Motorola MOTORIZR Z3 User manual

MOTORIZR Z3
TM
Slider Features
Open/Close Slider
To open or close the slider,
push the push bar up
or down.
1
Slide Tone
To play a tone when you
open or close the slider,
start at the home screen,
press the center key,
then select
Settings
Personalize
Slide Tone
Scroll right to set the tone
Off or On, then press Back.
Key volume (set in Ring
Styles> Detail) must be on
for slide tone to be heard.
2
Slide Closed Feature
To run or close active
applications when you
close the slider, start at the
home screen, press the
center key, then select
Settings
Initial Setup
Slide Closed
Scroll right to set the slide
to Continue Task or End
Task, then press Back.
Tip: If Continue Task is set,
calls continue even when
the slider is closed. Java
applications run regardless
of this setting and must be
ended manually.
3

MOTORIZR Z3
TM
Take and Store a Picture
From the home screen, press the
side Camera key. You can also
press the center key and
then select
Multimedia
Camera
Tip: The camera takes photos
in standard or full-screen (land-
scape) mode. Simply close the
slider and rotate the phone to
see the viewfinder in
landscape mode.
1
Point the camera lens at the
photo subject.
Tip: Press Options and then
press Light On to turn on the
camera light in low-light
settings.
To take the picture, press the
side camera key or the
center key.
2
Store Only is highlighted.
Press Select.
Tip: To set the storage
location of your pictures,
refer to the Store Multimedia
lesson.
4
To discard the picture,
press D. To save the
picture, press Options.
3

MOTORIZR Z3
TM
Change Camera Settings
From the camera viewfinder,
scroll up or down using the
navigation key to see the
current settings for Zoom,
Style, Exposure, and
Lighting Conditions.
1
Scroll right or left to change
a setting.
2
To see more camera settings,
press Options.
3
Scroll to Camera Setup and
press Select.
4
To change the resolution,
press Change. Scroll to a
resolution and press Select.
5
Press Back to return to the
camera viewfinder.
6

MOTORIZR Z3
TM
Record and Play Video Clips
From the home screen, press the
center key, then select
Multimedia
Video Camera
Tip: To send your video in a
message, the video length must
be set to MMS. Press Options
(left soft key), select Video
Camera Setup and then select
Video Length. Scroll right until
length is set to MMS, then
press Back.
1
Point the camera lens at the
video subject.
Tip: Press Options and then
press Light On to turn on the
camera light in low-light
settings.
To start recording, press the
side Camera key e. To stop
recording, press Stop.
2
To discard the video, press
D. To save the video,
press Options.
3
Store Only is highlighted.
Press Select.
4
To play a video after it’s
stored, select Videos from
the Multimedia menu.
5
Scroll to the video and
press the center key.
Use the navigation keys to
control the video:
Up – pause/play
Down – stop
Left – play previous video
Right – play next video
Tip: To switch the video
to full-screen (landscape)
mode, select Options then
select Play Full Screen.
6

MOTORIZR Z3
TM
Send A Message With Multimedia
From the home screen, press
the center key and scroll
to Messages.
Press Select, scroll to Create
Message, and then press the
center key.
1
Enter your message
(optional) and then
press Options.
3
Scroll to Message and press
the center key.
2
Insert is highlighted.
Press Select.
4
5
Scroll to the type of object
you want to send in the
message, for example a
picture, video, or voice
note, and press Select.
Here we will show you how
to send a picture.
Scroll up or down to the
item you want to send and
press the center key. Then
press Send To.
6
Press Send.
8
Scroll to a name in your
phonebook and press the
center key. Repeat to add
other recipients.
Tip: To enter a new number
or email address, press
Options. Then select Enter
Number or Enter Email.
7

MOTORIZR Z3
TM
Play Music
Press the center key, then select
Games & Apps
Digital Audio Player
1
Scroll to the song you want
to play and press the
center key.
Note: If you close the slider
while using the Digital Audio
Player, a phone menu
appears but the player is still
running in the background,
which drains the battery. To
stop the player, select exit/
end from within the player.
3
Scroll to Songs and press the
center key.
2
Use the navigation keys to control
the music:
Left (press & hold) – rewind
Left (press & release within first two seconds) – previous song
Left (press & release after first two seconds) – beginning of song
Center – pause/play
Right (press & hold) – fast forward
Right (press & release) – next song
4

