English
✂
Quick Reference
Options Menu Quick Access Menu ‡
stac130.bk : qkref.fm5 Page 3 Tuesday, May 12, 1998 4:27 PM

English
Special Keys
SPress to turn phone on and off.
OPress to accept call, setting, option,...
EPress to access the Quick Access features.
MPress to access the Options or phone book
menus.
CPress to reject call, setting, option,...
<# Press to select entries and menu options.
IPress to add a phone book entry.
QPress to retrieve a phone book entry.
Making a Call
Enter Phone No. O.
Receiving a Call
Open the phone, or press O, *or #.
Ending a Call
Press O, Cor close the phone.
Making an Emergency Call
Enter 112O. The call will be directed to a
central emergency operator.
Redialling the Last Number Called
1Press Oto display the last number dialled.
2Press Oto call the number.
One-Touch Dialling
Press and hold the appropriate digit key 1to 9for
numbers in the first nine memory locations.
Storing Numbers in the Phone Book
1Press Ito access the Phone Book.
2Press Oto select phone memory, or
#Oto select SIM card memory.
3Enter Phone No. O, then Name O, then
Location O.
Dialling Phone Book Numbers
Press QLocation O.
Quick Access Features
Press Efollowed by the appropriate key, or press
E, scroll to the feature and press Oto select.
Quick Reference
✂
stac130.bk : qkref.fm5 Page 4 Tuesday, May 12, 1998 4:27 PM

Introduction 1English
Introduction
Congratulations on your purchase of a cellular telephone from Motorola, the world leader in cellular
technology.
All Motorola cellular telephones are manufactured to exacting specifications and world-class quality
standards, and are designed to withstand the harshest environmental conditions. Our commitment to
Total Customer Satisfaction and over sixty five years of experience in personal communications mean you
can depend upon the quality of this Motorola product.
This cellular telephone incorporates Personality™. Unique to Motorola, Personality™ removes the
complexity of cellular communications by guiding you through the features and presenting you with
simple choices every step of the way. Personality™ also allows you to personalise the way you use your
phone - for example, different ringer tones, a phone book and network selection preferences - all
presented with clarity and simplicity. In this manual, each of the Personality™ features is identified with
an Osymbol to indicate that it is customisable to meet your requirements.
This cellular telephone has been designed for use with the worldwide GSM (Global System for Mobile
communications) network. By using digital communications methods, your phone provides a number of
advantages over traditional cellular systems:
• Superior speech quality is attained without the usual background noises and interference.
• Your conversation may be encrypted for security. Conversations cannot be eavesdropped using
scanning equipment when the signal is encrypted.
• You are not restricted to use within one country.
Your subscriber number is not contained within the phone as with other systems. Instead, a 'Smart Card'
known as a SIM (Subscriber Identity Module) is supplied by your Cellular Service Provider. All call billing is
made to the subscriber number on the card whether it is used in this or any other GSM unit.
stac130.bk : intro.fm5 Page 1 Tuesday, May 12, 1998 4:27 PM

Introduction
2
English
Getting Started
In order to get started straight away with your new GSM
StarTAC, follow these simple steps:
Charge the Battery
!Before you use your phone, please see the ‘Your Battery’
section for important information on battery charging.
1Remove the battery from its holder and clip it into your phone.
2Connect the travel charger to the phone and plug it into a
standard mains socket.
Powering On
1Insert the SIM card into the tray on the side of your phone.
2Fully extend the antenna.
3Open your phone and press Sto switch on.
4If prompted, enter your PIN code and press O.
Once a GSM network is located by your phone, it connects and
the network name appears on the display.
Making a Call
1Enter the number you want to call.
AEven if you call a local number, you must also enter the full
area (but not country) code.
2Press O. Your call is placed!
IMPORTANT! Ending a Call
When you have finished your conversation, you must end the
call, even if the other person terminates the call. To end the call,
press O,C or close the phone.
AIf you do not end the call, you will remain connected and you
will be charged for the duration of the connection.
Exploring
Now you can leave your phone on while charging the battery,
making and receiving calls, and exploring features of your phone
at your leisure.
stac130.bk : intro.fm5 Page 2 Tuesday, May 12, 1998 4:27 PM

