Motorola MOTOKRZR K1m User manual

MOTOKRZR K1m
USER GUIDE
MOTOKRZRTM
VSPOT RED
CMYK 00/100/76/06

113
Motorola, Inc.
Consumer Advocacy Office
600 N US Hwy 45
Libertyville, IL 60048
www.hellomoto.com
Note: Do not ship your phone to the above address. If you need to
return your phone for repairs, replacement, or warranty service, please
contact the Motorola Customer Support Center at:
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Certain mobile phone features are dependent on the capabilities and
settings of your service provider’s network. Additionally, certain
features may not be activated by your service provider, and/or the
provider’s network settings may limit the feature’s functionality. Always
contact your service provider about feature availability and functionality.
All features, functionality, and other product specifications, as well as
the information contained in this user’s guide, are based upon the latest
available information and believed to be accurate at the time of
printing. Motorola reserves the right to change or modify any
information or specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. The Bluetooth trademarks are owned by their
proprietor and used by Motorola, Inc. under license. Microsoft and
Windows are registered trademarks of Microsoft Corporation. All other
product or service names are the property of their respective owners.
© 2009 Motorola, Inc. All rights reserved.
Caution: Changes or modifications made in the radio phone, not
expressly approved by Motorola, will void the user’s authority to operate
the equipment.
Manual Number: 6809515A77-A
U.S. patent Re. 34,976

1
HELLOMOTO
Introducing your new MOTO KRZR ™K1m wireless phone. Here’s a quick anatomy lesson.
N
Contacts
P
X
51
Smart/
Speakerphone
Key
Make & answer
calls.
Scroll up, down,
left, or right.
Turn on & off,
hang up, exit
menus.
Select.
Volume Keys
Left Soft Key Right Soft Key
Clear/Back Key
Mini USB Port
Charge &
connect phone
accessories.
Voice
Command/
Voice Record
Key
Play/
Pause
Skip
back.
Skip
forward.
Music Player Controls/
Camera
Increase/
decrease
volume.
Launch
music,
lock player
controls
or
use camera
(press and
release).
N
P
X
51

2
6Îì
MON 7/30/07
8:45am
Contacts Bluetooth
E
F
A C
I
GD
H
H
E
A
F
1
2
3
Press the center
key sto open the
Main Menu.
Press and hold the
Power Key P for a
few seconds or until
the display lights up to
turn on your phone.
4
Home Screen Main Menu
Press the center
key sto select.
Press the navigation
key S
up , down ,
left , or right to
highlight a menu
option.
Go To Exit
My Stuff
B

3

4
contents
contents
menu map . . . . . . . . . . . 6
essentials . . . . . . . . . . . . 8
about this guide. . . . . . . 8
battery . . . . . . . . . . . . . . 9
turn it on . . . . . . . . . . . 10
adjust volume . . . . . . . 10
make a call. . . . . . . . . . 11
answer a call . . . . . . . . 11
change call alert. . . . . . 12
view your phone
number . . . . . . . . . . . . 12
main attractions . . . . . 13
airplane mode . . . . . . . 13
MP3 music player . . . . 13
take & send photo . . . . 24
record & play video clip 26
send multimedia
message . . . . . . . . . . . 28
receive multimedia
message . . . . . . . . . . . 31
memory card . . . . . . . . 32
cable connections . . . . 36
Bluetooth™
connections . . . . . . . . . 36
TTY operation . . . . . . . 38
basics . . . . . . . . . . . . . . 41
home screen . . . . . . . . 41
navigation key . . . . . . . 43
menus . . . . . . . . . . . . . 44
enter text. . . . . . . . . . . 46
external display . . . . . . 52
handsfree speaker. . . . 52
change a code or
password. . . . . . . . . . . 53
lock/unlock phone . . . . 54
if you forget an unlock
code or security code . 54
customize . . . . . . . . . . 55
ring styles & alerts. . . . 55
answer options . . . . . . 56
wallpaper . . . . . . . . . . . 56
screen saver . . . . . . . . 56
display brightness . . . . 57
display timeout . . . . . . 57
backlight . . . . . . . . . . . 57
talking phone settings . 58
conserve battery . . . . . 58
calls . . . . . . . . . . . . . . . 59
redial . . . . . . . . . . . . . . 59
automatic redial . . . . . . 59
silence a call alert . . . . 59
emergency calls . . . . . 60
call history . . . . . . . . . . 60