MOTORIZR Z3
TM
Store Multimedia
Select Memory Card or
Phone and press the
center key.
Tip: To see how much
space is left on the memory
card or in phone memory,
press Details.
4
To copy or move a file
from your phone’s internal
memory to the memory
card, open a file list, such
as Pictures, scroll to the
file, and press Options.
Note: Moving a file to the
memory card deletes the
original from
phone memory.
5
6
Scroll to Manage, then
press Select. Scroll to Copy
or Move and press Select.
An icon in the upper right
corner of the camera or video
viewfinder screen shows the
current storage device, memory
card or phone .
To change the storage device,
press Options.
2
Memory Card is highlighted.
Press the center key.
7
Scroll to Switch Storage Device and
press Select.
3
You can use a memory card with
your phone to store and retrieve
multimedia objects such as
songs and pictures.
1

MOTORIZR Z3
TM
Select Text Entry Methods/Modes
Text Entry Methods
There are two ways to enter text
messages:
predictive text entry (default method)
regular text
To choose an entry method,
press the center key, then select
Messages
Create Message
Message
1
Press Options, scroll to Text
Setup and press Select.
2
Scroll to Primary Text and
press Change to select
the entry method for the
primary text mode.
3
For the language selected on your
phone there are three text
entry methods:
iTAP <language> – Predictive text,
where the phone predicts each word as
you enter it.
TAP <language> – Regular text, where
you must press a key to enter
each character.
Tap Extended – Same as TAP, but
special characters are available.
Scroll to the desired entry method and
press Select.
Here we will show you how to change
predictive text to regular text.
4
Text Entry Modes
There are four text entry modes:
Primary – The text entry method
(iTAP, TAP, or Tap Extended) you
use most often.
Secondary – The text entry method
you use occasionally, or can be
set to no text entry method.
Numeric – Allows texting of
numbers only.
Symbol – Allows texting of
symbols only.
To set the text entry mode, start at any
text entry screen, press Options and
scroll to Change Text Mode #. Press
Select, scroll to the desired mode, and
press Select.
Tip: Press #to toggle between text
entry modes. The mode displays in the
upper left corner.
5

MOTORIZR Z3
TM
Enter Contacts
In this lesson we show you how
to enter a contact stored to
phone memory.
From the home screen, press the
center key, scroll to Phonebook
and press Select.
Scroll to New Entry and press
the center key.
1
Continue to enter information
in the other fields of the
phonebook entry.
3
First Name is highlighted. Press
the center key. Enter the name
and press Ok.
2
Scroll to Type, then scroll
right to the desired setting
(Mobile, Home, Work, Fax,
Pager, Other).
4
You can add multiple num-
bers for the same person.
To add more numbers,
press Options. Scroll to
Add Number and press
Select. Type the additional
number and scroll right to
the desired setting.
5
When you are finished,
press Done.
Tip: To find contacts in your
phonebook, type the first
letters of the contact on
your keypad.
6

MOTORIZR Z3
TM
Change the Phonebook View
You can sort your contacts by
first or last name.
From the home screen, press the
center key, then select
Phonebook
Options
1
Scroll to Setup and
press Select.
2
Sort by: is highlighted.
Scroll right to the desired
setting, then press Back.
Your contacts are displayed
in the order you selected.
3
You can sort your contacts
by category.
Press Options, scroll to Filter
by, and then press Select.
Note: When you open your
phonebook, press # or *to
see your categories. Categories
aren’t available for phonebook
entries stored on the SIM card.
4
Scroll to Category and press
Select. Scroll to the category
you want to sort by and
press Select.
Only contacts in the category
you selected are displayed.
5
You can view your contacts
stored on your SIM card,
in your phone’s internal
memory, or both.
Press Options, scroll to
View, and then
press Select.
6
Scroll to the desired option
and press Select.
Only contacts in the
storage location you
selected are displayed.
7

