Moxa Technologies V2403 Series User manual

P/N: 1802024030012
*1802024030012*
V2403 Series
Quick Installation Guide
Version 2.1, January 2021
Technical Support Contact Information
www.moxa.com/support

2021 Moxa Inc. All rights reserved.

- 2 -
Overview
The Moxa V2403 series fanless x86 embedded computer is based on the
Intel® 3rd gen Core-i™ series processor, features the most reliable I/O
design to maximize connectivity, and supports dual wireless modules,
making it suitable for a diverse range of communication applications. The
computer’s thermal design ensures reliable system operation in
temperatures ranging from -40 to 70°C with a special purpose Moxa
wireless module installed. The V2403 series supports “Moxa Hardware
Monitoring” for device I/O status monitoring and alerts, system
temperature monitoring and alerts, and system power management.
Closely monitoring system status makes it easier to recover from errors
and provides the most reliable platform for your applications.
Package Checklist
Before installing the V2403, verify that the package contains the following
items:
•V2403 embedded computer
•Terminal block to power jack converter
•Wall mounting kit
•Quick installation guide (printed)
•Warranty card
NOTE: Please notify your sales representative if any of the above
items are missing or damaged.
V2403 Panel Layout
The following figures show the panel layouts of the V2403.
Front View
Rear View

- 3 -
LED Indicators
The following table describes the LED indicators located on the front panel
of the V2403.
LED Name
LED Color
LED Function
Power
Green
Power is on and functioning normally.
Off
Power is off or power error exists.
Storage
Yellow
CFast card/HDD/SSD is transmitting data
Off
CFast card/HDD/SSD is not transmitting data
LAN (1 or 2)
Green
100 Mbps Ethernet mode
Yellow
1000 Mbps Ethernet mode
Off
10 Mbps or no activity
TX (P1-P4)
Green
Serial ports P1-P4 transmitting data
Off
Serial ports P1-P4 not transmitting data
RX (P1-P4)
Yellow
Serial ports P1-P4 receiving data
Off
Serial ports P1-P4 not receiving data
NOTE
The mini-PCIe card’s LED behavior depends on the module.
Installing the Mini-PCIe Modules and USIM Cards
ATTENTION
Select
“-W” models (e.g., V2403-C2-W-T) when placing V2403
order
s for wireless applications. Moxa will add 3 mini-PCIe
sockets during production. Note that
the internal storage kit
cannot be used with
“-W” models. To expand the storage of “-W
”
models, use an mSATA card.
The V2403 features 3 mini-PCIe sockets on the bottom panel.
•Socket 1: USB + PCIe signal, for Wi-Fi mini-PCIe card
•Socket 2: USB signal, for 3G/LTE mini-PCIe card (Sierra Wireless
MC7304, MC7354, MC9090)
•Socket 3: SATA signal (for mSATA)

- 4 -
Installing a mini-PCIe Card in Socket 1 and Socket 3
STEP 1: Loosen the 6 screws
in
the middle of the bottom
cover and
then open the
bottom cover.
STEP 2: Obliquely insert the mini-PCIe module card.
STEP 3: Push down the mini-PCIe module card and fasten it with the 2
black screws from the module card package you purchased from Moxa.
STEP 4: If you installed a wireless mini-PCIe card, connect the antenna
cables with wireless module card.
No.1 & No.3: Wi-Fi mini-PCIe card.
STEP 5: Replace the bottom cover.
Installing a mini-PCIe Card in Socket 2
STEP 1: Loosen the 6 screws
in
the middle of the bottom
cover and open the bottom
cover.
STEP 2: Get the upper heat sink cover from
the wireless package
.
STEP 3: Obliquely insert the mini-PCIe module card in socket 2, and
fasten it with the 2 black screws from the wireless package.

- 5 -
STEP 4: Connect the antenna cables to the
wireless module card
:
No.
2 & No. 4: 3G/LTE mini-PCIe card
No.
5: GPS
STEP 5: Use the fillister to obliquely buckle the heat sink that was already
installed inside the V2403 computer, as shown below:

STEP 6: Slightly push down the upper heat sink cover and use the silver
screw from the wireless package to fasten the upper heat sink cover
(outlined in red below).

