Motorola ThinkPhone XT2309-2 User manual

Front
camera
Fingerprint
sensor
Power
button
SIM card
tray
USB-C®/charger/
headset jack
Speaker
Microphone
Proximity
sensor
Speaker
Meet your
Volume
buttons
en-GB
Put the card(s) in and power on
1 Insert the SIM tool into
the tray hole to pop out
the tray.
Make sure that you use
the correct size of SIM
card and don't cut the
SIM card.
2 One-SIM model. Insert
the SIM card with the
gold contacts up, then
gently push the tray
into the slot.
Two-SIM model. Turn
the phone and the tray
over to add another SIM
card (optional).
Nano SIM
Wireless
charging
area
2
Main camera
NFC
touchpoint
MicrophoneFlash
Ultra-wide/
macro camera
Red key
1
Depth camera
Before using your phone, please read the legal,
safety and regulatory information provided with your
product.
1Red key
Press and hold to customise the red key.
Press once to open your favourite app or shortcut.
Press twice to open the customised Ready For menu.
The feature may dier based on the software updates.
Connect with 5G: 5G service plan and 5G network coverage required;
available only in selected areas; device not compatible with all 5G networks.
Contact your service provider for details.
3 Press and hold the
Power button, then
follow the prompts to
get started.
2Wireless charging
Charge your phone using a Qi-certified wireless charger (sold separately).

With moto care, extend your
warranty coverage up to three years,
and take advantage of features like
accidental damage protection. Visit:
motorola.com/motocare
(UK and Ireland only)
care
motorola.com
Disposal and recycling. For help recycling products and packaging
responsibly, visit www.motorola.com/recycling.
Extreme heat or cold. Don't use your phone in temperatures below
-20°C or above 45°C. Don't store/transport your phone in temperatures
below -20°C or above 60°C.
Legal disclaimers. Features, services and applications are network
dependent and may not be available in all areas; additional terms/charges
may apply. Product specifications and other information contained in this
guide are believed to be accurate at the time of printing. Motorola reserves
the right to correct or change any information without notice.
Arbitration. Your purchase is governed by a binding arbitration clause. For
more information and how to opt out, see the legal guide that came with
your phone.
SAR information (on e-label). To view specific absorption rate (SAR) values
for this phone, from the Home screen swipe up and tap Settings> , then
type Regulatory labels, and from your phone's dial pad, type *#07# or visit
www.motorola.com/sar.
Supported frequencies and power (Model XT2309-2). This phone is
capable of operation on the following frequencies, subject to location and
network availability.
Operating
mode Frequency range MHz / Band Maximum nominal transmit power dBm
Bluetooth 2400 – 2483.5 20 dBm EIRP
Wi-Fi 2400 – 2483.5 20 dBm EIRP
Wi-Fi 5150 – 5250 23 dBm EIRP
Wi-Fi 5250 – 5350/5470 – 5725 20 dBm EIRP
Wi-Fi 5725 – 5850 14 dBm EIRP
Wi-Fi 5945 – 6425 23 dBm EIRP
NFC 13.56 -18.84 dBuA/m @ 10m
GNSS 1559 – 1610 N/A
GSM (Australia
not applicable) 2/3/5/8 33/30
UMTS 1/2/4/5/8/19 24
LTE 1/2/3/4/5/7/8/12/13/17/18/19/20/
25/26/28/32/38*/39/40/41*/42
/43/48/66
23/(26*)
5G n1/2/3/5/7/8/20/28/38/40/
41/66/77*/78* 23/(26*)
Copyright and trademarks. MOTOROLA, the stylised M logo, MOTO and the
MOTO family of marks are trademarks or registered trademarks of Motorola
Trademark Holdings, LLC. ThinkPhone is a trademark of Lenovo. Google,
Android, Google Play, and other related marks and logos are trademarks of
Google LLC. USB Type-C® and USB-C® are registered trademarks of USB
Implementers Forum. All other product or service names are the property of
their respective owners. © 2022 Motorola Mobility LLC. All rights reserved.
Product ID: ThinkPhone by Motorola (Model XT2309-2)
Manual number: SSC8D78411-A
Help and more
Get answers, updates and info:
• Help is here: from the Home screen, swipe up and tap Settings> Help
to learn how to use your phone and get support.
• Get more: get software, user guides and more at
www.motorola.com/support.
• Get apps: tap Play Store to browse and download apps.
• Ready For: your phone works with Ready For, a new platform
that extends your phone's experience to any compatible PC,
TV or monitor. To learn more, scan the QR code or visit
www.motorola.com/ready-for.
• Uninstall an app: touch and hold the app, then drag it to Uninstall.
• Backup and restore: log in to your Google account to restore contacts,
calendar and more.
• Use a headset: to use a headset, you'll need one with a USB-C
connector. If you're using a 3.5-mm headset, you'll need an adapter to
connect a 3.5-mm connector to USB-C. Headset and adapter may be
sold separately.
Caution: screen protectors may reduce your phone's touchscreen sensitivity.
Do not use screen protectors thicker than 0.5mm.
Legal information. This guide provides important legal, safety and
regulatory information that you should read before using your product. For
the complete legal information, from the Home screen swipe up and tap
Settings > , then type Legal information, or visit
www.motorola.com/device-legal.
Water, splash and dust resistance. Liquid damage is not covered under
warranty. Water, splash and dust resistance were tested to IP68 standards
under controlled laboratory conditions. Withstands immersion in up to 1.5
metres of fresh water for up to 30 minutes. Resistance will decrease as a
result of normal wear. Not designed to work while submerged underwater.
Do not expose to pressurised water, or liquids other than fresh water. Do
not attempt to charge a wet phone. Not waterproof. For more about your
phone's water-repellent design and care, swipe up and tap Settings> Help.
Battery safety. To prevent possible burning and injury, the battery in your
phone should only be removed by a Motorola-approved service centre or
similar skilled personnel.
If your phone becomes unresponsive, press and hold the Power button
until the screen goes dark and your phone restarts. Charge your phone
using a compatible Motorola charger (may be sold separately). Use of other
chargers is not recommended and may impair the charging performance.
Don't charge your phone in temperatures below -20°C or above 45°C.
Chargers that do not comply with applicable national standards may be
unsafe, with risk of death or injury, and may cause slow charging or product
damage. To view applicable standards and to learn more, see the "Legal
information" section of this guide or visit www.motorola.com/device-legal.
Warning about high volume usage. To prevent possible hearing
damage, do not listen at high volume levels for long periods. When
your headset volume reaches the high volume threshold, a warning
will be shown. Tap OK to dismiss it, or wait one to five seconds, then
press the Volume up button to dismiss the alert and enable the volume to
continue to be adjusted.
