Motorola EWR6300 User manual

MEA
Enhanced Wireless
and
Portable Wireless
Routers
Users Guide
Documentation Revision 3.1.2

Mesh Enabled Architecture EWR/PWR Users Guide
iii
Copyrights
The Motorola products described in this document may include copyrighted Motorola computer programs. Laws in the
United States and other countries reserve for Motorola certain exclusive rights for copyrighted computer programs.
Accordingly, any copyrighted Motorola computer programs contained in the Motorola products described in this
document may not be copied or reproduced in any manner without the express written permission of Motorola.
Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication,
estoppels or otherwise, any license under the copyrights, patents or patent applications of Motorola, except for the
normal nonexclusive, royalty-free license to use that arises by operation of law in the sale of a product.
Disclaimer
Please note that certain features, facilities and capabilities described in this document may not be applicable to or
licensed for use on a particular system, or may be dependent upon the characteristics of a particular mobile
subscriber unit or configuration of certain parameters. Please refer to your Motorola contact for further information.
Trademarks
Motorola, the Motorola logo, and all other trademarks identified as such herein are trademarks of Motorola, Inc. All
other product or service names are the property of their respective owners.
Copyrights
© 2005 Motorola, Inc. All rights reserved. No part of this document may be reproduced, transmitted, stored in a
retrieval system, or translated into any language or computer language, in any form or by any means, without the
prior written permission of Motorola, Inc.

iv
Table of Contents
1PRODUCT INTRODUCTION...................................................................................1
1.1 Product Contents......................................................................................................1
2DEVICE INSTALLATION.........................................................................................2
2.1 Installation Requirements ........................................................................................2
2.1.1 Enhanced Wireless Router (EWR)...............................................................................2
2.1.2 Portable Wireless Router (PWR)..................................................................................2
2.2 Software Requirements............................................................................................2
2.3 Equipment Requirements.........................................................................................3
2.3.1 EWR6300 .....................................................................................................................3
2.3.2 PWR6300 .....................................................................................................................3
2.4 MAC Address Label Location ..................................................................................5
2.4.1 EWR .............................................................................................................................5
2.4.2 PWR .............................................................................................................................5
2.4.3 MAC Address Table .....................................................................................................5
2.5 EWR6300 Assembly Information .............................................................................7
2.5.1 EWR6300 Assembly.....................................................................................................7
2.5.2 EWR Installation procedure:.........................................................................................7
2.5.3 EWR6300 Mounting Bracket........................................................................................7
2.6 PWR6300 Assembly Information ...........................................................................10
2.6.1 PWR Installation Procedure .......................................................................................11
2.7 Device Deployment Considerations......................................................................11
2.7.1 Antenna Deployment Tips..........................................................................................12
2.8 Testing the Device Installation...............................................................................12
3DEVICE CONFIGURATION...................................................................................13
3.1 IP Addressing Considerations...............................................................................13
3.2 Accessing the MEA Device Administration Web Pages......................................13
3.2.1 User Name and Administrator Access Information ....................................................13
3.2.2 Viewing MEA Redirecting Page .................................................................................15
3.2.3 Viewing MEA Device Administration Home Page......................................................16
3.2.3.1 Viewing MEA Device Administration Home Page as a Normal User.........16
3.2.4 Viewing the EWR Device Administration Configuration Tab......................................18
3.2.4.1 Viewing the EWR Device Configuration Tab as a Normal User................19
3.3 Device Addressing Schemes.................................................................................21
3.3.1 Network DHCP Scheme.............................................................................................21

