Motorola MOTO W233 RENEW User manual

GO TO
more information
Quick Start Guide
accessories:
user’s guide:
www.motorola.com
www.motorola.com/support/W233
MOTO
TM
W233 renew
congratulations!
let’s go
congratulations!
Thanks for purchasing the environmentally
responsible MOTO™ W233 Renew phone made
from plastics that contain recycled water bottles.
•Less packaging and lighter weight reduces
transportation emissions.
•Energy efficient charger (EPA level 4) and best in
class talk time (up to 9 hours) allows you to
conserve energy by reducing battery charge time.
•The entire outside of the phone (the housing) and
battery cover is 100% recyclable and designed for
disassembly for easy recycling/refurbishment at
the product end of life.
•This guide is printed on 100% recycled paper and
printed with vegetable-based inks. You can find
the full User's Guide at
www.motorola.com/support/W233 .
•As with other Motorola mobile devices, your
phone does not use lead solder.
So, let’s go. And don’t forget to recycle your old
phone in the postage-paid envelope included in
the box.
let’sgo
4
H
12
34
5 6
removing battery
Note: Your battery is
intentionally tight fitting.
microSD
SIM

your phone
basics customize
yourphone
right soft key
power/end key
navigation key
left soft key
send/answer key
center key
Performs the function shown on
the display above the key.
Make and answer calls. Press N
from the home screen to see a list
of recently dialed calls.
2.5 mm headset jack
Mini USB headsets are not
supported.
Select a highlighted option or
open a menu when you see åin
the display.
Performs the function
shown on the display
above the key.
Press and hold to turn
the phone on/off. Press
and release to end phone
calls.
Scroll through lists
and menus.
Note: Your phone may be a little different from the images in this guide.
basics
here are a few essentials
turn it on & off
Press and hold Pfor a few
seconds to turn the phone on/off.
menu navigation
Press the center key sto open
the Main Menu.
Press the navigation key Sup,
down, right or left to highlight a
menu option.
Press sor Select (left soft key) to
select the highlighted option.
Press swhen you see Min
the display to show menu
options.
customize
add your personal touch
create shortcuts
Choose the features you want to access with a single
key press from the home screen — really useful stuff:
Press s >wSettings > Personalize >Home Screen > Home Keys
set your screen saver and wallpaper
Change the wallpaper and screen saver images
to ones that make you smile.
Press s >wSettings > Personalize > Screen Saver or Wallpaper
set ringtone and volume
There are times when you want to hear your ringtone
in all its glory, and there are times when you don’t.
Press s >wSettings >Ring Style
change the front cover
Remove the battery cover and battery, and firmly but
gently push the locking tabs from the phone to

go green calls
phonebook
shortc uts
reduce your carbon footprint
Your phone is the first mobile device ever to earn
CarbonFree™ certification, which means your phone
is carbon neutral.
An alliance with Carbonfund.org allows us to offset
the remaining carbon footprint through investments
in renewable energy and reforestation.
Visit
Carbonfund.org for more information about carbon
offsets and to find out what your carbon footprint is.
®
calls
it’s good to talk
make calls
Enter a number and press N.
answer calls
When your phone rings or
vibrates, press N.
end calls
Press P.
redial numbers
1From the home screen, press Nto see a list of
recently dialed calls.
2Scroll to the entry you want to call and press N.
release the top of the cover. Then, working down the
phone, release the cover and slide off.
Swap the keypad to the new cover, ensuring the top
and bottom tabs are located securely. To replace the
cover, first clip into the bottom of the phone and then
work up the body, locking the tabs at the top. Finally,
refit your battery and cover.
Caution: To avoid risk of personal injury or equipment damage,
and maintain compliance with international RF exposure
guidelines, do not use or charge your phone with either cover
removed.
Caution: The front cover is made of plastic, so be gentle with
it. Also, when removing the cover be careful not to expose it to
dirt, dust, liquids, condensation and static electricity. Always
use Motorola approved covers.
meet someone new? save their number
save contacts
1Enter the number on the home screen
and press STORE.
2Enter the contact details.
3Press DONE when you’re finished.
call contacts
1Press s> Phonebook.
2Scroll through the list to highlight the
contact’s number.
3Press N.

