Motorola MOTORIZR Z8 User manual

MOTORIZR Z8
Quick Start Guide
PMS 376c
CMYK 50/0/100/0

essentials
essent ial s
insert your SIM card
Yo u r Subscriber Identity Module (SIM) card stores your
phone number and other information.
Turn off your
phone before you install or remove a SIM card.
12
3
Note:
Before using your phone for the first time, be
sure to review the important safety information in the
user’s guide. Periodically review this information so you
remember how to safely use your phone.
Z8.ASIAEMEA.QSG.090307.fm Page 2 Friday, March 9, 2007 3:38 PM

essentials
insert your battery
Note: Your battery is intentionally tight fitting to ensure
consistent connection.
12
34
Z8.ASIAEMEA.QSG.090307.fm Page 3 Friday, March 9, 2007 3:38 PM

essentials
insert a memory card
You can store photos, sounds
and other multimedia objects
on a removable microSD
memory card
.
charge your battery
New batteries are not
fully charged. Plug the
battery charger into
your phone and an
electrical outlet.
The
battery charging icon
flashes while the battery
is charging, and stops
flashing when the battery is fully charged. Disconnect your
charger once charging is complete
.
Z8.ASIAEMEA.QSG.090307.fm Page 4 Friday, March 9, 2007 3:38 PM

essentials
turn it on & off
To turn on your phone ,
press and hold
O for a few
seconds. If prompted, enter
your SIM card PIN.
To turn off your phone ,
press and hold
O . The power menu is briefly displayed.
Continue to hold
O to turn off your phone.
slider
To open your slider , push the bumper bar up.
To close your slider , pull the bumper bar down.
Z8.ASIAEMEA.QSG.090307.fm Page 5 Friday, March 9, 2007 3:38 PM

essentials
make a call
To make a call , enter a phone number and press N .
To “hang up,” close the slider or press O .
answer a call
To answer a call when your phone rings and/or vibrates,
just open the slider or press
N .
To “hang up,” close the slider or press O .
make a video call
Enter a phone number and press the video call key or
press
Options > Video call to dial the number.
To “e n d ” a video call press O .
Z8.ASIAEMEA.QSG.090307.fm Page 6 Friday, March 9, 2007 3:38 PM

HELLOMOTO
HELLOMOTO
Introducing your MOTO RIZR™ Z8.
Tip: Press g to open the main menu and press again to
return to the Home screen. Press the navigation key up,
down, left, right to scroll or centre
s to select.
Right Soft Key
Clear/Back Key
Left Soft Key
Home Key
Volume Keys
Video Call Key
Media Player
Key
CameraKey
Secondary
CameraLens
Call Key End Key
Navigation Key
Primary
CameraLens
(on reverse)
Z8.ASIAEMEA.QSG.090307.fm Page 7 Friday, March 9, 2007 3:38 PM

HELLOMOTO
Home screen
The Home screen appears when you turn on the phone.
Your Home screen displays important status information,
such as messages and missed calls, using plug-ins.
The plug-ins that you can select are:
Calls , Messages , Email ,
Calendar , Profile , and Music .
From the Home screen press
Options > Settings to select the
plug-ins you want to display (up to five) and select your
wallpaper and softkey settings.
Help
Use the in-device help to find more information about
main phone features.
Press
Options > Help within a feature (where available) and
select from the topics displayed.
Z8.ASIAEMEA.QSG.090307.fm Page 8 Friday, March 9, 2007 3:38 PM

customise
You can make your Home screen personal and customise
the look and sound of your phone using profiles.
profiles
Each profile uses a group of settings to define items such
as ring tones, message alerts, screensavers and more.
There are five standard profiles that you can activate or
edit, or you can create your own.
Press g > GControl panel > Profiles > profile name > Options
>
Activate or > Edit or > New > enter profile name
ring style, volume and theme
You can change your ring style, volume, and theme from
the Basic tab in Profiles.
Press g > GControl Panel > Profiles: profile name > Options
>
Edit > Basic tab
Z8.ASIAEMEA.QSG.090307.fm Page 9 Friday, March 9, 2007 3:38 PM

contacts
phonebook
store a phone number
1 Enter a phone number in the Home screen.
2 Press Options > Store .
3 Enter a name and other details for the phone
number.
4 Press Options > Save to store the number on your
phone.
You can copy contacts between your
phone’s memory
and your
SIM card , refer to the User Guide.
call a stored phone number
Press g > AContacts
1 Scroll to the contacts entry.
Shortcut: In contacts, press keypad keys to enter
the first letters of an entry you want.
2 Press N to call the entry.
Z8.ASIAEMEA.QSG.090307.fm Page 10 Friday, March 9, 2007 3:38 PM

messaging
send a text message
Press g > EMessaging > Create new message > SMS
1 Select To to add a recipient. Enter the recipient’s
number or press
Contacts and select a contact.
2 Scroll down to the text entry field and press keypad
keys to enter text on the page.
Note: Press # to switch modes ( iTAP predictive text
h , Multi-tap standard entry i, Numeric n or Symbol o ).
3 When you finish the message, press the Send key.
receive a message
When you receive a new message, your phone plays an
alert. Also, the display shows
New message with a message
indicator, such as
É , and the Home screen messaging
plug-in is updated. Press the
View key to open the
message.
Z8.ASIAEMEA.QSG.090307.fm Page 11 Friday, March 9, 2007 3:38 PM