Mesh Enabled Architecture EWR/PWR Users Guide
v
3.3.2 Statically Provisioned Scheme...................................................................................21
3.3.3 User Supplied Scheme...............................................................................................22
3.3.3.1 Setting User Supplied IP Addresses..........................................................22
3.4 External Device Provisioning.................................................................................24
3.4.1 Connecting to the Ethernet Port.................................................................................25
4DEVICE MAINTENANCE ......................................................................................26
4.1 Resetting the EWR via the Device Administration Web Page.............................26
4.2 Restoring Factory Settings – User Supplied Mode Limitations..........................28
4.2.1 Recovering from EWR/PWR Reset-to-Default in User-Supplied Mode.....................28
4.2.1.1 Resetting Device Addressing Mode Using Device Manager.....................28
4.2.1.2 Resetting Device Addressing Mode via Configuration Web Page.............28
4.2.1.3 Resetting User-Supplied Parameters via Configuration Web Page ..........28
4.3 Restoring Factory Settings – Normal Operations................................................29
4.4 Changing the Web Interface Password.................................................................31
4.5 Security Provisioning Web Page...........................................................................33
4.5.1 Provision Username Section......................................................................................33
4.5.2 Provision Groupname Section....................................................................................33
4.6 Upgrading the Device Firmware ............................................................................34
5CUSTOMER SERVICE INFORMATION................................................................36
5.1 Obtaining Support...................................................................................................36
5.2 System Information.................................................................................................36
5.3 Return Material Request.........................................................................................37
5.4 Radio Products and Services Division..................................................................37
5.4.1 Radio Products and Services Division Telephone Numbers......................................37
5.5 Returning System Components to Motorola........................................................37
5.6 Returning FREs.......................................................................................................37
6WARRANTY INFORMATION................................................................................38
7FCC REGULATORY INFORMATION ...................................................................41
7.1 FCC Information......................................................................................................41
7.2 FCC RF Radiation Exposure Statement................................................................41
8SAFETY INFORMATION FOR THE MEA PRODUCTS........................................42
9SAFETY CERTIFICATION ....................................................................................43
9.1 CE Mark Certification..............................................................................................43

vi

Mesh Enabled Architecture EWR/PWR Users Guide
vii
List of Figures
Figure 2-1 EWR6300 Identification Label Example.............................................................5
Figure 2-2 PWR6300 Identification Label Example.............................................................5
Figure 2-3 EWR6300 External Connection Points..............................................................7
Figure 2-4. EWR6300 Mounting Bracket...............................................................................8
Figure 2-5. C-Clamp Bracket Assembly................................................................................9
Figure 2-6. EWR Pivot and Angle Locking Bolts...............................................................10
Figure 2-7. PWR External Connection Point......................................................................10
Figure 2-8 PWR6300 Cabinet Mounting.............................................................................11
Figure 3-1 Enter Network Password Initial Web Page Authentication Dialog ...............14
Figure 3-2. MEA Device Administration Redirecting Web Page.......................................15
Figure 3-3. MEA Device Administration Home Page (Super User Login)........................16
Figure 3-4. MEA Device Administration Home Page (Normal User Login) .....................17
Figure 3-5. EWR (PWR) Device Configuration Page (Super User Login) ........................18
Figure 3-6. EWR (PWR) Device Configuration Page (Normal User Login)......................20
Figure 3-7. Configuration Change Dialog...........................................................................22
Figure 3-8. System Update Save Completed Web Page ...................................................23
Figure 3-9. External Device Provisioning Table.................................................................24
Figure 4-1. Device Reset Prompt Web Page ......................................................................26
Figure 4-2. Device Reset in Progress Page........................................................................27
Figure 4-3. Restore Factory Settings Web Page................................................................29
Figure 4-4. Confirm Changes Window for Restore Factory Settings ..............................30
Figure 4-5. Factory Settings Restored Web Page..............................................................30
Figure 4-6. Enter New Password Web Page.......................................................................31
Figure 4-7. Confirm Changes Window for Enter New Password .....................................31
Figure 4-8. Password Changed Confirmation Web Page..................................................32
Figure 4-9. Security Provisioning Web Page .....................................................................33
Figure 4-10. Update Device Firmware Web Page.................................................................34

Figure 4-11. Confirm Upload Window for Firmware Update...............................................35
Figure 4-12. Firmware Upload Progress Web Page.............................................................35
viii

