INSTALLATION
AP-5131 Access Point
Installation Guide
72-70931_01.book Page 1 Monday, May 4, 2009 8:10 AM

72-70931_01.book Page 2 Monday, May 4, 2009 8:10 AM

1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.1 Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.2 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
1.3 Site Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2.0 AP-5131 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2.1 Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2.2 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2.3 Radio Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3.0 Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
3.1 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
3.2 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
3.3 AP-5131 Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.4 Mounting the AP-5131 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
3.5 LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Contents
72-70931_01.book Page iii Monday, May 4, 2009 8:10 AM

4.0 Basic AP-5131 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.1 Resetting the AP-5131 Password . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.2 Configuring Basic AP-5131 Device Settings . . . . . . . . . . . . . . . . . 25
4.3 Where to Go From Here? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.0 Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.0 Waste Electrical and Electronic Equipment (WEEE) . . . . . . 40
7.0 Motorola’s Enterprise Mobility Support Center . . . . . . . . . . 42
72-70931_01.book Page iv Monday, May 4, 2009 8:10 AM

v
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. Symbol is a registered trademark of Symbol Technologies,
Inc. All other product or service names are the property of their respective
owners. © Motorola, Inc. 2009. All rights reserved.
72-70931_01.book Page v Monday, May 4, 2009 8:10 AM

72-70931_01.book Page vi Monday, May 4, 2009 8:10 AM

Introduction 1
1 Introduction
The Motorola AP-5131 Access Point (AP) provides a bridge between Ethernet wired LANs or WANs
and wireless networks. It provides connectivity between Ethernet wired networks and radio-equipped
mobile units (MUs). MUs include the full line of Motorola terminals, bar-code scanners adapters (PC
cards, compact flash cards and PCI adapters) and other devices.
The AP-5131 provides a maximum 54Mbps data transfer rate via each radio. It monitors Ethernet
traffic and forwards appropriate Ethernet messages to MUs over the network. It also monitors MU
radio traffic and forwards MU packets to the Ethernet LAN.
The AP-5131’s GUI, CLI and help system have been re-branded to “AP-51xx” (with the exception of
the login screen to be used generically with the AP-5181 model access point (that shares the same
GUI and feature set).
The AP-5131 is available in two radio versions, a single-radio and dual-radio model. One version of
the device firmware runs on the AP-5131 regardless of its radio configuration.
The Motorola AP-5131 Access Point is available in the following base models:
• Single 802.11a/g radio, external antenna (Part No. AP-5131-4002X-WWR)
• Dual 802.11a+g radio, external antenna (Part No. AP-5131-1304X-WWR)
If new to the AP-5131 and access point technology, refer to the AP-51xx Product Reference Guide to
familiarize yourself with access point technology and the feature set exclusive to the Motorola
AP-5131. The guide is available, at http://support.symbol.com/support/product/manuals.do.
1.1 Document Conventions
The following graphical alerts are used in this document to indicate notable situations:
NOTE Tips, hints, or special requirements that you should take note of.
CAUTION Care is required. Disregarding a caution can result in data loss or
equipment malfunction.
!
72-70931_01.book Page 1 Monday, May 4, 2009 8:10 AM

AP-5131 Access Point: Installation Guide
2
1.2 Warnings
•Read all installation instructions and site survey reports, and verify correct equipment installation before
connecting the AP-5131 to its power source.
•Remove jewelry and watches before installing this equipment.
•Verify that the unit is grounded before connecting it to the power source.
•Verify that any device connected to this unit is properly wired and grounded.
•Connect all power cords to a properly wired and grounded electrical circuit.
•Verify that the electrical circuits have appropriate overload protection.
•Attach only approved power cords to the device.
•Verify that the power connector and socket are accessible at all times during the operation of the
equipment.
•Do not work with power circuits in dimly lit spaces.
•Do not install this equipment or work with its power circuits during thunderstorms or other weather
conditions that could cause a power surge.
•Verify there is adequate ventilation around the device, and that ambient temperatures meet equipment
operation specifications.
1.3 Site Preparation
•Consult your site survey and network analysis reports to determine specific equipment placement, power
drops, and so on.
•Assign installation responsibility to the appropriate personnel.
•Identify and document where all installed components are located.
•Provide a sufficient number of power drops for your equipment.
•Ensure adequate, dust-free ventilation to all installed equipment.
•Identify and prepare Ethernet and console port connections.
•Verify that cable lengths are within the maximum allowable distances for optimal signal transmission.
WARNING! Indicates a condition or procedure that could result in personal injury or
equipment damage.
72-70931_01.book Page 2 Monday, May 4, 2009 8:10 AM

