Motorola W210 User manual

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5GB1
INSTRUCTION MANUAL
•A preliminary draft copy of the User’s Manual follows this cover page.
•The User’s Manual will have the following text added to it:
"NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
. Reorient or relocate the receiving antenna.
. Increase the separation between the equipment and receiver.
. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
. Consult the dealer or an experienced radio/TV technician for help."
A statement according to FCC Part 15.19(a) will be included in the production version of the user's manual.
EXHIBIT 8

motorola.com
W210
CDMA

1
HELLOMOTO
Welcome to the world of Motorola digital wireless communications! We are pleased that
you have chosen the Motorola W210 wireless phone.
Earpiece
Listen to your voice
calls & messages.
Left Soft Key
Perform functions identified by
left display prompt.
Send/Answer Key
Make & answer calls. Press in
idle screen to see the recent
dialed calls.
Microphone
Power Connector
Port Insert the charger.
Navigation Key
Scroll through lists,
set volume.
Power/End Key
Press & hold to turn on/off the
phone. Press & release to end
phone calls, exit menu system.
Right Soft Key
Perform functions identified by
right display prompt.
Menu Key
Open a menu when you see
in the display.

2
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Certain mobile phone features are dependent on the
capabilities and settings of your service provider’s
network. Additionally, certain features may not be
activated by your service provider, and/or the
provider's network settings may limit the feature’s
functionality. Always contact your service provider
about feature availability and functionality. All
features, functionality, and other product
specifications, as well as the information contained
in this user's guide are based upon the latest
available information and are believed to be accurate
at the time of printing. Motorola reserves the right to
change or modify any information or specifications
without notice or obligation.
MOTOROLA and the Stylized M Logo are registered
in the US Patent & Trademark Office. 2005 All other
product or service names are the property of their
respective owners. © Motorola, Inc. 2005.
Manual Number:

3
check it out!
check it out!
Note: Your phone may not appear exactly as the phone image above, however, all key
locations, sequences, and functions remain the same.
Integrated Antenna
Embedded in the top-back
of the phone.
Battery Room
Headset jack
Lanyard Attachment

4
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to
water, rain, extreme humidity,
sweat, or other moisture.
Don’t expose your phone to
dust, dirt, sand, food, or other
inappropriate materials.
extreme heat or cold cleaning solutions
Avoid temperatures below
-10°C/14°F or
above 45°C/113°F.
To clean your phone, use only
a dry soft cloth. Don’t use
alcohol or other cleaning
solutions.
microwaves the ground
Don’t try to dry your phone in
a microwave oven.
Don’t drop your phone.

5
feature locator
main menu
Messages
• Create Message
•Voicemail
•TextMsgs
•QuickNotes
• Outbox
•Drafts
Phonebook
•[NewEntry]
Recent Calls
• Missed Calls
• Received Calls
• Dialed Calls
•CallTimes
Games
• Football
•Crazy
•Rabel
MyMenu
• [New MyMenu]
Alarm Clock
•[NewEntry]
Brew
• Mobile Shop
• Settings
•Help
Settings
•RingStyles
• Phone Status
• In-Call Setup
• Security
• Personalize
•InitialSetup
•Network
• Headset
More
•Calculator
• Stop Watch
• Datebook
•AlarnClock
• Service Dial

6
contents
contents
check it out! . . . . . . . . . . . 3
Use and Care . . . . . . . . . . 4
essentials . . . . . . . . . . . . . 8
about this guide . . . . . . . 8
RUIM card . . . . . . . . . . . 9
battery . . . . . . . . . . . . . . 9
battery tips . . . . . . . . . . 10
turn it on & off . . . . . . . 11
make a call . . . . . . . . . . 11
answer a call . . . . . . . . 11
correcting entry errors . 12
main attractions. . . . . . . 13
zoom number display. . 13
datebook . . . . . . . . . . . 13
read messages with
iMelody . . . . . . . . . . . . 18
fm radio . . . . . . . . . . . . 19
basics . . . . . . . . . . . . . . . 20
display . . . . . . . . . . . . . 20
menus . . . . . . . . . . . . . 22
text entry . . . . . . . . . . . 24
navigation key . . . . . . . 26
codes & passwords . . 26
lock & unlock phone. . . 27
phonebook search . . . . 27
storing phone numbers 28
adjusting in-call
microphone volume . . . 28
volume . . . . . . . . . . . . . 28
speakerphone . . . . . . . 29
using caller ID . . . . . . . 29
redialing last dialed,
received, or missed
number . . . . . . . . . . . . 29
speed dmialing. . . . . . . 30
keypad lock/unlock . . . 30
etiquette mode. . . . . . 30
shortcut . . . . . . . . . . . 31
personalizing . . . . . . . 31
customize . . . . . . . . . . . 32
ring style . . . . . . . . . . 32
time & date . . . . . . . . 33
animation . . . . . . . . . . 33
display appearance. . . 33
screen saver. . . . . . . . 33
home screen . . . . . . . 34
main menu . . . . . . . . . 34
battery save . . . . . . . . 34
answer options . . . . . 34
calls . . . . . . . . . . . . . . . . 35
recent calls. . . . . . . . . 35
redial . . . . . . . . . . . . . 35