STEP 7: Replace the bottom cover.
Installing the USIM card
The V2403 has 2 USIM slots for 3G/LTE wireless Internet connections.
Instructions for installing a USIM card are shown below:
Pull up the USIM card slot and insert the USIM card. When finished,
replace the holder and slide the slot towards the catch to fasten the
holder.


- 6 -
NOTE
You may also purchase 3G, 4G, and Wi-Fi external antennas from
from Moxa. Please contact Moxa sales representative for your
demand.
Installing the V2403
DIN-Rail Mounting
The V2403 can be installed on a DIN-rail with
the optional DIN
-rail kit. The DIN-rail kit
must be purchased separately. The DIN
-
rail
kit includes
two DIN-
rail brackets and eight
screws.
To attach the DIN-rail kit, complete the following steps:
1. Turn the V2403 over so the bottom is facing up.
2. Locate the screw holes on the bottom of the V2403.
3. Place the brackets on the bottom of the V2403 and align the screw
holes on the brackets with the screw holes on the V2403.
4. Insert and tighten the screws into the screw holes.
NOTE
Use all eight screws to ensure that the V2403 is safely and
securely installed on the DIN rail.
5. When the brackets are firmly attached with the screws, you can
install the V2403 onto a DIN-rail.

- 7 -
To remove the V2403 from the DIN-rail, first use a screwdriver to pull
down the DIN-rail connector to unlock it.
To re-install the V2403 on the DIN-rail, use a screwdriver to press the
buckle so that it can be released. At this point, it can be re-installed on the
DIN-rail.
Wall or Cabinet Mounting
The V2403 comes with two metal brackets for attaching it to a wall or the
inside of a cabinet.
Step 1: Use two screws for each bracket and attach the bracket to the
rear of the V2403.
Step 2: Use four screws per side to attach the V2403 to a wall or cabinet.

- 8 -
Connector Description
Power Connector
Connect the 9 to 36 VDC LPS or Class 2 power line to the V2403’s terminal
block. If the power is supplied properly, the Power LED will light up. The
OS is ready when the Ready LED glows a solid green.
Grounding the V2403
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
grounding screw (M4) to the grounding surface prior to connecting the
power.
ATTENTION
This product is intended to be mounted to a well
-grounded
mounting surface, such as a metal panel.
DVI-I Outputs
The V2403 comes with 1 DVI-I female connector for the DVI display. This
output interface is located on the front panel of the product. Be sure to
use the correct cable to connect the computer to the display.
HDMI Outputs
The V2403 comes with a type A HDMI female connector and a DVI-I
female connector on the front panel to connect an HDMI or DVI-I
supported monitor.
The screw hole above the HDMI connector is used to attach a customized
lock to the HDMI connector; a custom lock is needed since the shape of
different HDMI connectors are not the same. Please contact a Moxa sales
representative for details.
The lock appears as shown below:
The lock should appear as shown here after it is
attached to the V2403:

- 9 -
Ethernet Ports
The 10/100/1000 Mbps Ethernet ports use RJ45 connectors.
Pin
10/100 Mbps
1000 Mbps
1
ETx+
TRD(0)+
2
ETx-
TRD(0)-
3
ERx+
TRD(1)+
4
–
TRD(2)+
5
–
TRD(2)-
6
ERx-
TRD(1)-
7
–
TRD(3)+
8
–
TRD(3)-
Serial Ports
The serial ports use DB9 connectors. Each port can be configured by
software for RS-232, RS-422, or RS-485. The pin assignments for the
ports are shown in the following table:
Pin RS-232 RS-422
RS-485
(4-wire)
RS-485
(2-wire)
1
DCD
TxDA(-)
TxDA(-)
–
2
RxD
TxDB(+)
TxDB(+)
–
3
TxD
RxDB(+)
RxDB(+)
DataB(+)
4
DTR
RxDA(-)
RxDA(-)
DataA(-)
5
GND
GND
GND
GND
6
DSR
–
–
–
7
RTS
–
–
–
8
CTS
–
–
–
SATA Connector
The V2403 has 1 SATA-I/II connector for 2.5” SSD/HDD storage
expansion. To expand storage capacity, purchase an SSD/HDD and an
internal storage kit* through Moxa’s CTO** service.
*
Must be purchased separately for installing an SSD/HDD. For details,
check the optional accessories section of the V2403 datasheet.
**
CTO = Configure to order
mSATA Connector
The V2403 has 1 mini-PCIe socket with SATA signal for storage expansion.
Follow the “Installing the Wireless Modules” instructions.
CFast Slot
The V2403 has 2 CFast sockets. One slot is located on the front panel for
OS storage and the other slot is located inside the V2403 for backup OS
storage. Both slots support CFast Type-I/II with DMA mode.
To install an OS CFast card, remove the outer cover and insert the CFast
card in the socket. When finished, push the cover into the socket and
refasten the screws.
To install a CFast card for backup storage, purchase a CFast card through
Moxa’s CTO service. Refer to the V2406A datasheet for more information.
USB Hosts
The V2403 has 4 USB 2.0 Type A connectors. 2 USB ports are located on
the front panel; the other 2 USB ports are located on the rear panel. The
port supports keyboard and mouse, and can also be used to connect a
FlashDisk for storing large amounts of data.

- 10 -
Audio Interface
The V2403 comes with a Line-in audio connector for audio input and a
Line-out audio connector for audio output, allowing users to connect a
speaker or earphones.
DI/DO
The V2403 comes with 4 digital inputs and 4 digital
outputs
on a 2x5 terminal block.
Reset Button
Press the “Reset Button” on the rear panel of the computer to reboot the
system automatically. Pushing the reset button will restart system
immediately. Be aware that all unsaved data will be lost when pushing
this button.
Real-time Clock (RTC)
The V2403’s real-time clock is powered by a lithium battery. You can
easily replace the battery yourself using an optional battery kit*. However,
please note that there is a risk of explosion if the battery is replaced by an
incorrect type of battery. Refer to the V2403 Hardware User's Manual or
contact a qualified Moxa support engineer if you have any questions
about the RTC battery.
*
Moxa offers an “RTC battery kit” that you can use to easily replace the
battery. For details, check the optional accessories section of the V2403
datasheet.
ATTENTION
There is a risk of explosion if the battery is replaced by an
incorrect type of battery.
Powering on the V2403
To power on the V2403, connect the “terminal block to power jack
converter” to the V2403’s DC terminal block (located on the side panel),
and then connect the 9 to 36 VDC power adapter. Press the Power Button
to turn on the computer. Note that the Shielded Ground wire should be
connected to the top pin of the terminal block. It takes about 30 seconds
for the system to boot up. Once the system is ready, the Power LED will
light up.

- 11 -
Connecting the V2403 to a PC
Power on the V2403 computer after connecting a monitor, keyboard, and
mouse, and verifying that the power source is ready. Once the operating
system boots up, first configure the Ethernet interface. The factory
default settings for the V2403’s LANs are show below (W7E uses DHCP).
Default IP Address
Netmask
LAN 1
192.168.3.127
255.255.255.0
LAN 2
192.168.4.127
255.255.255.0
Configuring the Ethernet Interface
Linux users should follow these steps:
If you use the console cable to configure network settings for the first
time, use the following commands to edit the interfaces file:
#ifdown –a
//Disable LAN1~LAN2 interface first, before you
reconfigure the LAN settings. LAN1 = eth0, LAN2 = eth1//
#vi /etc/network/interfaces
//check the LAN interface first//
After the boot setting of the LAN interface has been modified, use the
following commands to immediately activate the LAN settings:
#sync; ifup –a
W7E users should follow these steps:
STEP 1:
Go to Start

Control Panel

Network and Internet

View
network status and tasks
Change adapter setting.
STEP 2:
In the Local Area Connection Properties screen, click Internet
Protocol (TCP/IP) and then select Properties. Select Internet
Protocol Version 4, and then click Properties.
STEP 3:
Click OK after inputting the proper IP address and netmask.
NOTE
Refer
to the V2403 user’s manuals for additional configuration
information.