5
contents
notepad . . . . . . . . . . . 61
return unanswered call 62
attaching a number. . . 62
speed dial . . . . . . . . . . 62
1-touch dial . . . . . . . . . 63
voicemail . . . . . . . . . . 63
other features . . . . . . . . 64
advanced calling . . . . . 64
messages. . . . . . . . . . 65
contacts . . . . . . . . . . . 67
personalize . . . . . . . . . 73
call times . . . . . . . . . . 78
Bluetooth™ wireless
connections . . . . . . . . 78
handsfree . . . . . . . . . . 80
network information . . 81
personal organizer . . . 82
security. . . . . . . . . . . . 83
fun & games. . . . . . . . 84
service & repairs . . . . . . 86
Battery Use & Safety . . 87
Battery Charging . . . . . 88
Software Copyright
Notice
. . . . . . . . . . . . . 90
Content Copyright . . . . 90
AGPS & Emergency
Calls
. . . . . . . . . . . . . . . 90
Industry CanadaNotice to
Users
. . . . . . . . . . . . . . 97
FCC Notice to Users . . . 97
Use & Care . . . . . . . . . . 98
MotorolaLimited Warranty
for the United States and
Canada
. . . . . . . . . . . . . 99
HearingAid Compatibility
with Mobile Phones
. . 102
Information from the World
Health Organization
. . 103
Product Registration . 103
Export Law
Assurances
. . . . . . . . . 103
Caringfor the Environment
by Recycling
. . . . . . . . 104
California Perchlorate
Label
. . . . . . . . . . . . . . 104
Privacy and Data
Security
. . . . . . . . . . . . 104
Smart Practices While
Driving
. . . . . . . . . . . . 105
index . . . . . . . . . . . . . . 107

6
menu map
menu map
main menu
A My Account
C Contacts
F Messaging
• Create Message
•Voicemail
• Inbox
• Outbox
• Preset Messages
•Drafts
• Browser Alerts
B Games & Apps
E My Stuff
• MP3 Player
•Camera
•Pictures
• Sounds
• Videos
• Video Camera
• Get Multimedia
H Web
G Settings
(see next page)
This is the standard main
menu layout. Your phone’s
menu may be a little different.
I Tools
• Calculator
• Datebook
• Voice Records
•AlarmClock
• Airplane Mode
D Call History
•Received
•Dialed
• Notepad
• Call Times

7
menu map
settings menu
t RingStyles
•Style
•Style Detail
l Personalize
• Home Screen
•MainMenu
•Skin
• Wallpaper
• Screen Saver
• Sound Settings
U In-Call Setup
• Auto Prepend ‘1’
• In-Call Timer
• Answer Options
u Security
• Phone Lock
• Lock Keypad
• Lock Application
• Restrict Calls
• New Passwords
Z Initial Setup
• SpeakerPhone
• Auto Redial
• Display Timeout
• Backlight
• TTY Setup
•Scroll
• Language
• Battery Save
• Brightness
•DTMF
• Hyphenation
• Master Reset
•MasterClear
j Network Info
• Current Network
•SetMode
• Service Tone
• Call Drop Tone
J Car Settings
• Auto Answer
• Auto Handsfree
•Power-offDelay
• Charger Time
S Headset
• Auto Answer
•VoiceDial
ò Location
• Location On
L Connection
• Bluetooth™ Link
c Apps Settings
• Backlight
• Sounds
• Notification
m Phone Info
•MyTel.Number
•BatteryMeter
• Storage Devices
• Other Information

8
essentials
essentials
about this guide
This guide shows how to locate a menu
feature as follows:
Find it: s > DCall History > Dialed
This example shows that from the home
screen, you must press the center key
s to
open the main menu, scroll to
Call History , then
scroll to and select
Dialed . Press S to scroll
and the center key
s to select a menu
option.
CAUTION: Before using the phone for the
first time, read the
Important Safety and
Legal Information
included in the
gray-edged pages at the back of this guide.
032259o
symbols
This means a feature is network/
subscription dependent and may not
be available in all areas. Contact your
service provider for more
information.
This means a feature requires an
optional accessory.

