Welcome
Welcome to the world of Motorola digital wireless
communications! We are pleased that you have chosen the
Motorola
V
Series 120c wireless phone to keep you
connected with ease.
Power Key
Turn the phone
on and off.
Display
Headset Jack
Insert headset
accessory for
hands-free use.
Volume Keys
Adjust earpiece
and ringer volume.
End Key
End phone calls,
exit menu system.
Left Soft Key
Perform functions
identified by left
display prompt.
Earpiece
Menu Key
Voice Key
Record and activate
voice notes,
phonebook and
shortcut names.
Right Soft Key
Perform functions
identified by right
display prompt.
Scroll Keys
Move through
menus and lists.
Send Key
Send and answer
calls, view recent
dialed calls list.
Accessory Connector Port
Insert charger, FM Stereo Radio
Headset, and phone accessories.
Microphone