Mesh Enabled Architecture EWR/PWR Users Guide
1 Product Introduction
Thank you for purchasing the MEA Enhanced Wireless Router (EWR) or the MEA Portable
Wireless Router (PWR). Both of these devices are designed to integrate with the Mesh Enabled
Architecture (MEA®) wireless communication system capable of supporting high data rate
mobile communication at variable rates of vehicular speeds. This document provides detailed
installation and configuration instructions for installing the MEA EWR and PWR.
The EWR is designed to be deployed outdoors, while the PWR is designed for indoor use, such
as traffic cabinets or inside outdoor kiosks. Both of these devices offer wireless coverage in
large geographic areas and provide wireless network access to one or more IP devices via a
built-in RJ45 Ethernet port.
Both the EWR and the PWR efficiently combine the functionality of a Motorola Wireless Router
and client modem into a single cost-effective wireless network component. This makes it easy
for any Ethernet-ready device to access a Mesh Enabled Architecture (MEA), mobile broadband
network. IP-enabled computers, video cameras, sensors, signs, signals, and other devices can
all be Mesh Enabled to send and receive data at burst rates of up to 6 Mbps. All standard
Wireless Router functionality including Multi-Hopping®, near Line-of-Sight communications, and
geo-location services are fully supported.
The EWR and the PWR are configured for the connection of multiple IP addressable devices
using standard Ethernet connectivity. This allows devices that cannot accept the PCMCIA
based WMC6300 product to function transparently on a MEA network without drivers
1.1 Product Contents
Each MEA EWR and PWR is a full-featured wireless networking device. The following is a list
of the items provided with each device:
EWR
•MEA Enhanced Wireless Router
•1 Field Attachable Sealed Ethernet Boot
•High Gain Antenna
•Power Cord
PWR
•MEA Portable Wireless Router
•15 foot cable assembly
•PWR cable connector (end 1): Switchcraft EN3C2F
•PWR cable connector (end 2): Molex 19121-009 spade lugs
•Mag Mount Antenna
1

2 Device Installation
2.1 Installation Requirements
2.1.1 Enhanced Wireless Router (EWR)
The MEA Enhanced Wireless Router 6300 (EWR6300) is an infrastructure device positioned in
a fixed location, such as on a pole, wall, or rooftop. The device requires professional installation
to ensure the installation is performed in accordance with FCC licensing regulations.
The EWR provides range extension, a means to route around obstructions, a fixed location
reference for use in Geo-Location, and the capability of enabling IP devices.
The EWR6300 comes with a mounting bracket that can be attached to a pole with a diameter of
1-3.5 inches. For correct MEA deployment, a power source for each EWR must be provided.
2.1.2 Portable Wireless Router (PWR)
The PWR6300 Portable Wireless Router (PWR) has the same functionality as the EWR,
including network routing, Multi-Hopping®, and geo-location services, but in a smaller form. It
combines the functionality of a Wireless Router and the Wireless Modem Card into a single
device. Adding an Ethernet port to a Wireless Router enables video cameras, computers or any
other Ethernet-capable device to get high-speed access to the MEA wireless broadband
network, without the need to purchase a separate Wireless Modem Card.
The MEA Portable Wireless Router 6300 (PWR6300) is an infrastructure device positioned in a
fixed location, such as on a traffic cabinet or outdoor kiosk.
The PWR6300 provides range extension, a means to route around obstructions, a fixed location
reference for use in Geo-Location, and the capability of enabling IP devices.
2.2 Software Requirements
Two types of software interfaces will be required during the installation and setup process of the
EWR and PWR device: MeshManager and the EWR Device Administration web interface.
MeshManager software needs to be installed and running on a network computer prior to EWR
and PWR installation and configuration. MeshManager will be used in the EWR and PWR
setup process to validate the installation of the device. MeshManager software will also be
used to manage an EWR, PWR, and other subscriber devices within the MEA network.
The EWR Device Administration web interface is also utilized by the PWR and is used to
administer and configure the device. The web interface can be accessed by connecting a PC to
the wired interface. Additional information is provided later in this manual.
Detailed information about MeshManager software and its usage is found in the following
publications: QuickStart for MeshManager and MeshManager Users Guide.
2

Mesh Enabled Architecture EWR/PWR Users Guide
2.3 Equipment Requirements
An EWR6300 and a PWR6300 are utilized similarly to a subscriber device within a MEA
network. Both will be used with the following Motorola’ infrastructure devices: IAP6300 and
MWR6300.
2.3.1 EWR6300
The following list defines the standard MEA hardware components needed to set up a EWR:
•EWR Box with N-type Antenna Connector
•120V A/C Power Cable with a NEMA 5-15 plug
•Antenna with N-type Male Antenna Connector
•Mounting Bracket
The Network Operator must supply the following:
•Mounting Location
•Power Source (120V A/C or 5 V D/C depending on EWR configuration)
•Hand tools for bracket installation (7/16” wrench (2), Phillips screwdriver)
Optional Equipment:
•DC powered EWR (EWR6300-DC-IN)
•Power cord to connect to a photoelectric cell
Optional FCC Approved Antennas:
Manufacturer Part Number Gain Usage
Maxrad MFB24008 8 dBi Infrastructure
Maxrad MFB24004 4 dBi Infrastructure
Hyperlink HG2409U 8 dBi Infrastructure
2.3.2 PWR6300
The following list defines the standard MEA hardware components to install a PWR:
•PWR Box with N-type Antenna Connector
•15 feet cable assembly
•Mounting Bracket
3

