movistar PCD1021 User manual

1. Introduction
1.1 Phone Display

2
We continuously strive to improve our products. Therefore, we reserve the right to revise this
user manual or withdraw it at any time without prior notice.
1.2 Key
Key
Function
Dial/ Answer
Key
Make or answer a call.
View call logs in standby mode.
Hang-Up
Press and hold to turn the phone on/off.
End a call or reject an incoming call.
Return to the idle mode.
Right Soft
Key
In idle mode, press to turn the torch on for about 5 seconds.
In idle mode, press and hold to turn the torch on all the time, press again and the torch
will turn off.
Return to the previous menu.
Left Soft Key
Access the menu in idle mode.
When keypad is locked, press Left Soft key and * key to unlock the keypad

3
OK
Enter the Main menu in idle mode.
Confirm a selection.
Numeric Key
Enter numbers, letters or characters.
Select a submenu item labeled with the corresponding number.
*
Press twice quickly to enter „+‟to make an international call.
Press to switch input modes when entering text.
#
Press and hold to activate or deactivate the silent mode in idle mode.
Press and hold to enter the pause character (P) or the wait character (W) when
entering number. Press to enter a symbol when editing text.
Navigation Key
Within a menu, press Up, Down, Left or Right to scroll through menu options.
Note: “Press”in this manual, means press the key and release; “press and hold” means to
press and hold the key for at least two seconds.
1.3 Icons & Symbols
Icon
Description
Network - The left portion indicates whether your phone is already registered with a

4
network and the right portion indicates signal strength (from no signal to strongest
signal).
Battery - Indicates battery level with 3 battery level indicator bars. When charging, a
scrolling icon will be displayed. The more bars, the stronger the charge.
SMS - Indicates you have a new SMS.
Alert type is “Silent”.
Alert type is” vibration”
Alert type is “Ring”.
Missed call - Indicates there is a missed call.
Call Divert - Indicates that the call divert unconditional function is activated.
Lock - Indicates that the keypad is locked.
Earset is in use
Alarm - Indicates that the alarm clock is on.
2. Getting Started
2.1 Inserting the SIM Card

5
2.1.1 Remove the back cover and battery
2.1.2 Insert the SIM card
Make sure that the clipped corner of the SIM card is facing the correct direction (clipped corner at down
right) and the metallic contacts are facing downwards. Slide the SIM card into the card slot until it stops.

6
.
2.1.3 Install the battery and back cover

7
2.2 Turning on the Phone
To turn the phone on, press and hold the Hang-Up Key.

8
2.3 Charging the Battery
1. Make sure the battery is inserted. To charge the battery, plug in the charger connector at the
bottom of your phone (Charger port) and then plug the other end into an AC power socket.
2. The battery symbol indicates the charging status. During charging, the charge indicators will scroll.
When all the scroll bars are steady, the battery is fully charged.
3. Disconnect the charger from the phone.
4. Disconnect the charger from the AC power socket.
3. Text Entry
3.1 Input Method
During text editing, you can press the # Key to switch input modes or press the Left Soft Key [Options]
and select Input Method to select different input modes.
In any input mode, press the * Key to open the symbols input screen.
3.2 Predictive Text entry
“2~9”
Press to input letters.
1
Press to input symbols.
0
Press to enter a space.
Navigation Key ▲/▼/◀/▶
Press to browse the last or next available word.

9
Left Soft Key [Select]
Press to confirm the letter or word.
Right Soft Key [Clear]
Press to clear a letter, press and hold to clear all entries.
#
Press to switch the input modes.
*
Press to activate punctuation mode.
Example: How to enter the word " ERROR "
1. Press the # Key to switch to ES.
2. Press 3 7 7 6 7, “ERROR” appears..
3. Press the OK Key to confirm “ERROR”.
3.3 Multi-tap Input
Using this mode requires you to press a key as many times as the order of the letters listed on the key.
For example, to enter the word “casa” in basic text input mode “es”, press key 2 (ABC) three times,
press 2 (ABC) once, press key 7 (PQRS) four times, press key 2 (ABC) once.
3.4 Numeric Input
Press the # Key to select “123”then enter the numbers using the keypad.
4. Calling
4.1 Making a Call

10
1. In idle mode, enter the phone number.
2. Press the Dial Key to dial the number.
3. Press the Hang-up Key to end the call.
Note: During a call, press the Navigation Key Up/Down to adjust the volume.
4.1.1 Making an International Call
1. Press * twice quickly to enter "+" appears on the screen.
2. Enter the country code.
3. Enter the area code (normally without the 0 before it) followed by the phone number.
4. Press the Dial Key to call directly.
4.2 Answering a Call
Press the Answer Key to answer it.
Press the Hang-Up key to reject it.
5. Phonebook
5.1 Search Contact
1. Press Menu > Phonebook, you can enter first few letters of contact name directly.

