your phone’s features can be accessed through
the main menu. When you are using a feature, the
icon for that feature appears in the upper left
corner of the display.
aNet Access to Wireless Data
Services. See page 73.
bSettings
Display/Info
Phone Calls
DC/GC Options
Volume
Security
Advanced
Customize your phone.
See page 85.
mRing Tones
Vibrate All
list of ring tones
Ring Tones menu
Assign ring tones and turn
ringer off. See page 54.

10
Getting Started
jMy Info View personal phone
information, including
phone number and Direct
Connect number. See
page 7.
nDownloads Provides a catalog of ring
tones that you can
download directly to your
phone. Browse through
the catalog, download a
ring tone of your choice
and make that your
default ring tone. Ring
tones in this catalog
change frequently, so
check regularly for fresh
content. See page 56.
lGPS Find your approximate
geographical location.
See page 76.
dContacts
new contact form
list of contacts
Contacts menu
Create, view, store, edit
contacts. See page 33.
eMessages
Voice Mail
SMS
Net Alert
Access messages. See
page 57.
fCall Forward Set call forwarding
options. See page 40.
gMemo Store a number to access
later. See page 39.
hCall Timers Phone usage information.
See page 48.
iRecent Calls
list of calls
recent calls menu
Call Setup menu
Lists recent calls. See
page 28.
kCall Alert
list of call alerts
Call Alert menu
Lists call alerts. See
page 26.

11
Phone Basics
Status Icons
Status icons appear in the two rows at the top of
the display. Some appear at all times. Others
appear onlywhen your phone is engaged in certain
activities or when you have activated certain
features.
abcd
efgd
Battery Strength — More bars on
the battery indicate a greater
charge.
opqr
sSignal Strength — More bars next to the antenna indicate a
stronger signal.
APhone In Use — Your phone is
active on a phone call.
BDirect Connect In Use — Your
phone is active on a Direct
Connect call.
CTalkgroup In Use — Your phone
is active on a Group Connect call.
12Active Phone Line — 1 indicates
phone line 1 is ready to make
calls; 2 indicates phone line 2 is
ready to make calls.
GHI
JKLCall Forward — Your phone is set to forward calls. See “Call
Forwarding” on page 40.
vR
M
Ringer Off — Your phone is set
not to ring. See “Setting Your
Phone to Vibrate” on page 54.
uSpeaker Off — Sets Direct
Connect and Group Connect
sound to come through the
earpiece rather than through the
speaker.
wy Messages — You have one or
more messages. See “Receiving
Messages” on page 58.
ljik
mn T9 Text Input — You are using T9 Text Input to enter text. See
“Entering Text” on page 30.
DEF Internet — You are ready to
browse the internet or are
browsing the internet using a
secure connection.

12
Getting Started
SIM Card Security
Your SIM card stores all your Contacts and
protects your personal information. Since this
information is stored on your SIM card, not in your
phone, you can remove the information by
removing your SIM card.
Note: Except for making emergency calls, your
phone will not function without the SIM
card.
To prevent unauthorized use of your phone, your
SIM card is protected by a PIN that you enter each
time the phone is powered on. You can change the
PIN or turn off the requirement that it be entered.
Turning the PIN Requirement On and
Off
When the SIM PIN requirement is off, your phone
can be used without entering a PIN.
Important: When the SIM PIN requirement is off,
the personal data on your SIM card is
not protected. Anyone can use your
phone and access your personal data.
When the SIM PIN requirement is on, you are
prompted to enter your PIN each time you power
on your phone.
Note: If a SIM PIN is required, your phone will
not function until the SIM PIN is entered,
except for making emergency calls.
1From the main menu, select Settings >
Security > SIM PIN.
2Scroll to On or Off.
3Press Aunder Select.
4Enter the current SIM PIN.
Note: The default SIM PIN is 0000. Change your
PIN to prevent fraudulent use of the SIM
card (see “Changing the PIN” on page
13).
5Press Aunder Ok.
YZ Packet Data — You are ready to
transfer packet data or are
transferring packet data. See
“Using Your Phone as a Modem”
on page 48.
NO TTY — You are ready to use your
phone to make calls using a
teletypewriterdevice. See “Making
TTY Calls” on page 49.