media player
audio pl ayer
play music
Your phone can play and store MP3, AAC, AAC+ and
Enhanced AAC+ music files.
Press g > FMedia Studio > Media Gallery > Music tab or
press the Media Player key.
In the
Media Gallery , select a track from Playlists , Artists , Tracks , or
Albums .
When the Media Player is displayed:
• Play or pause – Press the centre key s .
•Stop– Press S down.
• Play previous or next – Press S left or right.
• Change volume – Press the volume keys.
• Return to the Media Gallery – Press S up.
Your music will continue to play.
• Hide the player – Press g to go to the main
menu. This lets you use other phone features
while playing music.
Tip: Want some help? Press Options > Help .
Z8.ASIAEMEA.QSG.090307.fm Page 12 Friday, March 9, 2007 3:38 PM

media player
play video
Press g > FMedia Studio > Media Gallery > Video tab.
In the
Media Gallery , select the video you want to play.
When the Media Player is displayed:
• Play or pause – Press the centre key s .
•Stop– Press S down.
• Skip back or forward – Press S left or right.
• Change volume – Press the volume keys.
• Return to the Media Gallery – Press S up.
Note: The Media Player is used to play music or videos.
You cannot play both at the same time.
Tip: Want some help? Press Options > Help .
Z8.ASIAEMEA.QSG.090307.fm Page 13 Friday, March 9, 2007 3:38 PM

photos
photos
take a photo & store or send it
Press g > FMedia Studio > Camera or the camera key to
see the camera viewfinder.
Note: To take a photo with the primary camera (back) the
slider must be closed. To take a photo with your
secondary camera (front) the slider must be open.
Press the centre key
s or the camera key to take the
photo in the viewfinder. After you take your photo:
• To save the photo and return to the viewfinder
press the centre key
s or S left.
• To discard the photo and return to the viewfinder
press
S right.
• To save the photo and go to the Media Gallery press
S up.
• To save the photo and create an MMS message
with the photo inserted press
S down.
Tip: Want some help? Press Options > Help .
Z8.ASIAEMEA.QSG.090307.fm Page 14 Friday, March 9, 2007 3:38 PM

videos
videos
record a video & store or send it
Press g > FMedia Studio > Camcorder to see the video
viewfinder.
Note: To take a video with the primary camera (back) the
slider must be closed. To take a video with your
secondary camera (front) the slider must be open.
Press the centre key
s or camera key to start and stop
recording the video. After you record your video:
• To play/pause (preview) the video, press the
centre key
s .
• To save the video and return to the viewfinder
press
S left.
• To discard the photo and return to the viewfinder
press
S right.
• To save the video and go to the Media Gallery press
S up.
• To save and go to the MMS editor with the video
inserted in the message press
S down.
Tip: Want some help? Press Options > Help .
Z8.ASIAEMEA.QSG.090307.fm Page 15 Friday, March 9, 2007 3:38 PM

Bluetooth™ wireless
Bluet ooth™ wireless
use Bluetooth
Tip: Want some help? Press Options > Help .
Your phone can make handsfree calls using an optional
Bluetooth headset or car kit.
Note: The use of wireless phones while driving may
cause distraction. Discontinue a call if you can’t
concentrate on driving. Additionally, the use of wireless
devices and their accessories may be prohibited or
restricted in certain areas. Always obey the laws and
regulations on the use of these products.
Before you try to connect your phone with a
handsfree or music device
, make sure the device is on
and
ready in pairing or bonding mode (see the user’s
guide for the device).
Press g > CConnectivity > Bluetooth > Enabled audio devices tab
>
New device
Your phone lists the devices it finds within range.
1 Scroll to a device in the list and press the
centre key
s .
2 If necessary, press Yes or OK to connect to the device.
Z8.ASIAEMEA.QSG.090307.fm Page 16 Friday, March 9, 2007 3:38 PM

Bluetooth™ wireless
3 If necessary, enter the device passkey (such as 0000 )
and press
OK .
When your phone is connected, the Bluetooth indicator
O is highlighted in the status bar.
Shortcut: When your phone’s Bluetooth power is on,
your phone can automatically connect to a Bluetooth
device you have used before. Just turn on the device, or
move it near the phone. If the device doesn’t connect,
turn it off and back on. To turn your phone’s Bluetooth
power on, press
g > CConnectivity > Bluetooth > Bluetooth on .
For specific information about a device, refer to the
instructions that came with it.
Z8.ASIAEMEA.QSG.090307.fm Page 17 Friday, March 9, 2007 3:38 PM

accessories
accesso ri es
S705 Sound Pilot™ S9 Bluetooth™ Headset
H670 Bluetooth™ Headset MicroSD™ Memory Card
I HF1000 Bluetooth™ Car Kit Car Charger
Z8.ASIAEMEA.QSG.090307.fm Page 18 Friday, March 9, 2007 3:38 PM

www.hellomoto.com
Certain mobile phone features are dependent on the capabilities and
settings of your service provider’s network. Additionally, certain
features may not be activated by your service provider, and/or the
provider's network settings may limit the feature’s functionality.
Always contact your service provider about feature availability and
functionality. All features, functionality, and other product
specifications, as well as the information contained in this user's
guide are based upon the latest available information and are
believed to be accurate at the time of printing. Motorola reserves the
right to change or modify any information or specifications without
notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. All other product or service names are the property
of their respective owners. The Bluetooth trademarks are owned by
their proprietor and used by Motorola, Inc. under license.
© Motorola, Inc., 2007.
Caution: Changes or modifications made in the radio phone, not
expressly approved by Motorola, will void the user’s authority to
operate the equipment.
Manual Number: 6803542F58
Z8.ASIAEMEA.QSG.090307.fm Page 19 Friday, March 9, 2007 3:38 PM

www.motorola.com @6809507A69O@
6803542F58
CMYK 50/0/100/0
Pantone 376