11
2. Enter the contact name.
5.2 Add New Contact
To create a new SIM/phone contact:
1. Select Menu > Phonebook > Add new contact.
If you want to change the storage position, press the Left Soft Key [Options] and then select
Phonebook settings > Preferred storage to set the storage position.
2. Press the Options > Select > To SIM/To phone to edit the contact information.
3. Press the Options Key > Done to save the contact.
.
6. Messaging
6.1 Create Message
1. Select Menu > Messaging>Write message.
2. In content, you are able to add text message into your message.
3. After finished, press the Left Soft Key [Options] and select send to to go to the following
options:enter number,Add from Phonebook.
6.2 Broadcast Message

12
1. Select Menu > Messaging > Broadcast message.
2. Press the Left Soft Key [On]/[Off] to Activate /Deactivate this function.
3. Press the Navigation Key Down to select Channel settings to enter the channel number.
7. Call history
7.1 View Call History
1. Select Menu > Call history.
2. Press the Navigation Key to view different call logs.
3. Choose a particular number and press the Dail/Answer Key to call the number directly.
4. Select Delete call logs if you want.
8. Settings
You can configure your cellular phone to best suit your usage preferences.
8.1 Adjust Call Settings
Select Menu > settings> Call settings.
8.2 Activate user profiles
1. Select Menu >settings> User profiles.
2. Select one of the profiles.
3. Select Customize to adjust the settings, such as ring type, volume, and so on.

13
4. Go back to the previous menu, select Activate.
9. Multimedia
9.1 Sound Recorder
1. Select Menu > Multimedia > Sound recorder.
2. Press the Left Soft Key [Options] and select Settings to set the format and quality.
3. Back to the previous menu, select Opitions > New record.
4. In the recording screen, you can press the Left Soft Key to pause or continue.
5. If you have finished, press the Right Soft Key [Stop] to stop recording and save it.
9.2 FM Radio
Note: The radio will not work unless the headset is attached. Attach the headset to the USB
port located at the bottom of the phone.
To operate the radio:
1. Select Menu > Multimedia > FM radio.

14
2. Press the Navigation Key Down to activate or deactivate the FM radio.
3. Press the * / # Key to adjust the volume.
4. Press the options to activate or deactivate Auto search.
5. Press the Navigation Key Right/Left to switch the channels. If auto search is activated, pressing
the Navigation Key Right/Left will switch the available searched channels; if auto search is
deactivated, pressing the Navigation Key Right/Left will switch to varying channels by 0.1 intervals.
6. Press the Left Soft Key [Options] to access the options.
10. Fun & Games
You can enjoy the built-in game/s here.
Note: Headset profile can only be activated by plugging in a headset.
11. Extra
As most of the features are very simple, here only list the important features.
11.1Create a new event
1. Select Menu > Extra > Calendar.
2. Press the Navigation Key to select a date.

15
3. Press the Left Soft Key [Options] and select Add event.
4. Select the event type.
5. Enter the event information.
6. Press the Right Soft Key [Done] to save.
11.2Set an alarm
1. Select Menu > Extra > Alarm.
2. Select an alarm and then press the Left Soft Key [Edit] to create.
3. Press the Navigation Key Left or Right to turn it on or off.
4. You may enter other information and save your settings.
12. Organizer
12.1.1 Calculator
Your phone has a built in calculator. Enter the numbers using the keypad. An icon will appear on the
screen indicating how to do calculations:
Keys
Operation
Up
Addition
Down
Subtraction
Left
Multiplication

16
Note: press the Navigation Key Up/ Down can switch between +, M+, M-, -; press the Navigation
Key Left/ Right can switch between MC, x, ÷, MR.
13. STK
Note: The submenus of this feature depend on the operator and different operators may provide
different services (some SIM cards do not support STK).
Right
Division
Left Soft Key
To calculate
Right Soft Key
To clear or exit Calculator
# key
To enter decimal point

17
14. Precautions
Please carefully read and observe the terms below:
Safe power on
Do not use your cellular phone where it is restricted to use or you might cause a disturbance or
danger.
Safe transportation first
Please observe all related local laws and regulations.
Please drive with both hands.
Safe transportation should be considered when driving.
Disturbance
All cellular phone services may be disrupted.

18
Turn off when in the hospital
Please follow related restrictions.
Please switch your cellular phone off when near a medical instrument.
Turn off on an airplane
Please follow related restrictions.
Do not use your cellular phone on an airplane.
Turn off when at a gasoline station
Do not use your cellular phone at a filling station or around fuels or chemicals.
Turn off near exposure Area
Please observe related limitations and do not use your cellular phone near an area where
explosions can occur.
Proper use
As described in this manual, your cellular phone can be used only in proper locations.
If possible, please do not touch the antenna area of your phone.

19
Use qualified after sales service
Only a qualified technician can repair your cellular phone.
Accessories and batteries
Only use the authorized accessories and batteries and do not connect to incompatible
products.
Waterproof
Your cellular phone is not waterproof. Please keep it away from water.
Backup
Remember to make a backup or keep a written record of all important information saved in
your cellular phone.
Connect to other devices
Please read the user manual of the device to get more detailed security instructions before
connecting to other devices and do not connect to an incompatible product.

20
SOS emergency calls
Make sure your cellular phone is switched on and in a service area. In idle mode, input the
SOS number, then press the Dial Key. Advise where you are and do not hang up without
permission.
This mobile phone has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiated radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
