Motorola BSR 64000 User manual

BSR 64000 Quick Start
Guide

Notice
Copyright © 2002
Motorola, Inc.
All rights reserved
No part of this publication my be reproduced in any form or by any means or used to make and any derivative work
(such as translation, transformation or adaptation) without written permission from Motorola, Inc.
Motorola reserves the right to revise this publication and to make changes in content from time to time without
obligation on the part of Motorola to provide notification of such revision or change. Motorola provides this guide
without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of
mechantability and fitness for a particular purpose. Motorola may make improvements or changes in the product(s)
described in this manual at any time.
Motorola,the stylized M logo, and Intelligence Everywhere are registered tradmarks of Motorola, Inc. Broadband
Services Router, BSR, BSR 64000, RiverDelta, SmartFlow are trademarks of RiverDelta Networks, Inc. All other
trademarks and registered trademarks are the property of their respective owners.
503406-001
TPD-0040-01 Rev A
Published:October, 2002

iii
Contents
Preface
Scope v
Audience v
Documentation Set v
Conventions vi
Notes, Cautions, Warnings vii
Contacting Support viii
Quick Start
Introduction 1
Configuring the Servers 2
Physically Install the BSR 3
Accessing the CLI to Set System Passwords 4
Setting System Passwords 5
Specifying System Time Information 7
Configure SNMP 9
Configure the Ethernet IP Address 9
Configure Cable IP Address 10
Configure the POS Module 11
Configure Routing 12
Routing Policy 12

BSR 64000 Quick Start Guide
iv
Configure RIP v1 or RIP v2 on an Interface 12
Configure OSPF on an Interface 13
Configure BGP on an Interface 14
Configure the CMTS 15
Configure the Downstream Port 17
Configure the Upstream Ports 18
Save the Configuration 19

v
Preface
Scope
This document describes the basic tasks used to get the Motorola™ Broadband
Services Router™ 64000 (BSR 64000™) out of the box, running, connected to the
network and operational.
Audience
This document is for use by those persons who will install and configure the
BSR 64000™ product. Only trained service personnel should install, maintain, or
replace the BSR 64000.
Documentation Set
The following documents comprise the BSR 64000 documentation set:
•BSR 64000 Command Reference Guide
This document contains the Command Line Interface (CLI) commands for
managing, configuring, and maintaining the BSR 64000.
•BSR 64000 Configuration and Management Guide
This document provides the instructions and procedures for configuring and
managing the BSR 64000.
•BSR 64000 Installation Guide
This document describes how to install the BSR 64000 product.

BSR 64000 Quick Start Guide
vi
•BSR 64000 Release Notes
These documents provide information about features not described or incorrectly
documented in the main documentation set; known problems and anomalies;
product limitations; and problem resolutions.
•BSR 64000 SNMP MIB Reference Guide
This document describes the Simple Network Management Protocol (SNMP)
MIBs; provides information that describes standard and proprietary MIB support;
describes how to walk the MIBs and how to compile and load the SNMP MIBs. It
also provides task examples.
•BSR Troubleshooting Guide
This document provides instructions and procedures for troubleshooting the BSR
product.
•BSR 64000 Quick Start Guide
This document provides basic tasks used to get the BSR 64000™ out of the box,
running, connected to the network, and operational.
Conventions
This document uses the conventions in the following table:
Convention Example Explanation
angle brackets < > ping <ip-address>
ping 54.89.145.71 Arguments in italic and enclosed by angle
brackets must be replaced by the text the
argument represents. In the example,
54.89.345.71 replaces <ip-address>. When
entering the argument, do not type the angle
brackets.
bar brackets [ ] disable [level] Bar brackets enclose optional arguments. The
example indicates you can use the disable
command with or without specifying a level.
Some commands accept more than one
optional argument. When entering the
argument, do not type the bar brackets.

Preface
vii
Notes, Cautions, Warnings
The following icons and associated text may appear in this document.
bold text cable relay-agent-option Boldface text must be typed exactly as it
appears.
brace brackets {} page {on |off} Brace brackets enclose required text. The
example indicates you must enter either on or
off after page. The system accepts the
command with only one of the parameters.
When entering the text, do not type the brace
brackets.
italic text boot system <filename> Italic type indicates variables for which you
supply values in command syntax descriptions.
It also indicates file names, directory names,
document titles, or emphasized text.
screen display Wed May 6 17:01:03
2000 This font indicates system output.
vertical bar | page {on |off} A vertical bar separates the choices when a
parameter is required. The example indicates
you can enter either command:
page on or page off
When entering the parameter, do not type the
vertical bar or the brace brackets.
Note: A note contains tips, suggestions, and other helpful information, such
as references to material not contained in the document, that can help you
complete a task or understand the subject matter.
Caution: The exclamation point, within an equilateral triangle, is intended to
alert the user to the presence of important installation, servicing, and
operating instructions in the documents accompanying the equipment.
Convention Example Explanation

