Moxa Technologies NPort DE-311 Manual

NPort DE-311
Hardware Installation Guide
Fourth Edition, June 2008
www.moxa.com/product
©2008 Moxa Inc., all rights reserved.
Reproduction without permission is prohibited.

NPort DE-311
Hardware Installation Guide
The software described in this manual is furnished under a license agreement and may be used only in
accordance with the terms of that agreement.
Copyright Notice
Copyright ©2008 Moxa Inc.
All rights reserved.
Reproduction without permission is prohibited.
Trademarks
MOXA is a registered trademark of Moxa Inc.
All other trademarks or registered marks in this manual belong to their respective manufacturers.
Disclaimer
Information in this document is subject to change without notice and does not represent a commitment on the
part of Moxa.
Moxa provides this document “as is,” without warranty of any kind, either expressed or implied, including, but
not limited to, its particular purpose. Moxa reserves the right to make improvements and/or changes to this
manual, or to the products and/or the programs described in this manual, at any time.
Information provided in this manual is intended to be accurate and reliable. However, Moxa assumes no
responsibility for its use, or for any infringements on the rights of third parties that may result from its use.
This product might include unintentional technical or typographical errors. Changes are periodically made to the
information herein to correct such errors, and these changes are incorporated into new editions of the
publication.
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll-free: 1-888-669-2872
Tel: [phone]
Fax: [phone]
Moxa China (Shanghai office):
Toll-free: 800-820-5036
Tel: [phone]
Fax: [phone]
Moxa Europe:
Tel: [phone]
Fax: [phone]
Moxa Asia-Pacific:
Tel: [phone]
Fax: [phone]

Table of Contents
Chapter 1 Introduction..............................................................................................1-1
Features.............................................................................................................................. 1-2
Product Specifications........................................................................................................ 1-2
Package Checklist .............................................................................................................. 1-3
Front/Top/Rear/Bottom Panel Views.................................................................................. 1-4
Chapter 2 Overview...................................................................................................2-1
LED Indicators................................................................................................................... 2-2
Housing.............................................................................................................................. 2-2
DIN Rail.................................................................................................................. 2-2
Wall Mount............................................................................................................. 2-3
Chapter 3 Serial Installation.....................................................................................3-1
DIP Switch Settings............................................................................................................ 3-2
DB9 Female Connector Pinouts......................................................................................... 3-2
RS-232 Pinouts ....................................................................................................... 3-2
RS-232 Loopback Tester ........................................................................................ 3-3
RS-422/485 Pinouts ................................................................................................ 3-3
RS-422 Loopback Tester ........................................................................................ 3-3
Mini Adapter........................................................................................................... 3-3
Chapter 4 Ethernet Installation................................................................................4-1
Connecting to the Ethernet Port ......................................................................................... 4-2
Connecting to a Hub or Switch............................................................................... 4-2
Connecting to a PC ................................................................................................. 4-2
Chapter 5 Power Connection...................................................................................5-1
Connecting the Power Adapter........................................................................................... 5-2
Power Status Check............................................................................................................ 5-2
Appendix A Telnet Console........................................................................................A-1
Opening the Telnet Console .............................................................................................. A-2
Navigating the Telnet Console .......................................................................................... A-2
Main Menu........................................................................................................................ A-3
serverConfig........................................................................................................... A-3
Serialport................................................................................................................ A-4
Monitor .................................................................................................................. A-4
Ping........................................................................................................................ A-4
Restart.................................................................................................................... A-4
Exit......................................................................................................................... A-5
Menu Tree ......................................................................................................................... A-5
Appendix B Serial Console.........................................................................................B-1
Appendix C Declaration of Conformity .....................................................................C-1