AP-5131 Specifications 3
2 AP-5131 Specifications
2.1 Physical Characteristics
The AP-5131 has the following physical characteristics:
2.2 Electrical Characteristics
The AP-5131 has the following electrical characteristics:
Dimensions 5.32 inches long x 9.45 inches wide x 1.77 inches thick.
135 mm long x 240 mm wide x 45 mm thick.
Housing Metal, Plenum Housing (UL2043)
Weight 1.95 lbs/0.88 Kg (single-radio model)
2.05 lbs/0.93 Kg (dual-radio model)
Operating
Temperature
-20 to 50° Celsius
Storage Temperature -40 to 70° Celsius
Altitude 8,000 feet/2438 m @ 28° Celsius (operating)
15,000 feet/4572 m @ 12° Celsius (storage)
Vibration Vibration to withstand .02g/Hz, random, sine, 20-2k Hz
Humidity 5 to 95% (operating) 5 to 85% (storage)
Electrostatic
Discharge
15kV (air)
8kV (contact)
Drop Bench drop 36 inches to concrete (excluding side with connectors)
Operating Voltage 48Vdc (Nom)
Operating Current 200mA (Peak) @ 48Vdc
170mA (Nom) @ 48Vdc.
72-70931_01.book Page 3 Monday, May 4, 2009 8:10 AM

AP-5131 Access Point: Installation Guide
4
2.3 Radio Characteristics
The AP-5131 has the following radio characteristics:
Transmitter Power 22 dBm Maximum (country, channel and data-rate dependant)
802.11b/g
19 dBm +/- 1 dBm @ 1, 2, 5.5, 11 Mbps
19 dBm +/- 1 dBm @ 6 and 9 Mbps
18 dBm +/- 1 dBm @ 12 and 18 Mbps
17 dBm +/- 1 dBm @ 24 and 36 Mbps
16 dBm +/- 1 dBm @ 48 and 54 Mbps
802.11a
17 dBm +/- 1 dBm @ 6 and 9 Mbps
16 dBm +/- 1 dBm @ 12 and 18 Mbps
15 dBm +/- 1 dBm @ 24 and 36 Mbps
14 dBm +/- 1 dBm @ 48 and 54 Mbps
Operating Channels 802.11a radio - Channels 1-35 (4920-5825 MHz)
802.11b/g radio - Channels 1-13 (2412-2472 MHz)
802.11b/g radio - Channel 14 (2484 MHz Japan only)
Actual operating frequencies depend on regulatory rules and
certification agencies.
Radio Data Rates 802.11a radio 6, 9, 12, 18, 24, 36, 48, and 54 Mbit/Sec
802.11g radio 6, 9, 12, 18, 24, 36, 48, and 54 Mbit/Sec
802.11b radio 1, 2, 5.5, 11 Mbps
Wireless Medium Direct Sequence Spread Spectrum (DSSS)
Orthogonal Frequency Division Multiplexing (OFDM)
72-70931_01.book Page 4 Monday, May 4, 2009 8:10 AM

Hardware Installation 5
3 Hardware Installation
An AP-5131 installation includes mounting the AP-5131 on a table-top, wall, ceiling T-bar or above
the ceiling orientation, connecting the AP-5131 to the network (LAN or WAN port connection),
connecting antennas and applying power. Installation procedures vary for different environments.
3.1 Precautions
Before installing the AP-5131 verify the following:
• Do not install in wet or dusty areas without additional protection. Contact a Motorola
representative for more information.
• Verify the environment has a continuous temperature range between -20° C to 50° C.
3.2 Package Contents
Check package contents for the correct model AP-5131 and applicable AP-5131 accessories. Each
available configuration (at a minimum), contains:
• AP-5131 (two base models available)
• Single 802.11a/g radio, external antenna (Part No. AP-5131-4002X-WWR)
• Dual 802.11a+g radio, external antenna (Part No. AP-5131-1304X-WWR)
• AP-5131 Install Guide
• Accessories Bag (4 rubber feet for desk mounting and a LED light pipe and badge with label
for above the ceiling installations)
Verify the model indicated on the bottom of the AP-5131 is correct. Contact the Motorola Support
Center to report missing or improperly functioning items.
NOTE There are numerous SKUs available containing at least one AP-5131
radio model (either 802.11a or 802.11b/g), Install Guide and Accessories
Bag. However, some SKUs contain various antenna and Motorola Power
Injector combinations. Refer to the AP-51xx Product Reference Guide to
familiarize yourself with all available AP-5131 product SKUs. The guide is
available on the Motorola Web site, at
http://support.symbol.com/support/product/manuals.do.
72-70931_01.book Page 5 Monday, May 4, 2009 8:10 AM