9
essentials
battery
install the battery
1
2
3
charge the battery
1 Insert the
charger into the
USB connector
on your phone
as shown.
2 Plug the other
end of the charger into the appropriate
electrical outlet.
3 When your phone displays Charge Complete ,
remove the charger.
Tip: You can safely leave the charger
connected to the phone after charging is
complete. This will
not damage the battery.

10
essentials
When you charge the battery, the battery level
indicator at the upper right of the screen
shows charging progress. At least one
segment of the battery level indicator must be
visible to ensure full phone functionality while
charging.
To charge from your PC:
You can charge your battery by connecting a
cable from your phone’s mini-USB port to a
high-power USB port on a computer (not a
low-power one such as the USB port on your
keyboard or bus-powered USB hub). Typically,
USB high-power ports are located directly on
your computer.
Both your phone and the computer must be
turned on, and your computer must have the
correct software drivers installed. Cables and
software drivers are available in Motorola
Original data kits, sold separately.
turn it on
1 Open your phone.
2 Press and hold
the power key for
three seconds.
The phone may
require several
seconds to power on.
3 If necessary, enter your four-digit unlock
code (the last four digits of your phone
number) and press
OK to unlock the
phone.
adjust volume
Press the up or
down volume keys
to:
Power
Key
Volume
Keys

11
essentials
• increase or decrease earpiece volume
during a call
• increase or decrease ringer volume
setting when the home screen is
visible (phone must not be in a call and
flip must be open)
• silence an incoming call alert
make a call
Note: You must dial the phone number from
the home screen. See page 41.
1 Dial the number.
Tip: If you make a mistake, press the
clear key
B to delete the last digit. Press
and hold
B to clear all digits.
2 Press N to make the call.
3 Press P to end the call.
Tip: Closing the flip also ends the call unless
you are using the speakerphone feature (see
page 52).
answer a call
1 Press N to answer.
2 Press P to end the call.
Tip: You can set the phone to answer calls
when you open the flip:
Find it: s > GSettings > In-Call Setup
>
Answer Options > Open To Answer
Note: If the phone is locked, you must first enter
your four-digit unlock code to answer the call.

12
essentials
change call alert
phone flip open
From the home
screen, press the
down volume key
to switch to lower
call alert volume,
then switch to vibrate and, finally, to silent
alert. Press the up volume key to cycle back
from silent alert to vibrate and then to the
lowest alert volume setting.
phone flip closed
Press the up or
down volume key
for two seconds,
then press the
smart/speaker-
phone key to scroll
through alert styles:
Loud , Soft , Vibrate , Vibe then
Ring
, and Silent . Alert styles are shown on the
external display.
After scrolling to the desired alert style, press
the up or down volume key to save the setting
and return to the home screen.
view your phone
number
To view your phone number from the home
screen:
• Press B# .
or
• Press s > GSettings > Phone Info
>
My Tel. Number .
While you are on a call, press
Options , then
select
My Tel. Number .
Volume
Keys
Volume keys
Smart/
Speaker-
phone key

13
main attractions
main attractions
You can do much more with your phone than
make and receive calls!
airplane mode
Note: Consult airline staff about the use of
Airplane Mode in flight. Turn off your phone
whenever instructed to do so by airline staff.
Airplane mode turns off your phone’s calling
features in locations where wireless phone
use is prohibited. You can use the phone’s
other non-calling features in airplane mode.
Find it: s > ITools > Airplane Mode
>
Airplane Mode > On or Off
Your phone can prompt you to activate or
deactivate airplane mode each time you turn
on the phone:
Find it: s > ITools > Airplane Mode
>
Prompt atStartup > On or Off
MP3 music player
Use your phone’s MP3 music player to play
MP3 music files that you copy to your phone
or to an optional memory card (see page 32).
If you have a memory card in your phone, the
music player uses it as its default storage
device for music. If you do not have a memory
card, the player uses phone memory.
Note: You can use the Sounds option of My Stuff
(see page 85) to listen to music files in
formats other than MP3. However, the
Sounds
option does not include all of the capabilities
of the MP3 music player.