1
1
Chapter 1 Introduction
Welcome to Moxa’s NPort Express, a compact palm-sized communications device that allows you
to control RS-232/422/485 serial devices over a TCP/IP Ethernet.
This chapter is an introduction to the NPort Express and includes the following sections:
Features
Product Specifications
Package Checklist
Front/Top/Rear/Bottom Panel Views
The NPort Express DE-311 provides a data communications solution for connecting Windows and
Linux hosts to asynchronous serial devices over a TCP/IP Ethernet network. Using the NPort
Express is like adding a serial port to your PC using a serial board, but with the added advantage
of the TCP/IP network. With the NPort Express, Windows hosts can connect to a native serial port
and PC-based Linux hosts can connect to a real tty port, all over a network. Virtually any serial
device can be attached to the NPort Express to become network accessible, and the network can be
configured to allow control of the device from any location in the world.
After driver installation, Windows will recognize the serial port on the NPort Express as a real
COM port; Linux will recognize the port as a real tty port. The NPort Express provides basic
transmit/receive data functions, as well as RTS, CTS, DTR, DSR, and DCD control signals.
The NPort Express can be used with your existing applications and comes with a software utility
and maintenance wizard.

NPort DE-311 Hardware Installation Guide Introduction
Features
•3-in-1 RS-232/422/485 serial interface
•Auto-detecting 10/100 Mbps Ethernet connection
•Built-in Ethernet and TCP/IP protocol
•Compact size for easy integration
•Supports MAC based IP configuration
•Supports configuration store and copy for easy deployment
•Supports Windows Real COM drivers and Linux real TTY drivers
•Operation modes include TCP Server, TCP Client, UDP Server/Client, Ethernet Modem, and
Pair Connection
Product Specifications
Hardware
Processor 16 bit CPU
Memory 512 KB
Connector DB9 female
Interface
LAN Auto-detecting 100BaseTX (10/100 Mbps)
Serial RS-232/422/485 (DIP switch selectable)
No. of serial ports 1
RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS-422: TxD+/-, RxD+/-, RTS+/-, CTS+/-, GND
Signals
RS-485: Data+/-, GND
Performance
Speed 50 bps to 230.4 Kbps
Configuration
DE-311 Parity None, Even, Odd
Data Bits 7, 8
Stop Bits 1, 2 (with parity setting of None)
DE-311 Rev. 2 Parity None, Even, Odd, Space, Mark
Data Bits 5, 6, 7, 8
Stop Bits 1, 1.5, 2
Supported OS
Windows XP, Windows 2000, Windows NT, Windows 95/98/Me Real COM driver, Unix fixed
tty driver for UnixWare SVR4.2, UnixWare 7 SVR5, SCO Open Server, SCO Unix, Linux real
tty driver
Protocols
TCP, IP, UDP, Telnet, RTelnet, DHCP, ICMP, BootP
1-2

NPort DE-311 Hardware Installation Guide Introduction
Operation Modes
Driver Mode, TCP Server, TCP Client, UDP Server/Client, Ethernet Modem, Pair Connection
Management
Serial console Telnet console NPort Configurator for Windows/Linux Real COM Installer for
Windows Monitor Utility for Windows Firmware upgrade function supported NPort Admin for
Linux tty driver
Supported OS
Windows XP, Windows 2000, Windows NT, Windows 95/98/Me Real COM driver, Unix fixed
tty driver for UnixWare SVR4.2, UnixWare 7 SVR5, SCO Open Server, SCO Unix, Linux real
tty driver
Power and Environment
Power Requirements DE-311 DC 9V to 20V, 400 mA (max.) at 9V
DE-311 Rev. 2 DC 9V to 30V, 300 mA (max.) at 9V
Operating Temperature 0 to 55°C
Operating Humidity 5 to 95% RH
Dimensions (W×D×H) 90 ×100.4 ×22 mm (including ears)
67 ×100.4 ×22 mm (without ears)
Regulatory Approvals FCC, CE, UL, CUL, TÜV
Package Checklist
DE-311/110V 1 NPort Express DE-311 Universal Serial Device Server
DE-311/230V 1 NPort Express DE-311 Universal Serial Device Server
Both models include
•Windows 95/98/ME/NT/2000/XP Real COM driver, Linux real tty driver
•NPort Management Suite software
•Power adapter
•User’s Manual, software CD-ROM
•DB9/M – DB9/M adapter
Optional Accessories
DIN rail mounting kit For 35 mm DIN rail; includes 4 screws
1-3