AP-5131 Access Point: Installation Guide
6
3.3 AP-5131 Placement
For optimal performance, install the AP-5131 away from transformers, heavy-duty motors, fluorescent
lights, microwave ovens, refrigerators and other industrial equipment. Signal loss can occur when
metal, concrete, walls or floors block transmission. Install the AP-5131 in open areas or add access
points as needed to improve coverage.
Place the AP-5131 using the following guidelines:
• Install the AP-5131 at an ideal height of 10 feet from the ground.
• Orient the AP-5131 antenna vertically for best reception.
• Point the AP-5131 antenna(s) downward if attaching to the ceiling.
Motorola recommends conducting a site survey to define and document radio interference obstacles
before installing the AP-5131 to maximize its radio coverage area.
3.3.1 AP-5131 Antenna Options
Both Radio 1 and Radio 2 require one antenna and can optimally use two antennas per radio (4
antennas total for dual-radio models). Two antennas per radio provides diversity that can improve
performance and signal reception. Motorola supports two antenna suites for the AP-5131. One
antenna suite supporting the 2.4 GHz band and another antenna suite supporting the 5.2 GHz band.
Select an antenna model best suited to the intended operational environment of your AP-5131.
Antenna connectors for Radio 1 are located in a different location from the Radio 2 antenna
connectors. On single radio versions, the R-SMA connectors can support both bands and should be
connected to a R-SMA dual-band antenna or an appropriate single band antenna. If necessary a
R-SMA to R-BNC adapter (Part No. 25-72178-01) can be purchased separately from Motorola.
NOTE On a single-radio AP-5131, Radio 1 can be configured to be either a 2.4
GHz or 5.2 GHz radio. On a dual-radio model, Radio 1 refers to the AP-
5131’s 2.4 GHz radio and Radio 2 refers to the AP-5131 5.2 GHz radio.
However, there could be some cases where a dual-radio AP-5131 is
performing a Rogue AP detector function. In this scenario, the AP-5131 is
receiving in either 2.4 GHz or 5.2 GHz over the Radio 1 or Radio 2
antennas depending on which radio is selected for the scan.
72-70931_01.book Page 6 Monday, May 4, 2009 8:10 AM

Hardware Installation 7
Certain Rogue AP Detection and Intrusion Detection features use an AP-5131 radio to perform dual-
band scanning. The dedicated radio should be connected to an appropriate dual-band dipole antenna
(Part No. ML-2452-APA2-01).
The 2.4 GHz antenna suite includes the following models:
Part Number Antenna Type Nominal Net Gain (dBi)
ML-2499-11PNA2-01R Wide Angle Directional 8.5
ML-2499-HPA3-01R Omni-Directional Antenna 3.3
ML-2499-BYGA2-01R Yagi Antenna 13.9
ML-2452-APA2-01 Dual-Band 3.0
NOTE An additional adapter is required to use ML-2499-11PNA2-01R and
ML-2499-BYGA2-01R model antennas. Please contact Motorola for more
information.
72-70931_01.book Page 7 Monday, May 4, 2009 8:10 AM

AP-5131 Access Point: Installation Guide
8
The 5.2 GHz antenna suite includes the following models:
For detailed specifications on the antennas available to the AP-5131, refer to the AP-51xx Product
Reference Guide. Appendix A of that document contains detailed AP-5131 antenna specifications and
their instructions for optimal use. The guide is available on the Motorola Web site, at
http://support.symbol.com/support/product/manuals.do.
3.3.2 Power Injector System
The AP-5131 can receive power either directly form a Motorola 48V AC-DC power supply
(Part No. 50-14000-243R) or via an Ethernet cable connected to the LAN port (using the 802.3af
standard).
When users purchase a Motorola WLAN solution, they often need to place access points in obscure
locations. In the past, a dedicated power source was required for each access point in addition to the
Ethernet infrastructure. This often required an electrical contractor to install power drops at each
access point location. An approved power injector solution merges power and Ethernet into one
cable, reducing the burden of installation and allows optimal AP-5131 placement in respect to the
intended radio coverage area.
The Power Injector is included in certain AP-5131 kits. The Power Injector
(Part No. AP-PSBIAS-1P2-AFR) is an integrated AC-DC converter and 802.3af power injector which
requires 110-220V AC power to combine low-voltage DC with Ethernet data in a single cable
connecting to the AP-5131.
The Motorola AP-5131 Power Supply (Part No. 50-14000-243R) is not included in the kit and is
orderable separately as an accessory.
Part Number Antenna Type Nominal Net Gain (dBi)
ML-5299-WPNA1-01R Panel Antenna 13.0
ML-5299-HPA1-01R Wide-Band Omni-Directional
Antenna
5.0
ML-2452-APA2-01 Dual-Band 4.0
CAUTION The AP-5131 supports any standards-based 802.3af compliant power
source (including non-Motorola power sources). However, using the
wrong solution (including a POE system used on a legacy Motorola
access point) could severely damage the AP-5131 and void the
product warranty.
!
72-70931_01.book Page 8 Monday, May 4, 2009 8:10 AM