contents
7
return a call . . . . . . . . . 36
mute a call . . . . . . . . . . 36
caller ID . . . . . . . . . . . . 36
emergency calls . . . . . 37
international calls. . . . . 37
voice mail . . . . . . . . . . 38
special characters . . . . 38
other features . . . . . . . . 39
phonebook. . . . . . . . . . 39
recent calls . . . . . . . . . 40
messages . . . . . . . . . . 41
settings . . . . . . . . . . . . 44
more features . . . . . . . 48
game . . . . . . . . . . . . . . 48
alarm clock. . . . . . . . . . 48
service and repairs . . . . 49
Specific Absorption Rate
Data . . . . . . . . . . . . . . . . 50
index. . . . . . . . . . . . . . . . 52

8
essentials
essentials
about this guide
This guide shows how to locate a menu
feature as follows:
Find it: Press > Phonebook > Serach By >
Find/Jump
This example shows that, from the home
screen, you press to open the menu,
highlight and select
Phonbook , highlight and
select
Search , then highlight and select
Find/Jump .
Press up or down to highlight a menu
feature. Press
X on the navigation key to
select the highlighted menu feature.
symbols
This means a feature is
network/subscription dependent
and may not be available in all
areas. Contact your service
provider for more information.
This means a feature requires an
optional accessory.

9
essentials
RUIM card
Your Removable-User Identity
Module (RUIM) card contains
personal information like your phone
number and phonebook entries.
Caution: Don't bend or scratch your RUIM
card. Keep it away from static electricity,
water, and dirt.
battery
battery installation
battery charging
New batteries are
shipped partially
charged. Before you
can use your phone,
install and charge
the battery as
described below.
Some batteries
perform best after
several full charge/discharge cycles.
When the battery charging is complete, the
battery icon will change to a battery full
icon ( ) and the screen displays
Charging
Complete
.
12
3

10
essentials
Tip: Relax, you can't overcharge your
battery. It will perform best after you fully
charge and discharge it a few times.
battery tips
Battery life depends on the network, signal
strength, temperature, features, and
accessories you use.
• Always use Motorola
Original batteries and
chargers. The warranty does
not cover damage caused by
non-Motorola batteries and/or chargers.
• New batteries or batteries stored for
a long time may take more time to
charge.
• When charging your battery, keep it
near room temperature.
• When storing your battery, keep it
uncharged in a cool, dark and dry
place.
• Never expose batteries to
temperatures below -10°C (14°F) or
above 45°C (113°F). Always take your
phone with you when you leave your
vehicle.
• It is normal for batteries to gradually
wear down and require longer
charging times. If you notice a
change in your battery life, it is
probably time to purchase a new
battery.
Contact your local recycling center
for proper battery disposal.
Warning: Never dispose of batteries in a
fire because they may explode.

11
essentials
turn it on & off
To turn on your
phone, press and
hold for 2
seconds. If
prompted, enter
your 8-digit RUIM
card PIN code and/or 4-digit unlock code.
Caution: If you enter an incorrect PIN code
3 times in a row, your RUIM card becomes
disabled and your phone displays
RUIM
Blocked
. Contact your service provider if your
RUIM is blocked.
To turn off your phone, press and hold
for 2 seconds. If prompted, enter your
4-digit unlock code.
make a call
In home screen, enter a phone number (up
to 32 digits) and press . To end a call,
press .
answer a call
To answer an incoming call, press or any
key if
Answer Option is set to Any Key . To end a
call, press .
If your phone subscribes to Caller ID, a
caller's phone number will be displayed on
screen. If caller's number is stored in the
Phonebook , the caller's name will be
displayed.

12
essentials
correcting entry errors
To correct a misdialed digit, press to
erase one digit at a time. You can erase all
the digits at once by pressing and
holding it down over one second.