Introduction 3English
Total Customer Satisfaction
At Motorola, Total Customer Satisfaction is a top priority. If you
have a question, a suggestion or a concern about your Motorola
Cellular Phone, Motorola wants to hear from you.
Please contact the Motorola Cellular Response Centre by fax on:
[phone], or use one of the local phone numbers in
the following countries:
Austria 0660 7246
Belgium 0800 72 370
Denmark 43 43 15 56
Egypt 02 3411800
Eire 01 402 6887
Finland 0800 117 036
France 0801 63 67 03
Germany 0180 35050
Greece 00800 441 28150
Italy 02 69 633 316
Jordan 06 863750
Kuwait 484 2000 Ext 1177
Lebanon 01 744156
Luxembourg 0800 21 99
Netherlands 0800 022 27 43
Norway 22 55 10 04
Oman 790925
Portugal 01 318 0051
Qatar 418999
Saudi Arabia 01 2303294
South Africa 0800 11 48 49
Spain 902 100 077
Sweden 08 445 1210
Switzerland 0800 553 109
Turkey 0212 2729090
UK 0500 55 55 55
United Arab Emirates 04 32 11 66
For e- mail queries contact : mcrc@ ei. csg. mot. com
For Internet queries contact : http:// www. mot. com
Motorola’s Warranty
Your Cellular Phone is warranted by Motorola to be of
satisfactory quality, fit for its purpose and comply with applicable
Motorola specifications for a period of twelve (12) months from
the date you bought it (verified by reference to your proof of
purchase).
This warranty does not apply if the phone has
1been mishandled, misused, wilfully damaged, neglected,
improperly tested, repaired, altered or defaced in any way.
2a defect arising as a result of any failure to follow instructions
either in the manual or product specification.
3a defect which has arisen from the use of non- Motorola
approved accessories or ancillary items attached to or in
connection with the telephone.
This warranty does not affect your statutory rights as a consumer.
stac130.bk : intro.fm5 Page 3 Tuesday, May 12, 1998 4:27 PM

Introduction
4
English
stac130.bk : intro.fm5 Page 4 Tuesday, May 12, 1998 4:27 PM

Contents 5English
Contents
Safety
Important information for the efficient and safe operation of your phone................................................................................7
About Your Phone, Battery and SIM Card
Introduces your phone, explains how to charge and maintain batteries and explains about your SIM Card ........................11
Making and Receiving Phone Calls
Explains how to call a number, how to redial and how to accept a call ....................................................................................21
Menu Navigation
Explains how to access and use the phone’s menus....................................................................................................................33
Using The Options Menu
Provides an explanation of the Options Menu and how to use it..............................................................................................37
Using the Quick Access Menu
Provides an explanation of the Quick Access Menu and how to use it......................................................................................71
Accessories
Details the accessories available for use with your phone..........................................................................................................75
What To Do If...
Helps you to solve any problems that may occur.........................................................................................................................77
Index
A comprehensive index .................................................................................................................................................................79
The Manufacturer reserves the right to make changes in technical and product specifications without prior notice.
stac130.bk : toc.fm5 Page 5 Tuesday, May 12, 1998 4:27 PM

Contents
6
English
Understanding this Manual
Many of your phone options are accessed by a simple menu
system. A full description of the menus and how to move around
them is covered in the later section Menu Navigation. When the
manual describes the use of each menu item, it will be assumed
that you are familiar with the menu system.
Key Presses
Key presses are represented in this manual using symbols so that
you may locate and use the required sequence quickly. A
sequence of key presses may be shown as follows:
MOC
This means that you should press Mfollowed by Oand
then C, in sequence, not simultaneously.
Entering Information
When you are requested to enter information, such as the
number of the phone you wish to call, this is represented in bold
type. For example:
Phone No. - enter the required telephone number.
PIN - enter your Personal Identification Number.
Unlock Code - enter your unlock code.
Location - enter the Phone Book location number.
Prompts and Messages
Your phone responds to key presses by displaying either easy to
understand prompts that guide you to the next action, or simple
messages confirming that your action is complete. Prompts and
messages are represented in this manual in LCD style, for
example:
Enter PIN or Completed.
Other Symbols
You will find the following symbols used throughout this manual:
AA Note contains additional information which is relevant to
the feature/item.
!A Caution contains important additional information which
is relevant to the efficient and/or safe usage of your phone.
OThis symbol indicates that the feature is a Personality™
feature that can be customised to meet your requirements.
LThis symbol indicates a short key sequence for the feature.