music
shortcutsmessages
emergency calls
To call an emergency number,
enter the emergency number and
press N.
Your service provider programs emergency phone
numbers (such as 911) that you can call under any
circumstances, even when your phone is locked.
Emergency numbers vary by country. Your phone’s
pre-programmed emergency number(s) may not work
in all locations, and sometimes an emergency call
cannot be placed due to network, environmental, or
interference issues.
music
when you need music, all you need is your phone
To use the music player, insert a microSD memory
card, which is an optional accessory.
Your phone can play songs in the iMelody, MIDI and
MP3 file formats. Your phone cannot play WMA, AAC,
AAC+, AAC++ files, or MP3 files with a bit rate higher
than 320 Kbps.
play music
From the home screen, press your phone’s left soft
key to access the music player.
get music
music player controls
view song list Before music playback,
press Sup or down.
play/pause Press s.
fast forward Press & hold Sright.
next/previous song Press Sright or left.
rewind Press & hold Sleft.
messa ges
sometimes it’s better 2 text
send messages
1Press s> Messages > Create Messages > Create Message.
2Select the message type: New Text Msg or
New Picture Msg.
3Enter your message, and/or insert a picture, animation,
sound, quick note or contact info.
TIP: In a text entry screen, press #to switch
entry modes.
4Press OK and scroll to a contact.
5Press ADD and scroll to any other contact/s you
wish to add.
6Press SEND to send the message.
read messages
When you receive a message you will see 1 New message
on your screen. Press Read to open the message. You
can reply to the message by pressing Reply.
shortc uts
a few shortcuts you’ll find very useful
voicemail
Press and hold 1. If your voicemail number is pre-
set, you will connect. If not, press 1then Store. If you
don’t know the number, ask your service provider.
recent calls
Quickly see your call history by pressing s>Call Log.
You can then choose to access your Received Calls, Dialed Calls
or Call Times.
lock/unlock keys
Prevent accidental calls by pressing sfollowed
by *. Your screen will go black and your keys
are locked.
music player
Press MUSIC (left soft key) from the home screen.
quick text
To set quick text on your home screen press s>
wSettings>Personalize > Home Screen > Home Keys > Up, Down, Left,
or Right > Quick Text.

menu map
displayUSB drag & drop
Copy music to your phone’s memory card.
1With a memory card inserted and your phone in
the home screen, insert the USB cable in your
phone and your PC.
2On your phone, press Yes to connect your phone
as a storage device. Name the device “W233
Mobile” and click Finish.
3On your computer, open Microsoft® Windows®
Media Player 11.
4On the Sync tab, select More Options. Under
Device, select W233 Mobile.
5Select Properties, check the “Create folder
hierarchy on device” box, and click OK.
TIP: To access music stored on your microSD
memory card, press s> hMultimedia > Music Library >
s > Switch Storage Devices.
Note: You can use your phone to find songs played on
the radio, television, or other music source. For more
information, see the User's Guide or visit
www.motorola.com/support/W233 .
áWebAccess
•t-zones
• Web Shortcut
•GotoURL
• Web Session
•StoredPages
• History
• General Setting
sCall Log
• Received Calls
• Dialed Calls
• Notepad
• Call Times
#t-zones
•MyAlbum
• My Journal
•Games
• HiFi Ringers
• Wallpapers
• Screensavers
ÉOrganizer
•Games&Apps
• Calculator
•MyMenu
•AlarmClock
• Stop Watch
• Dialing Services *
•Calendar
eMessages
•Create
•Inbox
•Draft
•Outbox
•QuickNotes
•Voicemail
• Browser Msgs
• Info Services *
• Picture Msg Template
hMultimedia
•Pictures
• Music Library
&Help
nPhonebook
wSettings
•Personalize
• Ring Style
• Call Forward
•InCallSetup
•InitialSetup
•PhoneStatus
• Headset
•Network
•Security
This is a standard main menu
layout. Your phone’s menu may
be a little different.
* Network Dependent
USB Drag & Drop
it’s easier than you think
Note: Please download the USB charging driver onto
your PC, at
http://www.motorola.com/support/W233 .
1With a memory card inserted and your phone in
the home screen, insert the USB cable in your
phone and your PC.
Note: You can use Microsoft™ Windows™ 2000 or
Windows XP™. Other operating systems may not
be compatible with W233.
2Press Yes to connect your phone as a storage
device.
3Use the My Computer window to find
Removable Device.
4Drag and drop your music, photos and other stuff
that you want to copy.
Two folders are available, Music and Pictures.
To help manage your music, you can also create
more folders in the Music folder.
5When you’re done, use the Safely Remove
Hardware feature to finish.
status indicators
Status indicators appear across the top of the
home screen:
Note: Your phone’s home screen may be a little
different.
Music Mymenu
WED 12/30/09
10:51am
h
t
&
&
&
&
É
Y
5Éì
S
hõ
W
Signal
Strength
Indicator
Signa
Stren
Indica
Roaming
Active
Active
Call
Alert type
New
Message
Headset
Battery
Level