13
main attractions
main attractions
zoom number display
Zoom number display is a smart function
that lets you see the screen numbers more
easily by altering the screen font size
depending on how many digits are in the
number. Because most people enter seven
digits most frequently, your font size is
large most of the time and becomes
smaller only when necessary.
datebook
The datebook is a calendar that lets you
schedule and organize events such as
appointments and meetings. You can
review your schedule of events for the
week or by the day, and have the datebook
play a reminder alarm for specific events.
Note: You must set the phone’s correct
time and date in order to use the datebook.
To schedule or review events in the
datebook:
Find it: Press > More > Datebook
viewing by the week
When you open the datebook, your phone
displays a calendar for the week. Lines or
filled boxes under each day indicate
scheduled events.

14
main attractions
view by day
Select a day in the week view and press
VIEW to see the day’s events. You can store,
edit, view, copy, and delete any event from
the day view.
view by event
Select an event in the day view and press
VIEW to open the detailed event view. You
can edit, copy, and delete events from the
event view.
add a new event
You can add a new event two different
ways.
Find it: Press > More > Datebook > day >
New Entry or > More > Datebook > day > >
New > Event
To set u p th e Event detail, follow the steps
below. A title is required for a datebook
event. All other information is optional.
1 Press CHANGE to select Title .
2 Use the keypad keys to enter a title for
the event.
3 Press OK to store the event title.
4 Press up and down to scroll to other
fields and enter information as
necessary.
Other fields let you enter
Start , Duration ,
Date , Repeat , and Alarm .
5 Press DONE to store the new event and
return to the day view.

15
main attractions
add a new task
You can add a new task by doing the
following:
Find it: Press > More > Datebook > day >
>
New > Task
To set u p the Task detail, follow the steps
below. A summary is required for a
datebook task. All other information is
optional.
1 Press CHANGE to select Summary .
2 Use the keypad keys to enter a
summary for the task.
3 Press OK to store the task summary.
4 Press up or down to scroll to other
fields and enter information as
necessary.
Other fields let you enter
Start Date ,
Deadline , Priority , Completed , Category , and Status .
5 Press DONE to store the new task and
return to the day view.
change event/task information
To change information about an existing
event/task:
Find it: Press > More > Datebook
1 Press left or right to scroll to the
scheduled event/taks day.
2 Press VIEW to display the day view.
3 Press up or down to scroll to the
event/task you want to change.
4 Press VIEW to display the event/task.
5 Press EDIT to edit the event/task.

16
main attractions
6 Press up or down to scroll to the
detail you want to change.
7 Press CHANGE to edit the information.
8 Use the keypad keys to enter the new
information.
9 Press DONE to store the information.
copy an event/task
To copy information from a current
event/task to a new event/task:
Find it: Press > More > Datebook
1 Press left or right to scroll to the
scheduled event/task day.
2 Press VIEW to display the day view.
3 Press up or down to scroll to the
event/task to copy.
4 Presss to open the Datebook Menu .
5 Press up or down to scroll to Copy .
6 Press SELECT to copy the event/task.
7 Press YES to confirm the copy.
Your phone assumes that you want to
change the date, and displays the
Date
field.
8 Use the keypad keys to enter the date
information.
9 Press left or right to scroll to the day,
month, and year.
10 Press OK to save the copy of the
event/task.
11 Press up or down to scroll to
event/task details and edit the
information as necessary.
12 Press DONE to store the new event/task
and return to the day view.

17
main attractions
delete an event
Find it: Press > More > Datebook
1 Press left or right to scroll to the
scheduled event day.
2 Press VIEW to display the day view.
3 Press up or down to scroll to the
event to delete.
4 Press to open the Datebook Menu .
5 Press up or down to scroll to Delete .
6 Press SELECT to select Delete .
For non-repeating events, a
confirmation message will pop up.
Choose
Yes or No to confirm or cancel
the delete. For repeating events, the
phone displays a delete event menu:
Press up or down to scroll to
This Event
Only
or Repeat Events . Press SELECT to select
the event(s) to delete.
delete a task
Find it: Press > More > Datebook
1 Press left or right to scroll to the
scheduled task day.
2 Press VIEW to display the day view.
3 Press up or down to scroll to the
event to delete.
4 Press to open the Datebook Menu .
5 Press up or down to scroll to Delete .
6 Press SELECT to select Delete .
7 A confirmation message will pop up.
Choose
Yes or No to confirm or cancel
the delete.
