Moxa Single-Strand Fiber Converter
Hardware Installation Guide
1. Introduction
IEEE802.3u 100 Mbps Fast Ethernetsupports
two types of media for network connection:
10/100BaseT(X) and 100BaseFX.The
Single-Strand Fiber Converter (ME60) is designed
with an optic Wavelength Division Multiplexing
(WDM) technology that transports bi-directional
full duplexsignals over a single- strand fiber cable
simultaneously.
100Base-Xnetwork allows 512-bit time delay
between any two node-stations in a collision
domain. This switch-based converter breaks up
the TPas well as Fiber segments' collision
domain and extends the cabling distance.
Copyright 2003
Moxa TechnologiesCo., Ltd.
All rights reserved.
Reproduction without permission is prohibited.
Tel: +866-2-8919-1230
Fax:+886-2-8919-1231
www.moxa.com
support@moxa.com.tw
2. Model Descriptions
Model TX, RX Wavelength
TX(Transmit)1310 nm
ME60A RX(Receive) 1550 nm
TX(Transmit)1550 nm
ME60B RX(Receive) 1310 nm
Note:
ME60A/ME60B products mustbe installed in
pairs. I.e., install an ME60Aat one end, and an
ME60B at the other end.
ME60Aand ME60B can be identified by looking
at the labels on the products side orback panel.
3. Installing MOXASingle-Strand Fiber
Converter
Note:
The Single-Strand Fiber Converter Series is
hot-swappable.
l Wear a grounding device to protectagainst
electrostatic discharge.
l Verify thatthe AC-DC adapter conforms to your
country sAC power requirement and then
insert the power plug.
l Install the media cable fornetwork connection.
Attach the single-strand fibercable
Fiber
Port Install ME60Aand ME60B models at the
ends of the single-strand fiber cable.
"100FDX" is only for WDM
Attach a Cat.5 UTPcable to the TPport.
TP
Port
MPR: (Default): To a switch or hub
DTE: To a workstation or NIC
Note: The "DTE"/"MPR" slide switch is on
the side panel.
Note for TP portcable connection:
l Use a straight-through cable.
Cable pin-outsforRJ45 jack 1, 2,3,6to 1,2,3,
6 are shown below:
Configure the MPR-DTE slide switch on the side
panel for connecting to a hub or NIC (Network
Interface Card).
l MPR (Default): To a switch or hub
l DTE: To a workstation or NIC (Network
Interface Card). (DTE pin-outs are set up as
crossover on the board)
TX-1310/RX-1550
ME60A
WDM Single Fiber
Single-Strand
Fiber TX-1550/RX-1310
ME60B
WDM Single Fiber
4. LED Description
LED location and status are shown below:
LED Color Function
FXLNK/ACT
Green
Lit forfiber port connection
Blinks when fiber port is
transmitting
FX100 Green
Lit
when fiber port speed is
at 100 Mbps
FXFDX/COL
Amber
Lit when fiber port is at
full-duplexmode
Blinks when collisions
occur
TP LNK/ACT
Green
Lit when TPis connecting
Blinks when TP is
transmitting
TP 100 Green
Lit when TPspeedis 100
Mbps
Off when TP speed is 10
Mbps
PWRGreen
Lit when +5V power is on
5. DC Jack and AC-DC Power Adapter
The DC jack's central post is 2.5 mm wide
6. Specifications
l Technology
Standards: IEEE802.3u, 10/100BaseT(X),
100BaseFX
DataTransfer Rate: 100 Mbps/148,800 PPS,
10 Mbps/14,880 PPS
FlowControl:IEEE802.3xcompliant for
full-duplex. Back pressure flowcontrol for
half-duplex.
l Interface
RJ45 ports: 10/100BaseT(X)
Fiber ports: 100BaseFX(SC connectors
available)
LED Indicators: POWER, FX: LNK/ACT, 100,
TP: LNK/ACT, FDX/COL
Dip switch: MPR (Default): Toa switch or hub
DTE: To a workstation or NIC, Network
Interface Card.
l Cable limitation
UTPCable: Cat. 5 cable (up to 100 m)
Single-Strand Fiber Cable: Recommended:
9/125 µm single-mode, Optional: 8.3/125,
8.7/125 or 10/125 µm single-mode
Wavelength: ME60ATX: 1310 nm/RX: 1550
nm, ME60B TX: 1550 nm/RX:1310 nm
Min. TXOutput: -10 dBm
Max. TXOutput: -7 dBm
Sensitivity: -32 dBm
l Power
Input voltage: 5VDC
Input current: 1A
l Environment
Operating temperature: 0 to 50°C
Ambient Relative Humidity: 5 to 90%
l Mechanical
Dimensions:26.2(H) ×70.3(W) ×94(D) mm
l RegulatoryApprovals:
FCC Part 15 Class A and CE Mark
7. Service Information
Customer satisfaction is our numberone concern.
To ensure that customers receive the full benefit
of our products, Moxa Internet Services has been
set up to provide technical support, driver
updates, product information, and user s manual
updates.
l E-mail for technical support:
support@moxa.com.tw
l World Wide Web sites for product information:
http://www.moxa.com
http://www.moxa.com.tw
Copyright 2003
Moxa TechnologiesCo., Ltd.
All rights reserved.
Reproduction without permission is prohibited.
Tel: +866-2-8919-1230
Fax:+886-2-8919-1231
www.moxa.com
support@moxa.com.tw
DC Jack: 2.5mm
DC Input: +5V
(DC current: full load consumption 0.7A)
SC Single-Strand Fiber
FX TP
LNK/ACT
100
FDX/COL PWR
TP