NPort DE-311 Hardware Installation Guide Introduction
Front/Top/Rear/Bottom Panel Views
DE-311 RS-232/422/485 Device Server
Express
PWR
Link
Ready
Serial
DC-IN
SW
RESET 10/100M
Ethernet
8
8
9
8
8
Bottom Panel View
56
7
Rear Panel View
1
Front Panel View
3
3
4
Top Panel View
3
4
3
2
ON
123
1. DB9 female serial port
2. DIP switches
3. DIN rail screw holes
4. Wall mount screw holes
5. RJ45 10/100BaseTX Ethernet port
6. Reset button—hold down for
a. 3 sec to erase password
After 3 sec, the ready LED will flash every
twice every second. Release the reset
button at this time to erase password.
b. 10 sec to load factory defaults
After 10 sec, the ready LED will flash five
times each second. Release the reset
button at this time to load factory defaults.
7. Power input
8. Rubber base pads
9. Technical information
1-4

2
2
Chapter 2 Overview
The following topics are discussed in this chapter:
LED Indicators
Housing
¾DIN Rail
¾Wall Mount

NPort DE-311 Hardware Installation Guide Overview
LED Indicators
The NPort Express’s top panel contains five LED indicators, as described in the following table.
LED Name LED Color LED Function
red Power is on
PWR off Power is off, or power error condition exists
orange 10 Mbps Ethernet connection
green 100 Mbps Ethernet connection
Link
off Ethernet cable is disconnected, or has a short
green The NPort Server is ready
blinking
The NPort is requesting an IP address from the DHCP or
BootP server. After receiving the IP, the LED will stop
blinking.
Note: The LED will also blink while holding down the reset
button; see page 1-5 for details.
Ready
off The NPort Server has malfunctioned
Housing
DIN Rail
The DIN rail attachments provide a very convenient installation option for many industrial
applications. Installation instructions are as follows:
STEP 1: Use the screws to attach the DIN rail mounts to the NPort Express’s ears.
⇒
STEP 2: The two ends of the rail mount are
named A and B. Hook the A end over
the top edge of the rail.
STEP 3: Push the unit against the rail. You
should hear the B end clicking into
place over the bottom edge of the rail.
A
A
B
B
NOTE The DIN rail-mounting kit is an optional accessory.
2-2

NPort DE-311 Hardware Installation Guide Overview
To remove the NPort Express from the DIN rail, simply reverse Steps 2 and 3 above. Use your
fingers to pull down on the B end, which should release the bracket from the rail.
Wall Mount
Wall installation is another convenient installation option for many industrial applications.
Installation instructions are as follows:
STEP 1: Obtain two screws with heads no greater than 6.5 mm in diameter and shafts no greater
than 3 mm in diameter. At the desired wall location, drive the screws into the wall with
7.8 cm separation between the screws. Do not drive the screws all the way into the wall;
leave about 2 mm clearance.
7.8 cm
6.5 cm
STEP 2: Hang the NPort Express on the two
screws using the apertures on the ears,
and then slide the unit downwards.
STEP 3: For added stability, simply tighten the
two screws.
DE-311 RS-232/422/485 Device Server
Express
PWR
Link
Ready
2-3
Serial SW
DC-IN RESET 10/100M
Ethernet
DE-311 RS-232/422/485 Device Server
Express
PWR
Link
Ready
Serial SW
DC-IN RESET 10/100M
Ethernet
To remove the NPort Express from the wall mount, simply reverse Steps 2 and 3.