Hardware Installation 9
A separate Power Injector is required for each AP-5131 comprising the network.
The Power Injector can be installed free standing, on an even horizontal surface or wall mounted
using the power injector’s wall mounting key holes. The following guidelines should be adhered to
before cabling the Power Injector to an Ethernet source and an AP-5131:
• Do not block or cover airflow to the Power Injector.
• Keep the Power Injector away from excessive heat, humidity, vibration and dust.
• The Power Injector is not a repeater, and does not amplify the Ethernet data signal. For
optimal performance, ensure the Power Injector is placed as close as possible to the
network data port.
to AP-5131 LAN
Port
Data Power
AP-5131
Power
Injector
Wireless LAN
72-70931_01.book Page 9 Monday, May 4, 2009 8:10 AM

AP-5131 Access Point: Installation Guide
10
To install the Power Injector to an Ethernet data source and AP-5131:
1. Connect the Power Injector to an AC outlet (110VAC to 220VAC).
2. Connect an RJ-45 Ethernet cable between the network data supply (host) and the Power
Injector Data In connector.
3. Connect an RJ-45 Ethernet cable between the Power Injector Data & Power Out connector
and the AP-5131 LAN port.
Ensure the cable length from the Ethernet source (host) to the Power Injector and AP-5131
does not exceed 100 meters (333 ft).
The Power Injector has no On/Off power switch. The Power Injector receives power and is
ready for AP-5131 device connection and operation as soon as AC power is applied.
CAUTION Ensure AC power is supplied to the Power Injector using an AC cable
with an appropriate ground connection approved for the country of
operation.
NOTE Cabling the Power Injector to the AP-5131’s WAN port renders the
AP-5131 non-operational. Only use a AP-PSBIAS-1P2-AFR model power
injector with the AP-5131’s LAN port.
!
72-70931_01.book Page 10 Monday, May 4, 2009 8:10 AM

Hardware Installation 11
The Power Injector demonstrates the following LED behavior under normal and/or problematic
operating conditions:
For more information and device specifications for the Power Injector, refer to the Power Injector
Quick Install Guide (Part No. # 72-99410-01) available from the Motorola Web site, at
http://support.symbol.com/support/product/manuals.do.
3.4 Mounting the AP-5131
The AP-5131 can rest on a flat surface, attach to a wall, mount under a suspended T-Bar or above a
ceiling (plenum or attic). Choose one of the following mounting options based on the physical
environment of the coverage area. Do not mount the AP-5131 in a location that has not been
approved in a site survey.
3.4.1 Desk Mounting
The desk mount option uses rubber feet (found in the accessories bag shipped with the AP-5131)
allowing the unit to sit on most flat surfaces.
To install the AP-5131 in a desk mount orientation:
1. Turn the AP-5131 upside down.
2. Remove the backings from the four (4) rubber feet and attach them to the four rubber feet
recess areas on the AP-5131.
LED AC (Main) Port
Green (Steady) Power Injector is receiving
power from AC outlet
Indicates a device is
connected to the
Power Injector’s outgoing
Data & Power cable
Green (Blinking) Output voltage source is out
of range
The Power Injector is
overloaded or has a
short circuit
72-70931_01.book Page 11 Monday, May 4, 2009 8:10 AM

