Moxa Technologies DA-682A Series User manual

DA-682A Series Embedded Computer
Hardware Manual
Third Edition, May 2015
www.moxa.com/product
© 2015 Moxa Inc. All rights reserved.

DA-682A Series Embedded Computer
Hardware Manual
The software described in this manual is furnished under a license agreement and may be used only in accordance with
the terms of that agreement.
Copyright Notice
© 2015 Moxa Inc. All rights reserved.
Trademarks
The MOXA logo is a registered trademark of Moxa Inc.
All other trademarks or registered marks in this manual belong to their respective manufacturers.
Disclaimer
Information in this document is subject to change without notice and does not represent a commitment on the part of
Moxa.
Moxa provides this document as is, without warranty of any kind, either expressed or implied, including, but not limited
to, its particular purpose. Moxa reserves the right to make improvements and/or changes to this manual, or to the
products and/or the programs described in this manual, at any time.
Information provided in this manual is intended to be accurate and reliable. However, Moxa assumes no responsibility for
its use, or for any infringements on the rights of third parties that may result from its use.
This product might include unintentional technical or typographical errors. Changes are periodically made to the
information herein to correct such errors, and these changes are incorporated into new editions of the publication.
Technical Support Contact Information
www.moxa.com/support
Moxa Americas
Toll
-free: 1-888-669-2872
Tel:
[phone]
Fax:
[phone]
Moxa China (Shanghai office)
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe
Tel:
[phone]
Fax: [phone]
Moxa Asia
-Pacific
Tel:
[phone]
Fax: [phone]
Moxa India
Tel:
[phone]
Fax:
[phone]

Table of Contents
1. Introduction...................................................................................................................................... 1-1
Overview ...........................................................................................................................................1-2
Model Descriptions and Package Checklist.............................................................................................. 1-2
Appearance........................................................................................................................................1-3
Dimensions ........................................................................................................................................1-4
Features ............................................................................................................................................1-4
Hardware Block Diagram .....................................................................................................................1-5
DA-682A Basic System.................................................................................................................1-5
Hardware Specifications ......................................................................................................................1-5
Basic Systems.............................................................................................................................1-5
Expansion Modules ............................................................................................................................. 1-7
Software-Selectable Serial Ports.................................................................................................... 1-7
Ethernet LAN Ports ...................................................................................................................... 1-7
Ethernet Switching ......................................................................................................................1-7
Universal PCI Slot........................................................................................................................1-7
Non-standard Baudrates ...................................................................................................................... 1-8
2. Hardware Installation ....................................................................................................................... 2-1
Placement Options ..............................................................................................................................2-2
Desktop .....................................................................................................................................2-2
Rack mounting............................................................................................................................2-2
Wiring Requirements...........................................................................................................................2-4
Connecting the Power .........................................................................................................................2-5
Reset Button ......................................................................................................................................2-5
Front Panel LED..................................................................................................................................2-6
Connecting to a Display ....................................................................................................................... 2-7
Connecting USB Devices ...................................................................................................................... 2-8
Gigabit LAN Ports................................................................................................................................ 2-9
Upgrading the Memory Module ........................................................................................................... 2-10
Installing a CompactFlash Card .......................................................................................................... 2-11
Installing a Disk on Module (DOM) ...................................................................................................... 2-12
Installing one or two SATA Hard Disks................................................................................................. 2-12
Installing and Removing Expansion Modules......................................................................................... 2-14
DA-SP08-I-DB/DA-SP08-DB/DA-SP08-I-EMC4-DB Serial Expansion Modules ............................................ 2-15
DA-SP08-I-TB/DA-SP08-I-EMC4-TB Serial Expansion Modules................................................................ 2-15
DA-LN04-RJ LAN Expansion Module..................................................................................................... 2-16
3. BIOS Setup........................................................................................................................................ 3-1
Entering the BIOS Setup......................................................................................................................3-2
Main Information ................................................................................................................................ 3-3
Advanced Settings .............................................................................................................................. 3-3
Boot Configuration.......................................................................................................................3-4
HDC Configuration.......................................................................................................................3-4
Video Configuration .....................................................................................................................3-5
Chipset Configuration...................................................................................................................3-6
Hardware Monitor........................................................................................................................3-7
Security Settings ................................................................................................................................3-7
Set Supervisor Password ..............................................................................................................3-7
Power Settings ...................................................................................................................................3-8
Turbo Mode ................................................................................................................................ 3-8
Auto Wake on S5 ........................................................................................................................ 3-8
Wake on LAN ..............................................................................................................................3-8
Boot Settings .....................................................................................................................................3-9
Boot Type...................................................................................................................................3-9
PXE Boot to LAN..........................................................................................................................3-9
Add Boot Options ........................................................................................................................3-9
USB Boot ...................................................................................................................................3-9
EFI Device First........................................................................................................................... 3-9
Boot Delay Time..........................................................................................................................3-9
Legacy ..................................................................................................................................... 3-10
Exit Settings .................................................................................................................................... 3-10
Exit Saving Changes .................................................................................................................. 3-10
Save Change Without Exit .......................................................................................................... 3-10
Exit Discarding Changes ............................................................................................................. 3-10
Load Optimal Defaults................................................................................................................ 3-11
Load Custom Defaults ................................................................................................................ 3-11
Save Custom Defaults................................................................................................................ 3-11
Discard Changes ....................................................................................................................... 3-11
Upgrading the BIOS .......................................................................................................................... 3-11