3
3
Chapter 3 Serial Installation
The following topics are discussed in this chapter:
DIP Switch Settings
DB9 Female Connector Pinouts
¾RS-232 Pinouts
¾RS-232 Loopback Tester
¾RS-422/485 Pinouts
¾RS-422 Loopback Tester
¾Mini Adapter

NPort DE-311 Hardware Installation Guide Serial Installation
DIP Switch Settings
The top panel contains a table which describes how to configure the serial port using the three DIP
switches.
SW1 Serial Connection SW2 SW3 Serial Interface Mode
ON Console (19200,N,8,1) --- --- RS-232
OFF OFF RS-232
OFF ON RS-422
ON OFF RS-485 by RTS
OFF Data Comm.
ON ON RS-485 ADDC
The DIP switches are located on the rear panel. SW1 toggles the serial port between data and
console operation (ON or up for serial console operation, and OFF or down for data
communication). Data operation is the normal operating mode for controlling serial devices;
console operation is for accessing the NPort Express configuration parameters. Note that after
modifying SW1 settings, the NPort Express will reboot to initialize the new mode. You must wait
a few seconds for the green Ready LED to blink off and then on again, indicating that the function
of the serial port has been changed.
SW2 and SW3 control the serial port’s data communication interface. Note that RTS stands for
Ready to Send and ADDC stands for Automatic Data Direction Control.
Keep the following points in mind when setting the DIP switches.
•RS-232 Console
To use the serial port as a console connection, such as when using Moxa PComm Terminal
Emulator or HyperTerminal, set SW1 to the ON position.
•Telnet Connection
Some configuration may be carried out through a Telnet connection, during which data is
transmitted through the NPort Express’s Ethernet port. However, you must set SW1 to the OFF
position to establish a Telnet connection.
DB9 Female Connector Pinouts
RS-232 Pinouts
DB9 (Female) PIN RS-232
1 DCD
2 TxD
3 RxD
4 DSR
5 GND
6 DTR
7 CTS
8 RTS
5 4 3 2 1
9 8 7 6
9 ---
3-2

NPort DE-311 Hardware Installation Guide Serial Installation
RS-232 Loopback Tester
PIN Signal
1 DCD
2 TxD
3 RxD
4 DSR
5 GND
6 DTR
7 CTS
8 RTS
RS-422/485 Pinouts
DB9 (Female) PIN RS-422 RS-485
1 RxD-(A) ---
2 RxD+(B) ---
3 TxD+(B) Data+(B)
4 TxD-(A) Data-(A)
5 GND GND
6 CTS-(A) ---
7 CTS+(B) ---
8 RTS+(B) ---
5 4 3 2 1
9 8 7 6
9 RTS-(A) ---
RS-422 Loopback Tester
PIN Signal
1 RxD-(A)
2 RxD+(B)
3 TxD+(B)
4 TxD-(A)
5 GND
6 CTS-(A)
7 CTS+(B)
8 RTS+(B)
9 RTS-(A)
Mini Adapter
The NPort Express DE-311 accepts devices with both male and female
connectors. A D-shell female serial connector is built-in, and a DB9 male
null-modem adapter is included as a standard accessory.
3-3

NPort DE-311 Hardware Installation Guide Serial Installation
If you want to make your own DB9 male to DB9 male null-modem (or crossover) cable, the
correct pinouts are as follows:
232-SR slangiS
DCD
DxT
DxR
RSD
DNG
RTD
STC
STR
232-SR slangiS
DCD
DxR
DxT
RTD
DNG
RSD
STR
STC
gniriWelbaC
1
2
3
4
5
6
7
8
1
3
2
6
5
4
8
7
medoM-lluN)elaM(9BD
retpadainiM
9BDs113-ED
)elameF(
9BDseciveD
)elameF(
PIN RS-232 RS-422 RS-485
1 DCD RxD-(A) ---
2 TxD RxD+(B) ---
3 RxD TxD+(B) Data+(B)
4 DSR TxD-(A) Data-(A)
5 GND GND GND
6 DTR CTS-(A) ---
7 CTS CTS+(B) ---
8 RTS RTS+(B) ---
9
12345
876
ON
123
9 --- RTS-(A) ---
NOTE The adapter is included with the DE-311 as a standard accessory.
3-4