AP-5131 Access Point: Installation Guide
12
3. Attach the Radio 1 and/or Radio 2 antennas to their correct connectors. The antenna covers
will most likely need to be removed to orient the antenna upward in a typical desktop
installation.
For information on the antennas available to the AP-5131, see
“AP-5131 Antenna Options” on page 6.
4. Cable the AP-5131 using either the Motorola Power Injector solution or an approved line
cord and power supply.
For Motorola Power Injector installations:
a. Connect a RJ-45 Ethernet cable between the network data supply (host) and the Power
Injector Data In connector.
b. Connect a RJ-45 Ethernet cable between the Power Injector Data & Power Out
connector and the AP-5131 LAN port.
c. Ensure the cable length from the Ethernet source (host) to the Power Injector and
AP-5131 does not exceed 100 meters (333 ft). The Power Injector has no On/Off power
switch. The Power Injector receives power as soon as AC power is applied. For more
information on using the Power Injector, see “Power Injector System” on page 8.
For standard power adapter (non Power Injector) and line cord installations:
a. Connect a RJ-45 Ethernet cable between the network data supply (host) and the AP-5131
LAN port.
CAUTION Ensure you are placing the antennas on the correct connectors
(depending on your single or dual-radio model and frequency used) to
ensure the successful operation of the AP-5131.
!
72-70931_01.book Page 12 Monday, May 4, 2009 8:10 AM

Hardware Installation 13
b. Verify the power adapter is correctly rated according the country of operation.
c. Connect the power supply line cord to the power adapter.
d. Attach the power adapter cable into the power connector on the AP-5131.
e. Attach the power supply line cord to a power supply
5. Verify the behavior of the AP-5131 LEDs. For more information, see “LED Indicators” on
page 21.
6. Return the AP-5131 to an upright position and place it in the location you wish it to operate.
Ensure the AP-5131 is sitting evenly on all four rubber feet.
7. The AP-5131 is ready to configure. For information on basic AP-5131 device configuration,
see “Configuring “Basic” Device Settings” on page 25.
3.4.2 Wall Mounting
Wall mounting requires hanging the AP-5131 along its width (or length) using the pair of slots on the
bottom of the unit and using the AP-5131 itself as a mounting template for the screws.
The mounting hardware and tools (customer provided) required to install the AP-5131 on a wall
consists of:
• Two Phillips pan head self-tapping screws
(ANSI Standard) #6-18 X 0.875in. Type A or AB Self-Tapping screw, or
(ANSI Standard Metric) M3.5 X 0.6 X 20mm Type D Self-Tapping screw
• Two wall anchors
• Security cable (optional)
To mount the AP-5131 on a wall:
1. Orient the AP-5131 on the or ceiling by its width or length.
CAUTION Do not actually connect to the power source until the cabling portion
of the installation is complete.
CAUTION An AP-5131 should be wall mounted to concrete or plaster-wall-board
(dry wall) only. Do not wall mount an AP-5131 to combustible
surfaces.
!
!
72-70931_01.book Page 13 Monday, May 4, 2009 8:10 AM

AP-5131 Access Point: Installation Guide
14
2. Using the arrows on one edge of the case as guides, move the edge to the midline of the
mounting area and mark points on the midline for the screws.
3. At each point, drill a hole in the wall, insert an anchor, screw into the anchor the wall
mounting screw and stop when there is 1mm between the screw head and the wall.
If pre-drilling a hole, the recommended hole size is 2.8mm (0.11in.) if the screws are going
directly into the wall and 6mm (0.23in.) if wall anchors are being used.
4. If required, install and attach a security cable to the AP-5131 lock port.
5. Attach the Radio 1 and/or Radio 2 antennas to their correct connectors.
6. For information on the antennas available to the AP-5131, see
“AP-5131 Antenna Options” on page 6.
7. Place the large corner of each of the mount slots over the screw heads.
8. Slide the AP-5131 down along the mounting surface to hang the mount slots on the screw
heads.
9. Cable the AP-5131 using either the Power Injector solution or an approved line cord and
power supply.
For Motorola Power Injector installations:
a. Connect a RJ-45 Ethernet cable between the network data supply (host) and the Power
Injector Data In connector.
b. Connect a RJ-45 Ethernet cable between the Power Injector Data & Power Out
connector and the AP-5131 LAN port.
c. Ensure the cable length from the Ethernet source (host) to the Power Injector and
AP-5131 does not exceed 100 meters (333 ft). The Power Injector has no On/Off power
switch. The Power Injector receives power as soon as AC power is applied. For more
information on using the Power Injector, see “Power Injector System” on page 8.
CAUTION Ensure you are placing the antennas on the correct connectors
(depending on your single or dual-radio model and frequency used) to
ensure the successful operation of the AP-5131.
NOTE The AP-5131 must be mounted with the RJ45 cable connector oriented
upwards to ensure proper operation.
!
72-70931_01.book Page 14 Monday, May 4, 2009 8:10 AM