BSR 64000 Quick Start Guide
viii
Contacting Support
Use the following information to contact Support:
Warning: This symbol indicates that dagerous voltages levels are present
within the equipment. These voltages are not insulated and may be of
sufficient strength to cause serious bodily injury when touched. The symbol
may also appear on schematics.
U.S. 1-888-944-HELP
1-888-944-4357
International +.215-323-0044
WWW http://www.gi.com/BUSAREA/CUSACC/websupport.html
Email [e-mail]

Quick Start

Quick Start
1
Introduction
Use the BSR 64000™ Quick Start Guide to unpack the product, connect it to the
network, and establish minimal operation.
Follow these basic configuration tasks to make the BSR 64000 operational:
•Configuring the Servers
•Physically Install the BSR
•Accessing the CLI to Set System Passwords
•Specifying System Time Information
•Configure SNMP
•Configure the Ethernet IP Address
•Configure Cable IP Address
•Configure the POS Module
•Configure Routing
•Configure the CMTS
•Save the Configuration
Note: Detailed installation procedures and configuration and management
procedures are covered in the BSR 64000 product documentation set.

BSR 64000 Quick Start Guide
2
The following illustration shows the basic configuration of the BSR 64000:
Configuring the Servers
The following servers are required for the basic operation of the BSR on your
network, and must be configured to allow cable modems to range and register
properly on the HFC network:
•DHCP
•TFTP
The following DHCP options are necessary:
Note: The CM configuration file must be stored on the TFTP server.
CM1
10/100
SWITCH
TFTP /DNS/DHCP/TOD
SERVER
CM2
C
MC M
D
S
/
R
F
U
S
/
R
F
U
S
/
R
F
D
S
/
R
F
BSR 64000
12345678910111213141516
12345678910111213141516
12345 678910111213141516
Cable IP X.X.X.X
netmask
Cable IP X.X.X.X netmask
secondary
RF plant

Quick Start
3
•IP address
•Router address
•TFTP server address
•Bootfile for the CM configuration file
The following servers can be configured to operate the BSR on your network for
management, provisioning, troubleshooting and billing purposes:
•LDAP
•Event (Syslog) Server
•Provisioning Server
•DNS
For more information on installing the servers, refer to the vendor server software
documentation.
Physically Install the BSR
Follow these steps to physically install the BSR:
1. Understand and follow all safety warnings.
2. Prepare the site area for the BSR installation.
3. Mount the BSR chassis in the equipment rack.
4. Connect the power, network cables, terminal cable, and alarm leads to the BSR.
5. Turn on the BSR and observe the system LEDs.
Refer to the following document for additional instructions:

BSR 64000 Quick Start Guide
4
•BSR 64000 Installation Guide
Accessing the CLI to Set System Passwords
Follow these steps to access the CLI from a console session in order to configure
password privileges for enabled modes and telnet:
1. Configure the terminal application on your PC to use COM port 1 or 2.
2. Configure the terminal port to the following settings:
•Bits per second: 9600 bits per second
•Data bits: 8
•Parity: None
•Stop bits: 1
•Flow control: None
3. Start your terminal or terminal application to connect to the BSR.
4. Power on the BSR 64000.
5. The terminal session begins and the password prompt displays. The password is a
null value by default. Press the Enter key. The RDN> prompt displays.
6. To enter Privileged EXEC mode, use the enable command in User EXEC mode,
as shown in the following example:
Note: Make sure that the serial cable is connected properly and the terminal
application is configured correctly. Refer to the BSR 64000 Installation Guide
for more information.
Warning: Do not interrupt the boot process.

Quick Start
5
RDN>enable
The Password prompt displays.
7. To enter Privileged EXEC mode, press the Enter key at the password prompt. The
password is a null value by default.
8. To enter Global Configuration mode in order to set system passwords, use the
configure command, as shown in the following example:
RDN#configure
The RDN(config)# prompt displays.
Setting System Passwords
System passwords should be set immediately. System passwords can contain up to 31
uppercase or lowercase alphanumeric characters and a numeric character cannot be
the first character. Spaces are valid password characters. The user must enter the
correct password to gain access to the BSR and privileged-level commands.
Follow these steps to configure the BSR system passwords:
1. To set the password for a console (terminal) session that allows access to the BSR
in User EXEC mode, use the password console command in Global
Configuration mode, as shown below:
RDN(config)#password console {0|7}<password>
where:
0indicates that the following password is unencrypted (clear text).
7indicates that the following password is encrypted.
password is the user-defined password that is no more than 31 characters.
Note: Access to a telnet session is denied if the password for both the
console and telnet is not set.