The Network Operator must supply the following:
•Mounting Location
•Power Source (12 VDC)
•Hand tools for bracket installation
Optional Equipment:
•An Antenna Cable and connector
Antenna Options are the following:
Manufacturer Part Number Gain Usage
Maxrad BMMG2400ML195MSMA 0 dBi Mobile
Antenex TRA24003 3 dBi Mobile
4

Mesh Enabled Architecture EWR/PWR Users Guide
2.4 MAC Address Label Location
2.4.1 EWR
The transceiver Media Access Control (MAC) address and the Ethernet MAC address is
typically listed on a label located on the antenna end of the EWR6300. A sample label is shown
in Figure 2-1.
Record the transceiver MAC Address and Ethernet MAC Address in the MAC Address
Table below, as they will be required later to configure and test the device.
Figure 2-1 EWR6300 Identification Label Example
Transceiver
MAC
Address
Ethernet
MAC
Address
2.4.2 PWR
The transceiver and Ethernet MAC addresses are recorded on a label located on the PWR unit.
Record these numbers in the MAC Address Table, as they will be required later to configure and
provision the device.
Figure 2-2 PWR6300 Identification Label Example
2.4.3 MAC Address Table
The MAC Address table has been included for recording the Ethernet MAC address and
transceiver MAC address for a set of EWR and PWR devices as a quick reference. These
5

addresses will be required later in the configuration and management process.
Write the MAC numbers into the MAC Address Table provided below.
MAC Address Table
MAC Address (00-05-12-0A-xx-yy) ETH MAC Address (00-05-12-30-xx-yy)
6

Mesh Enabled Architecture EWR/PWR Users Guide
2.5 EWR6300 Assembly Information
The EWR6300 Assembly information will be described in the following subsections.
2.5.1 EWR6300 Assembly
A
ntenna Connector
Power Out (3-pin)
(
o
p
tional
)
Power In (4-pin)
Test Port
(Not Shown) RJ45 (Data) Port
Figure 2-3 EWR6300 External Connection Points
2.5.2 EWR Installation procedure:
The following instructions describe the EWR6300 hardware installation procedure:
1. If desired, mount the EWR box using the enclosed bracket. Refer to the EWR6300
Mounting Bracket section for detailed information.
2. Insert the Antenna into the N-type Connector on the top of the box, and tighten.
3. Insert the Power Plug into the 4-pin Connector and tighten.
4. Verify the MAC address and Ethernet (ETH) address has been recorded in Section 2.4.3.
Both addresses will be required to configure and test the device.
5. The Test Port is unused during deployment.
2.5.3 EWR6300 Mounting Bracket
The EWR6300 mounting bracket is identical to the mounting bracket for the IAP6300 and the
MWR6300. The bracket is robust secure; and can be used for horizontal, vertical, and off-angle
pole mounted installations. The mounting bracket is preinstalled and supplied with two 3 1/2 x
1/4 inch stainless steel bolts. The mounting bracket can accommodate up to a 3 1/4 inch
diameter mounting pole. Substitute for the 1/4-inch bolts supplied with the bracket may be used
to accommodate mounting poles smaller than 3 inches.
Motorola strongly recommends the use of stainless steel mounting hardware to prevent
corrosion. The standard mounting hardware supplied with the bracket is stainless steel. The
bracket is made of aluminum.
The following procedure outlines the required steps for installing a MEA EWR6300 using the
bracket shown in Figure 2-4.
7

Figure 2-4. EWR6300 Mounting Bracket
1 Using the deployment guidelines described in the MEA Setup and Deployment User’s
Guide, locate an appropriate mounting pole such at a streetlight cobra arm or a metal
post. The mounting pole can be vertical, horizontal, or project at almost any angle.
2 Remove one of the C-Clamp Bracket bolts so that the bracket can be positioned around
the mounting pole. If necessary, remove the second bolt. When the two halves of the
Clamp Bracket are correctly positioned, reinstall the bracket bolts.
Note: The C-Clamp Bracket Assembly requires two 3 1/2 x 1/4 inch stainless steel bolts
to secure the C-Clamp to a mounting pole. Each bolt is supplied with (2) stainless steel
flat washers, (1) lock washer, and (1) stainless steel nut. The bracket hardware should
be installed as indicated in Figure 2-5.
8