14
main attractions
load music
To copy music from a computer to your
memory card, see page 34.
Some wireless providers offer services
that allow you to buy and download
music from a Web site. Contact your wireless
provider for more information.
Note: If you download a protected file and
store it on your memory card, you can use the
file only while your memory card is inserted in
your phone. You cannot send, copy, or change
protected files.
play music—flip closed
To activate the MP3 player or to resume
playback
while the flip is closed, press and
hold the smart/speakerphone key
until the
touch sensor controls are lit (see page 1).
Lock the touch sensor controls by holding the
smart/speakerphone key
for two seconds .
Repeat this step to unlock the controls.
touch sensor controls
pause/play
Press & release y .
fast forward Press & hold z (for at
least two seconds).
skip to next
song
Press & release z .
rewind Press & hold x (for at
least two seconds).
skip back to
previous
song
Press & release x (for at
least two seconds).
turn off
music
player
Press & hold y (for at least
four seconds).

15
main attractions
play music—flip open
To activate your phone’s MP3 music player
while the flip is open :
Find it: s > EMy Stuff > MP3 Player
Your phone displays the My Music menu:
The MP3 player
My Music menu includes:
My Music
Playlists
Recently Played
Artists
Albums
Songs
Genres
Help
Options Exit
Highlighted
Selection
Press Exit
to exit
MP3 player.
Press Options
to open
Options menu.
option description
Playlists Create or play a playlist.
Recently Played View & play songs you played
recently.
Artists Find & play music by an
artist.
Albums Find & play music from a
specific album.
Songs Find & play a song.
Note: All of your phone’s
songs are listed here. Some
songs do not have
Artist , Album ,
or
Genre information, so that
information is not included.
Genres Find & play music from a
specific genre (type of music)
such as rock or jazz.

16
main attractions
While a song is playing on the MP3 player,
your phone’s screen will look similar to the
following:
Use these keys to control the MP3 player:
Help Read help tips for a good
music experience.
option description
All Songs
ne a Little Bit Closer.mp3
05 Come a Little Bit Clos. . .
Hello Moto.mp3
adrenaline
flawless
e a Little Bit Closer.mp
1:33 4:49
Options Back
When lit, indicates
Replay turned on.
When lit,
indicates
Shuffle
turned on.
controls with flip open
pause/play
Press & release the center
key
s .
or
Press Options > Pause to
pause. Press
Resume to
resume play.
fast forward Press & hold S right
(for at least two seconds).
skip to next
song
Press & release S right .
rewind Press & hold S left (for at
least two seconds).
skip back to
previous
song
Within first two seconds of
song, press &
release
S left .

17
main attractions
play music from a playlist
Play aplaylist or song:
Find it:
s > EMy Stuff > MP3 Player > Playlists
1 Scroll to the playlist you want and press
the center key
s .
2 To play the entire playlist beginning with
the first song, press the center key
s
again.
or
To begin play at a selected song, scroll to
the song you want and press the center
key
s .
Play all songs from all playlists:
Find it:
s > EMy Stuff > MP3 Player > Playlists
1 Press Options .
2 Scroll to Play and press Select .
return to
song
beginning
After first two seconds of
song, press &
release
S left .
scroll up/
down
through list
Press S up or down.
turn off
music
player
Press Back until you return to
the
My Music menu, then
press
Exit .
or
Press O .
controls with flip open

18
main attractions
play music from the
Recently Played list
Find it: s > EMy Stuff > MP3 Player
>
Recently Played
Scroll to a song and press the center key s .
find & play music by artist
Play an album or song:
Find it:
s > EMy Stuff > MP3 Player > Artists
1 Scroll to the artist you want and press the
center key
s .
2 Scroll to the album you want and press
the center key
s .
3 To play the entire album beginning with
the first song, press the center key
s
again.
or
To begin play at a selected song, scroll to
the song you want and press the center
key
s .
Play all songs:
Find it:
s > EMy Stuff > MP3 Player > Artists
1 Scroll to the artist you want and press
Options .
2 Scroll to Play and press Select .