BSR 64000 Quick Start Guide
6
2. To set the password for a telnet session that allows access to the BSR in User
EXEC mode, use the password telnet command in Global Configuration mode,
as shown below:
RDN(config)#password telnet {0|7}<password>
where:
0indicates that the following password is unencrypted (clear text).
7indicates that the following password is encrypted.
password is the user-defined unencrypted password for the BSR that is no
more than 31 characters.
3. To set the Privileged EXEC password, use the enable password command, as
shown below:
RDN(config)#enable password {0|7}<password>
where:
0indicates that the following password is unencrypted (clear text).
7indicates that the following password is encrypted.
password is the user-defined unencrypted password for the BSR that is no
more than 31 characters.
4. Automatic encryption is disabled by default. If you want to encrypt all currently
unencrypted passwords and all future passwords entered on the BSR, use the
service password-encryption command in Global Configuration mode, as
shown below:
RDN(config)#service password-encryption
If you want to turn off the service password encryption feature so that passwords
entered in the future are no longer encrypted, use the no service
password-encryption command in Global Configuration mode, as shown below:

Quick Start
7
RDN(config)#no service password-encryption
5. The show running-config command is used to determine if the password name
and encryption has been set. Use the show running-config command in
Privileged EXEC mode to verify your configuration, as shown below:
RDN(config)#show running-config
Refer to the following documents for additional instructions:
•BSR 64000 Configuration and Management Guide
•BSR 64000 Command Reference Guide
Specifying System Time Information
Follow these steps to specfiy the system time information:
1. To set the system clock time zone for the BSR, use the clock timezone command
in Global configuration mode, as shown in the following example:
RDN(config)#clock timezone <word><hours><minutes>
where:
word is the name of the time zone.
hours represents the number of hours offset from the Universal Time
Coordinated (UTC), which is a range between -23 and +23 hours from the
UTC.
Note: The no service password-encryption command does not unencrypt
passwords that are already encrypted. If you want to unencrypt encrypted
passwords, you must change them manually.
Note: The show running-config command output identifies the system
password with the number 0 if it is unencrypted. If the system password is
encrypted, it is identified with the number 7.

BSR 64000 Quick Start Guide
8
minutes represents the number of minutes offset from the UTC from 0 to 59.
2. To set the BSR system clock, enter Ctrl Z to return to Privileged EXEC mode and
enter either of the clock set commands, as shown in the examples below:
RDN#clock set <hh:mm:ss><day><month><year>
where:
hh:mm:ss is the hour, minute, and second in hh:mm:ss format.
day is the day of the month from 1 to 31.
month is the first three letters of the month.
year is any year between 1993 and 2035.
For example:
RDN#clock set 11:22:30 5 Apr 2001
3. To check the BSR clock settings that you set, use the show clock command in
Privileged EXEC mode.
Refer to the following documents for additional instructions:
•BSR 64000 Configuration and Management Guide
•BSR 64000 Command Reference Guide

Quick Start
9
Configure SNMP
Follow these steps to configure SNMP on the BSR:
1. To enable all versions of SNMP running on the SNMP server, use the
snmp-server enable command in Global Configuration mode, as shown in the
following example:
RDN(config)#snmp-server enable
2. Configure SNMP server identification, access levels, packet size and traps.
3. Compile or import new SNMP MIBs.
4. Use an SNMP browser to configure or view MIBs.
Refer to the following documents for additional instructions:
•BSR 64000 Configuration and Management Guide
•BSR 64000 SNMP MIB Reference Guide
•BSR 64000 Command Reference Guide
Configure the Ethernet IP Address
Follow these steps to assign the primary Ethernet IP address and subnet mask and
configure some basic system parameters:
1. To enter the Ethernet interface, use the interface ethernet commandinGlobal
Configuration mode, as shown in the following example:
RDN(config)#interface ethernet <slot>/<port>
where:
slot is the SRM module slot on the BSR.
port is the port interface on the SRM module.

BSR 64000 Quick Start Guide
10
2. To enter the primary Ethernet IP address and subnet mask, use the ip-address
command in Interface Configuration mode, as shown in the following example:
RDN(config-if)#ip-address {<ip-address><subnet-mask>}
where:
ip-address is the IP address designated for the Ethernet interface.
subnet-mask is the subnet mask designated for the Ethernet interface.
Refer to the following documents for additional instructions:
•BSR 64000 Configuration and Management Guide
•BSR 64000 Command Reference Guide
Configure Cable IP Address
Follow these steps to configure the cable IP address and subnet mask:
1. To enter the cable interface, use the interface cable command in Global
Configuration mode, as shown in the following example:
RDN(config)#interface cable <slot>/<port>
where:
slot is the DOCSIS module slot on the BSR
port is the port interface on the DOCSIS module.
2. To enter the cable IP address and subnet mask, use the ip-address command in
Interface Configuration mode, as shown in the following example:
RDN(config-if)#ip-address {<ip-address><subnet-mask>}
where:
ip-address is the IP address designated for the cable interface.
subnet-mask is the subnet mask designated for the cable interface.