Mesh Enabled Architecture EWR/PWR Users Guide
3 1/2 x 1/4 inch bolt
1/4 Flat Washer
1/4 Flat Washer
1/4 Lock Washer
1/4 Hex Nut
Note: All Hardware is Stainless Steel
Figure 2-5. C-Clamp Bracket Assembly
3. Position the bracket in the desired location and securely tighten the two bracket bolts.
4. If required, loosen the Pivot Bolt and the Angle Locking Bolt (Figure 2-6) so that the
antenna connector is positioned vertically.
5. Ensure that the antenna connector is still vertical and tighten the Pivot Bolt using a 7/16-
inch open-end wrench or socket wrench.
6. Tighten the Angle Locking Bolt using a #1 Phillips screwdriver.
9

6 x 32 x 3/4
Angle Locking Bolt
1/4 x 1 inch Pivot Bolt
(Requres 7/16 Wrench)
Figure 2-6. EWR Pivot and Angle Locking Bolts
NOTE: Some IAP6300 and MWR6300 enclosures may have a bolt or plug in the center of the
back of the box. To maintain the integrity of the box, DO NOT REMOVE THIS PLUG.
2.6 PWR6300 Assembly Information
The VMM6300 Assembly shows the external connection points on a VMM6300 box.
N-Type
Antenna
Connector
Power
Reset
Power
Connector
Ethernet
(Crossover MDI-X)
Figure 2-7. PWR External Connection Point
10

Mesh Enabled Architecture EWR/PWR Users Guide
2.6.1 PWR Installation Procedure
The following instructions describe the PWR6300 hardware installation procedure:
1. Mount the PWR in a traffic cabinet or kiosk. The device is not waterproof and should be
reasonably protected from moisture and other exposed outdoor environments.
2. Connect the antenna to the N-type connector.
3. Insert the Power Plug into Power Connector.
4. Verify the transceiver and Ethernet MAC address have been recorded in Section 2.4.3, as it
will be required to configure and test the device.
5. The Test Port is unused during deployment.
Figure 2-8 PWR6300 Cabinet Mounting
2.7 Device Deployment Considerations
When deploying the EWR6300 or the PWR6300 consider the following:
•The antenna should be a minimum of 30 inches from any nearby metal poles to avoid
distortion of the RF pattern.
•The antenna must have a separation distance of at least 2 meters from the body of all
persons and must not be co-located or operating in conjunction with any other antenna or
transmitter.
•Users and installers must be provided with antenna installation and transmitter operating
conditions to satisfy RF exposure compliance.
•Typically, the EWR and the PWR are distributed within a network and are used as
subscriber devices. A rule of thumb is to deploy 2-3 hop networks to optimize range, latency,
and throughput to subscriber devices.
•It is required that the EWR/PWR chassis be grounded to minimize the possibility of ESD
(electrostatic discharge) induced damage.
11

2.7.1 Antenna Deployment Tips
Locate the antenna to minimize multipath:
- Minimize interference from nearby transmitters
- Maximize chance of a direct line of sight connection to other devices.
- Mount the supplied antenna vertically
2.8 Testing the Device Installation
Verify the operation of each installed EWR6300 and PWR device using the following procedure:
1. Apply power to the EWR6300 or the PWR6300, as applicable.
(On the PWR device, the power reset button will be illuminated to red.)
2. Obtain the transceiver MAC address and the Ethernet address that was recorded earlier in
the MAC_Address_Table section of this document. The address will be in the format 00-05-
12-0A-xx-yy for the transceiver and 00-05-12-30-xx-yy for Ethernet.
3. From the MeshManager software screen, display the devices using the Display MAC
Addresses selection from the Preferences menu
Note: This step assumes that the device has been automatically detected via the Auto-Add
feature, or manually added using the Add New Device menu item in MeshManager.
4. Within the MeshManager software screen, select the appropriate EWR or PWR in the EWR
device tree. Note: The same EWR template is used for both device types.
5. Within the MeshManager software screen, right-click on the device MAC address and select
the Ping option.
A successful response to the Ping command verifies that the EWR or PWR is successfully
communicating to the infrastructure devices.
12
