MILESTONE User Guide 9/14/09

Please note:
This draft documents features as they were available and functioning at the time of production.
Any screen captures are preliminary.
This draft uses an A6-size template.

1Congratulations
Congratulations
MOTOROLA MILESTONETM
MOTOROLA MILESTONETM gives you a premium
browsing and messaging experience with the very
latest from GoogleTM, all in the thinnest touch QWERTY
slider around.
• Browsing. Get more from the Web, with a huge
screen and full HTML. Search, browse, everything
you want to do, all made easier.
• Organization. Unify your work and personal life
with calendar, email, and contacts.
• Maps, entertainment, and more. The latest
technology and apps. Google Maps™mapping
service to find your way. YouTube™to stay
entertained. Easy access to Google and thousands
of Android applications to expand your world.
Caution: Before assembling, charging or using your
phone for the first time, please read the important
legal and safety information packaged with your
phone. Once your phone is up and running, press
Menu > Settings > Aboutphone > Safety &
Regulatory to read the full information.
More information
On your phone—Press Home > Help Center.
On your computer—Go to www.motorola.com/
support.
So, whether you want to read, watch, or play, we can
help.

2Congratulations
Your phone
the important keys & connectors
Press to put the
display to sleep,
or hold to turn off
3.5mm Headset Jack
Home Key
Back Key
Microphone
Menu Key
To u chscreen
CameraKey
Power Key
Volume Keys
Press to open
menu options.
Press to close
any menu or app
& return to the
home screen.
Press to go
back.
Search Key
Press for text
search or hold
for voice search.
Micro USB
Connector
Charge or
connect to PC.
Note: Your phone might look a little different.
When you open or turn your phone,
the screen adjusts for you.
Scroll &
Return
Space
Alternate
Shift
Press for text
search or press
& hold for voice
search.
Select
Delete
Search
Menu

3Let’s go
TOC to be developed Let’s go
let’s get you up and running
Assemble & charge
Caution: Please read “Battery Use & Safety” on
page 52.
1cover off 2SIM in
3microSD in (may
already be inserted)
4battery in
5cover on 6charge up
3H

4Let’s go
Set up & go
The first time you turn on your phone, a setup wizard
guides you through signing in to your existing
Google™ account. If you don’t have a Google account,
you can create one using the wizard.
Note: Be sure to enter the date and time so that
certain key features work on your phone.
Tip: Remember to write down your username and
password, and keep them in a safe place.
Turn it on & off
To turn on your phone, press and
hold Power (on top of the
phone).
To turn off your phone, press and
hold Power , then tap Power
off.
Wi-Fi connect
If you want to use a Wi-Fi computer network for even
faster Internet access, press Menu > Settings
>Wireless & networks > Wi-Fi settings.
Cool content & more
Browse and download thousands of the coolest apps
on the planet from Android MarketTM. Learn more
about downloading new apps with “Android
MarketTM” on page 22. Your phone comes with a
microSD memory card installed—you can load it up
with photos, videos, and music from your computer
using “USB drag & drop” on page 46.

5Touchscreen & keys
Touchscreen & keys
a few essentials
Touch tips
Here are some tips on how to navigate around your
phone.
Tap
To choose an icon or
option, tap it.
Tap & hold
To open special options,
tap and hold an icon or
other item. Try it: In the
home screen, tap and
hold a shortcut or widget
to move or delete (there’s
more in “Widgets” on
page 8).
Dialer Contacts Browser
Barbara Espenschied
Mobile [phone]
Dialer Call log FavoritesFavorites
Mobile [phone]
Mobile [phone]
Fiona Radley
Harold Jenkins
Drag
To scroll through a list or
move slowly, drag across
the touchscreen. Try it: in
the home screen, tap and
hold the App Tray icon ( )
and drag up.
Tip: When you drag or flick a
list, a scroll bar appears on
the right. Drag the scroll bar
to move the list to a letter A - Z.
Flick
To scroll through a list or move quickly, flick across the
touchscreen (drag quickly and release).
Tip: When you flick a long list, tap the screen to stop it
from scrolling.
Zoom
Get a closer look at maps or web pages. To zoom in,
double-tap the screen, or tap the screen with two
fingers and then slide them apart. To zoom out, double
tap the screen again, or drag your fingers together.
B
Barbara Espenschled
Mobile [phone]
Dialer Call log FavoritesFavorite s
Mobile [phone]
Mobile [phone]
Flona Radley
Harold Jenkins
Mobile [phone]
Mobile [phone]
Leo Heaton
Mick West
Mobile [phone]
Sandra Poliska

6Touchscreen & keys
Gestures
Draw on your screen to get to your favorite apps. To
open Gestures, tap the Gestures icon on the home
screen or in the App Tray.
Draw the gesture for the
action you want. For
example, draw a “V” to go
to voicemail.
To see which actions are
already assigned to
gestures, press Menu .
You’ll also see several
gestures that are
unassigned.
To assign an action to a
gesture, press Menu ,
tap the unassigned gesture,
then tap an app from the
list.
Call Voicemail
*86
Key tips
Menu, home, & back
Press Home to close any menu or app and return to
the home screen. Press and hold Home to show
the last few apps you used, then tap an app to open it.
In the home screen, press Home to open or close
the main menu.
Press Menu to open menu options, or Back to
go back.
Sleep & wake up
To save your battery, prevent
accidental taps, or when you want
to wipe smudges off your
touchscreen, put the touchscreen to
sleep by pressing Power . To
wake up the touchscreen, just
press Power again, or open the phone.
Home Key
Back Key Menu Key

7Home screen
To change how long your phone waits before the
screen goes to sleep automatically, press Menu
>Settings > Location & security > Screen timeout.
Tip: To make the screen lock when it goes to sleep,
use “Screen lock” on page 49.
Power key menu
Press and hold Power to open the power key
menu, where you can turn off the phone (Power off),
or turn Airplane mode or Silent mode on or off.
Adjust volume
Press the volume keys to
change the ring volume (in the
home screen), or the earpiece
volume (during a call).
Spin the screen
The touchscreen can rotate 90 degrees to stay
right-side up when you rotate your phone:
Find it: Menu > Settings > Sound & display
>Orientation
Home screen
quick access to the things you need most
Quick start: Home screen
The home screen gives you all your latest information
in one place. It’s what you see when you turn on the
phone or press Home from a menu. It’s basically
like this:
The home screen extends beyond what you see on
the screen to give you more room for adding
Status Bar
Flick or drag this bar down
to see details.
Status Indicators
Shortcuts
Tap to open.
Drag up to see
all your apps.
App Tr ay

8Home screen
shortcuts, widgets, and more. Flick the home screen
left and right to see more panels.
Widgets
Add a widget such as a clock, music player, or a
calendar that shows upcoming appointments.
To open a widget, tap it. To add widgets,
press Menu > Add > Widgets.
Note: If you install apps from Android Market that
have widgets, those widgets appear on the home
screen.
Shortcuts
The shortcut icons at the bottom of your home screen
are the first apps in your main menu.
To add shortcuts to the home screen, open the apps
tray, then drag the app to the home screen. Or, press
Menu > Add > Shortcuts.
Apps
Your phone comes with some applications already, and
you can download and install more (see “Download
apps” on page 15 and “Browse & install apps” on
page 22. To open an app, tap it.
App tray
All the apps on your phone, including the apps that
came with your phone, and the ones you download
and install, are on your App Tray.
To open the App Tray, tap and drag up.