MOTORIZR Z3
TM
Use Voice Commands
You can place calls and
perform other tasks by speaking
commands to your phone.
From the home screen, press
and release the voice key A
on the right side of
your phone.
Tip: To hear the voice prompts
easily, use a Bluetooth headset
or activate the speakerphone
by pressing Settings > Sound >
Speakerphone > On, and
pressing OK.
1
Your phone dials the number.
3
After you hear or see “Say a
command,” say the command, for
example, “Call Tomas Smith” or
“Call 6175551212.” When using
names, say the name exactly as it
is stored in your phonebook.
Tip: You can say a phonebook
entry’s name and type together,
for example “Call Tomas Smith
Mobile” to call the mobile number
stored for Tomas Smith.
2
For more information and other
ways to use voice commands,
press Help.
4

MOTORIZR Z3
TM
Set Up Bluetooth Headset
From the home screen,
press the center key,
then select
Settings
Connection
Bluetooth Link
Setup
1
Select Power, then scroll
right to turn the power On.
Now that you have turned
the Bluetooth feature on, you
can pair (link) the headset
with your phone.
After you have successfully
paired your headset and
phone, you do not need to
repeat the
pairing procedure.
2
Press and hold the Call
button on the headset
until the light turns on and
remains steadily lit.
If the light is flashing or
does not remain steadily
lit, make sure the headset
is fully charged and repeat
this step.
Note: If your headset has a
folding microphone, quickly
unfold the microphone as
soon as the light is
steadily lit.
3
Select the headset, then
press Yes when prompted
to bond.
5
Enter the passcode 0000
and press Ok.
When pairing is successful,
the headset light changes
from steadily lit to flashing
and the Bluetooth icon
appears in the top
status bar.
6
To test the pairing
connection, put the
headset on and make
a call.
If your phone and headset
are successfully paired,
you will hear ringing.
Tip: To save battery life,
keep your headset turned
off when not in use.
7
On your phone, press Back,
then select
Audio Devices
Look for Devices
4

MOTORIZR Z3
TM
Copy/Receive Files with Bluetooth
Disconnect the receiving device
from any existing Bluetooth con-
nections and place it discover-
able mode.
From the home screen, press the
center key, then select
Settings
Connection
Bluetooth Link
Find Me
Note: If you are prompted to turn
Bluetooth on, select Yes.
1
On the sending phone, scroll
to the object that you want
to copy to the other device.
Here we will copy a picture.
2
Press Options, then select:
Manage > Copy for a
media file.
Send Contact > Bluetooth
for a phonebook entry.
Send for a datebook event
or bookmark.
3
Select a recognized device
name, or select [Look For
Devices] to search for the
device to which you want to
copy the object.
Note: Once you connect your
phone to a Bluetooth device,
that device can start a similar
Bluetooth connection with your
phone. Your display shows the
Bluetooth indicator Owhen
there is a Bluetooth connection.
4
On the Scan Results screen,
select the receiving device
and press Select.
5
On the receiving device,
select Grant.
6
On the receiving device,
select Accept.
7

MOTORIZR Z3
TM
Install and Remove Memory Card
To install memory card, press
battery door release latch and
remove battery door.
1
Slide card under metal clip
and into card slot. Card
should be inserted with the
print side up.
2
To remove memory card,
push down on the retainer
tab and slide the memory
card out of the slot.
3
Replace the battery cover.
4

MOTORIZR Z3
TM
Transfer Files Using a USB Cable
When you finish, remove the
phone with memory card safely
from your computer.
On a PC, right click the Safely
Remove Hardware icon at the
bottom of your computer screen,
then select USB Mass Storage
Device and press Stop.
On a Mac, select and drag the
Removable Disk icon to
the Trash.
6
Select USB Mass Storage
Device and press OK.
Now it is safe to disconnect
the cable.
7
On your phone, scroll right to
change Default Connection back
to Data Connection. Press Back
when you are finished.
8
Press the center key,
then select
Settings
Connection
USB Settings
1
Scroll right to change
Default Connection to
Memory Card.
2
Drag and drop files between
your computer and phone.
5
Find where your phone’s
memory card displays as a
Removable Disk icon.
On a PC, this is in the My
Computer window. On a Mac,
it’s on the desktop.
Double click the Removable
Disk icon.
4
Attach one end of the Motorola
Original Enhanced USB cable to
your phone and the other end
to a USB port on your computer.
3

MOTORIZR Z3
TM
Use Phone in Restricted Areas
Press the center key,
then select
Settings
Airplane Mode
1
Scroll right until airplane
mode is set to On. Press
Back when you
are finished.
2
