NPort 6150/6250 Series
Quick Installation Guide
Edition 8.0, August 2016
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll
-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa China (Shanghai office):
Toll
-free: 800-820-5036
Tel:
[phone]
Fax:
[phone]
Moxa Europe:
Tel:
[phone]
Fax:
[phone]
Moxa Asia-Pacific:
Tel:
[phone]
Fax:
[phone]
Moxa India:
Tel:
[phone]
Fax:
[phone]

2016 Moxa Inc. All rights reserved.

- 2 -
Overview
The NPort 6150/6250 series secure serial device servers provide reliable
serial-to-Ethernet connectivity for a wide range of serial devices. The
NPort 6150/6250 support TCP Server, TCP Client, UDP, and
Pair-Connection operation modes to ensure the compatibility of network
software. In addition, the NPort 6150/6250 also support Secure TCP
Server, Secure TCP Client, Secure Pair-Connection, and Secure Real COM
modes for security critical applications such as banking, telecom, access
control, and remote site management.
Package Checklist
Before installing a NPort 6150/6250 secure device server, verify that the
package contains the following items:
•1 NPort 6150 or NPort 6250
•Power adapter (does not apply to -T models)
•2 wallmount ears
•Documentation and software CD
•Quick installation guide (this guide)
•Warranty card
Optional Accessories
•DK-35A: DIN-rail mounting kit (35 mm)
•DIN-rail power supply
•CBL-RJ45M9-150: 8-pin RJ45 to male DB9 cable
•CBL-RJ45M25-150: 8-pin RJ45 to male DB25 cable
NOTE: Please notify your sales representative if any of the above items
are missing or damaged.
Hardware Introduction
NPort 6150

- 3 -
NPort 6250
Reset Button—Press the Reset Button continuously for 5 sec to load
factory defaults. Use a pointed object, such as a straightened paper clip or
toothpick, to press the reset button. This will cause the Ready LED to blink
on and off. The factory defaults will be loaded once the Ready LED stops
blinking (after about 5 seconds). At this point, you should release the
reset button.
LED Indicators
LED Name
LED Color
LED Function
PWR
Red
Power is being supplied to the power input.
Ready
Red
Steady on
Power is on and the NPort is
booting up.
Blinking
Indicates an IP conflict, or, the
DHCP or BOOTP server did not
respond properly or a relay
output occurred. Check the relay
output first. If after resolving the
relay output the RDY LED is still
blinking, then there is an IP
conflict, or the DHCP or BOOTP
server did not respond properly.
Green
Steady on
Power is on and the NPort is
functioning normally.
Blinking
The device server has been
located by the Administrator’s
Location function.
Off
Power is off, or power error condition exists.

- 4 -
LED Name
LED Color
LED Function
Link
Orange
10 Mbps Ethernet connection
Green
100 Mbps Ethernet connection
Off
Ethernet cable is disconnected, or has a short.
P1, P2
Orange
Serial port is receiving data.
Green
Serial port is transmitting data.
Off
No data is being transmitted or received
through the serial port.
P1, P2
in-use LED
Green
Serial port was opened by server side
software.
Off
Serial port has not been opened by server side
software.
Adjustable pull high/low resistor for RS-422/485 (150
KΩor 1 KΩ)
Jumpers are used to set the pull high/low
resistors. The default is 150 kΩ. Short
the jumpers to set this value to 1 kΩ. Do
not use the 1 kΩ setting with RS
-232
mode, since doing so will degrade the
RS
-232 signals and shorten the
communication distance.
Hardware Installation Procedure
STEP 1:
Connect the 12-48 VDC power adaptor to the NPort 6150 and
then plug the power adaptor into a DC outlet.
STEP 2:
For first-time configuration, use a cross-over Ethernet cable to
connect the NPort
6150 directly to your computer’s Ethernet
cable. For connecting to a network, use a standard
straight-through Ethernet cable to connect to a hub or switch.
STEP 3:
Connect the NPort 6150’s serial port to a serial device.
Placement Options
The NPort 6150/6250 can be placed flat on a desktop or other horizontal
surface. In addition, you may use the DIN-rail or wallmount options, as
illustrated below.
Wallmount
Din Rail

- 5 -
Software Installation Information
The Documentation and software CD contains the user’s manual, NPort
Search Utility, and the PComm Lite Suite. Insert the CD into your
computer’s CD-ROM drive and follow the on-screen instructions. Please
refer to the user’s manual for additional details on using the NPort Search
Utility and PComm Lite.
Pin Assignments and Cable Wiring
RS-232/422/485 Pin Assignment (male DB9)
Pin RS-232
RS-422
4-wire RS-485
2-wire
RS-485
1
DCD
TxD-(A)
–
2
RXD
TxD+(B)
–
3
TXD
RxD+(B)
Data+(B)
4
DTR
RxD-(A)
Data-(A)
5
GND
GND
GND
6
DSR
–
–
7
RTS
–
–
8
CTS
–
–
9
–
–
–
Two serial cables for connecting the NPort 6150 to a serial device can be
purchased separately. The wiring diagrams for the two cables are shown
below.
Specifications
LAN
Ethernet
NPort 6150/6250: 10/100 Mbps, RJ45
NPort 6250-S-SC: Single-mode fiber
NPort 6250-M-SC: Multi-mode fiber
Protection
Built-in 1.5 kV magnetic isolation
Serial
No. of ports
NPort 6150: 1
NPort 6250: 2
Interface
RS-232/422/485 (male DB9)
Serial Communication Parameters
Parity
None, Even, Odd, Space, Mark
Data bits
5, 6, 7, 8
Stop bit(s)
1, 1.5, 2
Flow control
RTS/CTS, XON/XOFF, DTR/DSR
Speed
50 bps to 921.6 kbps
Console Port RS-232 (please see the User’s Manual for
detailed operating instructions)
Memory
One SD socket
Software Features
Protocols
ICMP, IPv4/v6, TCP, UDP, DHCP, BOOTP, Telnet,
DNS, SNMP, HTTP, SMTP, HTTPS, SSL, SSH,
PPPoE, RFC2217
Utilities
NPort Search Utility for Windows
Security Protocols
DES/3DES/AES

- 6 -
OS Driver Support
Windows Real COM Drivers: Windows
95/98/ME/NT/2000, Windows
XP/2003/Vista/2008/7/8/8.1/10 (x86/x64),
Windows 2008 R2/2012/2012 R2 (x64),
Windows Embedded CE 5.0/6.0, Windows XP
Embedded
Fixed TTY Drivers: SCO Unix, SCO OpenServer,
UnixWare 7, QNX 4.25, QNX 6, Solaris 10,
FreeBSD, AIX 5.x, HP-UX 11i, Mac OS X
Linux Real TTY Drivers: Linux 2.4.x, 2.6.x, 3.x
Management: SNMP MIB-II
IP Routing: Static, RIP-I, RIP-II
Configuration
Web Console, Serial/Telnet Console, Windows
utility
Power Requirements
Power input
12 to 48 VDC
Mechanical Specifications
Material
Aluminum (1 mm)
Environmental Limits
Operating Temperature
Standard models:
NPort 6150/6250 series:
0 to 55°C (32 to 131°F)
Wide temp. models:
NPort 6150-T/6250-T series:
-40 to 75°C (-40 to 167°F)
Storage Temperature
Standard models:
NPort 6150/6250 series:
0 to 55°C (32 to 131°F)
Wide temp. models:
NPort 6150-T/6250-T series:
-40 to 75°C (-40 to 167°F) ,
5 to 95% RH
Regulatory Approvals
EMC
FCC Class A, CE Class A
Safety
UL, CUL, TÜV