4
4
Chapter 4 Ethernet Installation
The following topics are discussed in this chapter:
Connecting to the Ethernet Port
¾Connecting to a Hub or Switch
¾Connecting to a PC

NPort DE-311 Hardware Installation Guide Ethernet Installation
Connecting to the Ethernet Port
Connecting to a Hub or Switch
For most applications, plug one end of your Ethernet cable into the NPort Express’s
10/100BaseTX port, and the other end into a hub or switch that is connected to your network. In
this case, you should use a standard straight-through Ethernet cable, which is readily available
from many commercial vendors. You may also make your own cable by referring to the following
cable wiring diagram.
Straight-Through Cable
RJ45 Plug Pin 1
NPort Express
RJ45 Jack
Connector RJ45 Jack Connecto
r
Tx+
Tx-
Rx+
Hub
Cable Wiring
11
22
33
Tx+
Tx-
Rx+
Rx- 66Rx-
Connecting to a PC
If you are connecting the NPort Express directly to your PC’s Ethernet port, use a crossover
Ethernet cable. You can make your own crossover cable by referring to the following cable wiring
diagram.
Cross-Over Cable
RJ45 Plug Pin 1
NPort Express
RJ45 Jack
Connector RJ45 Jack Connector
Tx+
PC LAN Card
Cable Wiring
13Rx+
Tx-
Rx+
Rx-
26
31
62
Rx-
Tx+
Tx-
4-2

5
5
Chapter5 Power Connection
The following topics are discussed in this chapter:
Connecting the Power Adapter
Power Status Check

NPort DE-311 Hardware Installation Guide Power Connection
Connecting the Power Adapter
The following steps explain how to connect the NPort Express’s power adapter:
1. Plug the power adapter’s DC plug into the DC-IN jack on the NPort Express.
2. Plug the power adapter into an electrical outlet.
Note that there is no on/off switch. The NPort Express will turn on automatically as soon as power
is supplied. The red PWR LED will glow to indicate that the unit is receiving power.
Ethernet
Power to
Device Server
Female DB9
Connector
DE-311RS-232/422/485 Device Server
Express
PWR
Link
Ready
Serial
DC-IN
SW
RESET 10/100M
Ethernet
Power Status Check
Use the PWR LED to verify that the unit is receiving power. A red light indicates that power is
being received. If the LED is off, no power is being received. If the unit is plugged in and the
PWR LED does not light up, there may be a problem with the unit.
5-2

A
A
Appendix A Telnet Console
The Telnet console is used to view and modify the unit’s configuration. After installing the unit
into a serial device, administrators configure their device remotely by opening a Telnet console
session over the network. The following examples refer to a Telnet console session on a Windows
98 host, but the same instructions should apply to all Windows operating systems.
The following topics are discussed in this appendix:
Opening the Telnet Console
Navigating the Telnet Console
Main Menu
¾serverConfig
¾Serialport
¾Monitor
¾Ping
¾Restart
¾Exit
Menu Tree

NPort DE-311 Hardware Installation Guide Telnet Console
Opening the Telnet Console
A Telnet console session may be opened from the Windows Start menu. Select Start ÆRun... to
open a dialog box, and then enter the following:
telnet [unit’s IP address]
Click OK to begin the Telnet session.
At the prompt, enter “1” for ansi/vt100, and then press Enter.
The main menu of the unit’s Telnet console will appear as shown.
Navigating the Telnet Console
Once the Telnet console has been opened, you may navigate through the console using the
following keys:
•Arrow keys: Use the arrow keys to navigate between different options. If the arrow keys do not
respond, you may need to verify your terminal settings by selecting Preferences in the
Terminal menu:
A-2
